KING CANOPY G0712 Manual de usuario
Storage Garage 7.5 ft x 12 ft
7 ft 7 in Wide x 12 ft Deep x 6 ft 1 in Side Height /
7 ft 8 in Center Height
King Canopy Item # G0712
With 6 Legs, 1 Pc. Cover, 1 Zippered Front Wall,
Elastic Ball Straps, Foot Pads and Stakes.
WARNING:
Keep all ame and heat sources
away from this tent fabric. It is not
re proof. The fabric will burn if
left in continuous contact with
any ame source.
These Tools Are
Recommended:
www.northlineexpress.com
1-877-734-2458
PARTS LIST
5X9-15PC
(16) 69 Inch Pipe
3X0-15PC
(6) 36 Inch Pipe
3W16PC
(6) 3-Way Fittings
4W16PC
(3) 4-Way Fittings
FOOT16PC-SL
(6) Metal Foot Pads
STAKE-GAR
(12) Foot Pad Stakes
T0712SF-GAR
(1) Cover with Rear Wall & Side Walls
T07SEWZF-GAR
(1) Zippered Front Wall
BALL
(35) Elastic Ball Straps
SC15
(4) Single Side Pipe Clamps
DC15
(2) Double Side Pipe Clamps
www.northlineexpress.com
1-877-734-2458
ROOF FRAME ASSEMBLY
1- Start assembly with top frame as shown Diagram A
in Diagram A. The 36 inch pipes are
used for the roof rafters and 69 inch
pipes form the length of frame. Start
assembly with center peak as circled
in Diagram A.
Diagram B
Diagram C
36 Inch Pipe
69 Inch Pipe
2- Once you have assembled the roof frame,
insert the legs on one side using the
69 inch pipes with the foot pads installed.
69 Inch Pipe
3- With the top frame laying over on one side
and the legs inserted on the other side as seen in
Diagram B, drape the one piece cover with
sides and rear wall over the frame.
Make sure you have the open end in
the direction needed. Pull the one side
down over the frame with the legs
inserted. You can also pull the rear
over the frame partially. Next, insert
the legs on the opposite side and pull the
remainder of the cover on.
Foot Pad
Front
Side
www.northlineexpress.com
1-877-734-2458
COVER ASSEMBLY
PICTURE-1
PICTURE-3
ATTACH BALL STRAPS
With frame assembled and cover on, you can now attach cover
to frame using the ball straps. The grommet holes on the cover
for attaching straps are located along the back and front frame
line. Picture # 1 indicates where to nd grommet holes. Attach
the cover by running the strap through the grommet hole,
around the pipe, then loop the strap over the ball. If the straps
are too long for a tight t, you can double wrap them or make an
additional knot in the strap cord to shorten them.
To install side rails and wall support, slide a 69 inch pipe into the
sleeves at the bottom of the side walls, as shown in picture # 2.
Use double side clamp to connect to center leg and single side
clamp to connect to corner legs. (See pictures below.)
Your storage shelter can be used with or without the front
zipped wall. If you choose to use your front wall, install it with
the velcro strips and ball straps through the grommet holes,
then attach it with velcro enclosures as seen in picture # 3. The
wall can be removed quickly and easily at anytime.The front wall
has a zippered door that rolls up to gain access and closes for
storage. The sides and ends are extra long and can be buried in
the ground or use rock, stone or brick over them to help keep
unwanted creatures out. (See pictures below.)
Corner leg Corner leg PICTURE-2
Center leg
www.northlineexpress.com
1-877-734-2458
ANCHORING YOUR UNIT
This canopy is designed for use as a temporary structure. After assembly, the canopy MUST BE securely
anchored to the ground to prevent damage from winds. Your canopy will act like a kite in the wind if not
properly and securely anchored to the ground. Severe winds will cause the frame to twist and unanchored
legs will fall, thereby collapsing the canopy. If severe winds are expected, you must remove the cover from
the frame to prevent damage.
