Kohler K-1106 Manual de usuario

Installation Guide

Drop-In 120 V Bath Whirlpool

K-1106, K-1112, K-1114,

K-1126, K-1131, K-1139,

K-1144, K-1146, K-1148,

K-1154, K-1157, K-1160,

K-1162, K-1164, K-1192,

K-1194, K-1196, K-1198,

K-1201, K-1209, K-1221,

K-1224, K-1226, K-1231,

K-1239, K-1244, K-1246,

K-1248, K-1257, K-1263,

K-1266, K-1337

Mproduct numbers are for Mexico (i.e. K-12345M)

Los números de productos seguidos de Mcorresponden a México

(Ej. K-12345M)

Français, page ″Français-1″

Español, página ″Español-1″

1010564-2-H

Important Information

WARNING: When using electrical products, basic precautions should always be followed, including

the following:

Building materials and wiring should be routed away from the pump body and other heat-producing

components of the unit.

Install to permit access for servicing.

Grounding is required. The unit should be installed by a qualiﬁed service representative, and grounded.

WARNING: Risk of electric shock. A licensed electrician should make all electrical connections.

WARNING: Risk of electric shock. Disconnect power before servicing.

WARNING: Risk of injury or property damage. Please read all instructions thoroughly before

beginning installation, including the following requirements.

NOTICE: Follow all local plumbing and electrical codes.

Product Information

Electrical Requirements

The installation must have a Class A Ground-Fault Circuit-Interrupter (GFCI). The GFCI protects against

line-to-ground shock hazard. Use a 120 V, 15 A, 60 Hz dedicated service for the whirlpool.

″H″models require a separate 120 V, 15 A, 60 Hz dedicated service for the heater.

NOTE: If the pump supply cord is damaged, it must be replaced by the manufacturer, its service agent or

similarly qualiﬁed persons in order to avoid a hazard. The heater supply cord cannot be replaced. If the

cord is damaged the heater should be scrapped.

Product Notices

WARNING: Unauthorized modiﬁcation may cause unsafe operation and poor performance of the

whirlpool. Do not relocate the whirlpool pump, or make other modiﬁcations to the whirlpool system,

as this could adversely affect the performance and safe operation of the whirlpool. Kohler Co. shall not

be liable under its warranty or otherwise for personal injury or damage caused by any such

unauthorized modiﬁcation.

WARNING: Risk of electrical shock. Disconnect power before servicing.

WARNING: Risk of electrical shock. A licensed electrician should make all electrical connections.

WARNING: Risk of injury or property damage. Please read all instructions thoroughly before

beginning installation.

NOTICE: Follow all local plumbing and electrical codes.

Factory-Assembled Features

Factory installed components include pump with power supply cord and air switch transmitter. No

installation is needed.

″H″models are also supplied with a factory assembled heater.

An optional timer kit is available for certain models.

The whirlpool pump and piping are factory-assembled.

Connections and Service Access

1010564-2-H 2 Kohler Co.

Important Information (cont.)

Before installation, ensure proper access to the ﬁnal connections.

NOTICE: Provide unrestricted service access to the pump. You must provide access for servicing the

pump and controls. The access must be located immediately next to the pump. Study the roughing-in

information packed with the whirlpool.

Table of Contents

Important Information .............................................................. 2

Thank You For Choosing Kohler Company .............................................. 4

Tools and Materials ............................................................... 4

Before You Begin ................................................................. 4

Prepare the Site ................................................................. 5

Prepare the Whirlpool ............................................................. 6

Secure the Unit — Models With Support Blocks .......................................... 6

Secure the Whirlpool to the Stud Framing ............................................... 8

Secure the Unit — Models With Whirlpool Base .......................................... 9

Cut the Pump Banding Straps ...................................................... 10

Install the Plumbing .............................................................. 10

Install a Rim-Mounted Faucet ....................................................... 11

Make Electrical Connections ........................................................ 12

Test Run the Whirlpool ............................................................ 13

Complete the Finished Deck ........................................................ 14

Complete the Finished Wall ........................................................ 15

Clean-Up After Installation ......................................................... 15

Conﬁrm Proper Operation .......................................................... 15

Troubleshooting Procedure ......................................................... 17

Kohler Co. 3 1010564-2-H

Thank You For Choosing Kohler Company

We appreciate your commitment to Kohler quality. Please take a few minutes to review this manual before

you start installation. If you encounter any installation or performance problems, please don’t hesitate to

Company.

Tools and Materials

Before You Begin

CAUTION: Risk of product damage. Do not lift the whirlpool by the piping or pump, or use the

piping or pump for structural support of the whirlpool.

We recommend this whirlpool for drop-in installation.

Inspect the whirlpool for damage before you begin installation.

You must install this whirlpool to an adequately supported, level subﬂoor.

Conﬁrm adequate mounting and connection space for the faucet speciﬁed for your installation.

Kohler Co. reserves the right to make revisions in the design of products without notice, as speciﬁed

in the Price Book.

Sealant Pencil

Level

Pipe Wrench

Plus:

• Conventional woodworking tools

and materials

• Drop Cloth

• Construction adhesive (optional)

• Cement or mortar (optional)

• 2x4's or 2x6's

Safety Glasses

Tape Measure

1010564-2-H 4 Kohler Co.

1. Prepare the Site

NOTICE: Unless otherwise speciﬁed, ﬂoor support under the whirlpool must provide for a minimum of

80 lbs/square foot (390 kg/square meter) loading.

NOTICE: Do not support the whirlpool by the rim.

Make sure the ﬂooring offers adequate support for your whirlpool, and verify that the subﬂoor is

ﬂat and level.

The whirlpool should be installed in a drop-in, ﬂush, or tiled ledge installation. Construct 2x4 or 2x6

stud framing designed for your particular installation. Provide for a 1/16″(2 mm) gap between the

bottom of the whirlpool rim and the stud framing for drop-in installations. Frame the ﬂoor, or

construct a frame for a raised installation in accordance with the roughing-in information packed

with the whirlpool.

Carefully lay out and cut the rough deck material. Use the cut-out template if one is provided, or

refer to the roughing-in cut-out information.

Position the plumbing according to the roughing-in information packed. Cap the supplies, and

check for leaks.

Drop-In Installation

Whirlpool

Rim

Do not support

the whirlpool

by the rim.

Use the roughing-in

information to

construct the stud

framing.

Allow for the thickness of

the planned deck material.

Wood

Batten

Whirlpool

Rim

Flush Installation

Whirlpool

Rim

Use the roughing-in

information to

construct the stud

framing.

Tiled Ledge Installation

Kohler Co. 5 1010564-2-H

2. Prepare the Whirlpool

Install the drain to the whirlpool according to the drain manufacturer’s instructions. Do not connect

the trap at this time.

Position a clean drop cloth or similar material in the bottom of the whirlpool. Be careful not to

scratch the surface of the whirlpool.

3. Secure the Unit — Models With Support Blocks

CAUTION: Risk of product damage. Do not lift the whirlpool by the piping or pump, or use the

piping or pump for structural support of the whirlpool.

CAUTION: Risk of product damage. Do not support the whirlpool by the rim.

Choose the installation option that best applies to your particular installation. Follow the

appropriate instructions.

If the subﬂoor is not level, shim the whirlpool support blocks as necessary.

Option Using a Cement or Mortar Bed

NOTE: Do not use gypsum cement or drywall compound for this application, as they will not provide an

acceptable, durable bond.

NOTE: The pump support bracket (when the pump banding straps are cut) and support blocks must

rest directly on the subﬂoor.

Spread a 2″(5.1 cm) thick layer of cement or mortar on the subﬂoor where the whirlpool will be set.

This will help secure, level, and support the unit. Clear all the material away from the pump

support bracket and support block locations.

Position a piece of plastic drop cloth material on top of the cement or mortar bed. With help,

carefully lift the whirlpool into place, and make sure the pump support bracket and support blocks

do not rest in the bed material.

Insert the drain tailpiece into the trap. Make sure the whirlpool is level and resting on all support

blocks.

Remove the protective tape from the rim. Apply a continuous bead of high-quality silicone sealant

around the entire rim of the whirlpool.

Option Using Construction Adhesive

Apply a generous amount of high-quality construction adhesive to the bottom of the support blocks.

With help, carefully lift the whirlpool into position.

Position the rough

plumbing.

Frame the floor

according to the

roughing-in information.

Verify that the subfloor

offers adequate support,

and is flat and level.

