Huawei WS7200 Manual de usuario

Quick Start Guide

Contents

Quick Start Guide ................................................... 1

Guide de démarrage rapide ................................... 16

Schnellstartanleitung ............................................ 31

Guida rapida ....................................................... 46

Snelstartgids ....................................................... 61

Guia de início rápido ............................................. 76

Guía de inicio rápido ............................................. 91

Getting Started (WS7100)

Quick Start Guide

POWER RESETLAN1 LAN2 LAN3WAN

3 4 671 25

RESET button Power button: Press once to power on the device, or

press and hold for at least three seconds to power it o.

WAN port: Connect to optical modems, broadband modems, etc.

LAN port: Connect to a wired Internet device, such as a computer.

Power portH button Indicator

2 3

Getting Started (WS7200)

POWER RESETLAN1 LAN2 LAN3WAN

4 5 78

126

NFC detection area

RESET button Power button: Press once to power on the device, or

press and hold for at least three seconds to power it o.

WAN port: Connect to optical modems, broadband modems, etc.

LAN port: Connect to a wired Internet device, such as a computer.

Power portH button Indicator

2 3 4

7 8

Step 1: Connecting the cables

POWER RESETLAN1 LAN2 LAN3WAN

POWER

LAN

PON

RESET

HUAWEI WiFi AX3

WAN

LAN Internet

Optical/Broadband/cable modem

(from your broadband provider)

•Erect the all antennas upright to ensure optimized Wi-Fi®signal.

•If the indicator stays red, this indicates that the router is not connected to the Internet.

Please refer to "Step 2: Conguring the network settings".

1Connect your mobile phone or computer

to the router’s Wi-Fi network (no

password required).

Check for the Wi-Fi name on the bottom of

the new router.

XXXXXX

Wi-Fi Name: XXXXXX

Wi-Fi

Connected

2Open the browser, you will be

automatically redirected.

( If the page is not displayed

automatically, enter 192.168.3.1) .

Let's get started

Step 2: Conguring the network settings

3Enter your broadband account and password.

If your Internet connection does not require an account and password, please skip to

the next step.

Internet access wizard

Broadband account

Broadband password

VLAN

•If you have forgotten your broadband

account and password, contact your

broadband carrier to obtain a broadband

account and password.

• If you need to congure VLAN on your

network, contact your broadband carrier to

conrm the VLAN parameters, and enable

the VLAN switch on the screen.

4Set a new Wi-Fi name, Wi-Fi password, and admin password for the new router.

Internet access wizard

Prioritize 5 GHz

Wi-Fi network name

Wi-Fi network password

Admin password

Internet access wizard

Conguration complete.

Enable Prioritize 5 GHz: Priority usage of 5 GHz Wi-Fi band over 2.4 GHz band when signal

strength is equal to increase connection speeds.

Indicator

Steady green

Steady red

Flashing

Connected to the network

Not connected to the network

•Loose cable or connect error. Check the cable.

•Broadband network error. Contact your broadband carrier.

The router has detected a pairable device.

When other HUAWEI routers (with H or Hi button) are detected, the

indicator on the HUAWEI WiFi AX3 will ash. When this happens, press

the HUAWEI WiFi AX3's H button. The indicator should flash quickly,

indicating that the pairable device is connecting to the HUAWEI WiFi AX3.

The connection process is complete when the indicator stops ashing.

•If you touched the H button by accident, wait for 2 minutes till the

indicator returns to normal.

•The H button also features WPS functionality.

Manage the router with our mobile app

Scan the QR code to download and install the HUAWEI smart

device management app on your mobile phone or tablet.You can

use the app to manage your router.

Frequently Asked Questions (FAQ)

Q1: What can I do if I encounter any of the following issues when conguring the router?

•If your device did not detect the router's Wi-Fi: Ensure that the router is powered on. Wait for a

moment (till the router is started) and try to search again on your device.

•If you cannot visit the router's conguration page on your device: Ensure that your device is

connected to the router's Wi-Fi network, and then enter 192.168.3.1 in the browser to visit this

page on your device.

•If the page displays "Cable disconnected": Ensure that the router's WAN port is connected to

the modem's LAN port, and the modem has Internet access. Check that all joints are securely

connected and in good contact, and the network cables are in good condition.

If the issue persists, restore the router to the factory settings, and follow the guide to reconnect the

cables and congure the router.

Q2: How do I restore the router to its factory settings?

Connect the router to the power supply and wait until the router completes the startup process.

Use a needle or pin to press the RESET button on the router for more than two seconds until the

indicator light goes out. Wait for the router to complete the restart process. When the indicator

turns red, this indicates that the router has been restored to its factory settings.

If the router has been factory reset, you need to congure it again.
