Leica DM500 Manual de usuario

Leica DM500, DM500 B

Manual

Leica DM 500, DM500 B Manual 2

Chapter overview

Safety regulations 4

The Leica DM500 , DM500 B 15

Get Ready! 18

Get Set! 25

Go! 34

Care of the Microscope 36

Dimensions 39

Leica DM 500, DM500 B Manual 3

Contents

Safety regulations 4

Safety concept 5

Symbols used in this operating manual 6

Important Notes 7

Instructions on use 8

Health risks and dangers of use 10

Information for the person responsible

for the instrument 11

Care instructions 12

Accessories, maintenance and repair 13

Electrical data and ambient conditions 14

The Leica DM500, DM500 B 15

Congratulations! 16

Unpacking 17

Get Ready! 18

Attaching the viewing Tubes 19

Leica EZ Viewing Tube –

integrated eyepieces 20

Leica Standard Viewing Tube –

separated eyepieces 22

Eyeguards 23

Installing Objectives and Substage Condenser

Get Set! 25

Turning on the microscope 26

Using the Condenser 27

Prepare to View a Specimen Slide 28

Focusing 29

Viewing Tube Adjustment 30

Oil Immersion Technique 32

Go! 34

Ready! Set! Go! 35

Care of the Microscope 36

General maintenance 37

Dimensions 39

Leica DM 500, DM500 B Manual 4

Safety regulations

Leica DM 500, DM500 B Manual 5

Safety concept

The individual modules of the Leica DM micros-

copy series include an interactive CD-ROM with

all relevant user manuals several languages.

Keep it in a safe place, and readily accessible

to the user. User manuals and updates are also

available for you to download and print from

our web site at

www.leica-microsystems.com.

This operating manual describes the special

functions of the individual modules of the Leica

DM microscopy series and contains important

instructions for their operational safety, main-

tenance, and accessories.

The "Safety concept" booklet contains addi-

tional safety information regarding the service

work, requirements and the handling of micro-

scope, accessories and electrical accessories as

well as general safety instructions.

You can combine individual system articles with

articles from external suppliers. Please read the

user manual and the safety requirements of the

supplier.

Before installing, operating or using the instru-

ments, read the user manuals listed above. In

particular, please observe all safety instruc-

tions.

To maintain the unit in its original condition

and to ensure safe operation, the user must

follow the instructions and warnings contained

in these user manuals.

Leica DM 500, DM500 B Manual 6

Symbols used in this operating manual

Warning of a danger

•This symbol indicates especially impor-

tant information that must be read and

complied with.

Failure to comply can cause the following:

ϘHazards to personnel

ϘFunctional disturbances or damaged instru-

ments

Warning of hazardous electrical voltage

This symbol indicates especially impor-

tant information that is mandatory to

read and observe.

Failure to comply can cause the following:

ϘHazards to personnel

ϘFunctional disturbances or damaged

instruments

Danger due to hot surface.

This symbol warns against touching

accessible hot surfaces, e.g. those of

light bulbs.

For Model DM500 B (Battery Version)

 Dispose of old batteries and defective

appliances in accordance with the stat-

utory regulations.

Important information

This symbol indicates additional infor-

mation or explanations that intend to

provide clarity.

Explanatory notes

ϐThis symbol within the text points to addi-

tional information and explanations.

Leica DM 500, DM500 B Manual 7

Important Notes

Description

The Leica DM500 and DM500 B microscope meets

today's state of the art of technology. Neverthe-

less, hazards may still arise during operation.

The potential risks are described below.

•Before installing, operating or using the

instruments, it is required to read this

user manual. In particular, please observe all

safety instructions.

Contact address

Leica Microsystems (Switzerland) Ltd.

Industry Division

Max Schmidheiny Strasse 201

CH-9435 Heerbrugg (Switzerland)

User Manual

This user manual includes important instruc-

tions related to operating safety, maintenance

and accessories,

Your Leica DM500 or DM500 B micro-

scope comes with an interactive CD-ROM

with all relevant user manuals. Keep it in a safe

place, and readily accessible to the user. User

manuals and updates are also available for you

to download and print from our web site at

www.leica-microsystems.com

Accessories from third-party suppliers

You can combine individual system articles with

articles from external suppliers. Please read the

user manual and the safety requirements of the

supplier.

