NS3550-8T-2S Industrial

Managed Switch User

Manual

P/N 1072687-EN • REV E • ISS 25JAN19

2019 United Technologies Corporation.

Interlogix is part of UTC

Climate, Controls & Security, a unit of United Technologies

Corporation

Trademarks and patents

Trade names used in this document may be trademarks or registered trademarks of the

manufacturers or vendors of the respective products.

Manufacturer

Interlogix

2955 Red Hill Avenue, Costa Mesa, CA 92626

-5923, USA

Authorized EU manufacturing representative:

UTC Fire & Security B.V.

Kelvinstraat 7, 6003 DH Weert, The Netherlands

Version

This document applies to

NS3550-8T-2S.

FCC compliance

This device complies with part 15 of the FCC Rules. Operation is subject to the following

two conditions: (1) This device may not cause harmful interference,

and (2) this device

must accept any interference received, including interference that may cause undesired

operation.

FCC compliance

Class A:

This equipment has been tested and found to comply with the limits for a Class

A digital device, pursuant to pa

rt 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates, uses, and can radiate

radio frequency energy and, if not i

nstalled and used in accordance with the instruction

manual, may cause harmful interference to radio communications. Operation of this

equipment in a residential area is likely to cause harmful interference in which case the

user will be required to correc

t the interference at his own expense.

Canada

This Class A digital apparatus complies with CAN ICES

-003 (A)/NMB-3 (A).

Cet appareil numérique de la classe A est conforme à la norme CAN ICES

-003

(A)/NMB

-3 (A).

ACMA compliance

Notice!

This is a Class A product. In a domestic environment this product may cause

radio interference in which case the user may be required to take adequate measures.

Certification

EU directives

This product and

- if applicable - the supplied accessories too are marked with "CE" and

comply therefore with the applicable harmonized European standards listed under the

EMC Directive 2014/30/EU, the RoHS Directive 2011/65/EU.

2012/19

/EU (WEEE directive): Products marked with this symbol cannot be disposed of

as unsorted m

unicipal waste in the European Union. For proper recycling, return this

product to your local supplier upon the purchase of equivalent new equipment, or

dispose of it at designated collection points. For more information see:

www.recyclethis.info.

Product

warnings and

disclaimers

THESE PRODUCTS ARE INTENDED FOR SALE TO, AND INSTALLATION BY, AN

EXPERIENCED SECURITY PROFESSIONAL. UTC FIRE & SECURITY CANNOT

PROVIDE ANY ASSURANCE THAT ANY PERSON OR ENTITY BUYING ITS

PRODUCTS, INCLUDING ANY “AUTHORIZED DEALER”

OR “AUTHORIZED

RESELLER”

, IS PROPERLY TRAINED OR EXPERIENCED TO CORRECTLY INSTALL

SECURITY RELATED PRODUCTS.

For more information on warranty disclaimers and product safety information, please

check www.firesecurityproducts.com

/policy/product-warning/ or scan the following code:

Contact information

and

manuals

For contact information

and manuals, go to: www.interlogix.com or

www.firesecurityproducts.com

NS3550-8T-2S Industrial Managed Switch User Manual 1

Content

Important information 3

Chapter 1 Introduction 4

Package contents 4

Product description 5

Product features 6

Product specifications 9

Chapter 2 Installation 13

Hardware description 13

Installing the industrial managed switch 18

Cabling 21

Chapter 3 Switch management 27

Requirements 27

Management access overview 27

Remote Telnet 28

Web management 29

SNMP-based network management 30

Chapter 4 Web management 31

Main web page 33

System 34

Simple Network Management Protocol (SNMP) 60

Port management 70

Link aggregation 77

VLAN 84

Spanning Tree Protocol (STP) 110

Multicast 128

Quality of Service (QoS) 151

Access Control Lists (ACL) 174

Authentication 188

Security 222

MAC address table 238

LLDP 244

Network diagnostics 258

Loop protection 263

RMON 265

Ring 274

Chapter 5 Command line interface 288

Accessing the CLI 288

Telnet login 288

2 NS3550-8T-2S Industrial Managed Switch User Manual

Chapter 6 Command line mode 289

System Command 290

IP Command 296

Port Management Command 302

MAC Address Table Command 306

VLAN Configuration Command 309

Private VLAN Configuration Command 316

Security Command 318

Spanning Tree Protocol Command 364

Link Aggregation Command 373

Link Aggregation Control Protocol Command 375

LLDP Command 378

LLDP MED Command 382

EEE Command 386

Thermal Command 387

Ethernet Virtual Connections Command 388

Ethernet Protection Switching Command 392

Maintainence entity End Point Command 393

Quality of Service Command 400

Mirror Command 413

Configuration Command 415

Firmware Command 415

UPnP Command 416

MVR Command 417

Voice VLAN Command 421

Ethernet Ring Protection Switching Command 425

Loop Protect Command 430

IPMC Command 432

VLAN Control List Command 440

SMTP Command 443

Chapter 7 Switch operation 446

Address table 446

Learning 446

Forwarding and filtering 446

Store-and-forward 446

Auto-negotiation 447

Chapter 8 Troubleshooting 448

Appendix A Networking connection 450

Glossary 452

NS3550-8T-2S Industrial Managed Switch User Manual 3

Important information

Limitation of liability

To the maximum extent permitted by applicable law, in no event will UTCFS be liable

for any lost profits or business opportunities, loss of use, business interruption, loss of

data, or any other indirect, special, incidental, or consequential damages under any

theory of liability, whether based in contract, tort, negligence, product liability, or

otherwise. Because some jurisdictions do not allow the exclusion or limitation of liability

for consequential or incidental damages the preceding limitation may not apply to you.

In any event the total liability of UTCFS shall not exceed the purchase price of the

product. The foregoing limitation will apply to the maximum extent permitted by

applicable law, regardless of whether UTCFS has been advised of the possibility of

such damages and regardless of whether any remedy fails of its essential purpose.

Installation in accordance with this manual, applicable codes, and the instructions of the

authority having jurisdiction is mandatory.

While every precaution has been taken during the preparation of this manual to ensure

the accuracy of its contents, UTCFS assumes no responsibility for errors or omissions.

Advisory messages

Advisory messages alert you to conditions or practices that can cause unwanted

results. The advisory messages used in this document are shown and described below.

WARNING: Warning messages advise you of hazards that could result in injury or loss

of life. They tell you which actions to take or to avoid in order to prevent the injury or

loss of life.

Caution: Caution messages advise you of possible equipment damage. They tell you

which actions to take or to avoid in order to prevent damage.

Note: Note messages advise you of the possible loss of time or effort. They describe

how to avoid the loss. Notes are also used to point out important information that you

should read.

4 NS3550-8T-2S Industrial Managed Switch User Manual

Chapter 1

Introduction

The description of the IFS NS3550-8T-2S model is as follows:

Industrial L2+ 8-port 10/100/1000T

+ 2-port 100/1000X managed switch

Unless specified, the term “industrial managed switch” mentioned in this user manual

refers to the NS3550-8T-2S.

Package contents

Open the box of the industrial managed switch and carefully unpack it. The box should

contain the following items:

The industrial managed switch × 1

Quick installation guide × 1

CD with user manual × 1

DIN rail kit x 1

Wall mounting kit x 1

SFP dust-proof cap x 2

RJ45 dust-proof cap x 8

If any of these are missing or damaged, contact your dealer immediately. If possible,

retain the carton including the original packing materials for repacking the product in

case there is a need to return it to us for repair.

Chapter 1: Introduction

NS3550-8T-2S Industrial Managed Switch User Manual 5

Product description

The industrial managed switch is specially designed to build a full Gigabit backbone to

transmit reliable and high-speed data in demanding heavy industrial environments and

forward data to a remote network through fiber optic cabling. It comes with an IP30

rugged case and redundant power system. Besides support for 20 Gbps switch fabric

to handle extremely large amounts of video, voice, and important data in a secure

topology, the industrial managed switch provides user-friendly, advanced IPv6/ IPv4

management interfaces and abundant L2/L4 switching functions. It is the best

investment for expanding industrial business or upgrading its network infrastructure..

