Intermec 751G Instrucciones de instalación y funcionamiento

751G NI

Handheld Computer

Addendum

ii 751G NI Handheld Computer Addendum

Intermec Technologies Corporation

Worldwide Headquarters

6001 36th Ave.W.

Everett, WA 98203

U.S.A.

www.intermec.com

The information contained herein is provided solely for the purpose of allowing customers to operate and

service Intermec-manufactured equipment and is not to be released, reproduced, or used for any other purpose

without written permission of Intermec Technologies Corporation.

Information and specifications contained in this document are subject to change without prior noticed and do

not represent a commitment on the part of Intermec Technologies Corporation.

The word Intermec, the Intermec logo, Norand, ArciTech, Beverage Routebook, CrossBar, dcBrowser,

Duratherm, EasyADC, EasyCoder, EasySet, Fingerprint, INCA (under license), i-gistics, Intellitag, Intellitag

Gen2, JANUS, LabelShop, MobileLAN, Picolink, Ready-to-Work, RoutePower, Sabre, ScanPlus, ShopScan,

Smart Mobile Computing, SmartSystems, TE 2000, Trakker Antares, and Vista Powered are either trademarks

or registered trademarks of Intermec Technologies Corporation.

There are U.S. and foreign patents as well as U.S. and foreign patents pending.

751G NI Handheld Computer Addendum 3

751G Non-Incendive (NI) Handheld Computer Addendum

This addendum explains the hardware and software differences between the

751 “standard” (Windows Mobile 5.0) Mobile Computers and the 751G

(Windows Mobile 5.0) Mobile Computer. These differences include:

• no Bluetooth radio

• Common Access Card (CAC) support

• ability to disable the 802.11 b/g radio

• ability to change the radio country code

• more extensive NI certification rating

Operating System

The 751G runs Windows Mobile 5.0 only.

Bluetooth Radio

By design, the 751G does not provide power for Bluetooth; the 751G will

not recognize Bluetooth radio devices.

Common Access Card Interface

You can use the Common Access Card (CAC) reader with the 751G. You

will need to install a CAC adapter before you can attach the CAC reader.

The CAC adapter plugs into the top of the 751G and replaces the SD

cover.

The CAC reader allows applications to read and write to SmartCards using

the Microsoft Resource Manager. You will need to install the following to

use this feature:

• 751G CAC Adapter (P/N 074202)

• Common Access Card (CAC) Reader (P/N 074102)

Assured Radio Deactivation

The Assured Radio Deactivation feature allows you to deactivate 802.11

radio transmission. Once deactivated, the radio remains off until it is re-

activated.

To access Assured Radio Deactivation

1Tap the iConnect icon ( ) in the bottom right corner of the

Windows Mobile Start Screen.

2The iConnect menu appears with these options:

4 751G NI Handheld Computer Addendum

3Select Enable. The menu that then appears allows you to choose from

these options:

4To toggle the radio state, tap Assured Radio Deactivation.

The 751G immediately cold boots, and when restarting, your 751G

displays a dialog box with this message:

5Tap OK and a green (safe) status indicator displays in the bottom right

corner of the display. This green symbol indicates the radio is

deactivated and the 751G radio is transmitting no RF energy.

When you tap the iConnect menu item Assured Radio Deactivation to

toggle on (or off) this radio deactivation feature, the 751G immediately

cold boots and returns to operation in the selected state (either off or on).

When cold booting, your 751G displays the state of Assured Radio

Deactivation, which appears in the dialog box following the restart.

Assured Radio Deactivation Indicators

Indicator

Assured Radio

Deactivation Radio State

iConnect

indicator

color Transmit State

DOn Deactivated Green No radio transmission.

Safety on:

• No RF energy

transmitted.

XOff Active Red Radio can transmit.

Safety off:

• RF energy transmitted.

751G NI Handheld Computer Addendum 5

Configuring the 751G With the Setup Assistant

The Setup Assistant starts automatically the first time you turn on the

751G. Use the Setup Assistant to set or enable basic network parameters

and connect your 751G to the network. Use Intermec Settings to update

any of your device settings.

The Setup Assistant guides you through setting the following basic network

parameters:

• Date and time (including time zone)

• SSID (Network name)

• 802.1x security

• DHCP server or IP address, subnet mask, and default router

• Primary and secondary DNS and WINS addresses

• Device name

• Radio country code.

To set other parameters, use the Intermec Settings or another configuration

method.

To use the Setup Assistant

1Setup Assistant starts automatically the first time you turn on your

751G.

2Tap Next to start using Setup Assistant.

6 751G NI Handheld Computer Addendum

3Set the date.

4Set the time.

5Set the daylight time if you want to automatically adjust the clock for

daylight savings time changes.

751G NI Handheld Computer Addendum 7

6Tap Yes if you want to configure the radio country code. If you choose

Yes, you will also need to tap the keyboard icon on the display and enter

the password which is cfg802bg.

7Scroll through the list and select the radio country code you want to use.

8 751G NI Handheld Computer Addendum

8Tap Yes to set up any 802.11 security settings. The 751G uses the

standard 802.11 wireless security features. Available under AIT-3 CLIN

0040, FIPS (Federal Information Processing Standard) security can be

ordered separately

9Tap Yes if you want to obtain the IP address from a DHCP server or tap

No if you want to specify the IP address.

751G NI Handheld Computer Addendum 9

10 Specify a device name for the 751G.

11 Tap Yes if you want your settings to be saved if you cold boot the 751G

or tap NO if settings can be deleted.

Worldwide Headquarters

6001 36th Avenue West

Everett, Washington 98203

U.S.A.

tel 425.348.2600

fax 425.355.9551

www.intermec.com

751G NI Handheld Computer Addendum

*941-006-002*

P/N 941-006-002
