Intellinet 560900 Manual de usuario

24-PORT POE+

WEB-MANAGED GIGABIT

ETHERNET SWITCH

WITH 4 SFP COMBO PORTS

USER MANUAL!

Model 560900

INT-560900-01-UM-1013

FCC Warning

This equipment has been tested and found to comply with the limits for a Class A digital device,

pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy. It may cause harmful interference to radio communications if the

equipment is not installed and used in accordance with the instructions. However, there is no guarantee

that interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment to an outlet on a circuit different from that to which the receiver is

connected.

Consult the dealer or an experienced radio/TV technician for help.

CE Warning

This is a Class A product. In a domestic environment,this product may cause radio interference,in

which case the user may be required to take adequate measures.

Contents

Contents............................................................................................................................ 3!

1.!Introduction ............................................................................................................... 5!

1.1 Product Overview............................................................................................5

1.2 General Features ............................................................................................5

1.3 Software Features...........................................................................................5

1.4 Package Contents...........................................................................................6

2.!Hardware!Description................................................................................................. 7!

2.1 Dimensions .....................................................................................................7

2.2 Appearance & Front Panel..............................................................................7

2.3 LED Indicators ................................................................................................8

2.4 Rear Panel ......................................................................................................8

2.5 Hardware Installation ......................................................................................8

3.!Preparation!for!Web!Interface...................................................................................10!

4.!Web!UI!Configuration................................................................................................12!

4.1!Configuration ########################################################################################################## $%!

4.1.1 System Configuration.................................................................................12

4.1.2 Ports...........................................................................................................14

4.1.3 VLAN..........................................................................................................15

4.1.4 Aggregation................................................................................................17

4.1.5 LACP..........................................................................................................17

4.1.6 RSTP .........................................................................................................18

4.1.7 802.1X Configuration .................................................................................20

4.1.8 IGMP Snooping..........................................................................................22

4.1.9 Mirroring.....................................................................................................23

4.1.10 QoS..........................................................................................................24

4.1.11 Filter Configuration...................................................................................26

4.1.12 PoE (Power over Ethernet) Configuration................................................26

4.1.13 Rate Limit Configuration ..........................................................................27

4.1.14 Storm Control...........................................................................................28

4.2 Monitoring ############################################################################################################### "'!

4.2.1 Statistic Overview ......................................................................................30

4.2.2 Detailed Statics ..........................................................................................30

4.2.3 LACP Status ..............................................................................................31

4.2.4 RSTP Status ..............................................................................................31

4.2.4 IGMP Status...............................................................................................32

4.2.5 VeriPHY .....................................................................................................33

4.2.6 Ping............................................................................................................34

4.3 Maintenance ########################################################################################################### "(!

4.3.1 Warm Restart.............................................................................................35

4.3.2 Factory Default...........................................................................................35

4.3.3 Software upload .........................................................................................35

4.3.4 Configuration File Transfer ........................................................................36

!4.3.5 Logout ################################################################################################################## ")!

5.!Specifications............................................................................................................38!

1. Introduction

1.1 Product Overview

This switch is a 24-port 10/100/1000M PoE+ (with four Combo SFP ports) Rackmount Web-

Smart Switch. It supports the IEEE 802.3at Power over Ethernet standard, with a maximum of

390 watts power consumption per system. The switch also provides exceptionally smart web

management features, such as VLAN, QoS, RSTP, IGMP Snooping, LACP, IEEE 802.1X and

Storm Control.

The switch is a standard 19”rackmount design to fit into the rack environment. With these

features, the switch is a superb choice for a medium or large network environment to

strengthen its network connection and efficiency.

1.2 General Features

24-Port 10/100/1000BaseT(X) PoE+ with 4 Combo SFP open slots

IEEE 802.3at, up to 30 W per port

Maximum 390 W power consumption

48 Gbps non-blocking switching performance

8K MAC address table; up to 9K jumbo frames

Web-based configuration and management

802.1Q VLAN, QoS, Link Aggregation, RSTP, IGMP Snooping and IEEE 802.1X

1.3 Software Features

VLAN: 16, VLAN ID: 1 – 4094

Rapid Spanning Tree Protocol

IGMP Snooping V1&V2

LACP/Trunk: up to 8 groups

Quality of Service: up to 4 queues, 802.1p

PoE Control: PoE Port Enabled/Disable, Status

IEEE 802.1X, Source IP Filter

Storm Control: Broadcast, Multicast, Flood Unicast

Port: Port State, Speed/Duplex, Flow Control

Rate Limiting, Port Mirroring

Management: Web GUI, SNMP, password protection, configuration upload/download,

firmware upgrades

1.4 Package Contents!

Before you start to install this switch, verify your package contains the following items:

Switch

Power cord

User manual on CD

Rackmount kit with 8 screws

2. Hardware Description

This section primarily presents the hardware of the switch, physical dimensions, appearance,

front panel, rear panel and LED indicators.

2.1 Dimensions

45 ×440 ×330 mm (H×W ×D)

2.2 Appearance & Front Panel

The front panel of the switch consists of 24 gigabit RJ45 ports. Four of the gigabit RJ45 ports

(Ports1–4) are in combo with the four gigabit SFP open slots. The LED Indicators are also

located on the front panel.

Appearance

Front Panel

Note 1: The SFP ports are shared with normal RJ45 ports 1, 2, 3 and 4. For example: The

RJ45 Port 1 can not be used when SFP Port 1 is linked to a device.

Note 2: Press the Reset button for 5 seconds and the system configuration will be reset to the

default settings.

LED Display

RJ-45 Port

IEEE 802.3at PSE

4 RJ-45/SFP

Combo ports

Reset Button

2.3 LED Indicators

The LED Indicators present real-time information of systematic operation status. This table

provides description of LED status and the meaning.

Table 1-1 LED Indicators

LED

Status

Description

Power on

Power

Off

Switched to Off or disconnected from

power source

Link

Flashing

Data activating

Link / ACT

Off

No device is attached

Port is linked to powered device

PoE

Off

No powered device is connected

2.4 Rear Panel

The 3-pronged power plug is on the rear panel of the switch as shown as below. This is

reserved for AC power input.

2.5 Hardware Installation

The switch is typically mounted in a19”rack, installed in an IT room or other secured

place. Make sure all the power cables, Ethernet cables, mounting screws and such are

prepared and installed as described below, including clearance for adequate ventilation.

Ports1–24 are copper ports, requiring UTP/STP cable. These portsare also PoE ports,

requiring CAT 5/5eor above for the PoE application.

Ports 1–4 are also the combo SFP ports.

Ethernet cable requirements

The wiring cable types for data transmission are as below.

10 Base-T: 2-pair UTP/STP Cat. 3, 4, 5 cable, EIA/TIA-568 100-ohm (max. 100m)

100 Base-TX: 2-pair UTP/STP Cat. 5 cable, EIA/TIA-568 100-ohm (max. 100m)

1000 Base-T: 4-pair UTP/STP Cat. 5 cable, EIA/TIA-568 100-ohm (max. 100m)

The wiring cable types for data transmission and power delivery in any speed should be

Cat5 or above.

SFP Installation

When using the SFP ports, make sure the SFP types are compatible in terms of

transmission distance, wavelength and fiber cable can meet your request.

When connecting an SFP transceiver, plug in the SFP fiber transceiver first. The SFP

transceiver has two plugsfor fiber cable:one is TX (transmit);the other is RX (receive).

Cross-connect the transmit channel at each end to the receive channel at the opposite

end.

Rackmount Installation

Attach the brackets to the device using the screws provided in the rackmount kit.

Mount the device in a19” rack using four rackmounting screws provided by the rack

manufacturer.
