Intermec CK61G Instrucciones de instalación y funcionamiento

CK61G

Handheld Computer

Addendum

ii CK61G NI Handheld Computer

Intermec Technologies Corporation

Worldwide Headquarters

6001 36th Ave.W.

Everett, WA 98203

U.S.A.

www.intermec.com

The information contained herein is provided solely for the purpose of allowing customers to operate and

service Intermec-manufactured equipment and is not to be released, reproduced, or used for any other purpose

without written permission of Intermec Technologies Corporation.

Information and specifications contained in this document are subject to change without prior noticed and do

not represent a commitment on the part of Intermec Technologies Corporation.

The word Intermec, the Intermec logo, Norand, ArciTech, Beverage Routebook, CrossBar, dcBrowser,

Duratherm, EasyADC, EasyCoder, EasySet, Fingerprint, INCA (under license), i-gistics, Intellitag, Intellitag

Gen2, JANUS, LabelShop, MobileLAN, Picolink, Ready-to-Work, RoutePower, Sabre, ScanPlus, ShopScan,

Smart Mobile Computing, SmartSystems, TE 2000, Trakker Antares, and Vista Powered are either trademarks

or registered trademarks of Intermec Technologies Corporation.

There are U.S. and foreign patents as well as U.S. and foreign patents pending.

CK61G NI Handheld Computer Addendum 3

CK61G Non-Incendive (NI) Handheld Computer Addendum

The users of this product are cautioned to use accessories and peripherals

approved by Intermec Technologies Corporation. The use of accessories

other than those recommended, or changes to this product that are not

approved by Intermec Technologies Corporation, may void the compliance

of this product and may result in the loss of the user’s authority to operate

the equipment.

Shipping Information

Your CK61G Non-Incendive (NI) Handheld Computer ships with the

following:

• Power supply and cord

• Standard battery

• Spare battery

• Tethered stylus

• Spare stylus

• Charging dock

• SD card (256 MB)

•Strap

Key Features and Connection Information

The CK61G differs from the CK61 Handheld Computer in these areas:

• Security features

• Contact Memory Device (CMD) support

• Assured radio deactivation feature

• Bluetooth not supported

Operating System

The CK61G runs Windows Mobile 5.0 only.

Security

The CK61G uses the standard 802.11 wireless security features, which can

be configured using the Setup Assistant.

Available under AIT-III CLIN 0040, FIPS (Federal Information Processing

Standard) security can be ordered separately.

Caution: This marking indicates that the user should read all included

documentation before use.

4 CK61G NI Handheld Computer Addendum

Assured Radio Deactivation

The Assured Radio Deactivation feature allows you to deactivate 802.11

radio transmission. Once deactivated, the radio remains off until activated

by the user.

To access Assured Radio Deactivation

1Tap the iConnect icon in the lower right corner of the Windows Mobile

Start Screen. The menu appears with these options:

2Select Enable. The menu that then appears allows you to choose from

these options:

3To toggle the radio state, tap Assured Radio Deactivation.

The CK61G immediately cold boots, and when restarting, your

CK61G displays a dialog box with this message:

CK61G NI Handheld Computer Addendum 5

4Tap OK and a green (safe) status indicator displays next to the iConnect

icon in the bottom right corner of the display. This green symbol

indicates the radio is deactivated and the CK61G radio is transmitting

no RF energy.

When you tap the iConnect menu item Assured Radio Deactivation to

toggle on (or off) this radio deactivation feature, the CK61G immediately

cold boots and returns to operation in the selected state (either off or on).

When cold booting, your CK61G displays the state of Assured Radio

Deactivation, which appears in the dialog box following the restart.

Contact Memory Device

The CK61G provides an interface to Contact Memory Devices (CMD)

with a CMD probe. The probe allows the CK61G to read from or write to

the CMD.

The CK61G software includes MacSema drivers to enable the MacSema

probes. The probes attach to your CK61G using a serial connector on an

Intermec serial adapter.

These probes can be ordered via CLIN 0020 and CLIN 0024; both include

the Intermec serial adapter.

In-Dock Communication

When the CK61G is placed in its charging dock and a network connection

is established via USB, Ethernet, or serial connection to the host PC, the

radio is disabled. Your CK61G communicates with a host PC or other

device using the interface for the docking station (USB and ActiveSync,

Ethernet, or serial cable).

Assured Radio Deactivation Indicators

Indicator

Assured

Radio

Deactivation

Radio

State

iConnect

indicator

color Transmit State

DOn Deactivated Green No radio transmission.

Safety on:

• No RF energy

transmitted.

XOff Active Red Radio can transmit.

Safety off:

• RF energy transmitted.

6 CK61G NI Handheld Computer Addendum

To confirm radio status in-dock

1Tap iConnect.

2Tap Status.

3Tap Wireless. The Wireless Status dialog box appears. If radio

communication is enabled and active, then the Wireless Status dialog

box appears:

4Tap Xto close the window.

Bluetooth Radio

By design, the CK61G does not provide power for Bluetooth; the CK61G

will not recognize Bluetooth radio devices.

Radio Country Codes

Change the country code using the CK61G Setup Assistant when the

computer starts up the first time. To later change the country codes, use

Intermec Settings.

Configuring the CK61G With the Setup Assistant

The Setup Assistant starts automatically the first time you turn on the

CK61G. Use the Setup Assistant to set or enable basic network parameters

and connect your CK61G to the network.

The Setup Assistant guides you through setting the following basic network

parameters:

• Date and time (including time zone)

• SSID (Network name)

• 802.1x security

• DHCP server or IP address, subnet mask, and default router

• Primary and secondary DNS and WINS addresses

CK61G NI Handheld Computer Addendum 7

• Device name

• Radio country code

To set other parameters, use Intermec Settings or another configuration

method.

To use the Setup Assistant

1Tap Start > Programs > File Explorer, and then scroll to Setup

Assistant.

2Double-tap Setup Assistant.

3Tap Next to start using Setup Assistant. The Date screen appears.

4Set the date and tap Next. The Time Setup screen appears.

5Set the time. Tap Next and the Daylight Time Setup screen appears.

6Set the daylight time if you want to automatically adjust the clock for

daylight savings time changes and tap Next.

7Tap Yes if you want to configure the radio country code. If you choose

Yes, you will also need to tap the keyboard icon on the display and enter

the password which is cfg802bg.

8Scroll through the list and select the radio country code you want to use

and tap Next.

9Tap Yes to set up any 802.11 security settings . Once you are finished

setting up your security settings tap Next to continue.

Note: The CK61G uses the standard 802.11 wireless security features.

Available under AIT-3 CLIN 0040, FIPS (Federal Information

Processing Standard) security can be ordered separately.

CK61G NI Handheld Computer Addendum 9

10 Tap Yes if you want to obtain the IP address from a DHCP server or tap

No if you want to specify the IP address. Tap Next when you are

finished.

11 Specify a device name for the CK61G and tap Next to go to the next

screen.

12 Tap Yes if you want your settings to be saved if you cold boot the

CK61G or tap No if settings can be deleted.

Worldwide Headquarters

6001 36th Avenue West

Everett, Washington 98203

U.S.A.

tel 425.348.2600

fax 425.355.9551

www.intermec.com

CK61G Non-Incendive (NI) Handheld Computer Addendum

*941-004-002*

P/N 941-004-002
