Kramer VS-88A Manual de usuario

Kramer Electronics, Ltd.

USER MANUAL







Models:

VS-88A, VS-88V, SD-7588A, SD-7588V,

RC-8000

88 Series

Contents

Introduction 1

Getting Started 1

Overview 2

3.1

The 88 Series 2

3.2

High Quality Performance Recommendations 2

Your Matrix Switchers 3

4.1

Your VS-88A 8x8 Balanced Audio Matrix Switcher 3

4.2

Your VS-88V 8x8 Video Matrix Switcher 6

4.3

Your SD-7588A 8x8 Digital Audio Matrix Switcher 9

4.4

Your SD-7588V 8x8 SDI Matrix Switcher 12

4.5

Your RC-8000 Remote Controller 15

Installing in a Rack 18

Connecting Your Matrix Switchers 19

6.1

Dipswitch Settings 19

6.2

Connecting a Standalone Unit 20

6.3

Connecting Several Units with/without the Remote Controller 20

6.4

Connecting Several Units and the PC 22

6.5

Connecting a Component, Y/C, RGBS or RGBHV Switcher 23

Understanding the Modes 24

7.1

About the System Modes 24

7.1.1

Standalone Mode 24

7.1.2

IN SYSTEM Mode 24

7.2

About the Confirmation Modes 24

7.2.1

AT ONCE Mode 25

7.2.2

CONFIRM Mode 25

Operation 26

8.1

Technical Information 26

8.1.1

Setup Capacity 26

8.1.2

Switching the Power On 26

8.1.3

Timeout 26

8.1.4

System Settings Priority 27

8.2

Push Button Controls 27

8.2.1

Storing a Setting 27

8.2.2

Recalling a Setting 27

8.2.3

Locking and Unlocking Settings 28

Technical Specifications 30

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Contents

Figures

Figure 1: VS-88A 8x8 Balanced Audio Matrix Switcher 4

Figure 2: VS-88V 8x8 Video Matrix Switcher 7

Figure 3: SD-7588A 8x8 Digital Audio Matrix Switcher 10

Figure 4: SD-7588V 8x8 SDI Matrix Switcher 13

Figure 5: RC-8000 Remote Controller 16

Figure 6: Rear Panel Dipswitches 19

Figure 7: RS-485 System Connection: Switchers and Remote Controllers 21

Figure 8: System Connection: Switchers and the PC 22

Figure 9: Component Switcher: VS-88V Group Connection 23

Tables

Table 1: VS-88A 8x8 Balanced Audio Matrix Switcher Features 5

Table 2: VS-88V 8x8 Video Matrix Switcher Features 8

Table 3: SD-7588A 8x8 Digital Audio Matrix Switcher Features 11

Table 4: SD-7588V 8x8 SDI Matrix Switcher Features 14

Table 5: RC-8000 Remote Controller Top Panel Features 17

Table 6: RC-8000 Remote Controller Rear Panel Features 17

Table 7: Rear Panel Dipswitches 19

Table 8: Machine # Dipswitch Settings 19

Table 9: Push Button Sequence Summary 30

Table 10: Technical Specifications for 88 Series 31

Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range

of problems that confront the video, audio, presentation, and broadcasting

professional on a daily basis. In recent years, we have redesigned and upgraded

most of our line, making the best even better! Our 500-plus different models

now appear in eight groups

that are clearly defined by function.

Congratulations on purchasing your Kramer 88 Series switcher: VS-88A,

VS-88V, SD-7588A, and/or SD-7588V, and/or RC-8000 Remote Controller.

These products are ideal for:

Broadcast studios for on-air switching and signal routing

Production studios, for connecting various sources to acceptors

Non-linear editing suites and presentation applications

Each switcher package also includes the following items:

Power cord

Windows®-based Kramer control software

This user manual

2 Getting Started

We recommend that you:

Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

Review the contents of this user manual

Use Kramer high performance high resolution cables

1 GROUP 1: Distribution Amplifiers; GROUP 2: Video and Audio Switchers, Matrix Switchers and Controllers; GROUP 3:

Video, Audio, VGA/XGA Processors; GROUP 4: Interfaces and Sync Processors; GROUP 5: Twisted Pair Interfaces;

GROUP 6: Accessories and Rack Adapters; GROUP 7: Scan Converters and Scalers; and GROUP 8: Cables and Connectors

2 Downloadable from our Web site at http://www.kramerelectronics.com

3 Download up-to-date Kramer user manuals from the Internet at this URL: http://www.kramerelectronics.com

4 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Overview

3 Overview

The 88 Series is a group of 8x8 Vertical Interval Matrix Switchers

and a

Remote Control Panel for video/stereo audio/data signals that support the

simultaneous connection of one or more inputs to several outputs

. Vertical

Interval Switching

ensures an undisturbed picture transition. The major

innovation with the 88 Series is the ability to switch different kinds of signals

simultaneously. Section 3.1 outlines the 88 Series and section 3.2 includes

recommendations for achieving high quality performance.

