Interlogix TruVision TVD-2402 Manual de usuario

TruVision High Definition TVI Vandal Dome

Installation Guide

Product overview

This is the installation guide for TruVision High Definition TVI

dome TVD-2402/TVD-4402 and TVD-2404/TVD-4404. This

guide describes a standard installation.

Package contents:



Camera with power and

video output cables



4 screws and 4 anchors

for wall or ceiling

installation



Template



3 screws for install the

camera to back box

Hex wrench

Monitor output cable



Spare rubber knockout

There is a rubber knockout on the camera

back box. This one is for future use.



Installation Guide



•WEEE and Battery

Disposal

Camera description

1. Dome liner

2. Bubble

3. Lens

4. Power cable

5. CVBS video output cable

(black)

6. TVI video output cable

(grey)

7. Back box

8. DIP switch

9. Menu button

Note:

Please check the camera output settings before setting up a

system. The TVI video output can be only connected to DVR

with TVI signal input. The CVBS output supports the standard

monitor, test monitor, encoder and DVR.

For TVD-2402/TVD-4202, the CVBS and TVI output can not be

performed at the same time, you can use the built-in DIP

switch to select the camera video output.

For TVD-2404/TVD-4404, the built-in DIP switch is used to

enable/disable WDR feature, when WDR feature is enabled,

the CVBS output will be blocked out.

DIP switch

2 / 4 P/N 1072937-EN • REV A • ISS 26MAR15

Installation

To install the camera on a ceiling:

1. Using the template, place it level against the mounting

surface and mark the position of the mounting holes.

2. Following all local codes, drill and prepare the mounting

holes.

3. Remove the camera from its back box.

4. Loosen the three set of screws on the edge of the bubble

with the supplied hex wrench.

5. Remove the bubble and the dome liner.

6. Secure the back box to the ceiling with the supplied

screws.

Note: Please remove the rubber knockout for cable

routing outside of the camera, when required.

7. Using a 75-ohm coaxial video cable, connect the camera

TVI video output and a TVI DVR, and connect a 12 VDC

or 24 VAC power supply to the power cable.

8. Align the camera with the back box and tighten the set

screws to secure the camera to the back box.

7. Adjust the surveillance angle:

1) View the camera image on a monitor.

2) Rotate the panning table to adjust the pan direction [0

to 355°].

3) Loosen the tilting lock screw.

4) Rotate the tilting table to adjust the tilt direction [0 to

90°].

5) Tighten the tilting lock screw.

6) Rotate the camera lens holder [0 to 355°] to adjust the

lens to the surveillance angle.

8. Zoom and focus adjustment.

1) View the camera image using the monitor.

2) Loosen the zoom lever and move the screw between T

(Tele) and W (Wide) to obtain the appropriate angle of

view.

3) Tighten the zoom lock screw.

4) Loosen the focus lever and move the screw between F

(Far) and N (Near) to obtain the optimum focus.

5) Tighten the focus lock screw.

Zoom

Focus

Programming

Programming on TVI output:

Once the camera hardware has been installed, you can

configure the camera settings on the TVI DVR.

Please select PTZ protocol as TruVision Coax and click menu

button to call up the camera menu.

For more details, please see the TVI DVR user manual.

Programming on CVBS output:

Programming on CVBS output, you need to connect a monitor

and a TVS-C200 controller (purchase separately) as following

system figure.

The TVS-C200 has one male BNC output and a female output.

Please connect the male output to camera’s CVBS output and

female output to a monitor.

TVI

CVBS

P/N 1072937-EN • REV A • ISS 26MAR15 3 / 4

TVD-2402/TVD-4402

The camera has CVBS and TVI selectable video output.

Please set the built-in DIP switch to CVBS for viewing the

program on a standard monitor.

In such case, its TVI will be blocked out until you finish the settings and

change DIP switch back to TVI.

TVD-2404/TVD-4404

The camera has the CVBS and TVI dual video output. The

built-in DIP switch is for WDR/CVBS selection.

Please set the built-in DIP switch to CVBS for viewing the

program on a standard monitor.

When the programing is finished, you may change the DIP to

WDR to enable the WDR feature. In such case, the CVBS

output will be blocked out.

If the DIP is set as CVBS, the WDR feature will be disabled,

and the camera has CVBS and TVI output available at the

same time.

Specifications

Power

supply 24 VAC/12 VDC

Current

TVD-2402/ TVD-4402:

12 VDC: Max. 300 mA

24 VAC: Max. 210 mA

TVD-2404/TVD-4404:

12 VDC: Max. 375 mA

24 VAC: Max. 270 mA

Power

consumption TVD-2402/ TVD-4402:

12 VDC: Max. 3.5W

24 VAC: Max. 5W

TVD-2404/TVD-4404:

12V DC: Max. 4.5W

24V AC: Max. 6.5W

Weight

(net) 641 g / 1.41 lb. (without back box)

932 g / 205 lb. (with back box)

Dimensions

Ø145.3 x 124.2 mm

(Ø5.72 x 4.89 in. )

TVD-2402/TVD-4402:

TVD-2404/TVD-4404:

Regulatory information

Manufacturer

Interlogix.

2955 Red Hill Avenue, Costa Mesa, CA 92626

5923, USA

Authorized EU manufacturing representative:

UTC Fire & Security B.V.

Kelvinstraat 7, 6003 DH Weert, The Netherlands

FCC compliance

Class A: This equipment has been tested and

found to comply with the limits for a Class A

digital device, pursuant to part 15 of the FCC

Rules. These limits are designed to provide

reasonable protection against harmful

interference when the equipment is operated in a

commercial environment. This equipment

generates, uses, and can radiate radio frequency

energy and, if not installed and used in

accordance with the instruction manual, may

cause harmful interference to radio

communi

cations. Operation of this equipment in a

residential area is likely to cause harmful

interference in which case the user will be

required to correct the interference at his own

expense.

ACMA compliance

Notice! This is a Class A product. In a domestic

environment this product may cause radio

interference in which case the user may be

required to take adequate measures.

Canada

This Class A digital apparatus complies with

Canadian ICES-003.

Cet appareil numérique de la classe A est

conforme à la norme NMB-0330 du Canada.

Certification

N4131

European Union

directives

12004/108/EC (EMC directive): Hereby, UTC Fire

& Security declares that this device is in

compliance with the essential requirements and

other relevant provisions of Directive

2004/108/EC.

2012/19/EU (WEEE directive): Products marked

with this symbol cannot be disposed of as

unsorted municipal waste in the European Union.

For proper recycling, return this product to your

local supplier upon the purchase of equivalent

new equipment, or dispose of it at designated

collection points. For more information see:

www.recyclethis.info.

Interlogix is part of UTC Building & Industrial

Systems, a unit of United Technologies

4 / 4 P/N 1072937-EN • REV A • ISS 26MAR15

Trademarks and

patents

The trade names used in this document may be

trademarks or registered trademarks of the

manufacturers or vendors of the respective

products.

Contact information

For contact information, see www.interlogix.com or

www.utcfssecurityproducts.eu.