Original condition

To maintain the unit in its original condition

and to ensure safe operation, the user must

follow the instructions and warnings contained

in these user manuals.

Legal requirements

Adhere to general and local regulations relat-

ing to accident prevention and environmental

protection.

EC Declaration of Conformity

Electricallyoperatedaccessoriesareconstructed

based on the state of the art of technology and

are provided with an EC Declaration of Confor-

mity.

Leica DM 500, DM500 B Manual 8

Instructions on use

Intended use

The Leica DM500 and DM500 B microscopes are

optical instrument which use magniﬁcation and

illumination to improve the visibility of objects.

It is used for observing and documenting.

The Leica DM500 and DM500 B microscopes

may be used only in closed rooms and must be

placed on a solid ﬂoor.

The Leica DM500 or DM500 B microscopes can

be used in clean rooms without any problems.

•Position the Leica DM500 or

DM500 B microscope so that it can be

disconnected from the power supply at any

time. The power cord must remain accessible at

all times, because the power supply is foreseen

as mains disconnecting device.

Place of use

Only use the instruments in closed, dust free

rooms and between +10 °C and +40 °C. Protect

the devices from oil, chemicals and extreme

humidity. If using the devices outdoors, protect

them from dust and moisture. Never use electri-

cal devices outdoors. Install electrical devices at

least 10 cm from the wall and away from ﬂam-

mable substances.

Avoid large temperature ﬂuctuations, direct

sunlight and vibrations. These conditions

can distort measurements and micrographic

images.

In warm and warm-damp climatic zones,

the individual components require

special care in order to prevent the build-up of

fungus.

Non-intended use

•Using the instrument in any way

contrary to the speciﬁcations in the user

manual can lead to bodily harm and damage to

objects. Doing so can impair the functions of

the protective measures provided.

Never install any other plug (NEMA

5-15P) or unscrew any mechanical

components unless expressly instructed to do

so in the instructions.

CAUTION: Risk of explosion if battery is

replaced by an incorrect type. Dispose

of used batteries according to the instructions.

The devices and accessories described in

this operating manual have been tested

for safety and potential hazards.

Leica DM 500, DM500 B Manual 9

Instructions on use (continued)

•The responsible Leica aﬃliate must be

consulted whenever the instrument is

altered, modiﬁed or used in conjunction with

non-Leica components that are outside of the

scope of this manual.

•Unauthorized alterations to the device

or noncompliant use shall void all rights

to any warranty claims.

Transport

If at all possible, use the original packaging for

shipping or transporting individual modules.

In order to prevent damage from vibrations,

disassemble all moving parts that (according to

the user manual) can be assembled and disas-

sembled by the customer and pack them sepa-

rately.

Disposal

Disposal must comply with locally applicable

laws and regulations.

Integration in third-party products

When installing Leica products into third-party

products, the manufacturer of the complete

system or its dealer is responsible for follow-

ing all applicable safety instructions, laws and

guidelines.

Leica DM 500, DM500 B Manual 10

Health risks and dangers of use

Health risks

Workplaces with microscopes facilitate

and improve the viewing task, but they

also impose high demands on the eyes and

holding muscles of the user. Depending on the

duration of uninterrupted work, asthenopia

and musculoskeletal problems may occur. For

this reason, appropriate measures for reduction

of the workload must be taken:

ϘOptimum workplace layout

ϘFrequent changes of activity

ϘThorough training of the personnel, giving

consideration to ergonomic and organiza-

tional aspects

The ergonomic design and construction of the

Leica microscopy series are intended to reduce

the exertion of the user to a minimum.

Danger of infection

•Direct contact with eyepieces is a

potential transmission method for viral

infections of the eye.

The risk can be kept to a minimum by

using personal eyepieces for each indi-

vidual or detachable eyecups.

Dangers during use

ϘThe Leica DM500 or DM500 B microscope

may only be connected to a grounded

socket.

ϘThe Leica DM500 or DM500 B microscope

may not be operated unless it is in proper

functioning condition.

LED Klasse 1 /Class 1 LED Product

The illumination meets laser class 1 require-

ments in accordance with IEC 60825-1 "Safety

of LED products".

Caution: Use of controls or adjustments or

performance of procedures other than those

speciﬁed herein may result in hazardous radia-

tion exposure!

LED class 1

Class 1

LED Product