Provide a 1/16" (2 mm) gap

between the whirlpool rim

and framing.

Construct 2x4 or 2x6

stud framing according

to the roughing-in

information.

1010564-2-H 6 Kohler Co.

Secure the Unit — Models With Support Blocks (cont.)

Insert the drain tailpiece into the trap. Make sure the whirlpool is level and resting on all support

blocks.

Remove the protective tape from the rim. Apply a continuous bead of high-quality silicone sealant

around the entire rim of the whirlpool.

Option Using Silicone Sealant

With help, carefully lift the whirlpool into position.

Insert the drain tailpiece into the trap. Make sure the whirlpool is level and resting on all support

blocks.

Remove the protective tape from the rim. Apply a continuous bead of high-quality silicone sealant

around the entire rim of the whirlpool.

Kohler Co. 7 1010564-2-H

4. Secure the Whirlpool to the Stud Framing

Option for Integral Flange Models

Drill a small pilot hole through the nailing-in ﬂange at each stud. Add shims between the nailing-in

ﬂange and the studs as needed to eliminate gaps.

Nail 1/4” (6 mm) thick furring strips to the studs to shim out to the edge of the nailing-in ﬂange.

Use #6 large-head galvanized nails to secure the nailing-in ﬂange to the studs.

For tile ledge installations, size and install a pressure-treated wood batten along the nailing-in

ﬂange. Pre-drill nail holes through the wood batten and nailing-in ﬂange before securing with

galvanized nails.

Nail 1/4" (6 mm) furring

strips to the studs.

Drill a small pilot

hole through the

nailing-in flange.

Use #6 large-head galvanized

nails to secure to the studs.

Install a pressure-treated wood

batten along the nailing-in flange.

Stud Framing

1010564-2-H 8 Kohler Co.

5. Secure the Unit — Models With Whirlpool Base

CAUTION: Risk of product damage. Do not lift the whirlpool by the piping or pump, or use the

piping or pump for structural support of the whirlpool.

CAUTION: Risk of product damage. Do not support the whirlpool by the rim.

Choose the installation option that best applies to your particular installation. Follow the

appropriate instructions.

If the subﬂoor is not level, shim the whirlpool base as necessary.

Option Using a Cement or Mortar Bed

NOTE: Do not use gypsum cement or drywall compound for this application, as they will not provide an

acceptable, durable bond.

Spread a 2″(5.1 cm) thick layer of cement or mortar on the subﬂoor where the whirlpool will be set.

This will help secure, level, and support the unit.

Position a piece of plastic drop cloth material on top of the cement or mortar bed. With help,

carefully lift the whirlpool into place.

Insert the drain tailpiece into the trap. Make sure the whirlpool is level. Use screws or lag bolts to

secure the whirlpool base to the ﬂoor. Drill small pilot holes through the whirlpool base as needed.

Remove the protective tape from the rim. Apply a continuous bead of high-quality silicone sealant

around the entire rim of the whirlpool.

Option Using Construction Adhesive

Apply a generous amount of high-quality construction adhesive to the bottom of the whirlpool base.

With help, carefully lift the whirlpool into position.

Insert the drain tailpiece into the trap. Make sure the whirlpool is level. Use screws or lag bolts to

secure the whirlpool base to the ﬂoor. Drill small pilot holes through the whirlpool base as needed.

Remove the protective tape from the rim. Apply a continuous bead of high-quality silicone sealant

around the entire rim of the whirlpool.

Option Using Silicone Sealant

With help, carefully lift the whirlpool into position.

Insert the drain tailpiece into the trap. Make sure the whirlpool is level. Use screws or lag bolts to

secure the whirlpool base to the ﬂoor. Drill small pilot holes through the whirlpool base as needed.

Remove the protective tape from the rim. Apply a continuous bead of high-quality silicone sealant

around the entire rim of the whirlpool.

Spread a 2" (5.1 cm) layer of

cement or mortar bed material.

Apply a bead of

silicone sealant

around the entire

rim.

Apply construction

adhesive to the

whirlpool base.

Kohler Co. 9 1010564-2-H

6. Cut the Pump Banding Straps

NOTE: If your pump model does not have banding straps, proceed to the next section.

IMPORTANT! This step is necessary to make your Kohler whirlpool operate more quietly.

NOTE: Do not raise the pump higher than it was before you cut the pump banding straps. If the pump is

raised too high, it will not prime properly.

Use tin snips to cut the two pump banding straps. When the banding straps are cut, the pump

support bracket and pump will drop about 1/2″(1.3 cm) until they rest on the subﬂoor. If the pump

drops more than 1/2″(1.3 cm), shim under the pump support bracket so there is a 1/2″(1.3 cm)

gap between the pump and bracket to allow for proper drainage.

To minimize whirlpool noise and vibration, be sure the pump is not in direct contact with the

shipping bracket after the pump banding straps are cut.

Secure the pump support bracket to the subﬂoor with screws or lag bolts (not provided).

7. Install the Plumbing

CAUTION: Risk of property damage. Ensure a watertight seal on the whirlpool drain.

Connect the drain to the trap according to the drain manufacturer’s instructions.

NOTICE: An access panel will simplify future maintenance.

Install the faucet valving according to the faucet manufacturer’s instructions. Do not install the

faucet trim until instructed. Open the hot and cold water supplies, and check the supply

connections for leakage.

Run water into the whirlpool, and check the drain connections for leakage.

Drainage Suction Line

Pump

Cut the pump

banding straps.

NOTE:

Pump model illustrated may differ from your

actual product.

1010564-2-H 10 Kohler Co.

Otros manuales para K-1106

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Bañera de Kohler

Kohler

Kohler K-1209P-LA Manual de usuario

Kohler

Kohler Underscore K-5716-GCR Manual de usuario

Kohler

Kohler K-11343 Guía de inicio rápido

Kohler

Kohler Lakewood K-1649 Instrucciones de montaje

Kohler

Kohler K-1111-H2 Guía de inicio rápido

Kohler

Kohler LOVEE K-9289T Manual de usuario

Kohler

Kohler K-1106 Manual de usuario

Kohler

Kohler Memoirs K-1418-G Guía del usuario

Kohler

Kohler K-513-H2 Guía de inicio rápido

Kohler

Kohler Underscore K-1969-H2-0 Instrucciones de montaje

Kohler

Kohler K-1114 Guía de inicio rápido

Kohler

Kohler Sterling 7111 Series Instrucciones de montaje

Kohler

Kohler K-1375-AH Instrucciones de montaje

Kohler

Kohler K-1122-GLA Guía de inicio rápido

Kohler

Kohler Iron Works Tellieur K-727 Instrucciones de montaje

Kohler

Kohler K-1113 Instrucciones de montaje

Kohler

Kohler VOLUTE K-20610T Manual de usuario

Kohler

Kohler K-1167-H2-0 Instrucciones de montaje

Kohler

Kohler K-874-H Manual de usuario

Kohler

Kohler Roughing-In K-1112-L Manual de usuario

Kohler

Kohler K-1158 Guía de inicio rápido

Kohler

Kohler K-1375-LM Instrucciones de montaje

Kohler

Kohler Underscore K-1167-XH2GR Guía del usuario

Kohler

Kohler K-514-H2 Instrucciones de montaje

Manuales populares de Bañera de otras marcas

Agua

Agua BARTOLI-66 Manual de usuario

PAA

PAA PRELUDE Manual de usuario

BETTE

BETTE SILHOUETTE Manual de usuario

American Standard

American Standard Whirlpool/Bathing Pool 2748.XXXW Manual de usuario

Oliveri

Oliveri Naples Manual de usuario

Lyons

Lyons Elite ETLxx663219 Series Manual de usuario

Woodbridge

Woodbridge BJ500 Instrucciones de montaje

Whirlpool

Whirlpool Ariel ARL-702 Manual de usuario

TEIKO

TEIKO EXCELLENT DUO Manual de usuario

American Standard

American Standard Colony 5-1/2' x 32" Manual de usuario

American Standard

American Standard 3052OD.X0X Guía de inicio rápido

agape

agape MARSIGLIA AVAS1075 Manual de usuario

Kallista

Kallista P50045-G5 Instrucciones de montaje

Ariel

Ariel AM Series Manual de usuario

Agua

Agua BAHLI-60 Manual de usuario

DURAVIT

DURAVIT XViu 700443 Manual de usuario

American Standard

American Standard Colony 2740 Series Manual de usuario

Rapsel

Rapsel OFURO Manual
