Intermec 200 Manual de usuario

JANUS 900 MHz Terminal Emulation

for the Model 200 Controller

P/N 066576-001

Quick

Reference

Guide

IntermecCorporation

6001 36th Avenue West

P.O. Box 4280

Everett, WA 98203-9280

U.S. service and technical support: 1-800-755-5505

U.S. media supplies ordering information: 1-800-227-9947

Canadian service and technical support: 1-800-688-7043

Canadian media supplies ordering information: 1-800-268-6936

Outside U.S. and Canada: Contact your local Intermec service supplier.

The information contained herein is proprietary and is provided solely for the purpose of allowing

customers to operate and/or service Intermec manufactured equipment and is not to be released,

reproduced, or used for any other purpose without the written permission of Intermec.

Information and specifications in this manual are subject to change without notice.

1997 by Intermec Corporation

The word Intermec, the Intermec logo, JANUS, IRL, TRAKKER, Antares, Duratherm, Precision

Print, PrintSet, Virtual Wedge, and CrossBar are either trademarks or registered trademarks of

Intermec Corporation.

Throughout this manual, trademarked names may be used. Rather than put a trademark (or )

symbol in every occurrence of a trademarked name, we state that we are using the names only in an

editorial fashion, and to the benefit of the trademark owner, with no intention of infringement.

Contents

iii

Contents

Before You Begin vii

Warranty Information vii

About This Manual vii

Other Related Manuals ix

Getting Started

Introduction 1-3

Typical 900 MHz Configuration 1-4

Starting Terminal Emulation 1-5

Exiting Terminal Emulation 1-6

Unsupported Functions 1-7

Using TE Features

Using the JANUS TE Keypad 2-3

JANUS 2010 and 2020 Terminal Emulation Keypads 2-3

JANUS 2050 Terminal Emulation Keypads 2-4

Accessing the Commands on the Keypad 2-5

Accessing Uppercase Letters and Symbols 2-5

Accessing Characters or Commands 2-5

Viewing the Input Screen 2-7

How the Viewport Works 2-7

Understanding the Roll Command 2-8

Auto-Advancing Through Fields on 5250 TE Screens 2-9

Understanding Status Line Messages 2-10

Customizing Your Configuration

Changing TE Session Options 3-3

Accessing the Configuration Application 3-3

3270 and 5250 Configuration Parameters 3-5

Terminal 3-5

JANUS 900 MHz Terminal Emulation for the Model 200 Controller

Communications 3-5

Viewport 3-6

VT and ANSI Configuration Parameters 3-7

Terminal 3-7

Communications 3-8

Viewport 3-9

Setting Security for the TE Configuration Application 3-9

Using the Auto-Login Feature 3-11

Developing Auto-Login Scripts 3-11

Control Characters for Auto-Login Scripts 3-12

Loading the Auto-Login File 3-14

Configuring Terminal Emulation to Display International Characters 3-14

IBM 3270 and 5250 Code Pages 3-14

VT/ANSI Code Pages 3-15

AUTOEXEC.BAT and CONFIG.SYS Changes 3-15

3270 and 5250 Commands

Command Descriptions 4-3

Arrow Keys 4-3

Attention 4-3

Auto-Login Restart 4-4

Backtab 4-4

Clear 4-4

Cursor Home 4-5

Delete 4-5

End 4-5

Enter 4-6

Erase to End of Field 4-6

Erase Field 4-6

Erase Input 4-7

Erase Last Word 4-7

Error Reset 4-7

Exit 4-8

Fast Cursor Right/Left 4-8

Field+ and Field- 4-9

Field Exit 4-9

Help 4-10

Home 4-10

Insert 4-11

New Line 4-11

Contents

Paging Keys 4-12

Reset 4-13

Reshow 4-13

Roll Up and Roll Down 4-14

Scroll 4-15

Status 4-15

System Request 4-16

Tab 4-16

Program Function Keys 4-17

Program Attention Keys 4-20

3270 Keys 4-20

5250 Keys 4-20

Other Keys - 5250 Terminals 4-21

VT/ANSI Commands

Editing Key Commands - VT220/320 Terminals 5-3

Auto-Login Restart 5-3

Find 5-4

Insert 5-4

Next Screen 5-4

Previous Screen 5-4

Remove 5-5

Select 5-5

Program Function Keys 5-5

Additional Functions 5-8

Troubleshooting

Understanding Error Messages 6-3

Local Editing Errors 6-3

Reference

3270 and 5250 Command Summary A-3

VT220/320 Command Summary A-4

JANUS 900 MHz Terminal Emulation for the Model 200 Controller

VT/ANSI Additional Functions A-5

JANUS Viewport Movement Commands A-6

Terminal Emulation Files A-7

Reinstalling Terminal Emulation Software A-8

Sample Auto-Login Scripts A-10

TE.CFG Configuration File A-12

VT/ANSI Keyboard Remapping

Understanding VT/ANSI Key Support B-3

VT100 Terminals B-3

VT220/320 Terminals B-4

ANSI Terminals B-6

Remapping the JANUS Keys B-6

Index

nugnug

>JI

codecodeBefore You Begin

vii

Before You Begin

This section introduces you to standard warranty provisions, safety

precautions, warnings and cautions, document formatting conventions, and

sources of additional product information.

