Jetson Element Manual de usuario

ELEMENT

ELECTRIC FOLDING SCOOTER

TABLE OF CONTENTS

What’s in the Box 1

Features & Specs 2

Assembly 3

Charging the Battery 4

Unfolding the Element 5

Operating the Element 6

Speed Settings 7

Settings Mode 8

Riding the Element 9

Using the Thumb Throttle 10

Using the E-Brake 11

Using the Rear Foot Brake 12

Using the Kickstand 13

Folding the Element 14

Care and Maintenance 15

Safety Warnings 16

1. WHAT’S IN THE BOX

1. FRONT TIRE

2. RELEASE LEVER

3. HEADLIGHT

4. HANDLEBAR

5. DECK

6. REAR FOOT BRAKE

7. REAR TIRE

8. KICKSTAND

9. CHARGER

10. CHARGING CABLE

2. FEATURES & SPECS

• Product Dimensions: 37.01” x 17.91” x 44.69”

• Weight Limit: 220 lbs.

• Product Weight: 18.7 lbs.

• Recommended Age: 13+

• Tire Size: 6”

• Max Speed: Up To 15 mph

• Max Range: Up To 10 Miles

• Battery: 24V, 5.0Ah Lithium-Ion

• Motor: 250W Hub Motor

• Charger: 100-240V

• Charge Time: Up To 4 Hours

• Climbing Angle: Up To 15°

• Frame Material: Aluminum

ELEMENT

3. ASSEMBLY

Connecting the Handlebars:

• Look at the inside of each Handlebar and see which is

labeled L (left) and R (right).

• Place L into the left side and R into the right side (left and

right directions are as though you are standing on the Deck).

• Tighten by turning the Handlebars until they can no longer

turn. Make sure the Handlebars are tight and secure.

4. CHARGING THE BATTERY

A few must-do’s:

• Only use the included charger

• Plug the charger into the wall before the Charging Port

• Don’t turn on the Element while it’s charging (it needs its rest)

• Charge the battery until it is fully charged - up to 4 hours

• Replace the cover over the Charging Port when done

• Remember to have fun!

CHARGING INDICATOR ON THE CHARGER:

Red Light: Battery is charging

Green Light: Charging is complete

Charging Port

5. UNFOLDING THE ELEMENT

5.1

5.2 5.3

Unclip

Unclip the hook from the Rear

Foot Brake

Lift Handlebars away from Deck Lock the Release Lever by lifting it

up until it clicks.

Release

Lever

5.4 5.5

Make sure the Release Lever and

Handlebars are secure.

6. OPERATING THE ELEMENT

LED Display

• Powering On/Off - Hold the Power Button for 3 seconds to turn the Element

on or off.

• Light Function - Once the Element is on, tap the Power Button to turn on

the headlight and taillight. The light symbol will show on the LED Display.

• LED Display - Shows current speed and battery life remaining.

Settings

Button

Power

Button

7. SPEED SETTINGS

Press the Settings Button to cycle through the speed settings.

• P0 - No assistance from the motor

• P1 - Max speed up to 6 mph

• P2 - Max speed up to 11 mph

• P3 - Max speed up to 15 mph

Settings

Button
