Leica DM100 Manual de usuario

Leica DM100

User Manual

Ryf AG

Bettlachstrasse 2

2540 Grenchen

tel 032 654 21 00

fax 032 654 21 09

www.ryfag.ch

Leica DM100 User Manual 2

Congratulations!

Congratulations on purchasing the Leica DM100

Compound Microscope. This model’s exclu-

sive design features and full range of acces-

sories make it a truly versatile, high quality-

instrument.

Though the reliability and robustness of

Leica microscopes is already practically prover-

bial, they still require a certain degree of care

and attention. Therefore, we recommend that

you read this User Manual. It contains all the

information you need regarding operation,

safety and maintenance. Simply observing a

few guidelines will ensure that even after years

of intensive use, your microscope will continue

to work as smoothly and reliably as on the very

ﬁrst day.

We wish you the best of success in your work!

Leica DM100 User Manual 3

Important Notes

Symbols Used in this User Manual 5

Important Safety Notes 6

Instructions for Use 8

Health risks and dangers of use 10

Information for the Person Responsible for the Instrument 11

Accessories, maintenance and repair 12

Electrical data and ambient conditions 13

Assembling the Leica DM100

Unpacking 15

Identifying your Tube 16

Fitting the tube 17

Removing and Inserting Objectives 18

Installing the Mirror (optional) 20

Installing the Polarizer Kit (optional) 21

Using the Leica DM100

Switching on the Microscope 23

Selecting an Objective 24

Preparing for Viewing 25

Focusing 26

Adjusting the Binocular Tubes 27

Adjusting the Eyecups 29

Oil Immersion Technique (only 100× objective) 30

Care of the Microscope

Maintenance instructions 33

General maintenance 34

Dimensions

Dimensions 37

Table of Contents

Leica DM100 User Manual Important Notes 4

Important Notes

Leica DM100 User Manual Important Notes 5

Symbols Used in this User Manual

Warning! Safety hazard!

This symbol indicates especially impor-

tant information that must be read and

complied with.

Failure to comply can cause the following:

OHazards to personnel.

OInstrument malfunctions and damage.

Warning of hazardous electrical Voltage

This symbol indicates information that

must be read and observed.

Failure to comply can cause the following:

OHazards to personnel.

OInstrument malfunctions and damage.

Important Information

This symbol indicates additional infor-

mation or explanations that intend to

provide clarity.

Leica DM100 User Manual Important Notes 6

Important Safety Notes

Before installing, operating or using the

instrument, it is mandatory to read this

User Manual. In particular, please observe all

safety instructions.

The instruments and accessories

described in this User Manual have been

tested for safety and potential hazards.

Original condition

To maintain the unit in its original condition

and to ensure safe operation, the user must

follow the instructions and warnings contained

in this User Manual.

Non-intended use

Using the instrument in any way other

than that described in this User Manual

may result in personal injury or damage to

property. Doing so can impair the functions of

the protective measures provided.

The responsible Leica aﬃliate must be

consulted whenever the instrument is

altered, modiﬁed or used in conjunction with

non-Leica components that are outside of the

scope of this User Manual! Unauthorized altera-

tions to the instrument or noncompliant use

shall void all rights to any warranty claims.

"Safety Concept" Brochure

The "Safety Concept" brochure contains addi-

tional safety information regarding service

work, requirements and the handling of the

microscope, the electrical and other accessories

as well as general safety instructions.

Leica DM100 User Manual Important Notes 7

Disconnecting from the Power Supply

Always position the Leica DM100 so

that you can disconnect it from the

power supply at any time. The power cable

must remain accessible at all times, because the

power cable is intended as a power disconnect

device.

Plug

Never install any other plug

(NEMA 5-15P) or unscrew any mechani-

cal components unless expressly instructed to

do so in the instructions.

Legal Regulations

Adhere to general and local regulations rela-

ting to accident prevention and environmental

protection.

EC Declaration of Conformity

Electrically operated accessories are construc-

ted based on the state of the art of technology

and are provided with an EC Declaration of

Conformity.

Important Safety Notes (continued)

Leica DM100 User Manual Important Notes 8

Instructions for Use

This User Manual describes the Leica DM100

and includes important instructions related to

operating safety, maintenance and accessories.

Your Leica DM100 includes an interactive

CD-ROM with all relevant User Manuals in

additional languages. Keep it in a safe place,

and readily accessible to the user. You can also

download User Manuals and updates from our

website at www.leica-microsystems.com.

Intended Use

The Leica DM100 is an optical instrument for

improving the visibility of objects through

magniﬁcation and illumination. It is used for

observing.

Place of use

The Leica DM100 microscope may be used only

in closed rooms and must be placed on a solid

surface.

The Leica DM100 can be used at +10°C to +40°C.

Protect the microscope from oil, chemicals and

extreme humidity. If it is used outdoors, the

microscope must be protected from dust and

moisture. Never use electrical instruments

outdoors and place them at least 10 cm away

from the wall and from ﬂammable substances.

Avoid large temperature ﬂuctuations, direct

sunlight and vibrations. These conditions

can distort measurements and micrographic

images.

In warm and warm-damp climatic zones,

the individual components require

special care in order to prevent the build-up of

fungus.

Leica DM100 User Manual Important Notes 9

Instructions on Use (continued)

Accessories from third-party suppliers

You can combine individual system articles with

articles from external suppliers. Please read the

User Manual and the safety requirements of the

supplier.

Integration in third-party products

When installing Leica products into third-party

products, the manufacturer of the complete

system or its dealer is responsible for following

all applicable safety instructions, laws and

guidelines.

Transport

If at all possible, use the original packaging for

shipping or transporting individual modules.

In order to prevent damage from vibrations,

all moving parts that (according to the User

Manual) can be assembled and disassembled

by the customer should be packed separately.

Disposal

Disposal must comply with locally applicable

laws and regulations.

Leica DM100 User Manual Important Notes 10

Health Risks and Dangers of Use

Health Risks

Workplaces with microscopes facili-

tate and improve the viewing task, but

they also impose high demands on the eyes

and hand muscles of the user. Depending on

the duration of uninterrupted work at such a

workplace, impaired vision and problems with

the musculoskeletal system may occur. For this

reason, appropriate measures for reduction of

the workload must be taken:

OOptimum workplace layout

OFrequent changes of activity

OThorough training of the personnel, giving

consideration to ergonomic and organiza-

tional aspects

The ergonomic optical design and construction

of the Leica microscopes are intended to reduce

the exertion of the user to a minimum.

Danger of Infection

Direct contact with eyepieces can be a

potential transmission path for bacterial

and viral infections of the eye.

The risk can be minimized by the use of

personal eyecups.

Dangers during Use

OThe Leica DM100 may be connected to a

grounded socket only.

OThe Leica DM100 may be used when it is in

proper working condition only.

LED Class 1 /LED 1 Laser Product

The illumination meets laser class 1 require-

ments in accordance with IEC 60825-1 "Safety

of Laser devices".

Caution: Hazardous radiation may occur if

controls, adjustment jigs, or procedures other

than those outlined in this User Manual are

used!

LED Class 1

Class 1

LED Product
