Ipf electronic OR150400 Manual de usuario

MANUAL - Subject to alteration! Version: September 2011

ipf electronic gmbh

│

Rosmarter Allee 14 - 58762 Altena - Germany

│

Tel +49 2351 9365-0 - info@ipf-electronic.com -

www.ipf-electronic.com

OR150400 / OR150470

Retro-re lective sensors

nstallation and environment

Coatings on the optics and on the re lector impair the unction. The installation should there ore be carried

out in such a way that as little dust as possible is deposited and no liquid can get onto them during operation.

It must also be ensured that they are accessible or cleaning.

From time to time, the optics and re lector should be cleaned with a so t cloth moistened with alcohol or

soapy water.

Cable

The PVC connection cable o the pre-wired cable devices is not suitable or environments containing oil or

solvents and in applications where the cable is requently moved.

In such cases, the use o a plug device with an ip -Sensor lex cable socket is recommended.

nstallation and alignment

1. Mount the re lector in the desired position.

2. Cover the re lector, e.g. with adhesive tape, so that only the center (about 25% o the sur ace) remains

ree.

3. Then align the device on the re lector and asten it. Make sure that the re lector is perpendicular to the

line connecting it to the device. For optical reasons, keep a minimum distance o approx. 20cm rom the

re lector!

4. I the light beam is interrupted, the device must now switch sa ely.

5. Remove the adhesive tape rom the re lector.

Setting

The built-in potentiometer can be used to change the sensitivity and thus the range (distance between the

Retro-re lective sensors and the re lector). On delivery, the device is set to the maximum value. Turning it

counter-clockwise reduces the range. The ull setting range o the potentiometer is 12 revolutions.

I the light beam is interrupted, the switching output switches o (light switching, black core) and the yellow

switching state LED goes out.

Sa e operation is ensured when both the green unction LED and the yellow switching state LED light up when

the light path is ree and both LEDs go out when the object is recognized.

I the green LED does not light up when the light path is clear, either the sensitivity is set too low, the distance

to the re lector is too great, or the optics or re lector are dirty.

MANUAL - Subject to alteration! Version: September 2011

ipf electronic gmbh

│

Rosmarter Allee 14 - 58762 Altena - Germany

│

Tel +49 2351 9365-0 - info@ipf-electronic.com -

www.ipf-electronic.com

Note

The retro-re lective sensors o design 15 operate with a red light emitting diode. The devices are equipped

with a polarizing ilter, there ore re lectors suitable or polarized light must also be used.

The speci ied nominal ranges re er to a round re lector with 82mm diameter (AO000006 or AO000007). I

smaller re lectors are used, only a smaller maximum range is possible.

Electrical connection

OR150400 / OR150470

Technical data

Article no.

Voltage

Power

Output

Transmit

Element

Nominal

Range

Connection

OR150400 10 ... 36V DC 200mA pnp, no/nc LED, red, polarizing

ilter

0.2 ... 4m 3m PVC cable tail

OR150470 10 ... 36V DC 200mA pnp, no/nc LED, red, polarizing

ilter

0.2 ... 4m M8-connector 4pin

Safety Notice:

In case o direct impact on personal sa ety, the application o these products is prohibited.

Dark switching

(NO)

Light switching

(NC)
