USER MANUAL

Model:

VS-3232D

32x32 Digital Matrix Switcher

Contents

1Introduction 1

2Getting Started 1

2.1 Quick Start 2

3Overview 3

3.1 Defining EDID 4

3.2 Recommendations for Best Performance 4

4Defining the VS-3232D 32x32 Digital Matrix Switcher 4

4.1 Using the IR Transmitter 8

5Installing the VS-3232D in a Rack 9

6Connecting the VS-3232D 32x32 Digital Matrix Switcher 10

6.1 Port Numbering 11

6.1.1 EDID Numbering Examples 12

6.2 Connecting to the VS-3232D via RS-232 13

6.3 Connecting to the VS-3232D via Ethernet 13

6.3.1 Connecting the Ethernet Port directly to a PC 13

6.3.2 Connecting to the Ethernet Port via a Network Switch/Hub 15

7Operating Your Video Matrix Switcher 15

7.1 Startup Display 15

7.1.1 Viewing the Display 16

7.2 Using the Selector Buttons 16

7.3 Confirming Actions 16

7.3.1 Toggling between the At Once and Confirm Modes 17

7.3.2 Confirming a Switching Action 17

7.4 Switching Actions 17

7.4.1 Switching one Input to one Output 18

7.4.2 Switching Several Inputs to Several Outputs 18

7.4.3 Turning an Output Off 18

7.4.4 Turning Off Several Outputs 19

7.4.5 Recalling the Default Setup 19

7.5 Locking the Front Panel Buttons 20

8Using the Configuration Menus 20

8.1 Using the Setup Menu 20

8.1.1 Setup Menu—1: inXX=>ALL, Switching one Input to all Outputs 21

8.1.2 Setup Menu—3: outXX=>OFF, Turning an Output Off 21

8.1.3 Setup Menu—7: EDID, Assignment to an Input 21

8.1.4 Setup Menu—9: Delay, Setting for an Output 22

8.1.5 Setup Menu—4: store setup XX, Storing the Setup in a Preset 23

8.1.6 Setup Menu—6: recall setup XX, Recalling a Preset 23

8.2 Using the Config Menu 24

8.2.1 Config Menu—Input Signal Detection Display 25

8.2.2 Config Menu—Output Load Detection Display 25

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Contents

8.2.3Config Menu—Interface Configuration 26

8.2.4 Config Menu—Interface Reply Configuration 26

8.2.5 Config Menu—Protocol Configuration 27

8.2.6 Config Menu—Store Default Setup 27

8.2.7 Config Menu—Total Matrix Reset 27

8.2.8 Config Menu—Display Firmware Versions 28

9Configuring the Number of Installed Input and Output Ports 29

10 Installing and Using the Test Module to Troubleshoot Video Problems 29

10.1 Installing the Test Module 29

10.2 Setting the Resolution of the Generated Video 30

10.3 Setting the Pattern of the Generated Video 31

10.4 Using the Test Module to Troubleshoot Video Problems 31

10.4.1 Testing the Projector Output 31

10.4.2 Testing the Output Signal Path to the Projector 32

10.4.3 Testing the Input and Output Signal Path to the Projector 32

11 I/O Card Hardware Installation Instructions 32

12 Upgrading the VS-3232D Firmware 34

13 Technical Specifications 35

14 Default Communication Parameters 36

15 Factory Default EDID 36

15.1 DVI Input Card 36

15.2 DVI (HDCP) Input Card 37

15.3 HDMI Input Card 39

15.4 DVI Dual Channel Input Card 41

16 Communication Protocols 41

Figures

Figure 1: VS-3232D 32x32 Digital Matrix Switcher Front Panel 5

Figure 2: VS-3232D Front Panel Numeric Keypad 6

Figure 3: VS-3232D 32x32 Digital Matrix Switcher Rear Panel Showing DVI Cards 7

Figure 4: Connecting the VS-3232D 10

Figure 5: Sample Port Numbering 12

Figure 6: Local Area Connection Properties Window 14

Figure 7: Internet Protocol (TCP/IP) Properties Window 14

Figure 8: Default Startup Status Display Sequence 15

Figure 9: Resolution DIP-switch 30

Figure 10: Signal Paths for Isolating problems 31

Figure 11: Inserting the Card into a Slot 33

Figure 12: Card Handles 34

Contents

iii

Tables

Table 1: VS-3232D 32x32 Digital Matrix Switcher Front Panel Features 6

Table 2: VS-3232D Front Panel Numeric Keypad Labels 6

Table 3: VS-3232D 32x32 Digital Matrix Switcher Rear Panel Features 8

Table 4: Port Numbering 12

Table 5: EDID Configuration Requests and Results 13

Table 6: Available PC Resolutions for Generated Video (Jumper off) 30

Table 7: Available HDResolutions for Generated Video (Jumper on, default) 30

Table 8: Technical Specifications of the 32x32 Digital Matrix Switcher 35

Table 9: Technical Specifications of VS-3232D Compatible Cards 35

Table 10: Default Communication Parameters for the VS-3232D 36

Table 11: Hex Table (IN 1-32 to OUT 1-16) 41

Table 12: Hex Table (IN 1-32 to OUT 17-32) 43

Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range of

problems that confront the video, audio, presentation, and broadcasting

professional on a daily basis. In recent years, we have redesigned and upgraded

most of our line, making the best even better! Our 1,000-plus different models now

appear in 11 groups1

Congratulations on purchasing your Kramer VS-3232D 32x32 Digital Matrix

Switcher. This product is ideal for the following typical applications:

that are clearly defined by function.

•Professional display systems requiring video signal routing

•Broadcast, presentation and production facilities, as well as monitoring in

large duplication systems

•Rental/staging applications

The package includes the following items:

•VS-3232D 32x32 Digital Matrix Switcher

•Power cord

•Kramer RC-IR3infrared remote control transmitter (including the required

batteries and a separate user manual2)

•This user manual2

Note: Throughout this user manual the chassis configuration is shown with 32 DVI

inputs and 32 DVI outputs as a representation only. The following cards are

available and may be mixed in the same chassis:

•DVI

•DVI dual link

•DVI (HDCP)

•DVI (over 4LC fiber optic cable)

•HDMI (HDCP)

2 Getting Started

We recommend that you:

•Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

•Review the contents of this user manual

1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems; GROUP 4:

Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7: Scan

Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories and Rack

Adapters; GROUP 11: Sierra Products

2 Download up-to-date Kramer user manuals from http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Getting Started

•Use Kramer high-performance high-resolution cables1

•Use only the power cord that is supplied with this machine

2.1 Quick Start

The following quick start chart summarizes the basic setup and operation steps.

1 The complete list of Kramer cables is available from http://www.kramerelectronics.com

Overview

3 Overview

The Kramer VS-3232D is a high performance matrix switcher chassis that supports

up to 32 x 32 ports1for various signals (depending on the type of cards installed).

It features a very high bandwidth2

The VS-3232D is highly configurable–you can add or remove inputs and outputs

independently in groups of four and mix different types of input/ouput cards in the

same chassis. For example, you can configure a device as a 4 x 24 or a 32 x 8

matrix switcher to exactly suit your needs.

of up to 3.2Gbps (for the chassis only, effective

bandwidth of the system depends on the I/O cards) that ensures transparent

performance even in the most critical applications. The cards re-clock and equalize

the signals and the chassis can route any or all inputs to any or all outputs

simultaneously.

The VS-3232D features:

•Full 32 x 32 non-blocking matrix array to switch any of the 32 input digital

signals to any or all outputs (with limitations, see Section 6)

•Easy access to 59 preset memory locations for quick access to user-defined

setups

•The Kramer 2000 Protocol for serial control

•A 40 character by 2 line LCD that shows the operational status or the

configuration menu

•A lock function to prevent tampering with the front panel

•A default EDID (Extended Display Identification Data) for each input

•I-EDIDPro™ Kramer Intelligent EDID Processing™ – Intelligent EDID

handling and processing algorithm ensures plug and play operation for

DVI/HDMI systems

•Kramer Core™—flexible infrastructure conversion. Copper, fiber or

Twisted Pair, all can be used at the same time according to input/output

module selection. The matrix receives digital signals from compatible

Kramer transmitters, automatically converts between available infrastructure

options and sends the signals to compatible Kramer receivers

•Equalization and re-clocking on all card types

You can operate the VS-3232D via the front panel buttons3

•RS-232 serial commands transmitted by a touch screen system, PC or other

serial controller

or remotely via:

1 Can also be configured for other sizes (up to a maximum of 32 x 32)

2 For maximum bandwidth supported by each type of card see the Technical Specifications in Section 13

3 The VS-3232D is a sophisticated device but has been designed to be as simple as possible to operate. Due to space limitations on the

front panel 64 input/output selector buttons are instead substituted by a keypad. For details of how to route inputs to outputs, see

Section 7.2

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Defining the VS-3232D 32x32 Digital Matrix Switcher

•Ethernet over a LAN

•The infrared remote control transmitter

The VS-3232D is housed in a 19" rack-mountable enclosure.

To achieve the best performance:

•Connect only good quality connection cables, thus avoiding interference,

deterioration in signal quality due to poor matching, and elevated noise

levels (often associated with low quality cables)

•Avoid interference from neighboring electrical appliances that may

adversely influence signal quality

•Position your Kramer VS-3232D in a location free from moisture and away

from excessive sunlight and dust

3.1 Defining EDID

The Extended Display Identification Data (EDID1

3.2 Recommendations for Best Performance

) is a data-structure provided by

a display, to describe its capabilities to a graphics card (that is connected to the

display’s source). The EDID enables the video source to “know” what kind of

monitor is connected to the output. The EDID includes the manufacturer’s name,

the product type, the timing data supported by the display, the display size,

luminance data and (for digital displays only) the pixel mapping data.

To achieve the best performance:

•Use only good quality connection cables to avoid interference, deterioration

in signal quality due to poor matching, and elevated noise levels (often

associated with low quality cables)

•Avoid interference from neighboring electrical appliances that may

adversely influence signal quality and position your Kramer VS-3232D

away from moisture, excessive sunlight and dust

4 Defining the VS-3232D 32x32 Digital Matrix Switcher

Figure 1, Table 1, Figure 2and Table 2define the front panel of the VS-3232D.

1 Defined by a standard published by the Video Electronics Standards Association (VESA)

Defining the VS-3232D 32x32 Digital Matrix Switcher

Figure 1: VS-3232D 32x32 Digital Matrix Switcher Front Panel

Note: Buttons 11, 12 and 13 function as the TAKE, MENU and LOCK buttons respectively

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Defining the VS-3232D 32x32 Digital Matrix Switcher

Table 1: VS-3232D 32x32 Digital Matrix Switcher Front Panel Features

Feature

Function

Double-

function

Selector

Buttons

Area

Buttons

ESC Press to exit the current operation

2 EDID Press to assign EDID channels

3 STO

Press to store the current setup in the a preset

4 ALL

Press to connect an input to all outputs

5 OFF

Press to turn off an output

6 RCL1Press to recall a preset

7 DELAY Press to set the delay between confirming an action and the execution of the action

8 ENT Press to complete the input-output setup when using a one-digit number instead of

two digits2

Press to enter the options in a setup menu

9 IR Receiver Infrared remote control sensor

10 IR LED Lights yellow when receiving commands from the IR remote control transmitter

11 TAKE Button Press to confirm actions (see Section 7.3.2

)

MENU Button Press once to enable the ALL, OFF STO and RCL buttons (see Section 8).

Press again to enter the configuration menu (see 8.2Section

When in a Menu, press to cycle through the menu items

13 LOCK Button Press and hold for approximately 2 sec to lock/unlock the front panel buttons (see

Section 7.5

)

BREAKAWAY Button Press to exit a Menu (see Section 8

)

DEFAULT SETUP Button Press to recall the default setup (see Section 7.4.5

)

OUTPUTS/INPUTS

LCD Display

Displays the outputs (upper row) switched to the selected inputs (lower row), (see

Section 7.1

Displays user interface messages and menus

Figure 2: VS-3232D Front Panel Numeric Keypad

Table 2: VS-3232D Front Panel Numeric Keypad Labels

# Feature Function

17 ◄(Backward) Press to shift the sliding window to the right

18 1, 2, 3, 4, 5, 6, 7, 8, 9, 0 Numeric keypad, 1 to 0

19 ►(Forward) Press to shift the sliding window to the left3

1 After pressing the MENU button, this button lights and is enabled

2 For example, to enter input 5, you can either press 05 or 5, ENT

3 Since the LCD display is large enough to show only 13 cross-points out of a total of 32

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Conmutador de matriz de Kramer

Kramer

Kramer VS-5x5 Manual de usuario

Kramer

Kramer VSM-4x4HFS Manual de usuario

Kramer

Kramer VP-729 Manual de usuario

Kramer

Kramer Sierra Video 4848V5xl Manual de usuario

Kramer

Kramer VS-42HDCP Manual de usuario

Kramer

Kramer Sierra Video 3248V5Sxl Manual de usuario

Kramer

Kramer VS-88HN Manual de usuario

Kramer

Kramer VS-84HN Manual de usuario

Kramer

Kramer 1616HDEE Manual de usuario

Kramer

Kramer XL 1208V4S Manual de usuario

Kramer

Kramer VS-44H2 Manual de usuario

Kramer

Kramer VP-8x8TP Manual de usuario

Kramer

Kramer Sierra Video 6432V5Sxl Manual de usuario

Kramer

Kramer Sierra Video 4832V5xl Manual de usuario

Kramer

Kramer VP-16x18AK Manual de usuario

Kramer

Kramer Sierra Video 4832V5Sxl Manual de usuario

Kramer

Kramer 3232DEE Manual de usuario

Kramer

Kramer VS-48HDCPxl Manual de usuario

Kramer

Kramer VS-44FO Manual de usuario

Kramer

Kramer Sierra Pro XL 1616V3S Manual de usuario

Kramer

Kramer VS-48HDCPxI Manual de usuario

Kramer

Kramer VS-6464DN-EM Manual de usuario

Kramer

Kramer AFM-20DSP-AEC Manual de usuario

Kramer

Kramer VS-42H2 Manual de usuario

Manuales populares de Conmutador de matriz de otras marcas

Broadcast Tools

Broadcast Tools SS 8.2 Manual de usuario

Altimium

Altimium MATF32 Manual de usuario

ALFAtron

ALFAtron ALF-MUK44N Manual de usuario

Monoprice

Monoprice Blackbird 15377 Manual de usuario

PTN

PTN FMX12 Manual de usuario

CYP

CYP nT15GX01 Manual de usuario

TESmart

TESmart HMA0402A40 Manual de usuario

Octava

Octava HD4XSTPMX Manual de usuario

Intelix

Intelix FLX-88 Instrucciones de funcionamiento

Roland

Roland XS-1HD Manual de usuario

Atlona

Atlona AT-HDMI-22M Manual de usuario

Link

Link HD8X8 Manual de usuario

AMX

AMX AVS-OP-2020-117 Instrucciones y recetas

Lindy

Lindy 38042 Manual de usuario

Extron electronics

Extron electronics MTPX Plus Series Manual de usuario

Key Digital

Key Digital Champion KD-16x16CS Manual de usuario

Shinybow USA

Shinybow USA SB-8811 Manual de usuario

Optimus

Optimus Compact Manual de usuario
