Jetson BOLT Manual de usuario

BOLT

ELECTRIC FOLDING SCOOTER

TABLE OF CONTENTS

What’s in the Box 1

Features & Specs 2

Attaching the Seat 3

Attaching the Foot Rests 4

Attaching the Fenders 5

Charging the Battery 6

Unfolding the Bolt 7

Operating the Bolt 8

Riding the Bolt 9

Using the Thumb Throttle 10

Using the Brake 11

Using the Kickstand 12

Connecting the Bluetooth® 13

Folding the Bolt 14

Care and Maintenance 15

Safety Warnings 16

1. WHAT’S IN THE BOX 1. FRONT TIRE

2. HEADLIGHT

3. STEM QUICK RELEASE

4. HANDLEBAR

5. CARRYING HANDLE

6. SEAT

7. SEAT CLAMP

8. TAILLIGHT

9. REAR FENDER

10. REAR TIRE

11. KICKSTAND

12. FOOT REST

13. FRONT FENDER

14. FRONT TIRE

15. CHARGER

16. CHARGING CABLE

2. FEATURES & SPECS

• Product Dimensions: 40” x 20” x 37”

• Weight Limit: 250 lbs.

• Product Weight: 34 lbs.

• Recommended Age: 13+

• Tire Size: 12”

• Max Speed: Up To 16 mph/ 26 km/h

• Max Range: Up To 17 Miles/ 27 km

• Battery: 36V, 6.0Ah Lithium-Ion

• Motor: 250W Hub Motor

• Charger: 110-240V

• Charge Time: Up To 5 Hours

• Climbing Angle: Up To 15°

BOLT

3. ATTACHING THE SEAT

Open

Stem

Clamp

Slide Seat

into Stem

Tube

Turn the Knob

clockwise to

tighten Stem

Clamp

the Stem

Clamp

Place each Foot Rest onto the tubes and turn it towards

the rear tire until it is secure.

4. ATTACHING THE FOOT RESTS

5. ATTACHING THE FENDERS

Remove Bolt and Nut from the frame. Run the Bolt through the

Fender and frame, and secure using the Nut.

Front Fender

Bolt

Nut

Rear Fender Bolt

Nut

6. CHARGING THE BATTERY

A few must-do’s:

• Only use the included charger

• Plug the charger into the wall before the Charging Port

• Don’t turn on the Bolt while it’s charging (it needs its rest)

• Charge the battery until it is fully charged - up to 5 hours

• Replace the cover over the Charging Port when done

• Remember to have fun!

CHARGING INDICATOR ON THE CHARGER:

Red Light: Battery is charging

Green Light: Charging is complete

Charging

Port

7. UNFOLDING THE BOLT

7.1

7. 2

Slowly lift the

Handlebars up

Press the Stem

Quick Release

in to lock

8. OPERATING THE BOLT

• Powering On/Off - To turn the Bolt on, flip the power switch to ON. To turn

it off, flip the power switch to OFF.

• Light Function - Once the Bolt is on, hold the Horn for 3 seconds to turn

on the Headlight and Taillight. Hold the Horn for 3 seconds again to turn off

the lights.

• Cruise Control - Press the Cruise Control Button when you have reached

the speed you would like to maintain. Apply the brake to turn off Cruise

Control.

Horn

Power Switch

Cruise Control