IPv6/IPv4 full-function secure switch for building automation networking

The industrial managed switch is the ideal solution to fulfilling the demand of IPv6

management gigabit Ethernet switches, especially in the industrial-hardened

environment. It supports both IPv4 and IPv6 protocols, advanced Layer 2 to Layer 4

data switching and redundancy, QoS traffic control, network access control and

authentication, and secure management features to protect customer’s industrial and

building automation network connectivity with reliable switching recovery capability that

is suitable for implementing fault tolerant and mesh network architectures.

Redundant ring, fast recovery for critical network applications

The industrial managed switch supports redundant ring technology and features strong,

rapid self-recovery capability to prevent interruptions and external intrusions. It

incorporates advanced ITU-T G.8032 ERPS (Ethernet Ring Protection Switching)

technology, Spanning Tree Protocol (802.1s MSTP), and redundant power input

system into the customer’s industrial automation network to enhance system reliability

and uptime in harsh factory environments. In a certain simple ring network, the

recovery time of data link can be as fast as 20 ms.

Environmentally hardened design

With its IP30 aluminum case, the industrial managed switch provides a high level of

immunity against electromagnetic interference and heavy electrical surges which are

usually found on plant floors or in curb-side traffic control cabinets. It also possesses an

Chapter 1: Introduction

6 NS3550-8T-2S Industrial Managed Switch User Manual

integrated power supply source with a wide range of voltages (12 to 48 VDC or 24

VAC) for worldwide high availability applications requiring dual or backup power inputs.

Being able to operate under the temperature range from -40 to 75°C, the industrial

managed switch can be placed in almost any difficult environment.

Flexible and extendable solution

The industrial managed switch features 100BASE-FX and 1000BASE-SX/LX SFP

(Small Form-factor Pluggable) fiber-optic modules, meaning the administrator now can

flexibly choose the suitable SFP transceiver according to the transmission distance or

the transmission speed required to extend the network efficiently. The industrial

managed switch supports the SFP-DDM (Digital Diagnostic Monitor) function that can

easily monitor real-time parameters of the SFP for the network administrator such as

optical output power, optical input power, temperature, laser bias current, and

transceiver supply voltage

Product features

Physical port

• Eight 10/100/1000BASE-T gigabit RJ45 copper ports.

• Two 100/1000BASE-X mini-GBIC/SFP slots, SFP type auto detection.

Industrial case and installation

• IP30 aluminum case

• DIN-rail and wall-mount design

• Redundant power design

• 12 to 48 VDC, redundant power with polarity reverse protect function

• AC 24 V power adapter acceptable

• Supports EFT protection 6000 VDC for power line

• Supports Ethernet ESD protection for 6000 VDC

• -40 to 75°C operating temperature

Chapter 1: Introduction

NS3550-8T-2S Industrial Managed Switch User Manual 7

Layer 2 features

• Prevents packet loss with back pressure (Half-Duplex) and IEEE 802.3x PAUSE

frame flow control (Full-Duplex).

• High performance of Store-and-Forward architecture and runt/CRC filtering

eliminates erroneous packets to optimize the network bandwidth.

Storm control support:

• Multicast / Unknown-Unicast

Supports VLAN

• IEEE 802.1Q tagged VLAN

• Up to 255 VLANs groups out of 4094 VLAN IDs

• Provider bridging (VLAN Q-in-Q) support (IEEE 802.1ad)

• Private VLAN Edge (PVE)

• Protocol-based VLAN

• MAC-based VLAN

• Voice VLAN

Supports STP

• STP, IEEE 802.1D Spanning Tree Protocol

• RSTP, IEEE 802.1w Rapid Spanning Tree Protocol

• MSTP, IEEE 802.1s Multiple Spanning Tree Protocol, spanning tree by VLAN

• BPDU Guard

Supports link aggregation

• IEEE 802.3ad Link Aggregation Control Protocol (LACP)

