Configuration and

Measurement Instructions

Keysight M9710A High-Speed

Digitizers Hardware Extension of

89600 VSA Software

Notices

No part of this manual may be reproduced

in any form or by any means (including

electronic storage and retrieval or

translation into a foreign language)

without prior agreement and written

consent from Keysight Technologies, Inc.

as governed by United States and

international copyright laws.

Manual Part Number

M9710-90003

Published By

Keysight Technologies

Chemin des Aulx, 12

1228 Plan-Les-Ouates

Switzerland

Edition

Edition 1, February, 2017

Regulatory Compliance

This product has been designed and

tested in accordance with accepted

industry standards, and has been

supplied in a safe condition. To review the

Declaration of Conformity, go to

http://www.keysight.com/go/conformity.

Warranty

THE MATERIAL CONTAINED IN THIS

DOCUMENT IS PROVIDED “AS IS,” AND IS

SUBJECT TO BEING CHANGED, WITHOUT

NOTICE, IN FUTURE EDITIONS. FURTHER,

TO THE MAXIMUM EXTENT PERMITTED

BY APPLICABLE LAW, KEYSIGHT

DISCLAIMS ALL WARRANTIES, EITHER

EXPRESS OR IMPLIED, WITH REGARD TO

THIS MANUAL AND ANY INFORMATION

CONTAINED HEREIN, INCLUDING BUT

NOT LIMITED TO THE IMPLIED

WARRANTIES OF MERCHANTABILITY

AND FITNESS FOR A PARTICULAR

PURPOSE. KEYSIGHT SHALL NOT BE

LIABLE FOR ERRORS OR FOR

INCIDENTAL OR CONSEQUENTIAL

DAMAGES IN CONNECTION WITH THE

FURNISHING, USE, OR PERFORMANCE

OF THIS DOCUMENT OR OF ANY

INFORMATION CONTAINED HEREIN.

SHOULD KEYSIGHT AND THE USER HAVE

A SEPARATE WRITTEN AGREEMENT

WITH WARRANTY TERMS COVERING

THE MATERIAL IN THIS DOCUMENT THAT

CONFLICT WITH THESE TERMS, THE

WARRANTY TERMS IN THE SEPARATE

AGREEMENT SHALL CONTROL.

KEYSIGHT TECHNOLOGIES DOES NOT

WARRANT THIRD-PARTY SYSTEM-LEVEL

(COMBINATION OF CHASSIS,

CONTROLLERS, MODULES, ETC.)

PERFORMANCE, SAFETY, OR

REGULATORY COMPLIANCE, UNLESS

SPECIFICALLY STATED.

Technology Licenses

The hardware and/or software described

in this document are furnished under a

license and may be used or copied only in

accordance with the terms of such license.

U.S. Government Rights

The Software is “commercial computer

software,” as defined by Federal

Acquisition Regulation (“FAR”) 2.101.

Pursuant to FAR 12.212 and 27.405-3 and

Department of Defense FAR Supplement

(“DFARS”) 227.7202, the U.S. government

acquires commercial computer software

under the same terms by which the

software is customarily provided to the

public. Accordingly, Keysight provides the

Software to U.S. government customers

under its standard commercial license,

which is embodied in its End User License

Agreement (EULA), a copy of which can

be found at

http://www.keysight.com/find/sweula. The

license set forth in the EULA represents

the exclusive authority by which the U.S.

government may use, modify, distribute,

or disclose the Software. The EULA and

the license set forth therein, does not

require or permit, among other things,

that Keysight: (1) Furnish technical

information related to commercial

computer software or commercial

computer software documentation that is

not customarily provided to the public; or

(2) Relinquish to, or otherwise provide, the

government rights in excess of these

rights customarily provided to the public

to use, modify, reproduce, release,

perform, display, or disclose commercial

computer software or commercial

computer software documentation. No

additional government requirements

beyond those set forth in the EULA shall

apply, except to the extent that those

terms, rights, or licenses are explicitly

required from all providers of commercial

computer software pursuant to the FAR

and the DFARS and are set forth

specifically in writing elsewhere in the

EULA. Keysight shall be under no

obligation to update, revise or otherwise

modify the Software. With respect to any

technical data as defined by FAR 2.101,

pursuant to FAR 12.211 and 27.404.2 and

DFARS 227.7102, the U.S. government

acquires no greater than Limited Rights as

defined in FAR 27.401 or DFAR 227.7103-5

(c), as applicable in any technical data.

Safety Information

Please refer to the Startup Guide or User

Manual which was delivered with your

product for safety information.

Sales and Technical Support

To contact Keysight for sales and technical

support, refer to the “support” links on the

following Keysight web resources:

www.keysight.com/find/digitizer

www.keysight.com/find/assist (worldwide

contact information for repair and service).

Information on preventing damage to your

Keysight equipment can be found at

www.keysight.com/find/tips.

Introduction

M9710A Hardware Extension of 89600 VSA Software 3

Introduction

The 89600 VSA software (89601B) supports the Keysight M9710A High-Speed

Digitizer. This VSA measurement hardware configuration offers broadband vector

signal analyzer capabilities. The maximum analysis bandwidth is model dependent.

Model Option Maximum Span (Analysis Bandwidth)

M9710A -SR4 1.953 GHz (2.5 GHz in interleaved mode)

The present document aims to describe how to configure and use VSA software with

Keysight High-Speed Digitizers.

For details about VSA 89600 software usage, please refer to VSA software help

(http://rfmw.em.keysight.com/wireless/helpfiles/89600B/WebHelp/89600.htm).

The Vector Signal Analysis Basics application note gives detailed information about

VSA analysis theory (http://cp.literature.agilent.com/litweb/pdf/5989-1121EN.pdf).

Software installation

The latest VSA (89601B) software version can be downloaded from

http://www.keysight.com/find/VSA.

The support of M9710A digitizer also requires installing a plugin so that VSA can

recognize this hardware. This MD2 Hardware Extension for VSA software can be

accessed from following link:

MD2 Digitizers Hardware Extension for 89600 VSA Software

or found from M9710A product page (www.keysight.com/find/M9710A) > Technical

Support > Drivers, Firmware, and Software.

Once downloaded, execute MD2DigitizersHwExt_Setup-<versions>.exe and follow

the installation process.

VSA (89601B) gets updated frequently to support new hardware.

You must reinstall the above plugin anytime you upgrade the VSA

software version.

Checking if your hardware is included in VSA’s extension manager

Start > All Programs > VSA Extension Manager

Look for your hardware at the bottom, if not listed, then install the hardware extension

as described above.

4 M9710A Hardware Extension of 89600 VSA Software

Software installation

M9710A Hardware Extension of 89600 VSA Software 5

Updating MD2 Digitizer Hardware Extension after the installation of a

new 89600 VSA Software version

When updating your 89600 VSA Software version, the MD2 Digitizer Hardware

Extension has to be re-installed.

There are two solutions:

Option 1

From Windows> Control Panel > Programs > Programs and Features, select and right

click on Keysight MD2 Digitizers Extension of Keysight 89600 VSA.

And select Change.

The InstallShield Wizard opens.

Select Repair and click Next.

This automatically installs the MD2 Digitizers Hardware Extension in the new 89600

VSA Software version.

Software installation

Option 2

There is a tool allowing to install/desinstall the MD2 Digitizers Hardware Extension

on all of the different VSA versions installed in the system.

In order to proceed, execute:

C:\Program Files\Keysight\MD2\89600 VSA

Connectivity\MD2Digitizers\89600VSAIntegration.exe (or using your installation

path)

Follow the installation process.

Click OK.

The installation of the MD2 Digitizers Hardware Extension in the new 89600 VSA

Software version is now completed.

6 M9710A Hardware Extension of 89600 VSA Software

89600 VSA Software Configuration

M9710A Hardware Extension of 89600 VSA Software 7

89600 VSA Software Configuration

Configuring the 89600 VSA software application to use the

digitizer hardware

Create a configuration for Keysight M9710A digitizer

1. Start the 89600 VSA software application.

2. Configure the digitizer as the VSA measurement input by creating an 'Analyzer

Configuration' that uses your digitizer as the Logical Instrument (ADC) by per-

forming the following steps:

a. From the menu, go to Utilities >Hardware >Configurations, and click on

Add New Configuration button ( ). The 'New Hardware Configuration'

dialog opens.

b. De-select 'Simulate Hardware' if it is selected (1).

c. Select Keysight MD2 digitizers(2) from the list of 'Possible Logical Instru-

ment' and drag it or click on the button (3) to add it to the 'Con-

figuration' box .

89600 VSA Software Configuration

d. In the box below, ensure that the digitizer appears as the 'ADC' entry,

and if you have more than one digitizer connected - select the required

unit using the drop-down list (4).

e. You may either use the default name or specify another name for this ana-

lyzer configuration (5).

f. Click OK to close the 'New Hardware Configuration' dialog (6).

g. Before closing the 'Hardware Configurations' dialog, use the Current

Analyzer Configuration drop-down to select the newly created as the

current item ( Digitizer1 in the exemple below).

8 M9710A Hardware Extension of 89600 VSA Software

89600 VSA Software Configuration

M9710A Hardware Extension of 89600 VSA Software 9

Options and settings specific to high-speed digitizers

For specific acquisition modes, you may need to use high-speed digitizer specific

settings. These settings are available throught the digitizer hadware extension, and

can be managed from: Input > Extensions.

Calibration equalization: Enabling equalization improves the frequency

response and compensates for signal distortion. Four modes are available:

Off: No equalization(default)

Smooth roll off: minimizes the overshoot and ringing.

Sharp roll off: optimizes the frequency response flatness.

Custom: By default, Custom Equalization is equivalent to Equalization

Off.To Enable a custom equalization, please contact factory:

digitizers@keysight.com.

ControlIO1 signal: The digitizer supports multi-purposes IOs. This option allows

to select the signal used for the ControlIO1. For details about the possible sig-

nals, please refer to the User manual of your digitizer, section Multi-Purpose

Inputs and Outputs.

Enable external clock: See External Clock (page 12)

Enable interleaving: See Interleaved Mode (page 11)

Error on overrange: By default, if an overrange condition occurs on the ADC

inputs, the driver returns an error. Disabling this option disables the overrange

detection.

89600 VSA Software Configuration

External clock frequency: See External Clock (page 12)

Force Software DDC:This option is relevant only for digitizer products offering

hardware DDC and in not supported with M9710A.

MD2 Auto Calibration: See Calibration (page 10)

Multiboard synchronization:This feature is not supported with M9710A digit-

izer.

Calibration

By default 89600 VSA software automatically detects when a change of parameter

requires a new calibration of the digitizer module. This requirement is indicated on the

bottom right of the screen.

When a calibration is needed, user can either launch it from Utilities > Calibration or

by clicking on CAL: Needed .

It is possible to let the digitizer automatically performs a selfcalibration when required

by a change of the acquisition or digitizer parameter. To proceed, you have to enable

the option MD2 Auto Calibration from Input > Extensions window, then to manually

start the calibration once. The following calibrations will be automatic.

However, the MD2 Auto Calibration mode is not recommended when you are

modifying several parameters, since it can be time consuming to perform a calibration

after each parameter change, especially for multi-channel digitizer.

Multi-Channel Measurements

When using the Keysight High Speed Digitizers in VSA configuration, the digitizer

forms the measurement front-end data acquisition hardware for the 89600 VSA

software.

The M9710A digitizer supports single channel I+jQ, and cross channel measurement

configurations.

The M9710A also supports 2 channels Dual I + jQ.

10 M9710A Hardware Extension of 89600 VSA Software

Tabla de contenidos

Otros manuales de Instrumento de medición de Keysight Technologies

Keysight Technologies

Keysight Technologies N9030B Manual de usuario

Keysight Technologies

Keysight Technologies B1500A Manual de instrucciones

Keysight Technologies

Keysight Technologies E5061B Manual de usuario

Keysight Technologies

Keysight Technologies U1701B Manual de usuario

Keysight Technologies

Keysight Technologies N9340B Manual de usuario

Keysight Technologies

Keysight Technologies N5290/1A PNA Series Manual de usuario

Keysight Technologies

Keysight Technologies U5303A Guía del usuario

Keysight Technologies

Keysight Technologies N8262A P Series Manual de usuario

Keysight Technologies

Keysight Technologies P5000A Series Manual de usuario

Keysight Technologies

Keysight Technologies U1401B Manual de usuario

Keysight Technologies

Keysight Technologies FieldFox N9927-90002 Manual de usuario

Keysight Technologies

Keysight Technologies U9361F Manual de usuario

Keysight Technologies

Keysight Technologies U4205A Manual de usuario

Keysight Technologies

Keysight Technologies B2900A Series Manual de usuario

Keysight Technologies

Keysight Technologies B2980A Series Guía de instalación

Keysight Technologies

Keysight Technologies N9000B Manual de instalación y operación

Keysight Technologies

Keysight Technologies E4980A Manual de usuario

Keysight Technologies

Keysight Technologies N9000A Manual de instalación y operación

Keysight Technologies

Keysight Technologies BT2152B Manual de servicio

Keysight Technologies

Keysight Technologies LTE Manual de instalación

Keysight Technologies

Keysight Technologies E5072A Manual de usuario

Keysight Technologies

Keysight Technologies UXA N9040B Manual de instalación y operación

Keysight Technologies

Keysight Technologies N5511A-K26 Manual de usuario

Keysight Technologies

Keysight Technologies N9030B Manual de instalación y operación

Manuales populares de Instrumento de medición de otras marcas

Suaoki

Suaoki D40 Manual de usuario

Elster

Elster BK-G1.6 Manual de usuario

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manual

Duratool

Duratool D03128 Manual de usuario

Vega

Vega VEGAPULS 65 Manual de usuario

Tonghui

Tonghui TH2618B Manual de usuario

Tenmars

Tenmars TM-801 Manual de usuario

MSR

MSR 145 Manual de usuario

TPS

TPS WP-82 Manual de usuario

ELMETRON

ELMETRON CP-511 Manual de usuario

PCB Piezotronics

PCB Piezotronics 003C30 Manual de usuario

Tenma

Tenma 72-10465 Manual de usuario

Endress+Hauser

Endress+Hauser Proline Promag 50 Especificaciones técnicas

Siemens

Siemens SITRANS F Coriolis FCT030 Manual de lista de piezas

KLINGER

KLINGER CMF V Series Manual de usuario

EXFO

EXFO FTB-2 Manual de operación y mantenimiento

Keysight

Keysight M8290A Manual de usuario

ADTEK

ADTEK MW-5 Manual de usuario
