EasyCoder 201 II
Label-Taken Sensor Kit
P/N 1-960255-04
Edition 3
September 1998
Installation Instructions
EasyCoder 201 II – Installation Instructions
1
This booklet contains instructions on how to install the Label-
Taken Sensor Kit (LTS) on an EasyCoder 201 II printer. Installa-
tion should preferably be performed by an authorized service
technician.
For instructions on how to use the label-taken sensor, please refer
to the EasyCoder 201 II Technical Manual.
The Label-Taken Sensor kit consists of:
• 1 Reflecting Sensor assy. with bracket and cable
• 1 Screw
• This Installation Instructions booklet.
The status of the LTS has to be polled in the Intermec Fingerprint
programbymeansofthePRSTAT function,asotherwisetheprinter
will not react on the LTS signal.
❑Make a simple program that checks the printer's status, e.g.:
10 BREAK 1,88
20 BREAK 1 ON
30 FORMFEED
40 IF (PRSTAT AND 2) THEN BEEP
50 GOT0 40
60 END
RUN
You can break this program by transmitting the character X
(ASCII 88) decimal on the standard serial interface "uart1:".
LABEL-TAKEN SENSOR KIT
General Information
Preparation Before
Installation
Informationinthismanualissubjecttochangewithoutpriornoticeanddoesnot
represent a commitment on the part of Intermec Printer AB.
©CopyrightIntermecPTCAB,1998.Allrightsreserved.PublishedinSweden.
EasyCoder and Fingerprint are registered trademarks of Intermec Technolo-
gies Corp.
EasyCoder 201 II
Label-Taken Sensor Kit
Installation Instructions
Edition 3, September 1998
Part No. 1-960255-04
EasyCoder 201 II – Installation Instructions
2
LABEL-TAKEN SENSOR KIT, cont'd.
❑Turn off the power and remove the power cord.
❑Disconnect all communication cables.
❑Open the right-hand door.
❑Loosen the two screws that lock the cover.
❑Pull the cover straight back and remove it completely.
❑Open the left-hand door.
❑LoosenthethreescrewsthatholdtheCPUboardassy.andswing
the unit outwards as illustrated.
Step-by-Step Installation
Instructions
CoverScrews (2x)
230V
CPU Board Assy.
Screw (1x)
Screws (2x)
Continued!
EasyCoder 201 II – Installation Instructions
3
❑Remove the two screws that hold the front moulding.
❑Carefully manipulate the moulding so you can slip the cable of
the label-taken sensor through the gap between the moulding
and the centre-line wall of the printer.
❑Thread the cable back to the electronics compartment and
connectittoP-8ontheCPUboard,see nextpage.Becareful so
the cable will not interfere with the pulley of the print roller or
with the printhead lift mechanism.
❑Using the screw included in the kit, fit the sensor and the front
moulding as illustrated. The tab at the top of the sensor bracket
should be fitted into the lower of the two cross-shaped holes in
the front moulding.
❑Putback theoriginal (upper)screw holdingthe frontmoulding.
LABEL-TAKEN SENSOR KIT, cont'd.
Step-by-Step Installation
Instructions, cont'd.
LTS assy.
Tab
Front Moulding
Original Screw
Cable
New Screw
(incl. in the kit)
Continued!
EasyCoder 201 II – Installation Instructions
4
P-8
LTS
Step-by-Step Installation
Instructions, cont'd.
LABEL-TAKEN SENSOR KIT, cont'd.
❑Fitthe cablefromthe label-takensensor toconnector P-8at the
lower, front part of the CPU board.
❑Close the doors and cover in reverse order, refit the com-
munication cables and the power cord, and turn on the power.
❑Adjust the sensitivity of the label-taken sensor by means of the
uppermost potentiometer on the printer's rear plate:
• StartupFingerprintandruntheprogramdescribedonpage1.
Leave a label in the outfeed slot as to create a label-not-taken
condition.
• The printer should start to beep continuously. If not, turn the
potentiometer back and forth until the beeping starts.
• Adjust the potentiometer so the beeping does not stop when
the potentiometer is turned a quarter of a turn in either
direction.
• Remove the label. The beeping should cease immediately. If
necessary, readjust the potentiometer1.
• Break the program by typing Xon the host.
WARNING!
To avoid the risk of short-circuits, use
non-conductivetoolsonly,evenwhen
the power is off, since the memory
packages are battery backed-up.
The potentiometer is situated inside the
cover plate on the printer's rear plate.
CPU Board
P-8
Connect cable here!
1/.Ifadjustmentbymeansofthepotentio-
meter is proves insufficient, a strap on
P-14 on the CPU board can be fitted or
removed to change the sensitivity of the
LTS light-emitting diode:
Strap fitted: Higher intensity
No strap: Low intensity
MADE IN SWEDEN
Thermal Printer 201
Model #
1-201011-11
Serial #
115-230V 2.6-1.3A 50-60Hz
INTERMEC PRINTER AB MADE IN SWEDEN
50105
This equipment complies with the requirements for a Class Acomputing device in FCC Rules
Part 15 Subpart J. Operation of this device in a residential area may cause harmful interference
requiring the user to take whatever steps may be necessary to correct the interference.
UL
LISTED 65B5
R
N309
LR67809
V
DE
geprüfte
Sicherheit
Label-taken sensor
