Lantech IGS-0008A Manual de usuario

Lantech

IGS-0008A

8 10/100/1000T Industrial Switch

User Manual

V1.00

Oct-2010

Content

Overview............................................................1

Introduction............................................................. 1

Features................................................................. 2

Packing List............................................................ 3

Safety Precaution ................................................... 3

Hardware Description.........................................4

Dimensions............................................................. 4

Wiring the Power Inputs.......................................... 5

LED Indicators........................................................ 6

RJ-45 Pin Assignments........................................... 7

Cabling................................................................... 9

Mounting Installation........................................10

DIN-Rail Mounting ................................................ 10

Wall-Mount Plate Mounting................................... 12

Hardware Installation .......................................13

Installation Steps .................................................. 14

Overview

Introduction

The unmanaged industrial switch is a cost-effective solution and meets

the high reliability requirements demanded by industrial applications.

High-Speed Transmissions

The Industrial switch includes a switch controller that can automatically

sense transmission speeds (10/100/1000 Mbps). The RJ-45 interface

can also be auto-detected, so MDI or MDI-X is automatically selected

and a crossover cable is not required. All Ethernet ports have memory

buffers that support the store-and-forward mechanism. This assures

that data is properly transmitted.

Dual Power Inputs

To reduce the risk of power failure, the Industrial switch provides +9 ~

56 VDC dual power inputs. When power failure occurs, the device will

automatically switch to the secondary power input.

Flexible Mounting

The industrial switch is extremely compact and can be mounted on a

DIN-rail or a panel, so it is suitable for any space-constrained

environment.

Wide Operating Temperature

The operating temperature of the Industrial switch is in the range

between -20 ~ 60oC (standard model) or -40 ~ 75oC (wide operating

temperature model). With such a wide range, you can use the Industrial

switch in some of the harshest industrial environments that exist.

Easy Troubleshooting

LED indicators make troubleshooting quick and easy. Each

10/100/1000T port has 2 LED indicators that display the link status,

transmission speed and collision status. Also other LED indicators help

you diagnose the system immediately.

Features

Provides 8 x 10/100/1000Base-T Mbps Ethernet ports.

Store-and-Forward switching architecture

Back-plane (switching fabric): 16Gbps

Third-generation Broadcom switch with AV function

Guaranteed latency

Guaranteed BW

Synchronous timing

Provides 192Kbits memory buffer

4K-entry MAC address table

9720 bytes jumbo frame

Supports full/half duplex flow control

Supports broadcast storm protection

Supports MDI/MDI-X auto-crossover

Supports redundant +9 ~ 56 VDC power input

Provides flexible mounting: DIN-rail, Panel Mounting

Supports operating temperatures from -20 ~ 70oC (standard model) or

-40 ~ 75oC (wide operating temperature model)

Packing List

1 x 8-port 10/100/1000Base-T Industrial Ethernet Switch

1 x User Manual

2 x Wall Mounting Brackets with screws

Safety Precaution

Attention

If DC voltage is supplied by an external circuit, please use a

protection device on the power supply input.

Hardware Description

In this paragraph, we will introduce the Industrial switch’s dimensions,

port, cabling information, and wiring installation.

Dimensions

. The dimensions of the standard model that is not equipped with side

heatsinks are 36.2 x 142 x 105 mm (W x H x D). The figure below gives

the dimensions and views of each side of the 8-port 10/100/1000Base-T

Industrial Switch.

Wiring the Power Inputs

Please follow the steps below to insert the power wires.

Note

The wire gauge for the terminal block should be in the range

between 12~ 24 AWG.

V+ V-

V+ V1-

1. Insert the positive and negative wires into the V+ and V-

contacts on the terminal block connector.

2. Tighten the wire-clamp screws to prevent the DC wires

from loosing.

LED Indicators

The LED indicators located on the front panel display the power status

and network status of the Industrial switch; each has their own specific

meaning as the table shown below.

LED

Color

Description

Green

Power input 1 is active

Off

Power input 1 is inactive

Green

Power input 2 is active

Off

Power input 2 is inactive

Fault

Red

Power input 1 or 2 is inactive

Off

Power input 1 and 2 are bothfunctional, or no power

inputs

1 ~ 8

(Upper LED)

Green

Connected to network

Flashing

Networking is active

Off

Not connected to network

1 ~ 8

(Lower LED)

Green

Connected to network at speed of 1000Mbps

Off

Not connected to network or not working at speed of

1000Mbps

RJ-45 Pin Assignments

The UTP/STP ports will automatically sense for Fast Ethernet

(10Base-T/100Base-TX) or Gigabit Ethernet

(10Base-T/100Base-TX/1000Base-T) connection. Auto MDI/MDIX means that

the switch can connect to another switch or workstation without changing

straight through or crossover cabling. See the figures below for straight

through and crossover cable schema.

10/100Base-TX Pinouts

Pin Number

Assignment

Tx+

Tx-

Rx+

Rx-

Note

“+” and “-” signs represent the polarity of the wires that make up

each wire pair.

The table below shows the 10Base-T/100Base-TX MDI and MDI-X port

pinouts.

Pin Number

MDI-X Signal Name

MDI Signal Name

Receive Data plus (RD+)

Transmit Data plus (TD+)

Receive Data minus (RD-)

Transmit Data minus (TD-)

Transmit Data plus (TD+)

Receive Data plus (RD+)

Transmit Data minus (TD-)

Receive Data minus (RD-)

10/100Base-TX Cable Schema

Straight Through Cable Schema

Crossover Cable Schema

10/100/1000Base-T Pinouts

The table below describes the gigabit Ethernet RJ-45 pinouts.

Signal name

Description

BI_DA+

Bi-directional pair A+

BI_DA-

Bi-directional pair A-

BI_DB+

Bi-directional pair B+

BI_DC+

Bi-directional pair C+

BI_DC-

Bi-directional pair C-

BI_DB-

Bi-directional pair B-

BI_DD+

Bi-directional pair D+

BI_DD-

Bi-directional pair D-
