TruVision DVR 20 User Manual

Trademarks and patents Interlogix, TruVision names and logos are trademarks of

UTC Fire & Security.

Other trade names used in this document may be trademarks or

registered trademarks of the manufacturers or vendors of the

respective products.

Manufacture

UTC Fire & Security Americas Corporation, Inc.

2955 Red Hill Avenue, Costa Mesa, CA 92626-5923, USA

Authorized EU manufacturing representative:

UTC Fire & Security B.V.

Kelvinstraat 7, 6003 DH Weert, The Netherlands

Certification

FCC compliance Class A: This equipment has been tested and found to comply with

the limits for a Class A digital device, pursuant to part 15 of the

FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates,

uses, and can radiate radio frequency energy and, if not installed

and used in accordance with the instruction manual, may cause

harmful interference to radio communications. Operation of this

equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the

interference at his own expense.

European Union

directives 2004/108/EC (EMC directive): Hereby, UTC Fire & Security

declares that this device is in compliance with the essential

requirements and other relevant provisions of Directive

2004/108/EC.

2002/96/EC (WEEE directive): Products marked with this symbol

cannot be disposed of as unsorted municipal waste in the

European Union. For proper recycling, return this product to your

local supplier upon the purchase of equivalent new equipment, or

dispose of it at designated collection points. For more information

see: www.recyclethis.info.

2006/66/EC (battery directive): This product contains a battery

that cannot be disposed of as unsorted municipal waste in the

European Union. See the product documentation for specific

battery information. The battery is marked with this symbol, which

may include lettering to indicate cadmium (Cd), lead (Pb), or

mercury (Hg). For proper recycling, return the battery to your

supplier or to a designated collection point. For more information

see: www.recyclethis.info.

Contact information For contact information, see www.interlogix.com.

TruVision DVR 20 User Manual i

Content

Chapter 1 Product introduction 1

Product overview 1

Features 2

Chapter 2 Installation 5

Installation environment 5

Unpacking the TVR 20 and its accessories 5

HDD capacity 6

Connecting devices to the rear panel 7

Alarm inputs and outputs 8

Camera inputs 9

RS-485 port 9

RS-232 port 10

PTZ dome camera set up 10

Wiring the KTD-405 keypad 13

Using the KTD-405 keypad to address PTZ cameras in zone

mode 16

Monitor connections 18

Audio inputs and output 18

Chapter 3 Express setup 19

Chapter 4 Operating instructions 23

Control interfaces 23

Controlling the TVR 20 23

Using the front panel 24

Using the mouse 26

Using the remote control 27

Using a KTD-405/KTD-405-2D keypad 29

Screen overview 31

Chapter 5 Basic operation 35

Turning on the TVR 20 35

Logging on 35

TVR 20 toolbar overview 36

Live mode 37

Controlling a PTZ camera 42

Playing back recorded video 46

Bookmarking recorded video 49

Archiving recently recorded video 50

Searching and playing back recorded video 53

Playing back archived files on a PC 60

Manually acknowledging an alarm 60

ii TruVision DVR 20 User Manual

Logging off from setup mode 60

Turning off the TVR 20 60

Chapter 6 Advanced setup 61

Overview of the Menu toolbar 61

Camera settings 62

Alarm and event settings 72

Schedule settings 79

Network settings 84

Display settings 89

Managing users 92

System setup 94

System information 102

Chapter 7 Web browser 103

Web browser overview 104

Searching recorded video 105

Playing back and archiving recorded video 106

Windows Vista and 7 users 108

Chapter 8 eZ DDNS 111

Chapter 9 Troubleshooting 113

Appendix A Specifications 115

Appendix B Warranty and support 117

Index 119

TruVision DVR 20 User Manual 1

Chapter 1

Product introduction

Product overview

This is the TruVision DVR 20 User Manual for models:

• TVR-2004-500EA

• TVR-2004-1TEA

• TVR-2008-500EA

• TVR-2008-1TEA

• TVR-2016-500EA

• TVR-2016-1TEA

The TruVision DVR 20 (TVR 20) digital video recorder generation is based on

H.264 compression technology. It has enhanced recording capacity and

improved network image transmission speed with high image quality.

Comprehensive features and extended event recording settings enable the

almost universal application of this DVR series.

With Graphical User Interface (GUI), users can command specific actions on the

TVR 20 through graphical icons and visual indicators. Simply point, click, and

drag the playback bar on the screen to playback the recordings in any time slot.

There are multiple control inputs, which include mouse control, front panel

control, remote control, and keypad (KTD-405/KTD405-2D) control. Mouse

control is supported with the simple GUI, offering experienced PC users the

similarity of interactive command of a computer-controlled device. All GUI

functions can be operated via front panel, IR remote, and keypad as well.

The TVR 20 is engineered for express operations. Setup, copy, search, and

playback recordings in seconds with a simple “point and click” on the command

icons.

48BChapter 1: Product introduction

2 TruVision DVR 20 User Manual

Features

This section describes the available TVR 20 features.

Compression

The TVR 20 supports the following video features:

Pentaplex operation (simultaneous live, recording, playback, archiving and

remote viewing)

User friendly GUI with graphical icons and visual indicators

Real-time live display for all cameras

Simultaneous VGA, composite and S-video output

Storage

The TVR 20 supports the following storage features:

Built-in DVD burner

Supports eSATA

Two USB 2.0 ports (located on the front panel) for video archive and mouse

usage

Preview and playback

The TVR 20 supports the following preview and playback features:

Built-in DVR calculator for fast recording estimation

Express setup: Located in menu option for quick and easy installation

Express copy: Record video instantly while playing back (USB)

Express Playback: Simply point, click and drag the playback bar to view

previous recordings

Express Search: Use intuitive playback bar with a simple drag & drop

operation

Network

The TVR 20 supports the following network features:

Free eZ-DDNS Service

Remote configuration support from built-in web interface

Gigabit Ethernet interface for remote network viewing and controlling

On-screen PTZ control via mouse or front panel

48BChapter 1: Product introduction

TruVision DVR 20 User Manual 3

Other features

The TVR 20 supports the following additional features:

Auto-detect video mode (PAL or NTSC) on startup

Multiple Control Inputs: mouse/front panel/remote control

Audio recording capabilities*

Multi-language support

Watermark capabilities to identify intentional modifications of recorded data

Rack mountable

Support KTD-405/KTD405-2D keypad control

* Feature not available for all models.

48BChapter 1: Product introduction

4 TruVision DVR 20 User Manual

TruVision DVR 20 User Manual 5

Chapter 2

Installation

Installation environment

When installing your product, consider these factors:

• Ventilation

• Temperature

• Moisture

• Chassis load

Ventilation: Do not block any ventilation openings. Install in accordance with the

manufacturer’s instructions. Ensure that the location planned for the installation

of the unit is well ventilated.

Temperature: Consider the unit’s operating temperature (0 to 40°C, 32 to 104°F)

and noncondensing humidity specifications (10 to 90%) before choosing an

installation location. Extremes of heat or cold beyond the specified operating

temperature limits may reduce the life expectancy of the DVR. Do not install the

unit on top of other hot equipment. Leave 44 mm (1.75 in.) of space between

rack-mounted DVR units.

Moisture: Do not use the unit near water. Moisture can damage the internal

components. To reduce the risk of fire or electric shock, do not expose this unit to

rain or moisture.

Chassis: Equipment weighing less than 15.9 kg (35 lb.) may be placed on top of

the unit.

Unpacking the TVR 20 and its accessories

When you receive the product, check the package and contents for damage, and

verify that all items are included. There is an item list included in the package. If

any of the items are damaged or missing, please contact your local supplier.

49BChapter 2: Installation

6 TruVision DVR 20 User Manual

Items shipped with the product include:

• IR (infrared) remote control

• Two AAA batteries for the remote control

• AC power cord

• USB mouse

• External power supply unit x 1 (Europe and UK)

• DVR

• TruVision DVR 20 Quick Start Guide

• TruVision DVR 20 User Manual (on CD)

HDD capacity

Storage capacity for the TVR 20 varies depending on the model. Refer to Table 1

below for more information.

Table 1: TruVision DVR 20 model types

Model number Description

TVR-2004-500EA TruVision DVR Model 20, 4 ch, 500 GB

TVR-2004-1TEA TruVision DVR Model 20, 4 ch, 1 TB

TVR-2008-500EA TruVision DVR Model 20, 8 ch, 500 GB

TVR-2008-1TEA TruVision DVR Model 20, 8 ch, 1 TB

TVR-2016-500EA TruVision DVR Model 20, 16 ch, 500 GB

TVR-2016-1TEA TruVision DVR Model 20, 16 ch, 1 TB
