Huawei E587u Manual de usuario

Welcome to Huawei

Quick Start Guide

1

Thank you for choosing the HUAWEI Mobile WiFi.

zSupported functions and actual appearance depend on the specific models you

purchased. The following illustrations are provided for your reference only. For details

about the model you selected, consult your service provider.

zThis guide briefly describes the functions of the Mobile WiFi. For details about how to

set management parameters, see Help on the web management page.

zIf the Mobile WiFi is placed in an environment with poor ventilation, it may overheat

after extended use. When the Mobile WiFi overheats, it will switch off or disconnect

from the network automatically to protect itself. If this happens, place the Mobile WiFi

in a well-ventilated location, then restart the Mobile WiFi.

2

Getting to Know Your Mobile WiFi

Packing List

The package should contain the following items. If any of the items are missing or

damaged, contact your local dealer immediately.

Quick Start Guide

Safety Information Mobile WiFi Battery Data cable Charger

Some accessories are optional and are not provided with the modem. To purchase any

optional accessories, contact your local dealer.

3

Connection Scenarios

A Wi-Fi device or computer can be connected to the Internet through the Mobile WiFi. The

actual connection procedure depends on the operating system of the Wi-Fi device or

computer. The connection scenarios illustrated here are for your reference.

Scenario 1: Multi-device access via Wi-Fi Scenario 2: One-device access via USB

4

Scenario 3: Multi-device access via Wi-Fi and USB at the same time

5

Appearance

No. Item

1

Screen

2

WPS button

3

Power button

4

USB connector

Note:

WPS: Wi-Fi protected setup

6

Screen

No. Item

1

Signal strength

2

Network

3

zWi-Fi enabled

zNumber of devices connected

4

Internet connection

5

zNew messages

zNumber of new messages

6

Battery level

7

Roaming status

8

zM: Manual mode

zA: Auto mode

7

Before You Start

Installing the SIM Card and the Battery

Caution: Do not use any SIM card that is not standard

or is incompatible with the Mobile WiFi. Otherwise, the

Mobile WiFi may be damaged.

Install the SIM card in the card slot. Be sure that the SIM card is facing in the right direction,

as shown in figure 2, and then slide the SIM card into the slot.

1

2

1234

8

Installing the microSD Card

Note:

The microSD card is an optional accessory. If a microSD card did not come with your

Mobile WiFi, you may purchase one yourself.

zTo remove the microSD card, press in the

card gently. The microSD card will pop out

for removal.

zDo not remove the microSD card when it is

in use. Doing so may damage the card and

the Mobile WiFi, and data stored on the

card may be lost.

9

Charging the Battery

Note: If the battery has not been used for a long time, it must be charged first.

Method 1: Using the charger

Caution: Only use chargers compatible with the Mobile WiFi and provided by a

designated manufacturer. Use of an incompatible

charger or one from an unknown manufacturer may

cause the Mobile WiFi to malfunction, fail, or could

even cause a fire. Such use voids all warranties,

whether expressed or implied, on the product.

Method 2: Connecting to a PC for charging

Connect the Mobile WiFi to a PC using a

compatible data cable.
