LENCO TAB-711 Manual de usuario

USER'S MANUAL

TAB-711

MID-7509CM ROCKCHIP方案 ENGLISH MANUAL

标准说明书，封面封底70g书纸,135x102mm,钉装

For information and support,WWW.lenco.eu

Table of Contents

Table of Contents......................................P1

Features..................................................P2

Unit at a Glance .......................................P3

Getting Started....................................P4-P5

About Applications...............................P5-P6

Preinstalled Applications...........................P6

Connect to a Wi-Fi network....................P7-P8

Optional Connections................................P9

Specifications.........................................P10

Features

Browse the Web.

Visit your favorite websites

Check your e-mail

Keep in touch with friends and family

Watch YouTube™ videos

Browse the world’s most popular video-

sharing community

Read your favorite books

Download thousands of books with the

included E-book reader *

Discover thousands of apps for Android™

Games, applications, and more with

marketplace(need for customer installed)

Connect to the Internet wirelessly

High-speed Wi-Fi 802.11 b/g/n networking

Enjoy your media library anywhere

Portable powerhouse plays popular music,

video,and photo formats

microSD memory card reader

Increase your storage capacity (up to 16 GB

supported)

Built-in camera

Convenient front-facing camera

Automatic orientation detection

Read any way you want; the display adjusts

automatically!

Reading books in the ePub format requires

the included E-book reader application.

Unit at a Glance

4.ESC

Press this button to return to a previous screen.

5. microSD

Load external microSD memory cards here.

6. Headphone

Audio output connection for headphones.

7.DC IN 5V

Change and power the tablet with the included

power adapter.

8.USB OTG

Connect to a USB device or a computer to transfer

data (e.g. music, videos,photos, files).

9.USB HOST

Connect to a USB device

1. RESET

Press this button to reset the system when the

device is halted.

2. POWER

Press to turn the unit on, or to turn the screen on

or off.

Press and hold to access the Power Off menu.

3. MENU

Press to view the option menu.

1 2 3 4

Getting Started

Turning the Tablet on or off

2. Touch ok the screen to turn off the tablet.

Turning the Screen On or off

(Standby)

When the tablet is on, you can turn off the

screen to conserve battery power. Simply press

the Power key once to turn the screen

off. Press the Power key again to turn the

screen back on.

To turn the tablet on:

Press and hold the Power key until the LCD

screen turns on. Wait until the Home screen

appears; the tablet is now ready for use.

To turn the tablet off:

1.Press and hold the Power key until the

Device Options menu appears.

To conserve battery power, the screen

can be set to turn off automatically when

the tablet is not in use (between

1 minute and 30 minutes).

This Screen timeout option can be found

in the Display menu.

Getting Started

Unlocking the Screen

About Applications

To open an application, touch the application

icon on the home screen or in the Launcher

where you can tap the icon right up on the

home screen to get in..

Launcher screen:

The screen shown above is for illustrative

purposes only. Reserves the right to modify

and improve the final list of applications

available on the tablet.

When the screen turns off, you will have to

unlock the screen

when you turn it back on.

To unlock the screen, drag the lock icon across

the screen towards the lock icon.

About Applications

Preinstalled Applications

Some applications have been installed on your

tablet for your convenience.

These applications include:

Browse the web.

Perform simple mathematical operations.

Take pictures or videos with the

frontfacing camera.

Check your e-mail.

Play music.

Access the Settings menu to adjust the

tablet’s options.

Preinstalled Applications

Installing Applications

You can also download an install additional

applications from the device’s applications

marketplace, the web browser, or other

sources.

The tablet must be set to allow installation of

applications from non-Market sources. The

Unknown sources option can be set in the

Application settings menu.

Music

Settings

Connect to a Wi-Fi network

The Notification bar displays icons that indicate

your tablet’s Wi-Fi status.

Notification that an open Wi-Fi network is

in range.

Connected to a Wi-Fi network (waves

indicate connection strength).

When Wi-Fi is on, the tablet will look for and

display a list of available Wi-Fi networks.

[no icon] There are no Wi-Fi networks in

range, or the Wi-Fi radio is off.

1. Turn on the Wi-Fi radio if it is not already

on. To turn on Wi-Fi:

a.Go to the Home screen: Press the Home

key.

b.Open the Settings menu: tap the icon right

up on the home screen to get into the

launcher, then touch Settings icon.

c.Open the Wireless & networks menu: Slide

the icon to ON status.

If a network that you have connected to

previously is found, the tablet will

connect to it.If you don’t see your

network in the list, you can force the

tablet to re-scan. To scan for networks,

tap the Menu key, and then touch Scan.

Connect to a Wi-Fi network

To learn about how to add a Wi-Fi network

when it is not in range or when the router

is set to obscure the network name (SSID);

or to configure advanced Wi-Fi options,

please refer to the manual.

When you have successfully connected to a

Wi-Fi network, the Notifications bar at the the low

of the screen will show a Wi-Fi signal indicator.

2. Select an available Wi-Fi network to connect

to:

In the same Wi-Fi settings menu above,touch a

network in the list.

If the network is open,the tablet will prompt you to

confirm connection to the network. Touch Connect

to confirm.

If the network is secured (as indicated by a Lock

icon),the tablet will prompt you to enter a

password or other credentials.Touch the Wireless

password box to show the on-screen keyboard

and then use it to enter the password. Touch

Connect to confirm.

Optional Connections

Connecting to a Computer 3.Mount the storage.

Touch button Turn on USB storage to mount the

tablet’s built-in storage. When it is mounted, you

can copy files to or from your tablet.

Connect the tablet to a computer to transfer files.

1.Connect your tablet to the computer.

With the included USB cable: Plug the small end

of the cable into the USB 2.0 high speed

connector of the tablet. Plug the large end of the

cable into an available USB 2.0 high speed port

on the computer.

2.When your tablet is connected,slide up the

USB icon right down on the screen and then

touch icon USB connected.
