INSTRUCTION MANUAL

ENGLISH

CL330

400A AC Auto-Ranging

Digital Clamp Meter

True RMS

Measurement

Technology

600V

400A

40M

• OLED DISPLAY

• AUTO-RANGING

• DATA HOLD

• RANGE HOLD

• TEMPERATURE

• BAR GRAPH

GENERAL SPECIFICATIONS

Klein Tools CL330 is an automatically ranging true root mean square

(TRMS) digital clamp meter that measures AC current via the clamp,

AC/DC voltage, resistance, continuity, frequency, capacitance, and

tests diodes via test-leads, and temperature via a thermocouple probe.

It features a reverse contrast OLED display that optimizes viewability

in dark or bright environments and when viewed at angles far away

from normal to the display.

• Operating Altitude: 6562 ft. (2000m)

• Relative Humidity: <95% non-condensing

• Operating Temp: 32°to 122°F (0°to 50°C)

• Storage Temp: 14°to 122°F (-10°to 50°C)

• Accuracy: Values stated at 65° to 83°F (18° to 28°C)

• Temp Coefcient: 0.1 x (Quoted Accuracy) per °C above

28°C or below 18°C, corrections are required when ambient

working temp is outside of Accuracy Temp range

• Dimensions: 8.66" x 3.03" x 1.61" (220 x 77 x 41 mm)

• Weight: 9.88 oz. (280 g) including batteries

• Battery Type: 3 x AAA alkaline

• Battery Life: 20 hours

• Calibration: Accurate for one year

• Standards: Conforms to UL STD. 61010-1,

61010-2-032 and 61010-2-033.

Certified to CSA STD. C22.2, NO. 61010-1,

61010-2-032 and 61010-2-033.

• Pollution degree: 2

• Accuracy: ± (% of reading + # of least significant digits)

• Drop Protection: 3.3 ft. (1m)

• Safety Rating: CATIII 600V, Class 2, Double insulation

CAT III: Measurement category III is applicable to test and

measuring circuits connected to the distribution part of the

building’s low-voltage MAINS installation.

• Electromagnetic Environment: IEC EN 61326-1. This

equipment meets requirements for use in basic and controlled

electromagnetic environments like residential properties,

business premises, and light-industrial locations.

ENGLISH

Test Equipment Depot - 800.517.8431

99 Washington Street Melrose, MA 02176

TestEquipmentDepot.com

ELECTRICAL SPECIFICATIONS

Function Range Resolution Accuracy

AC Voltage

(V AC)

4.000V 1mV ±(1.5% + 5 digits)

40.00V 10mV ±(1.2% + 5 digits)

400.0V 100mV

600V 1V ±(1.5% + 5 digits)

DC Voltage

(V DC)

400.0mV 0.1mV ±(1.0% + 8 digits)

4.000V 1mV

±(0.8% + 3 digits)40.00V 10mV

400.0V 100mV

600V 1V ±(1.0% + 3 digits)

Input Impedance: 10MΩ

Frequency Range: 45 to 400Hz

Maximum Input: 600V AC RMS or 600V DC

AC Current

(A AC)

4.000A 1mA ±(2.5% + 30 digits)

40.00A 10mA ±(2.5% + 10 digits)

400.0A 100mA ±(2.0% + 10 digits)

Frequency Range: 50 to 60Hz

Resistance

400.0Ω 0.1Ω ±(1.2% + 5 digits)

4.000kΩ 1Ω

±(1.2% + 3 digits)

40.00kΩ 10Ω

400.0kΩ 100Ω

4.000MΩ 1kΩ

40.00MΩ 10kΩ ±(2.0% + 5 digits)

Maximum Input: 600V AC RMS or 600V DC

OTHER MEASUREMENT APPLICATIONS

Maximum Input: 600V DC or 600V AC RMS

•Diode Test: Approx. 1mA, open circuit voltage ~3.0V DC

•Continuity Check: Audible signal <10Ω, max current 1.5mA

•Sampling Frequency: 3 samples per second

•Auto Power off: After 10 minutes of inactivity.

