Verified Network Switch Guide
For use with Key Digital AV over IP Systems

IMPORTANT: Configure your network switch according to this guide BEFORE connecting your AV over IP units.

Introduction Pg. 2
Key Digital Supported AV over IP Models Pg. 2
System Facts Pg. 3
Network Switch Requirements for KD AV over IP Pg. 4
Verified Network Switches Table Pg. 5
Araknis Verified Switch Model List
Araknis Setup for 1080p Systems Pg. 9
Araknis Setup for 4K Systems Pg. 12
Cisco Verified Switch Model List
Cisco Meraki Series Pg. 16
Cisco SG / SF Series Pg. 17
Cisco Catalyst Setup for 4K Systems Pg. 24
D-Link Verified Switch Model List
D-Link Setup for 4K and 1080p Systems Pg. 35
Edgecore Verified Switch Model List
Edgecore AS4610-54T / Cumulus Linux version 3.7.15 Pg. 42
Engenius Verified Switch Model List
Engenius IGMP Setup for 1080p Systems Pg. 43
Linksys Verified Switch Model List
Linksys IGMP Setup for LGS***MPC models (Legacy) Pg. 47
Linksys IGMP Setup for 1080p Systems (Legacy) Pg. 51
Linksys IGMP Setup for 4K Systems (Legacy) Pg. 57
Luxul Verified Switch Model List
Luxul IGMP Setup for 4K and 1080p Systems Pg. 65
Netgear Verified Switch Model List
Netgear AV Series Network Switches Pg. 71
Netgear IGMP Setup for 4K and 1080p Systems Pg. 74
Niveo Verified Switch Model List
Niveo NGS Series IGMP Setup for 4K systems Pg. 79
Pakedge Verified Switch Model List
Pakedge S3 IGMP Setup for 4K and 1080p Systems Pg. 83
Pakedge SX Series IGMP Setup for 4K and 1080p Systems Pg. 89
Signamax Verified Switch Model List
Signamax SC-300 Series IGMP Setup for 4K systems Pg. 94
Titan Networx Verified Switch Model List
Titan Networx IGMP Setup for 1080p Systems Pg. 99
TP Link Verified Switch Model List
TP Link for 4K Systems Pg. 106
Wifi Router Setup and Requirements Pg. 116


2 | P a g e

Introduction

Thank you for purchasing a Key Digital AV over IP system.

Follow the instructions in this guide to enable the features for a reliable foundation for your AVoIP system.

Your AV over IP system MUST be integrated with one these verified network switches to function.

Network Switch setup may be different for 4K (KD-IP922, KD-IP822, KD-IP1022) and 1080p (KD-IP1080, KD-IP120)

systems. There are separate setup instructions for each where applicable.

Key Digital AV over IP Supported Models:

•4K Systems:

oKD-IP922ENC, KD-IP922DEC

oKD-IP822ENC, KD-IP822DEC

oKD-IP1022ENC, KD-IP1022DEC

•1080p Systems:

oKD-IP1080Tx, KD-IP1080Rx

oKD-IP120Tx, KD-IP120Rx, KD-IP120POETx, KD-IP120POERx

Key Digital’s AV over IP product family consists of many different models. Not all models are compatible together.

See Key Digital AV over IP Selection Guide for more info

3 | P a g e

System Facts

4K Systems: KD-IP822, KD-IP922, KD-IP1022 models

•Video Compression Standard: Motion JPEG 2000

•Data Stream Bandwidth: < 900 Mbps

Stream Resolution

Bandwidth

4K @ 60Hz/30Hz

≤ 850 Mbps

1080p @ 60Hz

≤ 250 Mbps

1080i / 720p @ 60Hz

≤ 125 Mbps

•Latency: ≈ 40ms @4K. Less at lower resolutions.

•PoE Power Consumption: ≤ 9 Watts per unit

•Required network cabling: CAT6 UTP/STP, CAT6A, CAT7

1080p Systems: KD-IP1080, KD-IP120 models

•Video Compression Standard: H.264

•Data Stream Bandwidth: < 15 Mbps

Stream Resolution

Bandwidth

1080p @ 60Hz

≤ 15 Mbps

1080i / 720p @ 60Hz

≤ 12 Mbps

480p @ 60Hz

≤ 4 Mbps

•Latency: ≈ 400ms @1080p. Less at lower resolutions.

•PoE Power Consumption: ≤ 6 Watts per unit

•Required network cabling: CAT5e UTP/STP, CAT6 UTP/STP, CAT6A, CAT7

4 | P a g e

Network switch Requirements for KD AV over IP

Key Digital’s AV over IP systems utilize multicasting technology to broadcast streams throughout the network.

AV over IP requires a network switch with IGMP (Internet Group Management Protocol) support to direct traffic of

the broadcast streams, ensuring that only the desired decoders receive the stream from the selected encoder.

If the system spans multiple network switches, it is required for the switches to be connected via 10G fiber cabling

for the purpose of stacking. You must use two of the same series of network switch in these scenarios for best

compatibility.

For 1080p systems (KD-IP1080, KDIP120 models) that plan to use the video preview feature of the Key Digital App,

IGMP v3 must be enabled. For 1080p or 4K systems that will not use the video preview feature, IGMP v2 is enabled.

KD-IP822, 922, 1022 systems require the following IP addresses to be reserved.They cannot be assigned to KD-

IP822, 922, or 1022 units:

192.168.1.1, 192.168.1.50, 192.168.1.90, 192.168.1.100, 192.168.1.150, 192.168.1.200

Feature

4K System

(KD-IP822, KD-IP922, KD-IP1022 models)

1080p System

(KD-IP1080, KD-IP120 models)

IGMP v2

X (for non-video preview systems)

IGMP v3

X (for video preview systems)

Bandwidth

1Gbps

100BaseT

8K Jumbo Frame

PoE

Optional

Optional (excl KD-IP120PoE models)

5 | P a g e

Verified Network Switches

Brand

Model

Port

Number

PoE

10G Fiber

Stacking

Approved for

KD-IP1080/120

Approved for

KD-IP822/922

Approved

for

KD-IP1022

Araknis

AN-210-SW-R-

8-POE

YES

AN-210-SW-F-

8-POE

YES

AN-210-SW-R-

16-POE

YES

AN-210-SW-F-

16-POE

YES

AN-210-SW-R-

24-POE

YES

AN-210-SW-F-

24-POE

YES

AN-210-SW-F-

48-POE

YES

AN-310-SW-R-8

YES

AN-310-SW-F-8

YES

AN-310-SW-R-

YES

AN-310-SW-F-

YES

AN-310-SW-R-

YES

AN-310-SW-F-

YES

AN-310-SW-R-

8-POE

YES

AN-310-SW-F-

8-POE

YES

AN-310-SW-R-

16-POE

YES

AN-310-SW-F-

16-POE

YES

AN-310-SW-R-

24-POE

YES

AN-310-SW-F-

24-POE

YES

AN-310-SW-F-

48-POE

YES

6 | P a g e

Brand

Model

Port

Number

PoE

10G Fiber

Stacking

Approved for

KD-IP1080/120

Approved for

KD- IP822/922

Approved

for

KD-IP1022

Cisco

SF500-48

YES

SG300-28

YES

Catalyst 3850

Series

YES

Meraki MS225

YES

D-Link

DGS-3630-

52PC

YES

DGS-3630-52TC

YES

DGS-3630-

28PC

YES

DGS-3630-28SC

YES

DGS-3630-28TC

YES

DGS-3130-54PS

YES

Edgecore

Mellanox

Edgecore

AS4610-54T

YES

Engenius

EGS5212P

YES

EGS7228FP

YES

EGS7252FP

YES

EWS1200D-10T

YES

EWS1200D-28T

YES

EWS1200D-52T

YES

EWS5912FP

YES

EWS7928P

YES

EWS7928FP

YES

EWS7952FP

YES

7 | P a g e

Brand

Model

Port

Number

PoE

10G Fiber

Stacking

Approved for

KD-IP1080/120

Approved for

KD-IP822/922

Approved

for

KD-IP1022

Linksys

LGS552P

YES

LGS528P

YES

LGS326P

YES

LGS318P

YES

LGS326MP

YES

LGS326P

YES

LGS326

YES

LGS318P

YES

LGS318

YES

LGS308MP

YES

LGS308P

YES

LGS308

YES

Luxul

AMS-4424P

YES

SW-610-24P-R

YES

SW-510-48P-F

YES

8 | P a g e

Brand

Model

Port

Number

PoE

10G Fiber

Stacking

Approved for

KD-IP1080/120

Approved for

KD-IP822/922

Approved

for

KD-IP1022

Netgear

GS716T

YES

GS724T

YES

GS748T

YES

GS752TP

YES

GS728TP

YES

M4250-

10G2XF-PoE

YES

(8)

YES

M4250-

26G4XF-PoE+

YES

M4250-

40G8XF-PoE+

YES

Niveo

NGSME24TH-

YES

Pakedge

S3L-24P

YES

SX-8EP

YES

SX-8P

YES

SX-24

YES

SX-24P16

YES

(16)

YES

SX-24P

YES

(24)

YES

Signamax

SC30020

YES

Titan

Networx

TNSS2400P

YES

TP-Link

TL-SG2428P

YES

TL-SG3210XHP-

YES

TL-SG3428XMP

YES

9 | P a g e

IGMP Setup Guide: Araknis

1080p Systems (KD-IP1080, KD-IP120)

1. IMPORTANT: Disconnect all the DHCP devices like routers, servers from the Araknis network switch.

2. Locate a pinhole “RESET” button at the front panel left bottom corner of your Araknis network switch. Using

a paper clip press and hold a reset button for more than 10 seconds and then release. Wait while the device

is restarted and ready to use (about 5min).

3. IMPORTANT: At this point all the displays should be displaying distorted randomly flashing video images.

4. Connect your PC to the Araknis network switch directly using a network cable.

5. If you have not done yet, configure your PC’s IP address to the same range as the switch (default

192.168.20.xxx).

6. Enter the switch’s IP address (default is 192.168.20.254) in your browser and press ENTER.

7. Enter username and password (default is “araknis” for both). Then click Log In.

10 | P a g e

8. Navigate to Settings -> System. Under IP Address Settings elect Static. Change an IP address to

192.168.1.251, Subnet Mask to 255.255.255.0, Default Gateway to 192.168.1.1 (in this case), and at the

bottom click Apply. If you are setting up multiple network switches it is recommended to set first one to

192.168.1.251, second to 192.168.1.252, and so on, and each switch must be set individually same way as

described below.

9. Page will refresh. Configure your PC’s IP address to the same range as the switch (default 192.168.1.xxx).

Enter the switch’s IP address (default is 192.168.1.251) in your browser and press ENTER.

10. Make sure the settings remain as above.

11. Navigate to Advanced -> Multicast -> IGMP Snooping. Under Settings select Enable for Status, V3 for

Version, and Enable for Report Suppression. Under VLAN Settings / VLAN ID 1 select Enable for IGMP