• Cisco ether-channel (static trunk)

• Maximum five trunk groups, up to 10 ports per trunk group

• Up to 20 Gbps bandwidth (Duplex Mode)

Provides port mirror (many-to-1)

Port mirroring to monitor the incoming or outgoing traffic on a particular port

Supports Ethernet Ring Protection Switching (ERPS)

Quality of Service

• Ingress shaper and egress rate limit per port bandwidth control

• Eight priority queues on all switch ports

• Traffic classification:

- IEEE 802.1p CoS

Chapter 1: Introduction

8 NS3550-8T-2S Industrial Managed Switch User Manual

- TOS / DSCP / IP Precedence of IPv4/IPv6 packets

- IP TCP/UDP port number

- Typical network application

• Strict priority and Weighted Round Robin (WRR) CoS policies

• Supports QoS and In/Out bandwidth control on each port

• Traffic-policing policies on the switch port

• DSCP remarking

Multicast

• Supports IGMP snooping v1, v2, and v3

• Supports MLD snooping v1 and v2

• Querier mode support

• IGMP snooping port filtering

• MLD snooping port filtering

• Multicast VLAN Registration (MVR) support

Security

• Authentication

−IEEE 802.1x Port-Based / MAC-Based network access authentication

−Built-in RADIUS client to co-operate with the RADIUS servers

−TACACS+ login users access authentication

−RADIUS / TACACS+ users access authentication

• Access Control List (ACL)

−IPv4 / IPv6 IP-based ACL

−MAC-based ACL

• Source MAC / IP address binding

• DHCP snooping to filter distrusted DHCP messages

• Dynamic ARP inspection discards ARP packets with invalid MAC addresses to IP

address binding.

• IP source guard prevents IP spoofing attacks.

• Auto DoS rule to defend against DoS attacks.

• IP address access management to prevent unauthorized intruders.

Management

• Switch management interfaces:

−Remote Telnet management

Otros manuales para NS3550-8T-2S

Tabla de contenidos

Otros manuales de Cambiar de Interlogix

Interlogix

Interlogix IFS MC350-4T-2S Manual de usuario

Interlogix

Interlogix NS3503-16P-4C Manual de usuario

Interlogix

Interlogix NS3552-8P-2S Manual de usuario

Interlogix

Interlogix NS4702-24P-4S-4X Manual de usuario

Interlogix

Interlogix IFS ANT-PNL-18DB-2G Manual de usuario

Interlogix

Interlogix NS3503-16P-4C Manual de usuario

Interlogix

Interlogix NS3552-8P-2S-V2 Manual de usuario

Interlogix

Interlogix NS3550-8T-2S Manual de usuario

Interlogix

Interlogix IFS ANT-OMN-15DB-2G Manual de usuario

Interlogix

Interlogix NS4750-24S-4T-4X Manual de usuario

Interlogix

Interlogix NS3050-8T Manual de usuario

Interlogix

Interlogix NS3500-24T-4C Instrucciones de instalación

Interlogix

Interlogix IFS NS3050-8T Manual de usuario

Interlogix

Interlogix NS3553-4P-1T-2S-V2 Manual de usuario

Interlogix

Interlogix IFS GE-DSH-73 Instrucciones de montaje

Interlogix

Interlogix NS3562-8P-2S Manual de usuario

Interlogix

Interlogix ES2402 Series Manual de usuario

Interlogix

Interlogix IFS NS3550-24T/4S Manual de usuario

Interlogix

Interlogix GE-DS Series Manual de usuario

Interlogix

Interlogix IFS NS2503-8P/2C Manual de usuario

Interlogix

Interlogix NS3553-4P-1T-2S Manual de usuario

Interlogix

Interlogix NS4702-24P-4X Manual de usuario

Interlogix

Interlogix IFS ANT-PNL-9DB-2G Manual de usuario

Interlogix

Interlogix NS3552-8P-2S-V2 Manual de usuario

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario
