Keysight Technologies N7015A Manual de usuario

N7015A Type-C High Speed Test Fixture Kit

Quick Start and Accessories Guide

N7015A Kit

Standard

Contents

Optional Accessories Included in the N7015A Kit if Ordered with the Kit

N7015A - 016 Option:

Type-C Low Speed Signal Access and Control Fixture

N7015A - 017 Option:

Type-C Receptacle Adapter

(2110-0623)

Replacement Fuses

(Qty. 4)

Power Supply Plug

Connector

(0360-2693)

Wrench

(8710-2803)

Type-C High

Speed Test Fixture

(8121-1242)

USB Cable

(N7016A)

Low Speed Fixture N7017A Adapter

Other Keysight Type-C Product(s) for use with N7015A

(sold separately)

N7018A Type-C

Test Controller

N7015-92002, September 2017

Power on the N7016A / N7018A fixture

by connecting it to the Infiniium

Oscilloscope using the

supplied USB cable

Connection Steps:

Prerequisites:

Download the Keysight USB Type-C Connectivity Solution User Guide from www.keysight.com/find/N7015A.

If you are using N7015A with N7016A: Download and install the Keysight N7015A/6A Type-C Interconnect Assembly software from www.keysight.com/find/N7015A.

If you are using N7015A with N7018A: Download and install the Keysight N7018A Type-C Test Controller software from www.keysight.com/find/N7018A.

Connect N7015A to

N7018A or N7016A using

the N7015A Type-C interface

cable. Keep the red dot on

the cable facing up to ensure

proper signal identification

Connect the 2.92 mm connectors of the

N7015A to channel 1 and 3 of the Infiniium

oscilloscope using the supplied wrench and

an 8”-lb torque wrench (8710-1765)

Connect the N7015A

fixture to the Device

Under Test

N7015A TYPE-C TEST FIXTURE SETUP

*N7015-92002*

N7015A setup with

N7018A Type-C Test Controller

N7015A setup with N7016A

Type-C Low Speed Fixture

For more information: Visit http://www.keysight.com/find/type-c

CAUTION: Minimize twisting of the N7015A cables while connecting these to the oscilloscope or the N7018A / N7016A test fixture.

It is recommended that you use the N7015A with the N7018A Type-C Test Controller as the N7018A is a superset of most of the features of the N7016A and

additionally provides power delivery controller capabilities and integrated testing over Type-C interfaces through a single connection.
