HD Network Dome Camera User’s Manual

Version 1.2.3

Welcome

Thank you for purchasing our network camera!

This user’s manual is designed to be a reference tool for your system.

Please read the following safeguard and warnings carefully before you use this series product!

Please keep this user’s manual well for future reference!

Important Safeguards and Warnings

1．Electrical safety

All installation and operation here should conform to your local electrical safety codes.

The power shall conform to the requirement in the SELV (Safety Extra Low Voltage) and the Limited

power source is rated 12V DC or 24V AC in the IEC60950-1. (Refer to general introduction) Please

note: Do not connect two power supplying sources to the device at the same time; it may result

in device damage! The product must be grounded to reduce the risk of electronic shock.

We assume no liability or responsibility for all the fires or electrical shock caused by improper handling

or installation.

We are not liable for any problems caused by unauthorized modification or attempted repair.

2．Transportation security

Heavy stress, violent vibration or water splash are not allowed during transportation, storage and

installation.

3．Installation

Do not apply power to the camera before completing installation.

Please install the proper power cut-off device during the installation connection.

Always follow the instruction guide the manufacturer recommended.

4．Qualified engineers needed

All the examination and repair work should be done by the qualified service engineers.

We are not liable for any problems caused by unauthorized modifications or attempted repair.

5．Environment

This series network camera should be installed in a cool, dry place away from direct sunlight,

inflammable, explosive substances and etc.

Please keep it away from the electromagnetic radiation object and environment.

Please make sure the CCD (CMOS) component is out of the radiation of the laser beam device.

Otherwise it may result in CCD (CMOS) optical component damage.

Please keep the sound ventilation.

Do not allow the water and other liquid falling into the camera.

Thunder-proof device is recommended to be adopted to better prevent thunder.

The grounding studs of the product are recommended to be grounded to further enhance the reliability

of the camera.

6. Daily Maintenance

Please shut down the device and then unplug the power cable before you begin daily maintenance

work.

iii

Do not touch the CCD (CMOS) optic component. You can use the blower to clean the dust on the lens

surface.

Always use the dry soft cloth to clean the device. If there is too much dust, please use the water to

dilute the mild detergent first and then use it to clean the device. Finally use the dry cloth to clean the

device.

Please put the dustproof cap to protect the CCD (CMOS) component when you do not use the camera.

Dome enclosure is the optical component, do not touch the enclosure when you are installing the

device or clean the enclosure when you are doing maintenance work. Please use professional optical

clean method to clean the enclosure. Improper enclosure clean method (such as use cloth) may result

in poor IR effect of camera with IR function.

7. Accessories

Be sure to use all the accessories recommended by manufacturer.

Before installation, please open the package and check all the components are included.

Contact your local retailer ASAP if something is broken in your package.

Accessory Name

Amount

Network Camera

Quick Start Guide

Installation Accessories Bag

Installation Position Diagram

Table of Contents

1General Introduction ..................................................................................................................1

1.1 Overview........................................................................................................................1

1.2 Features.........................................................................................................................1

1.3 Specifications................................................................................................................2

1.3.1 Performance...........................................................................................................2

2Structure ......................................................................................................................................5

2.1 Dimensions....................................................................................................................5

2.2 Port Description ............................................................................................................6

2.3 Listening.........................................................................................................................8

2.4 Bidirectional talk............................................................................................................9

2.4.1 Device-end to PC-end..........................................................................................9

2.4.2 PC-end to the Device-end....................................................................................9

2.5 Alarm Setup...................................................................................................................9

3Installation..................................................................................................................................12

3.1 Device Installation Introduction ................................................................................12

3.2 Device Installation Steps...........................................................................................12

3.2.1 General Installation.............................................................................................12

3.2.2 Manual Zoom Lens Focus Operation...............................................................15

3.2.3 Side Cable Exit....................................................................................................16

3.2.4 Cable Connection................................................................................................16

3.3 Micro SD Card Installation ........................................................................................17

4Quick Configuration Tool.........................................................................................................19

4.1 Overview......................................................................................................................19

4.2 Operation.....................................................................................................................19

5Web Operation..........................................................................................................................21

5.1 Network Connection...................................................................................................21

5.2 Login and Main Interface...........................................................................................21

6FAQ ............................................................................................................................................23

Appendix Toxic or Hazardous Materials or Elements ...............................................................24

1General Introduction

1.1 Overview

This series network camera combines traditional camera and network video technology into one unit

which integrates A/V data collection and transmission through network without aux devices. It uses

advanced H.264 and MJPEG video compression technology and G.711a audio compression technology,

which maximally guarantee the audio and video quality.

This series network camera enclosure has the strong resistance capacity, which can guarantee the

proper work performance under heavy strike. It supports real-time monitor and listening at the same time.

It supports analog video output and dual-way bidirectional talk.

It can be used alone or used in a network area. When it is used lonely, you can connect it to the network

and then use a network client-end. Due to its multiple functions and various uses, this series network

camera is widely used in many environments such home, office, bank, road monitor and etc.

1.2 Features

User

Management

Different user rights for each group, one user belongs to one group.

The user right shall not exceed the group right.

You can edit each group at anytime.

Storage

Function

Support central server backup function in accordance with your configuration and

setup in alarm or schedule setting

Support record via Web and the recorded file are storage in the client-end PC.

Support built-in Micro SD card.

Support network storage like FTP, support short-time storage when encounter

disconnection.

Alarm

Function

Real-time respond to external local alarm input and video detect as user pre-

defined activation setup and exert corresponding message in screen and audio

prompt(allow user to pre-record audio file)

Real-time video detect: motion detect, tampering.

Can generate an alarm when network abnormal, Micro SD card abnormal event

occurred.

Network

Monitor

Network camera supports one-channel audio/video data transmit to network

terminal and then decode. Delay is within 270ms (network bandwidth support

needed)

Max supports 20 connections.

Adopt the following audio and video transmission protocol: HTTP, TCP, UDP,

MULTICAST, RTP/RTCP, RTSP and etc.

Support web access, widely used in WAN.

Network

Management

Realize network camera configuration and management via Ethernet.

Support device management via web or client-end.

Support various network protocols.

Peripheral

Equipment

Support the on-off alarm device to alarm via the sound or the light.

Power

External power adapter DC12V/AC 24V (Only vandal proof series support AC

24V)

Support PoE.

Warning！

Do not connect two power supplying sources to the device at the same time; it

may result in device damage!

Assistant

Function

Log function

Support PAL/NTSC

Day/Night mode auto switch (electromagnetic ICR switch).

Auto iris adjustment

Built-in IR light. Support IR night vision (For IR Series only).

Backlight compensation: screen auto split to realize backlight compensation to

adjust the bright.

Support electronic shutter and gain setup.

Support 3D NR.

Support video watermark function to avoid vicious video modification.

1.3 Specifications

1.3.1 Performance

Please refer to the following sheets for network camera performance specification.

Model

Parameter

ICIP D3000AVIR-M

System

Main

Processor

High performance DSP

Embedded LINUX

System

Resources

Support real-time network monitoring, local record, and remote operation.

User Interface

Remote operation interface such as WEB, DSS, PSS

System Status

Micro SD card status, bit stream statistics, log, and software version.

Video Parameter

Image Sensor

1/3 inch CMOS

Pixel

2048(H)×1536(V)

Day/Night

Mode

Support day/night mode switch and electromagnetic IR-CUT at the same

time.

Auto Iris

DC drive

Gain Control

Manual/Auto

White Balance

Manual/Auto

BLC

On/Off

Electronic

Shutter

Manual/Auto

It ranges from 1/3 to 1/100000.

Video

Compression

Standard

H.264/H.264H/MJPEG

Video Frame

Rate

PAL:

Main stream (2048*1536@20fps)

extra stream 1(704*576@25fps)

extra stream 2(1280*720@1fps)

Main stream (1920*1080@25fps)

extra stream 1(704*576@25fps)

extra stream 2(1280*720@11fps)

NTSC:

Main stream(2048*1536@20fps)

extra stream 1(704*480@20fps)

extra stream 2(1280*720@1fps)

Main stream(1920*1080@20fps)

extra stream 1(704*480@30fps)

extra stream 2(1280*720@1fps)

Note:

Extra stream 2’s actual frame depends on device max capacity set which

can be adjusted within its range.

Video Bit Rate

H.264H: 40Kbps-8193Kbps. It is adjustable

MJPEG: 40Kbps-16384Kbps adjustable and bit rate is adjustable.

Support customized setup.

Video Flip

Support mirror.

Support flip function.

Snapshot

Max 1f/s snapshot. File extension name is JPEG.

Privacy Mask

Supports max 4 privacy mask zones

Video Setup

Support parameter setup such as bright, contrast.

Video

Information

Channel title, time title, motion detect, tampering, overlay.

Lens

2.7mm～12[email protected]

Lens Interface

¢14. Lens is the default accessories.

Audio

Audio Input

1-channe RCA LINE IN (additional cable required)

Audio Output

1-channe RCA LINE OUT (additional cable required)

Bidirectional

Talk Input

Reuse the first audio input channel

Audio Bit Rate

8kbps 16bit or 16kbps 16bit

Audio

Compression

Standard

G.711a/G.711Mu

Video

Motion Detect

396 (18*22) detection zones; sensitivity level ranges from 0 to 100; area

threshold 0-100.

Activation event, alarm device, audio/video storage, image snapshot, log,

email function and etc.

Privacy Mask

Activation event, alarm device, audio/video storage, image snapshot, log,

email function and etc.

Alarm Input

1-channel input，1-channel output

Record

and

Backup

Record

Priority

Manual>External alarm >Video detect>Schedule

Storage

Management

Support Micro SD card (64G) storage, NAS storage

Network

Wired Network

1-channel wire Ethernet port, 10/100 Base-T Ethernet

Network

Protocol

HTTP,TCP,ARP,RTSP,RTP,UDP,RTCP,SMTP,FTP,DHCP,DNS,DDNS,PP

PoE,IPv4/v6,SNMP,QoS,UPnP,NTP, QoS, 802.1x.

Remote

Operation

Monitor, system setup, log information, maintenance , upgrade and etc

Protocol

PSIA, ONVIF

AUX

Interface

Video Output

1-ch analog output, BNC port (need additional cable)

Reset

Built-in RESET button

IR light

IR distance 20~30 meters (For IR series product only)

General

Parameter

Power

Support AC24V, DC12V and PoE (AC 24V port is inside the device.)

Power

Consumption

General series: below 5W.

IR series: below 7W.

Working

Temperature

-20℃～+60℃

Working

Humidify

≤95%

Dimensions(m

¢151×119

Weight

1.25 kg

Installation

Support various installation modes

Tabla de contenidos

Otros manuales de Cámara de seguridad de ICRealtime

ICRealtime

ICRealtime ICR2200 Manual de usuario

ICRealtime

ICRealtime AVS-B2100 Manual de usuario

ICRealtime

ICRealtime PTZ-3660SIR Manual de usuario

ICRealtime

ICRealtime F Series Manual de usuario

ICRealtime

ICRealtime EL8000IR Manual de usuario

ICRealtime

ICRealtime AVS-4KD8021-IR Manual de usuario

ICRealtime

ICRealtime ICIPD3000 Manual de usuario

ICRealtime

ICRealtime ICIP-3000CCD-W Manual de usuario

ICRealtime

ICRealtime ICIP-B2000 Manual de usuario

ICRealtime

ICRealtime ICIPD2012VIR Manual de usuario

ICRealtime

ICRealtime AVSD2208VF Manual de usuario

ICRealtime

ICRealtime ICIP360L4 Manual de usuario

ICRealtime

ICRealtime F Series Manual de usuario

ICRealtime

ICRealtime ICIP-D2360 Manual de usuario

ICRealtime

ICRealtime ICIP-D2000-IR-B Manual de usuario

ICRealtime

ICRealtime Full HD(HD-SDI) CCTV Box Camera Manual de usuario

ICRealtime

ICRealtime ICIP-D2000-VIR Manual de usuario

ICRealtime

ICRealtime AVS-4MD5110-VIR Manual de usuario

ICRealtime

ICRealtime AVS Series Manual de usuario

ICRealtime

ICRealtime IPMX Series Manual de usuario

ICRealtime

ICRealtime THIP-P2078FM-IR Manual de usuario

ICRealtime

ICRealtime AVS-4MB4012-IR Manual de usuario

ICRealtime

ICRealtime ClearView WiFi-2MP-BL100 Manual de usuario

ICRealtime

ICRealtime PTZN23X4D Manual de usuario

Manuales populares de Cámara de seguridad de otras marcas

Okina USA

Okina USA SIR36-870VF650LP Manual de usuario

Divio

Divio NDR155PA Manual de usuario

Canon

Canon VB-C500D Manual de usuario

Easy Access

Easy Access EasyGuard Manual de usuario

Vivotek

Vivotek FD9389-EHV-v2 Manual de usuario

TUYA

TUYA COSMO W2 Manual de usuario

Eusso

Eusso UNC7500-IR Guía de configuración

urmet domus

urmet domus 1096/204 Manual de usuario

VC VC20 series Manual de usuario

Axis

Axis Q1614 Manual de usuario

ieGeek

ieGeek DD201 Manual de usuario

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manual de usuario

Vicon

Vicon V662-D-1 Instrucciones de funcionamiento

Grundig

Grundig GCH-K0274P Manual de usuario

Lorex

Lorex VANTAGE LBC7032 Manual de usuario

4xem

4xem WPT Manual de usuario

Samsung

Samsung SCV-3082 Manual de usuario

Vitek

Vitek VTC-C544 Manual de usuario