We recommend anchoring your canopy at each corner foot
and center foot on each side. Screw anchor into ground
next to canopy foot using a large screw driver (1). Tilting the
anchor slightly will help the anchor to cut into the ground.
Apply downward pressure while turning the anchor into the
ground. Leave approximately three inches of anchor out of
the ground.
TieRope(2) aroundthepipe,andthenbackthroughtheanchor
eye. Pull as tight as possible and secure. Anchor kits available
online at www.kingcanopy.com or call customer service at
1-800-800-6296 and ask about purchasing our 6-peice anchor
kit, item #A6200. ANCHOR KIT SOLD SEPARATELY
(1)
ANCHORS ARE NOT INCLUDED
(2)
www.northlineexpress.com
1-877-734-2458
IMPORTANT NOTICE: PLEASE READ CAREFULLY
We are condent that you will be completely satised with your King Canopy unit. Please take a moment
to read the very important information below, and call us with any questions you may have.
King Canopy/PIC America, LTD. has no control over wind, snow, ice, rain or any other weather condition and
we are in no way responsible for any damage caused by the canopy or to the canopy. We suggest you contact
your insurance carrier just as you would for any other outside structure.
OTHER PRECAUTIONS WHICH MUST BE FOLLOWED:
Keep all ame and heat sources away from this tent fabric. The tent fabric will burn if left in continuous
contact with any ame source.
DO NOT cook underneath or near canopy.
DO NOT store or use ammable liquids underneath or near canopy.
DO NOT ignite or store reworks underneath or near canopy.
DO NOT use bleach to clean cover.
DO NOT dry clean cover.
DO NOT wash cover in washing machine or dry in dryer. Hand wash with mild soap and water only.
DO NOT allow rain water, snow or ice to accumulate on top of cover.
DO NOT hang or suspend anything from the frame, grommets, truss system or ball straps of the unit.
REMOVE canopy cover before a storm, or disassemble entire canopy unit if possible.
REMOVE rain water, snow and ice from canopy cover.
This is a temporary structure and is not recommended for use as a permanent structure.
www.northlineexpress.com
1-877-734-2458
PRODUCT INFORMATION
Defective Parts
We try our best to eliminate any defective parts that are shipped with our products. If, however, you should nd
a defective part, we will replace – free of charge – any part which is defective. You will need to provide proof
of purchase showing date of purchase and provide us with detailed description of the defective component.
Your replacement will be shipped by ground shipping, freight prepaid. Next day or express shipping will
require freight collect and paid for by you, the consumer. Damages from improper anchoring, strong winds,
snow, ice or rain are not considered defects.
Improper Anchoring, Strong Winds, Rain Snow, or Ice
King Canopy/PIC America, LTD. does not guarantee these canopies under strong weather conditions. These
canopiesaredesigned toprotectagainst damages caused by sun, rain,treesap,birds,etc. Theyarenot designed
to hold roof loads that accompany snow, ice or heavy rains. If your canopy is not anchored securely, it can be
lifted by the wind and will y away. If your canopy takes ight, we are not responsible for any replacement. If
you know strong weather is predicted, remove the cover or take down the canopy unit completely. The cover
is designed to be quickly and easily removed.
Warranty
All components of this canopy feature a 1-year limited warranty and are warranted to be free from defects in
material and workmanship for a period of 1-year. You must complete and return the enclosed warranty card
promptly after purchase. Please retain your proof of purchase receipt; you will be asked to provide this receipt
in order to obtain warranty service.
Non-Warranty Replacement Parts
If after expiration of the warranty period, you require replacement parts please contact us at 1-800-800-6296.
We stock replacement parts and make them available to you at discounted prices. Our customer service
department will be pleased to assist you in any way possible.
Certain regions of the country are extremely hard on covers of any kind. Normal wear and tear is not covered
under the warranty, and should be expected.
In order to receive a discounted or free replacement part, you may be asked to return the part, freight prepaid,
to our warehouse for inspection before we will send a replacement. You must, in all cases, provide a copy of
your receipt showing the date of purchase, model number and price.
