Key Digital Champion KD-2X1 Manual de usuario

HDMI

Switchers

The Experts in Digital Video Technology and Solutions™

Champion Series™

Operating Instructions

KD-2X1 KD-4X1

Table of Contents

Introduction ................................................................ 1

Quick Setup Guide .......................................................... 2

Installation and Operation...................................................... 2

Push Button Control ..................................................... 3

Remote Control ........................................................ 3

IR Emitter Control ....................................................... 3

Mechanical / Technical Speciﬁcations ............................................ 4

Important Product Warnings & Safety Instructions ................................... 5

How to Contact Key Digital

.................................................... 6

Warranty Information ......................................................... 6

Always follow the instructions provided in this Operating Manual.

KD-1X2 KD-1X4

Introduction

Key Digital® Champion Series™ HDMI switchers are designed and engineered to offer the

best in quality, performance, and reliability while providing a cost effective HDMI switching

solution. The KD-2X1/KD-4X1 HDMI switchers provide multiple input to one output switching

and maintain crystal-clear, pristine picture and sound quality. Champion Series™ HDMI

switchers are a transparent solution for all digital video/audio switching applications and

support all SD, HD, and VESA video standards, including 1080p/60, 1920x1200, and 3D.

KD-2X1/KD-4X1 HDMI switchers feature pushbutton and optical IR switching, status-

monitoring LEDs, and support for advanced HDMI features: 3D, 4K Resolution.

About the KD-2X1/KD-4X1

½Digital switching of multiple (2 or 4) HDMI inputs to one (1) HDMI output

½Supports all SD, HD, and VESA (VGA, SVGA, XGA, WXGA, SXGA, UXGA) resolutions up to

1080p (60Hz & 50Hz)

»SD & HD: 480i, 480p, 720p, 1080i, 1080p

»VESA: From 640x480p up to 1920x1200p

½EDID and HDCP Transparency between display and sources

½Supports signal rates up to 10.2 Gb per second

½Compliant with HDCP copyright protection

½Supports 3D and 4Kx2K Resolutions

½Supports CEC (Consumer Electronics Control)

½Pushbutton and IR control

½Input and Output status indicated by LED

½Compatible with all control systems

Advanced HDMI® Features

½½3D – Capability to pass 3D stereoscopic signal formats

½½4K – 4096x2160/24 video resolution support for commercial applications such as Digital Movie

Theaters, CAD, Post Production, Graphics and etc.

Accessories

½External power supply: 5V 1A

½HDMI Lacing Clip

½Operating Instructions

½Warranty Card

Quick Setup Guide

½Step 1: Find a safe and convenient location to mount or place your KD-2X1/KD-4X1 unit

½Step 2: Begin with the KD-2X1/KD-4X1 unit and all input/output devices turned off with power

cables removed

½Step 3: Connect your HDMI sources to the input ports of your KD-2X1/KD-4X1 unit

½Step 4: Connect your HDMI display to the output port of your KD-2X1/KD-4X1 unit

½Step 7: Connect power to the KD-2X1/KD-4X1 unit

½Step 8: Power on input/output devices

HDMI

Plasma TV

Blu-Ray

DVD Player

Cable Box

HDMI

Satellite Box

Plasma TV

Blu-Ray

DVD Player

Cable Box

Satellite Box

KD-4X1

Installation and Operation

Before permanently securing the unit for ﬁnal installation of cabling behind walls or ceilings, test for

proper operation of the unit and the cables in your system.

It is recommended that you leave enough ventilation space to

provide sufﬁcient airﬂow and cooling, especially if you are going

to leave the unit powered at all times.

An optional HDMI cable clip (included) enables a method

for securing HDMI cables the KD-2X1/KD-4X1 units and

helps defeat intermittent or complete signal loss due to poor

connection.

Optional HDMI Cable

clip (included)

Pushbutton Control

Your KD-2X1/KD-4X1 unit may be controlled via the pushbutton on the front of the unit. Select

your desired input by depressing the “Input Select” button. The front LED indicators (1, 2, 3, 4)

correspond to the input that has been selected.