3.1 The 88 Series

The 88 Series includes the following items:

VS-88A (stereo audio matrix switcher for analog balanced audio)

VS-88V (video matrix switcher for analog composite video)

SD-7588A (audio matrix switcher for digital audio)

SD-7588V (video matrix switcher for digital video)

RC-8000 (remote controller for use with the switchers)

3.2 High Quality Performance Recommendations

Achieving high quality performance means:

Connecting only good quality connection cables, thus avoiding interference,

deterioration in signal quality due to poor matching, and elevated noise levels

(often associated with low quality cables)

Using good quality sockets and connectors for the sources and acceptors to

avoid signal path breaks

. Aim for Zero Ohm connection resistance and ensure

that sockets and connectors match the required impedance (75 ohms in video)

Avoiding interference from neighboring electrical appliances that may

adversely influence signal quality. Install unbalanced audio and video lines

(even though the cables are shielded) away from mains carrying cables, electric

motors, and transmitters

1 Switching is implemented during the vertical interval period according to the SMPTE RP-168 standard, when using

synchronized SDI sources

2 However, you cannot connect two or more inputs to a single output

3 Frequently used when recording or transmitting a video program involving several video sources

4 Poor quality connectors tend to rust, which may cause breaks

5 Balanced audio lines are less prone to interference

Your Matrix Switchers

Positioning the switcher correctly. Each switcher is housed in a professional

19-inch rack mountable enclosure, requiring one vertical rack space per

product

. The standard 19-inch (IU) EIA rack assembly requires no specific

spacing above or below the unit for ventilation

4 Your Matrix Switchers

This section describes the products

in the 88 Series range that can function

separately

or switch together in the same manner in the In System mode

4.1 Your VS-88A 8x8 Balanced Audio Matrix Switcher

The VS-88A is a high performance 8x8 stereo audio matrix switcher for

balanced audio stereo signals using detachable terminal block connectors. In

addition, the VS-88A:

Is a true matrix switcher, enabling the user to simultaneously route any input to

any or all outputs

Delivers excellent audio performance ensuring that it remains transparent in

almost any audio application

Is controllable via the front panel buttons as well as the built-in RS-232 and

RS-485 interfaces

Includes 15 preset memory locations for quickly and easily accessing the most

frequently used configurations

May be used with the RC-8000,an optional remote controller (see section 0)

Functions as a standalone unit as well as part of a Kramer multi-signal switcher

system

Figure 1 and Table 1 define the VS-88A:

1 To install a switcher in a rack, see section 5

2 Switchers in the 88 Series share identical front panel controls. Video switchers with the suffix V, have rear panel BNC

connectors. Audio switchers with the suffix A, have rear panel detachable terminal block connectors

3 Standalone

4 Section 7 describes the different modes

5 Which includes digital and analog video, digital and analog audio and RS-422 control switchers. When integrated in a

system, it switches together with the video during the vertical interval, thus supporting true IN SYSTEM mode

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your Matrix Switchers

Figure 1: VS-88A 8x8 Balanced Audio Matrix Switcher

Your Matrix Switchers

Table 1: VS-88A 8x8 Balanced Audio Matrix Switcher Features

# Feature Function

1 POWER Switch Illuminated switch supplying power to the unit

2 ALL Button Pressing ALL before pressing an INP button, connects that input to all outputs

3 OFF Button Pressing OFF after pressing an OUT button disconnects that output from the

inputs. To turn off the connections, press the ALL button and then the OFF

button

4 IN Select the output to which the input is switched (from 1 to 8)

SELECT

Buttons OUT Select the input to switch to the output (from 1 to 8)

5 STO Button Pressing STO (Store) followed by an output button stores the current setting

(refer to section 8.2.1)

6 RCL Button Pressing the RCL (Recall) button and the corresponding OUT key recalls a

setup. Press the RCL button again to implement the new status (refer to section

8.2.2)

7 IN SYSTEM Button Pressing IN SYSTEM twice

, switches between the Standalone mode (in which

the switcher implements any action independently from the others) and the In

System mode (in which all switchers implement the same action simultaneously)

8 TAKE Button

(TAKE = CONFIRM)

Pressing TAKE toggles the mode between the CONFIRM mode

and the AT

ONCE mode (user confirmation per action is unnecessary)

9 OUTPUT labels Identifies a connection between the output and the input shown below it

INPUT Status Display Displays the selected input switched to the output (marked above each input)

10 INPUT Terminal Block

Connectors

Connect to balanced stereo audio sources (from 1 to 8)

11 OUTPUT Terminal

Block Connectors

Connect to balanced stereo audio acceptors (from 1 to 8)

12 MACHINE # Dipswitches setup (refer to section 6.1)

13 RS-485 Connector RS-485 detachable terminal block port. Pins # 1 to # 3 are for RS 485 and pin #

4 is for vertical sync distribution

as Figure 7 illustrates

14 Power Connector with

Fuse

AC connector enabling power supply to the unit

15 RS-232 OUT 9-pin

D-sub Connector

Connects to the RS-232 IN 9-pin D-sub port of the next unit in the daisy-chain

connection

16 RS-232 IN 9-pin

D-sub Connector

Connects to PC or Remote Controller

1 For example, press ALL and then Input button # 2 to connect input # 2 to all the outputs

2 For example, press STO and then the Output button # 3 to store in Setup # 3

3 After pressing IN SYSTEM once, it blinks

4 When in Confirm mode, the TAKE button illuminates

5 The 88 Series RS-485 connector has 4 pins, and the remote controller RS-485 connector has just 3 pins

6 If the unit is the final unit in the daisy-chain connection, no termination is required

7 If the unit is not the first unit in the line, connects to the RS-232 OUT 9-PIN D SUB port of the previous unit in the line

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your Matrix Switchers

4.2 Your VS-88V 8x8 Video Matrix Switcher

The VS-88V is a high performance 8x8 composite video matrix switcher. In

addition, the VS-88V:

Is a true matrix switcher, enabling the user to simultaneously route any input to

any or all outputs

Supports more than 200MHz video bandwidth

Switches during the vertical interval

Accepts analog video as the external source for its vertical interval trigger

Is controllable via the front panel buttons as well as the built-in RS-232 and

RS-485 interfaces

Includes 15 preset memory locations for quickly and easily accessing the most

frequently used configurations

May be used with the RC-8000,an optional remote controller (see section 0)

Functions as a standalone unit as well as part of a Kramer multi-signal switcher

system

Can be combined as part of a group of VS-88V switchers that comprise a

component switcher

Figure 2 and Table 2 define the VS-88V:

1 Transitions are glitch-free when sources share a common reference sync

2 Which includes digital and analog video, digital and analog audio, and RS-422 control switchers. When integrated into a

system, it can provide the rest of switchers with the vertical interval trigger

3 Refer to section 6.5 and Figure 9 on page 23

Your Matrix Switchers

Figure 2: VS-88V 8x8 Video Matrix Switcher

Otros manuales para VS-88A

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Conmutador de matriz de Kramer

Kramer

Kramer VP-8x8 Manual de usuario

Kramer

Kramer AFM-20DSP-LE Manual de usuario

Kramer

Kramer Sierra Video 1608V3S Manual de usuario

Kramer

Kramer VS-88HCB Manual de usuario

Kramer

Kramer VS-44AV Manual de usuario

Kramer

Kramer 1616DS Manual de usuario

Kramer

Kramer VS-44H Manual de usuario

Kramer

Kramer Sierra Video 4832V5Sxl Manual de usuario

Kramer

Kramer VS-88H2A Manual de usuario

Kramer

Kramer XL 1616V4 Manual de usuario

Kramer

Kramer 1616HDEE Manual de usuario

Kramer

Kramer Sierra Video 4864V5Sxl Manual de usuario

Kramer

Kramer 3232D Manual de usuario

Kramer

Kramer VS-42HN Manual de usuario

Kramer

Kramer Sierra Video 3216V3 Manual de usuario

Kramer

Kramer VP-1608 Manual de usuario

Kramer

Kramer LASSEN XL 3216S Manual de usuario

Kramer

Kramer VS-2616 Manual de usuario

Kramer

Kramer Sierra Video 3248V5Sxl Manual de usuario

Kramer

Kramer VP-8x4AK Manual de usuario

Kramer

Kramer 3232S Manual de usuario

Kramer

Kramer VS-3232A Manual de usuario

Kramer

Kramer XL 1204V4 Manual de usuario

Kramer

Kramer 20-04400030 Manual de usuario

Manuales populares de Conmutador de matriz de otras marcas

Broadcast Tools

Broadcast Tools SS 8.2 Manual de usuario

Altimium

Altimium MATF32 Manual de usuario

ALFAtron

ALFAtron ALF-MUK44N Manual de usuario

Monoprice

Monoprice Blackbird 15377 Manual de usuario

PTN

PTN FMX12 Manual de usuario

CYP

CYP nT15GX01 Manual de usuario

TESmart

TESmart HMA0402A40 Manual de usuario

Octava

Octava HD4XSTPMX Manual de usuario

Intelix

Intelix FLX-88 Instrucciones de funcionamiento

Roland

Roland XS-1HD Manual de usuario

Atlona

Atlona AT-HDMI-22M Manual de usuario

Link

Link HD8X8 Manual de usuario

AMX

AMX AVS-OP-2020-117 Instrucciones y recetas

Lindy

Lindy 38042 Manual de usuario

Extron electronics

Extron electronics MTPX Plus Series Manual de usuario

Key Digital

Key Digital Champion KD-16x16CS Manual de usuario

Shinybow USA

Shinybow USA SB-8811 Manual de usuario

Optimus

Optimus Compact Manual de usuario
