Interlogix NS3500-24T-4C Manual de usuario

NS3500-24T-4C Managed

Switch User Manual

P/N 1073386-EN • REV A • ISS 08FEB18

2018 United Technologies Corporation.

Interlogix is part of UTC

Climate, Controls & Security, a unit of United Technologies

Corporation

Trademarks and patents

Trade names used in this document may be trademarks or registered trademarks of the

manufacturers or vendors of the respective products.

Manufacturer

Interlogix

2955 Red Hill Avenue, Costa Mesa, CA 92626

-5923, USA

Authorized EU manufacturing representative:

UTC Fire & Security B.V.

Kelvinstraat 7, 6003 DH Weert, The Netherlands

Version

This document applies to

NS3500-24T-4C.

FCC compliance

This device complies with part 15 of the FCC Rules. Operation is subject to the following

two conditions: (1) This device may not cause harmful interference, and (2) this device

must accept any interference received,

including interference that may cause undesired

operation.

FCC compliance

Class A:

This equipment has been tested and found to comply with the limits for a Class

A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to

provide

reasonable protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates, uses, and can radiate

radio frequency energy and, if not installed and used in accordance with the instruction

manual,

may cause harmful interference to radio communications. Operation of this

equipment in a residential area is likely to cause harmful interference in which case the

user will be required to correct the interference at his own expense.

Canada

This Class A

digital apparatus complies with CAN ICES-003 (A)/NMB-3 (A).

Cet appareil numérique de la classe A est conforme à la norme CAN ICES

-003

(A)/NMB

-3 (A).

ACMA compliance

Notice!

This is a Class A product. In a domestic environment this product may cause

radio interference in which case the user may be required to take adequate measures.

Certification

EU directives

This product and

- if applicable - the supplied accessories too are marked with "CE" and

comply therefore with the applicable

harmonized European standards listed under the

EMC Directive 2014/30/EU, the RoHS Directive 2011/65/EU.

2012/19

/EU (WEEE directive): Products marked with this symbol cannot be disposed of

as unsorted municipal waste in the European Union. For proper

recycling, return this

product to your local supplier upon the purchase of equivalent new equipment, or

dispose of it at designated collection points. For more information see:

www.recyclethis.info.

Product warnings and

disclaimers

THESE PRODUCTS ARE

INTENDED FOR SALE TO AND INSTALLATION BY

QUALIFIED PROFESSIONALS. UTC FIRE & SECURITY CANNOT PROVIDE ANY

ASSURANCE THAT ANY PERSON OR ENTITY BUYING ITS PRODUCTS,

INCLUDING ANY “AUTHORIZED DEALER” OR “AUTHORIZED RESELLER”, IS

PROPERLY TRAINED OR EXPERIENCED

TO CORRECTLY INSTALL FIRE AND

SECURITY RELATED PRODUCTS

For more information on warranty disclaimers and product safety information, please

check

www.firesecurityproducts.com/policy/product-warning/ or scan the following code:

Contact information and

manuals

For contact information go to:

www.interlogix.com or www.firesecurityproducts.com.

To get translations for this and other product manuals go to:

www.firesecurityproducts.com

Content

Important information 3

Chapter 1 Introduction 4

Package contents 4

Product description 5

Product features 8

Product specifications 11

Chapter 2 Installation 14

Hardware description 14

Chapter 3 Switch management 22

Requirements 22

Management access overview 22

Administration console 23

Web management 25

SNMP-based network management 25

Smart discovery utility 26

Chapter 4 Web configuration 28

Main web page 29

System 30

DHCP server 57

UDLD 68

Simple Network Management Protocol (SNMP) 70

Port management 82

Link aggregation 91

VLAN 99

Spanning Tree Protocol (STP) 126

Multicast 143

Quality of Service (QoS) 168

Access Control Lists (ACL) 191

Authentication 204

Security 239

Address table 254

LLDP 260

Network diagnostics 274

Loop protection 278

RMON 280

Chapter 5 Switch operation 290

Address table 290

Learning 290

Forwarding and filtering 290

NS3500-24T-4C Managed Switch User Manual 1

Store-and-forward 290

Auto-negotiation 291

Chapter 6 Troubleshooting 292

Appendix A Networking connection 293

Glossary 295

2 NS3500-24T-4C Managed Switch User Manual

Important information

Limitation of liability

To the maximum extent permitted by applicable law, in no event will UTCFS be liable

for any lost profits or business opportunities, loss of use, business interruption, loss of

data, or any other indirect, special, incidental, or consequential damages under any

theory of liability, whether based in contract, tort, negligence, product liability, or

otherwise. Because some jurisdictions do not allow the exclusion or limitation of liability

for consequential or incidental damages the preceding limitation may not apply to you.

