Kogan KAMN27FG6TA Manual de usuario

27” FULL HD 165Hz FREESYNC

GAMING MONITOR

(1920 x 1080)

KAMN27FG6TA

• Read all instructions before using the monitor and retain for future reference.

• Unplug the monitor before cleaning it.

• Use a clean, slightly dampened cloth to wipe the main monitor body.

• To c l e a n t h e s c r e e n , t u r n i t o f f u n p l u g i t a n d w a i t f o r i t to c o o l c o m p l e t e l y, t h e n w i p e

it with a dry micro-fibre cloth.

• Do not use cleaning alcohol, ammonia-based liquids or other harsh cleaners.

• This monitor is designed with ventilation holes on the back of the casing. Do not

cover or block them.

• Do not insert any object or spray any liquid into the vents.

• Avoid placing the monitor near heaters, stoves, fireplaces or other sources of heat.

• Place monitor in well ventilation room.

• Do not position the monitor in unsafe locations. If the monitor falls, it may be

damaged and may injure nearby people.

• Unplug the monitor if it is not going to be used for an extended period.

• Do not place heavy objects on the monitor, its power cord or any connected cable.

• Do not open the back panel of the monitor, as it contains a high-voltage current

even when not plugged in.

• Before disposing of any packaging, place all items on a soft, clean and flat surface

to ensure all components are accounted for.

The terms HDMI and HDMI High-Definition Multimedia

Interface and the HDMI Logos are trademarks or registered

trademarks of HDMI Licensing Administrator, Inc. in the

United States and other countries.

SAFETY & WARNINGS

Monitor

Stand bracket

Stand base

M4x20mm Screw (x2)

M4x12mm Screw

Power adapter

HDMI cable

User guide

OVERVIEW

LED indicator

Power input

Power button

HDMI

Exit button

HDMI

Down button

DisplayPort

Up button

Audio out (3.5mm jack)

Menu button

OVERVIEW

Before disposing of any packaging, place all items on a soft, clean and flat surface to

ensure all components are accounted for.

Monitor stand

1. Lay the monitor on a cloth with the LCD panel facing down to prevent it from being

damaged. Attach the stand bracket to monitor using the x2 M4x20 screws.

2. Attach the stand base to the stand bracket and secure it in place using the M4x12

screw.

ASSEMBLY

Monitor adjustment

The angle of the stand can be adjusted forward 5° and backwards 15° to achieve a

comfortable viewing experience.

Note: Take care not to touch the screen area when adjusting the angle of the monitor.

Before installing the VESA mount onto this monitor, ensure to the stand has been removed.

To ensure sufficient ventilation, Install the monitor at least 10 cm away from the wall and

leave approximately 10 cm of space at either side of the monitor.

1. Place a clean, dry and lint-free cloth on a flat, stable surface.

2. Gently lay the monitor on the cloth with the LCD screen facing down.

3. Identify the 4 mounting holes on the back of the monitor (Figure 1).

4. Assemble the VESA mount as per the instructions provided.

5. Ensure that all screws (not supplied) are tightened and secured properly.

VESA MOUNT

VESA mounting pattern 100 x 100mm, screw size M4.

Note:

VESA mount or mounting accessories are NOT included.

Figure 1

Power

1. Turn the PC and the monitor off before connecting them.

2. Connect the included power adapter to the monitor’s power input.

3. Connect the power adapter to the power outlet.

HDMI

Use the included HDMI cable to connect the monitor to your computer.

CONNECTIVITY

Power adapter

HDMI cable (included)

DisplayPort

Use a DisplayPort cable to connect the monitor to your computer.

Audio

1. Connect a 3.5mm audio cable to the audio out on the monitor.

2. Connect the audio cable to the 3.5mm port on your headphones or speakers.

Note: The monitor may need to be set as the PC’s default sound output device.

DP cable (not included)

Audio cable & headphones

(not included)