•Overload: "OL" indicated on display

•Polarity: "-" on display indicates negative polarity

•Display: 3-3/4 digit, 4000 Count, 128 x 64 pixel OLED display

ENGLISH

ELECTRICAL SPECIFICATIONS

Function Range Resolution Accuracy

Capacitance

40.00nF 0.010nF ±(4% + 25 digits)

400.0nF 0.100nF

±(4% + 8 digits)

4.000μF 0.001μF

40.00μF 0.010μF

400.0μF 0.100μF

4.000mF 0.001mF ±(10% + 9 digits)

Maximum Input: 600V AC RMS or 600V DC

Temperature

-40° to 104°F

°F

±(2.0% + 8 digits)

>104° to 932°F

°F ±(1.6% + 5 digits)

>932° to 1832°F

°F

±(2.0% + 2 digits)

-40° to 40°C

°C ±(2.0% + 4 digits)

>40° to 500°C

°C

±(1.5% + 3 digits)

>500° to 1000°C

°C ±(1.5% + 2 digits)

Frequency 10Hz to

1MHz

0.001Hz

to 1kHz ±(0.1% + 5 digits)

Duty Cycle

0.1% to 99.9%

(≤100kHz)

0.1% ±1.5%

(Range: 10% – 90%)

Sensitivity: 250mV and < 20V RMS

Maximum Input: 600V AC or 600V DC RMS

Test Equipment Depot - 800.517.8431

99 Washington Street Melrose, MA 02176

TestEquipmentDepot.com

WARNINGS

To ensure safe operation and service of the meter, follow these

instructions. Failure to observe these warnings can result in

severe injury or death.

• Before each use verify meter operation by measuring a known voltage

or current.

• Never use the meter on a circuit with voltages that exceed the

category based rating of this meter.

• Do not use the meter during electrical storms or in wet weather.

• Do not use the meter or test leads if they appear to be damaged.

• Use only with CAT III or CAT IV rated test leads.

• Ensure meter leads are fully seated, and keep fingers away from the

metal probe contacts when making measurements.

• Do not open the meter to replace batteries while the probes are connected.

• Use caution when working with voltages above 25V AC RMS or 60V

DC. Such voltages pose a shock hazard.

• To avoid false readings that can lead to electrical shock, replace

batteries when a low battery indicator appears.

• Do not attempt to measure resistance or continuity on a live circuit.

• Do not hold meter above hand & finger guard during use.

• Always adhere to local and national safety codes. Use personal

protective equipment to prevent shock and arc blast injury where

hazardous live conductors are exposed.

• Usage of this meter in any way other than that specified by the

manufacturer can impair safe operation, resulting in severe injury or death.

SYMBOLS ON METER

AC (Alternating Current)

AC/DC Voltage

Resistance (in Ohms) Audible Continuity

Double Insulated Class II Ground

Warning or Caution Risk of Electrical Shock

Diode Capacitance

Frequency

Duty-cycle

V Voltage (Volts) A Amperage (Amps)

Temperature (Fahrenheit / Celsius)

SYMBOLS ON DISPLAY

AC (Alternating Current) DC (Direct Current)

Negative Reading

Data Hold

Auto Auto Ranging MAX Maximum Value

MIN Minimum Value AVG Average Value

APO Auto Power Off Battery Strength Indicator

Audible Continuity Resistance Measurement

Degrees (Fahrenheit)

Degrees (Celsius)

Mega (value x 10

)

kilo (value x 10

)

milli (value x 10

-3

)

micro (value x 10

-6

)

nano (value x 10

-9

)

Volts

Amps Ohms

Hz/%

Frequency/Duty Cycle

MAX MIN

Max/Mix/Avg mode active

FEATURE DETAILS

ENGLISH

1. 4000 count OLED display 8. "MAX/MIN" button

2. Function selector switch 9. Data Hold button

3. Clamp 10.

Clamp trigger (press to open clamp)

4. "COM" jack 11. Arrow markings

5. "VΩ" jack 12. "SELECT" button

6. Display brightness button 13. Hand & finger guard

7. "RANGE" button

FUNCTION BUTTONS

ON/OFF

To power ON the meter, rotate the Function Selector switch

from

the OFF setting to any measurement setting. To power OFF the meter,

rotate the Function Selector switch

to the OFF setting. By default,

the meter will automatically power OFF after 10 minutes of inactivity.

If the meter automatically powers-OFF while in a measurement

setting, press any button (

) to power ON the

meter. To deactivate the power OFF functionality, press the Display

Brightness button

for more than one second while the meter is

powered on.

"SELECT" BUTTON (FOR SECONDARY FUNCTIONS)

The "SELECT" button

activates the secondary function for each

application accessible by the function selector switch

. For voltage,

it toggles between AC and DC. For the other functions, it switches

between °F and °C, between Hz and % Duty-cycle, and between

Continuity, Resistance, Capacitance and Diode-Test. The default

function for each application is printed on the meter in white; the

secondary function or functions for each setting is printed on the

meter in orange.

DISPLAY BRIGHTNESS

The OLED display can be operated at three different brightness levels

(low, medium, high). Press the Display Brightness button

to cycle

through and select the desired brightness.

DUAL DISPLAY LINES

The display has a primary and secondary display line. The primary

measurement is always displayed on the primary display line. When

measuring AC voltage, the measurement is displayed on the primary

display line, and the frequency is displayed on the secondary display

line.

NOTE:

When measuring at the lower extremes of a voltage

range (less than 10% of the range maximum, or below 100V for the

600V range), it may not be possible to measure frequency, which

may result in dashes on the display. In MAX/MIN mode, the primary

and secondary display lines are utilized as detailed in the MAX/MIN

section.

Secondary display line

Primary display line

Test Equipment Depot - 800.517.8431

99 Washington Street Melrose, MA 02176

TestEquipmentDepot.com

RANGE

The meter defaults to auto-ranging mode Auto. This mode

automatically determines the most appropriate measurement range

for the testing that is being conducted. To manually force the meter

to measure in a different range, use the "RANGE" button

1. Press the "RANGE" button

to manually select measurement

range (Auto is deactivated on the display). Repeatedly press the

"RANGE" button

to cycle through the available ranges, stopping

once the desired range is reached.

2. To return to auto-ranging mode, press and hold the "RANGE"

button

for more than one second (Auto is reactivated).

MAX/MIN

When the "MAX/MIN" button

is pressed, the meter keeps track of

the Maximum, Minimum and Average values as the meter continues

to take samples.

1. When measuring, press "MAX/MIN" button

to display the

Max value on the primary display line. MAXMIN and Max will

be shown on the display. Pressing "MAX/MIN"

will toggle

between the Maximum (Max), the Minimum (Min), and the

Average (Avg) values. The active measurement continually

updates on the secondary display line in this mode. If a new

maximum or minimum occurs, the display updates with that

new value. The average value continues to update as the meter

continues to take samples.

2. Press "MAX/MIN" button

for more than one second to return to

normal measuring mode.

DATA HOLD

Press HOLD

to hold the measurement on the display. Press

HOLD

again to release the display to return to live measuring.

FUNCTION BUTTONS

ENGLISH

OPERATING INSTRUCTIONS

CONNECTING TEST LEADS

Do not test if leads are improperly seated. Results could cause

intermittent display readings. To ensure proper connection, firmly

press leads into the input jack completely.

TESTING IN CAT III / CAT IV MEASUREMENT LOCATIONS

Ensure the test lead shield is pressed firmly in place. Failure to use

the CATIII / CATIV shield increases arc-flash risk.