Warranty Information

To receive a copy of the standard warranty provision for this product, contact

your local Intermec sales organization. In the U.S. call 1-800-755-5505, and in

Canada call 1-800-688-7043. Otherwise, refer to the Worldwide Sales & Service

list that comes with this manual for the address and telephone number of your

Intermec sales organization.

About This Manual

This table summarizes the information in each chapter and appendix.

Chapter What You Will Find

1 Provides basic information for setting up and using your JANUS data

collection computer with terminal emulation.

2 Describes the JANUS TE keypad and explains how to use terminal

functions on the keypad.

3 Tells you how to customize your JANUS terminal emulation

configuration.

4 Lists the terminal emulation commands you can use with your 3270 and

5250 terminals.

5 Lists the terminal emulation commands you can use with your VT/ANSI

terminals.

6 Provides information about error messages that you may encounter

while using terminal emulation software.

A Provides a summary of available TE commands for all supported

devices. It also provides copies of the configuration files included on

your TE installation disk.

B Provides information about VT/ANSI key support and instructions for

remapping keys on your JANUS device.

JANUS 900 MHz Terminal Emulation for the Model 200 Controllercodecode

D>JI

nuggnugg

viii

Terms and Conventions

The following special terms and conventions occur throughout the manual.

PC Keypad Input

Keystrokes to be entered into the PC are emphasized in bold. “Choose Y”

means you press the key labeled “Y” on the PC keyboard.

When you need to press and release a series of keys in order, the keys appear

in order with no connectors. “Press Shift A” means that you press and release

the Shift key, and then press A.

When you must press more than one key at the same time, the keys are

connected by a dash in the text. “Press Ctrl-Alt-Del” means that to perform a

warm boot on the host PC, you need to hold down the Ctrl, Alt,and Del keys

at the same time. When the keys are connected by a dash, you must press and

hold the keys in the order shown.

JANUS Keypad Input

Key icons represent keystrokes you enter on the JANUS device. For example,

“press

“ directs you to press the key labeled “

” on the JANUS

keypad.

PC and JANUS Commands

Command syntax appears in the text as you should enter it into the PC or

JANUS device. For example, to see a listing of directories on the device, type

the following command:

dir

Optional command line parameters are enclosed in brackets [ ].

Notes

The notes in this manual use the following format.

Note: Notes either provide extra information about a topic or contain special

instructions for handling a particular condition or set of circumstances.

IMPORTANT! Is used to flag critical information about a topic.

nugnug

>JI

codecodeBefore You Begin

Format Conventions for Bar Codes

You can scan the bar codes listed in this manual to enter data or perform a

command. The bar code labels in this manual are printed in the Code 39

symbology. Each bar code includes the name and human-readable

interpretation. For example:

The asterisks (*) at the beginning and end of the human-readable interpretation

are the start and stop codes for a Code 39 bar code label. If you are creating bar

code labels with a bar code utility, it may automatically supply the asterisks as

the start and stop code, so that you only need to type the actual text of the

command. You can also create and print configuration labels and reader

command labels in Code 93, which has its own start and stop codes.

Other Related Manuals

You may need to refer to other manuals when working with JANUS

900 MHz terminal emulation software. To order additional manuals, contact

your local Intermec representative.

Intermec Manuals Intermec

Part No.

odel 200 Controller System Manual 063439

RF System/9180 Controller User’s Manual 054292

900 MHz RF Equipment User’s Manual 066163

900 MHz RF Gateway User’s Manual 066164

ANUS 2010 Hand-Held Computer User’s Manual (4MB) 065714

ANUS 2020 Hand-Held Computer User’s Manual (4MB) 065715

ANUS 2050 Vehicle-Mount Computer User’s Manual (4MB) 065716

Other Manuals

Intermec recommends that 5250 users obtain a copy of the IBM 5494 Remote

Control Unit Functions Reference Manual for more detailed information

regarding 5250 commands, local editing functions, and error messages.

*$+*

Change Configuration

*$+*

Name

Bar code (Code 39)

Human-readable

interpretation

2010U.073