IR Remote Control

The KD-2X1/KD-4X1 can also be operated using the IR remote control provided with your unit.

The KD-2X1/KD-4X1 switcher features an IR sensor on the front of the unit for reception of the IR

command signals.

1 2 3 4

1 2 3 R1

4 5

7 8

6R2

9R3

Device Select

Auto

Power OffPower On

www.keydigital.com

Input

Sasha 10/16/2009

1 2 3 4

1 2 3 R1

4 5

7 8

6R2

9R3

Device Select

Auto

Power OffPower On

www.keydigital.com

Input

Input Select

Scroll Up/Down

R1, R2, R3

Reserved for future use

Numeric Keypad

All buttons not listed/

described in this manual

are currently inactive

IR Emitter Control

When using an IR Emitter / IR Extender (sold separately), the IR Emitter must be mounted over the

IR Sensor on the front of the KD-2X1/KD-4X1 unit. One end of the cable is connected to the IR

Receiver / Master Controller / IR Extender / IR Connecting Block, while the other end is mounted

over the IR Sensor of the KD-2X1/KD-4X1 unit.

Mechanical / Technical Speciﬁcations

Inputs 2/4 HDMI Connections

Outputs 1 HDMI Connection

Bandwidth TMDS bandwidth 10.2 Gb/s

Compliance with

HDMI Standard

Fully licensed and compatible with all HDMI and HDCP technologies

Link Single Link: 1080p/60, 12 bit color depth, 1920x1200 max

Deep Color Support Supports digital video formats in Deep Color Mode at

up to 12 bits/color

Lossless

Compressed Digital

Audio

Supports lossless compressed digital audio:

Dolby

TrueHD, Dolby

Digital Plus and DTS

™

-HD Master Audio

DDC Signal (Data) Input DDC Signal: 5 Volts p-p (TTL)

HDMI Video/Audio

Signal

Input Video Signal: 1.2 Volts p-p

HDMI Connector HDMI Connector: Type A, 19 Pin Female

I2C Communication EDID and HDCP Bi-Directional Transparency from Display to Source

Power Source 5 Volt DC @ 1 Amp, 100-240 VAC, 50-60 Hz

Dimensions KD-2x1 W = 3.75”, H = 1”, D = 2.5”

KD-4x1 W = 5.5”, H = 1”, D = 2.75”

Weight KD-2x1 - 0.5 lb

KD-4x1 - 0.9 lb

Terminology

Below is a list of terms and acronyms that reoccur in this Owner’s Manual and are commonly

referred to in the A/V Industry:

CEC Consumer

Electronics

Control

An optional protocol used in HDMI systems that allows HDMI

devices to pass control functions along to all devices within the

system.

DVI Digital Video

Interface

A digital interface standard created by the Digital Display Working

Group (DDWG) to convert analog video signals into digital video

signals to accommodate digital monitors. Typically used for PC

monitors, the video portion of HDMI is compatible with DVI using

simple adapters.

EDID Extended Display

Identiﬁcation Data

A VESA standard data format that contains basic information

about a monitor and its capabilities. Information includes vendor

information, maximum image size, color characteristics, factory

pre-set timings, frequency range limits, and character strings for

the monitor name and serial number.

VESA Video Electronics

Standards

Association

An international standards body for computer graphics founded

in the late 1980s by NEC Home Electronics and eight other video

display adapter manufacturers.

HDCP High-Bandwidth

Digital Content

Protection

The copy protection scheme adopted for use with HDMI/DVI.

HDMI High-Deﬁnition

Multimedia

Interface

An uncompressed, all-digital audio/video interface that supports

over one cable standard, enhanced, and high-deﬁnition video, and

multi-channel audio.

IR Infrared IR, like the infrared remote control. Simply point the front of an IR

remote control unit towards the IR sensor on the product to be

controlled.