In any event the total liability of UTCFS shall not exceed the purchase price of the

product. The foregoing limitation will apply to the maximum extent permitted by

applicable law, regardless of whether UTCFS has been advised of the possibility of

such damages and regardless of whether any remedy fails of its essential purpose.

Installation in accordance with this manual, applicable codes, and the instructions of the

authority having jurisdiction is mandatory.

While every precaution has been taken during the preparation of this manual to ensure

the accuracy of its contents, UTCFS assumes no responsibility for errors or omissions.

Advisory messages

Advisory messages alert you to conditions or practices that can cause unwanted

results. The advisory messages used in this document are shown and described below.

WARNING: Warning messages advise you of hazards that could result in injury or loss

of life. They tell you which actions to take or to avoid in order to prevent the injury or

loss of life.

Caution: Caution messages advise you of possible equipment damage. They tell you

which actions to take or to avoid in order to prevent damage.

Note: Note messages advise you of the possible loss of time or effort. They describe

how to avoid the loss. Notes are also used to point out important information that you

should read.

NS3500-24T-4C Managed Switch User Manual 3

Chapter 1

Introduction

The IFS L2+ 24-port 10/100/1000Mbps with four ports shared SFP managed gigabit

switch comes with the multi-port gigabit ethernet switch, SFP fiber optic connectibility,

and robust layer 2 features. The description of this model is as follows:

L2+ 24-port 10/100/1000Mbps

+ 4-port shared SFP managed gigabit switch

Unless specified, the term “managed switch” mentioned in this user manual refers to

the NS3500-24T-4C.

Package contents

Open the box of the managed switch and carefully unpack it. The box should contain

the following items:

The managed switch × 1

DB9 RS232 cable × 1

Rubber feet × 4

Rack mount accessory kit × 1

Power cord × 1

SFP dust-proof cap × 4

If any of these are missing or damaged, contact your dealer immediately. If possible,

retain the carton including the original packing materials for repacking the product in

case there is a need to return it to us for repair.

Note: User manuals and install guides are available for download from

www.interlogix.com.

4 NS3500-24T-4C Managed Switch User Manual

Chapter 1: Introduction

Product description

Cost-effective IPv6 managed Gigabit switch solution for enterprises

NS3500-24T-4C is a Layer 2+ managed Gigabit Switch that features 24-Port

10/100/1000BASE-T with 4-Port Shared 100/1000Base-X SFP and supports static

Layer 3 routing for enterprise-level network. The abundant L2 / L4 switching engine

offered by the NS3500-24T-4C performs effective data traffic control for enterprises and

VoIP service providers, video streaming, and multicast applications. Providing user-

friendly but advanced IPv6 / IPv4 management interfaces, it is well suited for backbone

and workgroup network applications by providing affordability, high performance, and

stable transmission quality.

Environment-friendly, variable fan design for silent operation

The managed switch features a 19-inch metal housing, no noise design, and an

effective ventilation system.It is able to operate reliably, stably, and quietly in any

environment without affecting performance.

Solution for IPv6 networking

With the IPv6/IPv4 dual stack and other management functions with user-friendly

interfaces, the NS3500-24T-4C is the best choice for IP surveillance, VoIP, and

wireless service providers to deploy the IPv6 network. More importantly, they help

SMBs upgrade their network infrastructures to the IPv6 era without any monetary

investment.

IPv4/IPv6 VLAN routing for secure and flexible management

To help customers stay on top of their businesses, the managed switch not only

provides ultra high transmission performance and excellent Layer 2 technologies, but

also a IPv4/IPv6 VLAN routing feature that allows cross over of different VLANs and

NS3500-24T-4C Managed Switch User Manual 5

Chapter 1: Introduction

different IP addresses for the purpose of having a highly secured, flexible management

and simpler networking application.

Robust Layer 2 feature

The managed switch can be programmed for advanced switch management functions

such as dynamic port link aggregation, Q-in-Q VLAN, private VLAN, Multiple Spanning

Tree Protocol (MSTP), Layer 2 to Layer 4 QoS, bandwidth control, and IGMP / MLD

snooping. Via aggregation of supporting ports, the managed switch allows the

operation of a high-speed trunk combining multiple ports. It consists of a maximum of

14 trunk groups with four ports for each group, and also supports fail-over.

Powerful security

The managed switch offers a comprehensive Layer 2 to Layer 4 Access Control List

(ACL) for enforcing security to the edge. It can be used to restrict network access by

denying packets based on source and destination IP address, TCP/UDP ports, or

defined typical network applications. Its protection mechanism also comprises 802.1x

port-based and MAC-based user and device authentication. With the private VLAN

function, communication between edge ports can be prevented to ensure user privacy.

Enhanced security and traffic control

The managed switch also provides DHCP Snooping, IP Source Guard, and Dynamic

ARP Inspection functions to prevent IP snooping from attack and discard ARP packets

with invalid MAC addresses. The network administrator can now construct highly-

secure corporate networks using considerably less time and effort than before.

User-friendly secure management

For efficient management, the managed switch is equipped with console, web, and

SNMP management interfaces. With the built-in web-based management interface, the

managed switch offers an easy-to-use, platform-independent management and

configuration facility. The managed switch supports standard Simple Network

Management Protocol (SNMP) and can be managed by any management software

based on the standard SNMP v1 or v2 protocol. For reducing product learning time, the

managed switch offers Cisco-like command via Telnet or console port, and the

customer doesn’t need to learn new commands from these switches. Moreover, the

managed switch offers secure management remotely by supporting SSH, SSL, and

SNMP v3 connections where the packet content can be encrypted at each session.

6 NS3500-24T-4C Managed Switch User Manual

Chapter 1: Introduction

Intelligent SFP diagnostic mechanism

The managed switch series supports a SFP-DDM (Digital Diagnostic Monitor) function

that can easily monitor real-time parameters of the SFP and SFP+ transceivers, such

as optical output power, optical input power, temperature, laser bias current, and

transceiver supply voltage.

NS3500-24T-4C Managed Switch User Manual 7

Chapter 1: Introduction

Applications

Layer 2+ VLAN static routing application

The managed switch features a built-in, robust IPv4/IPv6 Layer 3 traffic static routing

protocol to ensure reliable routing between VLANs and network segments. The routing

protocols can be applied by VLAN interface with up to 128 routing entries.

Multiple Spanning Tree Protocol for SMBs and workgroups

The managed switch features strong, rapid self-recovery capability to prevent

interruptions and external intrusions. It incorporates Multiple Spanning Tree Protocol

(802.1s MSTP) into the customer’s automation network to enhance system reliability

and uptime. The managed switch can easily help enterprises with the available network

infrastructure to build wireless AP, IP camera, and VoIP.

Product features

• 24-port 10/100/1000BASE-T gigabit Ethernet RJ45.

• Four 100/1000BASE-X SFP slots, shared with port 21 to port 24 compatible with

100Base-FX SFP.

• RS-232 DB9 console interface for basic switch management and setup.

Layer 2 features

• Prevents packet loss with back pressure (half-duplex) and IEEE 802.3x pause

frame flow control (full-duplex).

• High performance of Store-and-Forward architecture and runt/CRC filtering

eliminates erroneous packets to optimize the network bandwidth.

Storm control support:

• Broadcast / Multicast / Unknown-Unicast

Supports VLAN

• IEEE 802.1Q tagged VLAN

• Provider Bridging (VLAN Q-in-Q) support (IEEE 802.1ad)

• Private VLAN Edge (PVE)

• Protocol-based VLAN

• MAC-based VLAN

• Up to 255 VLANs groups, out of 4095 VLAN IDs

• IP Subnet-based VLAN

• Voice VLAN

• Management VLAN

8 NS3500-24T-4C Managed Switch User Manual

Otros manuales para NS3500-24T-4C

Tabla de contenidos

Otros manuales de Cambiar de Interlogix

Interlogix

Interlogix NS4750-24S-4T-4X-V2 Instrucciones de instalación

Interlogix

Interlogix IFS NS2503-8P/2C Manual de usuario

Interlogix

Interlogix ES2402 Series Manual de usuario

Interlogix

Interlogix GE-DS Series Manual de usuario

Interlogix

Interlogix IFS ANT-PNL-18DB-2G Manual de usuario

Interlogix

Interlogix NS3552-16P-2T-2S Manual de usuario

Interlogix

Interlogix IFS NS3502-8P-2S Manual de usuario

Interlogix

Interlogix NS3503-16P-4C Manual de usuario

Interlogix

Interlogix IFS NS3050-8T Manual de usuario

Interlogix

Interlogix ES3002-4P-4T Manual de usuario

Interlogix

Interlogix NS3500-24T-4C Manual de usuario

Interlogix

Interlogix IFS ANT-UNI-21DB-2G Manual de usuario

Interlogix

Interlogix NS3552-8P-2S-V2 Manual de usuario

Interlogix

Interlogix NS3553-4P-1T-2S-V2 Manual de usuario

Interlogix

Interlogix NS2052-8P-2C Manual de usuario

Interlogix

Interlogix NS4702-24P-4S-4X Manual de usuario

Interlogix

Interlogix NS3503-16P-4C Manual de usuario

Interlogix

Interlogix IFS NS3550-24T/4S Manual de usuario

Interlogix

Interlogix NS3562-8P-2S Manual de usuario

Interlogix

Interlogix IFS ANT-PNL-9DB-2G Manual de usuario

Interlogix

Interlogix NS3552-8P-2S-V2 Manual de usuario

Interlogix

Interlogix NS3500-24T-4C Instrucciones de instalación

Interlogix

Interlogix POC2502 Series Manual de usuario

Interlogix

Interlogix NS3562-8P-2S Manual de usuario

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario
