ICRealtime ICIP360L6 Manual de usuario

IC REALTIME SECURITY SOLUTIONS

ICIP360L6: 360 Degree Series IP Camera

Instruction Manual

Cameras:

HD-IP

I C R E A L T I M E S E C U R I T Y S O L U T I O N S

ICIP360L6 IP Camera Instruction Manual

IC Realtime

3050 N Andrews Ave Ext

Pompano Beach, FL33064

Phone 954.772.5327 • Fax 866.860.3860

Table of Contents

1. Features and Specifications.......................................................................1

a. Overview..........................................................................................1

b. Features............................................................................................1

c. Specifications...................................................................................3

d. Dimensions......................................................................................4

2. Camera Installation ....................................................................................6

a. General Overview...........................................................................6

b. Step by Step Guide .........................................................................7

c. SD Card Installation.......................................................................8

3. Web Operation ...........................................................................................9

a. Network Connection......................................................................9

b. Logging In, and Main Interface ..................................................10

c. EPTZ Controls .............................................................................11

4. Appendices................................................................................................13

a. Toxic or Hazardous Elements ....................................................13

I C R E A L T I M E S E C U R I T Y S O L U T I O N S

Features and Specifications

This section outlines the primary features of the ICRealtimeICIP360L6 IP Camera. It

also outlines basic Architectural and Engineering specifications.

1.a Overview

his IC Realtime series product is an excellent situational awareness IP Camera designed for the security

field. It adopts an embedded Linux operating system to maintain reliable, 24/7 operation. Utilizing

both H.264 video compression and G.711/AAC audio compression technology enables the highest

quality of recorded audio/video, while maintaining the lowest bitrate utilization.

The ICIP360L6 support 6 MegaPixel with an integrated microphone. This IPC is fully suited for full operation

as a standalone device, or can be paired to one of our ICR Network Video Recorders to add a great duration of

recorded video.

The high recording resolution and extreme wide angle lens design makes this IPC well equipped for installation

in various institutions ranging from residential, commercial, governmental, and enterprise environments.

1.b Features

IC Realtime ICIP360L6 IP Cameras all support the following features:

Real-time Monitoring

ICIP360L6 supports 3072*2048 @25FPS (P)/ 3072*2048 @26FPS (N) in Max FPS.

Protection

This product fully supports IK10 and IP66.

Secure Archiving

Chapter

I C R E A L T I M E S E C U R I T Y S O L U T I O N S

Audio Video data is compressed and packaged into a secure and proprietary video format (.dav files). This

bolsters archived video integrity, and prevents vicious data manipulation. Video is also watermarked with

special data for evidentiary purposes.

Compression Format

H.264 video and G.711/AAC audio enables high quality video recording while maintaining the lowest file sizes

possible.

SD Card Storage

As a standalone device, the IPC can hold a 64GB micro SD card suitable for storing video direct from the

camera.

Network Operation

Full system control (including live view, playback, backup, PTZ control, and system configuration) is available

with over the network. Client software is available for both Mac and PC systems.

EPTZ Control

This IPC includes a special de-warping algorithm, enabling users to „Virtually‟ Pan/Tilt/Zoom across a high

resolution image, in order to get the highest visibility and situational awareness from the camera.

1.c Specifications

Model

ICIP360L6 (PAL)

ICIP360L6 (NTSC)

Camera

Image Sensor

1/8” 6 Megapixel CMOS

Effective Pixels

3072(H)x2048(V)

Scanning System

Progressive

Electronic Shutter

Speed

Auto/Manual 1/3~1/10000

Auto/Manual 1/4~1/10000

Min. Illumination

Color: 0. 1LUX/F2.0

S/N Ratio

>52dB

Camera Features

Day/Night

Electromagnetic type IR-CUT, Support day/night mode

switch

Backlight Compensation

BLC

White Balance

Auto/ Manual

I C R E A L T I M E S E C U R I T Y S O L U T I O N S

Gain Control

Auto/Manual

Noise Reduction

Privacy Masking

Up to 4 areas

Lens

Focal Length

1.55mm

Max Aperture

F2.0

Angle of View

185°/185°/185°

Mount Type

Wall-mount, In-ceiling and bracket

Video

Compression

H.264/H.264H/H.264B/MJPEG

Resolution

3072*2048 25FPS

2048*2048 25FPS

2048*1536 25FPS

1600*1200 25FPS

3072*2048 26FPS

2048*2048 26FPS

2048*1536 26FPS

1600*1200 30FPS

Frame

Rate

Main Stream

3072*2048@25fps

Sub Stream

704*576@25fps

Bit Rate

H.264: 24K ~ 12288Kbps, MJPEG: 64K ~ 65536 Kbps

Network

Ethernet

RJ-45 (10/100/1000 Base-T)

Protocol

HTTP,TCP,ARP,RTSP,RTP,UDP,RTCP,SMTP,FTP,DHC

P,DNS,DDNS,PPPOE,IPv4/v6,SNMP,QoS,UpnP,NTP

ONVIF

ONVIF Profile S

Max. User Access

10 users

Smart Phone

iPhone, iPad, Android, Windows Phone

General

Power Supply

DC12V, PoE(802.3af)

Memory Slot

Micro SD

Power Consumption

<11W

Working Environment

-40°C~+60°C, Humidity≤95%

Dimensions

Φ150×50.7mm

Weight

<1kg

Protection

IK10, IP66

I C R E A L T I M E S E C U R I T Y S O L U T I O N S

1.d Dimensions

I C R E A L T I M E S E C U R I T Y S O L U T I O N S

1.e External Cable

NO.

Port

Port Name

Connector

Function Description

AUDIO

OUT

Audio output

port

RCA

Output audio signal to the speakers.

AUDIO IN

Audio input

port

RCA

Input audio signal, receive the analog audio signal from

the sound pick-up.

LAN

Network port

Ethernet

port

Connect to standard Ethernet cable.

I/O

I/O port

Connect I/O port

POWER

Power input

port

Connect DC 12V power, input power.

Port Name

Cable

Number

Cable Port

Name

Function Description

I/O port

ALARM_NO

Alarm output port. It is to output the alarm signal

to the alarm device.

NO：Normal open alarm output port.

This port needs to be used with ALARM_COM

port

ALARM_COM

Alarm output public port.

I C R E A L T I M E S E C U R I T Y S O L U T I O N S

Port Name

Cable

Number

Cable Port

Name

Function Description

ALARM_IN1

Alarm input port 1. It is to receive the on-off signal

from an external alarm source.

ALARM_IN2

Alarm input port 2. It is to receive the on-off signal

from an external alarm source.

GND

Ground port

I C R E A L T I M E S E C U R I T Y S O L U T I O N S

Camera Installation

This section outlines the proper way to mount and install an ICIP360L6 IP Camera.

Suitable methods of installing the IPC include either Ceiling installation, Ground

Installation, or Wall installations. Note that hardware including screws and anchors are

included for the camera installation.

2.a General Overview

Chapter