LED Light Emitting

Diode

Small light bulbs that illuminate to indicate a selection, and are

used as status indicators

Important Product Warnings:

1. Connect all cables before providing power to the unit.

2. Test for proper operation before securing unit behind walls or in hard to access spaces.

3. If installing the unit into wall or mounting bracket into sheet-rock, provide proper screw support

with bolts or sheet-rock anchors.

Safety Instructions:

Please be sure to follow these instructions for safe operation of your unit.

1. Read and follow all instructions.

2. Heed all warnings.

3. Do not use this device near water.

4. Clean only with dry cloth.

5. Install in accordance with the manufacturer’s instructions.

6. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus

(including ampliﬁers) that produce heat.

7. Only use attachments/accessories speciﬁed by the manufacturer.

8. Refer all servicing to qualiﬁed service personnel. Servicing is required when the device has

been damaged in any way including:

»Damage to the power supply or power plug

»Exposure to rain or moisture

Power Supply Use:

You MUST use the Power Supply provided with your unit or you VOID the

Key Digital® Warranty and risk damage to your unit and associated equipment.

How to Contact Key Digital

System Design Group (SDG)

For system design questions please contact us at:

½Phone: 914-667-9700

½E-mail: sdg@keydigital.com

Key Digital Trainings

For questions about Key Digital

Trainings please contact us at:

½Phone: 914-667-9700

½E-mail: training@keydigital.com

Customer Support

For customer support questions please contact us at:

½Phone: 914-667-9700

½E-mail: customersupport@keydigital.com

Technical Support

For technical questions about using Key Digital

products, please contact us at:

½Phone: 914-667-9700

½E-mail: tech@keydigital.com

Marketing and Public Relations:

For marketing and public relations information, please contact us at:

½Phone: 914-667-9700

½E-mail: marketing@keydigital.com

Repairs and Warranty Service

Should your product require warranty service or repair, please obtain a Key Digital

Return Material

Authorization (RMA) number by contacting us at:

½Phone: 914-667-9700

½E-mail: rma@keydigital.com

Feedback

Please email any comments/questions about the manual to:

½E-mail: customersupport@keydigital.com

Warranty Information

All Key Digital

products are built to high manufacturing standards and should provide years of

trouble-free operation. They are backed by a limited two-year parts and labor warranty.

Otros manuales para Champion KD-2X1

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cambiar de Key Digital

Key Digital

Key Digital KD-VP2500 HD Hot Rod Manual de usuario

Key Digital

Key Digital KD-SW4x1 Manual de usuario

Key Digital

Key Digital Phantom KD-HDSW2x1Pro Manual de usuario

Key Digital

Key Digital Pro Series Manual de usuario

Key Digital

Key Digital KD-CATHD150 Manual de usuario

Key Digital

Key Digital X4x1WUTx Manual de usuario

Key Digital

Key Digital KD-XWPS Manual de usuario

Key Digital

Key Digital KD-HDMI4X1 Manual de usuario

Key Digital

Key Digital KD-SX440WP Manual de usuario

Key Digital

Key Digital Champion KD-2X1 Manual de usuario

Key Digital

Key Digital FatCAT Tx KD-4PUV Manual de usuario

Key Digital

Key Digital KD-S2x1 Manual de usuario

Key Digital

Key Digital FatCAT Rx KD-4AUVRX Manual de usuario

Key Digital

Key Digital Champion SeriesKD-2x1CSK Manual de usuario

Key Digital

Key Digital KD-CSW2X1 Manual de usuario

Key Digital

Key Digital Black Bull KD-HDRV2X1 Manual de usuario

Key Digital

Key Digital KD-S2x1X-2 Manual de usuario

Key Digital

Key Digital KD-22HUCPro Manual de usuario

Key Digital

Key Digital KD-Pro2x1 Manual de usuario

Key Digital

Key Digital KD-X4x1WUTx Manual de usuario

Key Digital

Key Digital KD-IP922ENC-II Manual de usuario

Key Digital

Key Digital KD-CSW2X1 Manual de usuario

Key Digital

Key Digital KD-HDMI2X1 Manual de usuario

Key Digital

Key Digital KD-HDMI2X8P Manual de usuario

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario
