OWNER’S REFERENCE

PHANTOM II

STEREO PREAMPLIFIER

THE LEADER IN AUDIO ENGINEERING

PHANTOM II

Phantom II Stereo Preamplifier

Owner’s Reference, v1.0

Krell Industries, LLC.

45 Connair Road

Orange, CT 06477-3650 USA

This product complies with the EMC directive (89/336/EEC) and the low-voltage directive

(73/23/EEC).

IMPORTANT SAFETY INSTRUCTIONS

1. Read Instructions.

2. Keep these Instructions.

3. Heed all Warnings.

4. Follow all Instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not install near any heat sources such as radiators, heat registers, stoves, or other appa-

ratus (including amplifiers) that produce heat.

8. Unplug this apparatus during lightning storms or when unused for long periods of time.

9. Refer all servicing to qualified service personnel. Servicing is required when the apparatus

has been damaged in any way, such as a power-supply cord or plug is damaged, liquid has

been spilled or objects have fallen into the apparatus, the apparatus has been exposed to

rain or moisture, does not operate normally, or has been dropped.

10. The Phantom II preamplifier must be placed on a firm, level surface where it is not exposed to

dripping or splashing.

11. The ventilation grids on the top of the Phantom II preamplifier and the space underneath the

Phantom II preamplifier must be unobstructed at all times during operation. Do not place flam-

mable material above or beneath the preamplifier.

12. Before making connections to the Phantom II preamplifier, ensure that the power is off and other

components are in mute or stand-by mode. Make sure all cable terminations are of the highest

quality, free from frayed ends, short circuits, or cold solder joints.

13. Do not connect an RS-232 cable to the phono power port. Output from the phono power port

can seriously damage your computer.

14. Do not connect the cable from a Krell KPE phono stage to the RS-232 port.

15. THERE ARE NO USER SERVICEABLE PARTS INSIDE AN PHANTOM II PREAMPLIFIER.

Please contact Krell if you have questions not addressed in this guide.

This product is manufactured in the United States of America. Krell®is a registered trademark of Krell Industries, LLC., and is restricted for use

by Krell Industries, Llc., its subsidiaries, and authorized agents. Evolution Bias™ is a trademark of Krell Industries, LLC. and is a Krell technology

based on U.S. Patent No. 5,331,291. CAN Link™, CAST™, Evolution CAST™, and Krell Current Mode™ are trademarks of Krell Industries,

LLC. All other trademarks are registered to their respective companies.

TEL 203-298-4000

FAX 203-891-2028

E-MAIL [email protected]

WEBSITE http://www.krellonline.com

Contents

List of Illustrations, page 4

A Letter from Krell Industires LLC, page 5

SECTION ONE: Phantom II Features and Technology, page 6

Features, Revolutionary Krell CAST Technology,

Definition of Terms

SECTION TWO: Unpacking and Placement, page 11

Opening the Phantom II Shipping Carton

SECTION THREE: Quick Start, page 13

Connecting the Phantom II to Your System,

Operating the Phantom II

SECTION FOUR: Anatomy of the Phantom II, page 15

Front Panel Description, Remote Control Description,

Battery Installation, and Back Panel Description

SECTION FIVE: Connecting the Phantom II to Your System, page 26

Input and Output Connections, Connection Steps

SECTION SIX: Phantom II Operation, page 28

On/Off and Stand-by Operation

SECTION SEVEN: Customizing the Phantom II, page 29

Navigation Conventions, Menu Functions

SECTION EIGHT: Troubleshooting System Noise, page 43

WARRANTY, page 44

RETURN AUTHORIZATION PROCEDURE, page 46

SPECIFICATIONS, page 47

List of Illustrations

Figure 1, page 15

Phantom II Preamplifier Front Panel

Figure 2, page 19

Phantom II Remote Control

Figure 3, page 22

Phantom II Preamplifier Back Panel

A Letter from Krell Industries LLC

Dear Audio Enthusiast,

Thank you for your purchase of the Krell Phantom II preamplifier.

The preamplifier plays a vital role in audio playback by mediating the line-level out-

put of a wide variety of source components in preparation for the amplifier’s input.

At no other point in the reproduction process is music so vulnerable to change, as

the signal level is small, and susceptible to noise and distortion.

Having always valued the role of the preamplifier in fine audio systems, we take

preamplifier design very seriously. We realize that, no matter how impressive an

amplifier’s performance; it can be no better than that of the preamplifier driving it.

Our new Phantom II preamplifier employs balanced Krell Current Mode gain

stages from input to output, and Current Audio Signal Transmission (CAST)

receivers and transmitters. Utilizing these powerful technologies, the Phantom II

conveys the complete range of timbre and dynamics that comprise the foundation

musical performance. Typical of our latest preamplifier designs, the Phantom II

preamplifier includes a thoughtful suite of menu options, and can be customized

for the greatest ease of operation.

We hope that you enjoy your new Phantom II preamplifier.

Sincerely,

Krell Industries LLC

SECTION ONE

Phantom II Features and Technology

This section describes the innovative features and technology of the Phantom II

preamplifier, and defines CAST and other key terms used in this reference.

Circuity highlights

Sharing the same audio circuitry as its bigger brother, the Phantom II preamplifier

is a dual monaural circuit design with the left and right channels afforded their own

power supply regulation and individual full chassis sized boards. All signals gain is

realized in surface mount topology using proprietary multiple-output current mir-

rors with nearly 500 times the open loop linearity of other designs. Approaching 1

MHz of open loop bandwidth in a zero feedback, balanced, Krell Current Mode,

the Phantom output stage terminates in Krell CAST. A Complete Krell system

(source, preamp, and amplifier), connected using CAST interconnects reduces the

number of voltage gain stages to the minimum, one. The resulting noise floor

approaches the theoretical limit of technology. Negative feedback is not used any-

where in the preamp, nor is it necessary. Open-loop distortion is typically less than

0.003%. The volume control is realized with a balanced resistor ladder bandwidth

and transient response of the circuitry are virtually unaffected by the volume set-

ting.

Power Supply Highlights

The Phantom II audio circuits receive power from a Krell Current Mode analog

power supply. The power supply avoids the common integrated circuit topology

used in many preamplifiers and instead mimics the deign topology of Krell

Evolution e Series amplifiers. The circuitry is completely discrete giving it the ability

to respond quickly to current demands and also be unaffected by AC voltage

power fluctuations. Oversized for a preamplifier, the power supply features a 140

VA transformer and 35,000uF of capacitance.

Revolutionary Krell CAST Technology

Current Audio Signal Transmission, termed CAST, is a revolutionary method of

connecting analog audio components for unparalleled sonic performance.

Innovative engineering combines the new Krell CAST circuitry with existing Krell

Current Mode technology to create entire CAST systems that reproduce music

with incredible range, tonality, and precision.

The Voltage Signal Transmission

and the Traditional Audio System

Traditionally, signal is transmitted in the voltage domain between two components.

In an audio system, each component is a discrete entity with unique characteris-

tics that act upon the musical signal independently. Each component is unaware

of the other components in the system. The cables that connect the components

also have their own electrical characteristics, which affect the sonic presentation

of the entire system. CAST transmission unifies individual components and inter-

connects into an electrically-linked whole. The original signal remains unaltered

from source to speaker.

CAST Basics

Here is how a CAST audio system works. Internally, each CAST source transfers,

or amplifies, current using Krell Current Mode circuitry. This current signal is then

output using CAST circuitry. When the signal is received by a CAST input, Krell

Current Mode circuitry again takes over until the signal reaches the loudspeaker.

By maintaining the musical signal in the current domain from beginning to end, an

entire CAST system behaves as if it is one component. With CAST, circuit board

properties and signal transmission aberrations between components are eliminat-

ed. Cable impedances and their effects on the transmitted signal are non-existent.

How CAST and Krell Current Mode Interact

While CAST is a new method of transferring the musical signal between compo-

nents, its origin stems from Krell Current Mode, the technology developed to

transfer the musical signal within a component. CAST combined with Krell Current

Mode takes circuitry signal transmission to the next evolutionary level. In essence,

continued

Krell Current Mode maintains the integrity of the signal within the component and

CAST preserves the transmitted signal between components. Together, CAST and

Krell Current Mode technologies unify separate Krell components into a single

global circuit. Krell Current Mode technology enjoys bandwidth increases up to an

order of magnitude greater than their voltage based counterparts. This dramatic

increase in circuit bandwidth delivers near perfection in the audible band that typi-

cally suffers from phase distortions in voltage circuits.

CAST Cable Construction

A CAST system uses cables manufactured by Krell and other manufacturers spe-

cially licensed by Krell. Thin and flexible CAST cables are constructed with the

same build quality as other Krell components and are aesthetically matched to the

components that Krell manufactures. An all-metal body and locking connectors

with gold contacts are part of the standard no-compromise specification devel-

oped for every CAST cable made.

Evolution CAST

By employing radical current mirror circuitry, the Phantom II components elevate

the CAST technology to another level. This advanced use of the technology

increases the linearity, transient speed, and bandwidth of the Evolution compo-

nents while reducing the distortion by an order of magnitude.

The Best Musical Performance

When you operate a CAST system, you will hear significant improvements in every

performance area: speed, precision, dynamic range, depth and width of the sound

stage, transient impact, tonal balance, harmonic distortion, and more. The goal for

CAST is the same company goal used for all Krell products. Krell strives for the

delivery of the best performance of a musical event for you, using the full expres-

sion of technology to date.

(SECTION ONE: Phantom II Features and Technology continued)

Definition of Terms

The following are definitions of key terms used in this owner’s reference:

Inputs and Outputs

Balanced

A symmetrical input or output circuit that has equal impedance from both input

terminals to a common ground reference point. The industry standard for profes-

sional and sound recording installations, balanced connections have 6 dB more

gain than single-ended connections and allow the use of long interconnect cables.

Balanced connections are completely immune to induced noise from the system

or the environment.

CAST and Evolution CAST

Krell Current Audio Signal Transmission, or CAST, is a proprietary Krell circuit tech-

nology for connecting analog components, transmitting the audio waveform

between components in the current domain rather than in the voltage domain. The

speed and bandwidth provided by Krell CAST and its circuitry update, Evolution

CAST, yield accurate, realistic music reproduction, enabling connected compo-

nents to perform as if they are all part of a single circuit.

Single-ended

A two-wire input or output circuit. Single-ended connections are not recommend-

ed for connections requiring long cable runs. Use care when using single-ended

connections, because the ground connection is made last and broken first. Turn

the system off/on prior to making or breaking single-ended connections.

Operation

Off

When the stand-by/power LED is not illuminated, the preamplifier is off.

Stand-by

A low-power-consumption status that keeps the audio and regulator circuits at

idle. The stand-by/power LED is illuminated in red, when the preamplifier is in

stand-by mode. Krell recommends leaving the preamplifier in stand-by mode when

it is not playing music.

Operation

When the standby/power LED is illuminated in blue, the preamplifier is in opera-

tional mode and ready to play music.

continued

Technology

Krell Current Mode

A proprietary Krell circuit topology in which the audio gain stages of a component

operate in the current rather than voltage domain. This unique technology provides

the component with exceptional speed, and a wide bandwidth.

(SECTION ONE: Definition of Terms continued)

Tabla de contenidos

Otros manuales de Amplificador de Krell Industries

Krell Industries

Krell Industries FBI Manual de usuario

Krell Industries

Krell Industries Preamplifier KAV-250p Guía de inicio rápido

Krell Industries

Krell Industries KMA-i800 Guía de inicio rápido

Krell Industries

Krell Industries EVOLUTION 222 Manual de usuario

Krell Industries

Krell Industries Power Amplifier KST100 Guía de inicio rápido

Krell Industries

Krell Industries PHANTOM Manual de usuario

Krell Industries

Krell Industries Evolution Guía de inicio rápido

Krell Industries

Krell Industries Evolution 707 Guía de inicio rápido

Krell Industries

Krell Industries EVOLUTION TWO MONAURAL PREAMPLIFIER Guía de inicio rápido

Krell Industries

Krell Industries Evolution 202 Guía de inicio rápido

Krell Industries

Krell Industries KAV-400xi Manual de usuario

Krell Industries

Krell Industries Five-Channel Power Amplifier KAV-1500 Manual de usuario

Krell Industries

Krell Industries S-150m Manual de usuario

Krell Industries

Krell Industries Showcase DVD Guía de inicio rápido

Krell Industries

Krell Industries PAM-3 Manual de usuario

Krell Industries

Krell Industries 300 Manual de usuario

Krell Industries

Krell Industries Evolution Guía de inicio rápido

Krell Industries

Krell Industries Power Amplifier KSA 150 / 250 Manual de usuario

Krell Industries

Krell Industries Vanguard Manual de usuario

Krell Industries

Krell Industries 2250e Manual de usuario

Krell Industries

Krell Industries Evolution Two Manual de usuario

Krell Industries

Krell Industries PAM-1 Manual de usuario

Krell Industries

Krell Industries KAV-300I Guía de inicio rápido

Krell Industries

Krell Industries KAV-500 Guía de inicio rápido

Manuales populares de Amplificador de otras marcas

ASTRO

ASTRO HVO V40 P Manual de usuario

Marantz

Marantz SUPERSCOPE BLA-545 Instrucciones de montaje

NAD

NAD CI980 Manual de usuario

Technics

Technics SE-CH770 Manual de usuario

Harman Kardon

Harman Kardon HK6300 Manual de usuario

NAD

NAD T975 Manual de usuario

McIntosh

McIntosh MA6850 Manual de usuario

Electro-Harmonix

Electro-Harmonix ENGLISH MUFF’N Manual de usuario

Viatron

Viatron Autrix Manual de usuario

GME

GME GA9800 Manual de usuario

Atlas

Atlas CP700 Manual de usuario

Roland

Roland KC-1000 Manual de usuario

Pyle

Pyle PFMRA350BW Manual de usuario

Advantage

Advantage S-250 Manual de usuario

IRT Electronics

IRT Electronics DVA-3007 Manual de usuario

Dimavery

Dimavery BA-100 Series Manual de usuario

Sony

Sony XM-S400D Manual de usuario

Schertler

Schertler ROY X Manual de usuario