TESTING IN CAT II MEASUREMENT LOCATIONS

CAT III / CAT IV shields may be removed for CAT II locations. This

will allow testing on recessed conductors such as standard wall

outlets. Take care not to lose the shields.

5/32"

(4 mm)

.7" (18 mm)

INCORRECT

CORRECT

Replacement test leads must have a minimum rating of

CATIII 1000V, 10A.

ENGLISH

OPERATING INSTRUCTIONS

AC CURRENT (LESS THAN 400A)

AC Current is measured by pressing the clamp trigger

to open

the clamp and placing it around a current-carrying wire. When

measuring, care should be taken to ensure that the clamp is

completely closed with trigger

fully released, and that the wire

passes perpendicularly through the center of the clamp in line with

the arrow markings

To measure current:

1. Rotate the Function Selector switch

to the 400 A setting.

2. Place clamp around wire. The current measurement will be shown

in the display.

NOTE: If the measurement is less than 40A, rotate the Function

Selector switch

to the 40 A setting for improved resolution. If the

measurement is less than 4A, rotate the Function Selector switch

to the 4 A setting for improved resolution.

Disconnect test leads when measuring with the clamp.

WIRE

Tabla de contenidos

Otros manuales de Instrumento de medición de Klein Tools

Klein Tools

Klein Tools 501-915 Manual de usuario

Klein Tools

Klein Tools MM1300 Manual de usuario

Klein Tools

Klein Tools CL800E Manual de usuario

Klein Tools

Klein Tools CL320 Manual de usuario

Klein Tools

Klein Tools ET180 Manual de usuario

Klein Tools

Klein Tools Ranger TDR VDV501-090 Manual de usuario

Klein Tools

Klein Tools VDV500-705 Manual de usuario

Klein Tools

Klein Tools CL360 Manual de usuario

Klein Tools

Klein Tools CL2500 Manual de usuario

Klein Tools

Klein Tools CL700 Manual de usuario

Klein Tools

Klein Tools CL310 Manual de usuario

Klein Tools

Klein Tools Toner-Pro VDV500-123 Manual de usuario

Klein Tools

Klein Tools CL600 Manual de usuario

Klein Tools

Klein Tools 93LDM65 Manual de usuario

Klein Tools

Klein Tools ET920 Manual de usuario

Klein Tools

Klein Tools MM2000 Manual de usuario

Klein Tools

Klein Tools CL320 Manual de usuario

Klein Tools

Klein Tools CL900 Manual de usuario

Klein Tools

Klein Tools 501-915 Manual de usuario

Klein Tools

Klein Tools CL120KIT Manual de usuario

Klein Tools

Klein Tools CL110 Manual de usuario

Klein Tools

Klein Tools ET900 Manual de usuario

Klein Tools

Klein Tools CL120 Manual de usuario

Klein Tools

Klein Tools CL800 Manual de usuario

Manuales populares de Instrumento de medición de otras marcas

Suaoki

Suaoki D40 Manual de usuario

Elster

Elster BK-G1.6 Manual de usuario

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manual

Duratool

Duratool D03128 Manual de usuario

Vega

Vega VEGAPULS 65 Manual de usuario

Tonghui

Tonghui TH2618B Manual de usuario

Tenmars

Tenmars TM-801 Manual de usuario

MSR

MSR 145 Manual de usuario

TPS

TPS WP-82 Manual de usuario

ELMETRON

ELMETRON CP-511 Manual de usuario

PCB Piezotronics

PCB Piezotronics 003C30 Manual de usuario

Tenma

Tenma 72-10465 Manual de usuario

Endress+Hauser

Endress+Hauser Proline Promag 50 Especificaciones técnicas

Siemens

Siemens SITRANS F Coriolis FCT030 Manual de lista de piezas

KLINGER

KLINGER CMF V Series Manual de usuario

EXFO

EXFO FTB-2 Manual de operación y mantenimiento

Keysight

Keysight M8290A Manual de usuario

ADTEK

ADTEK MW-5 Manual de usuario
