release notes

hp StorageWorks

ha-fabric manager

Product Version: FW V05.01.00-24/HAFM SW V07.01.00-09

Sixth Edition (June 2003)

Part Number: AV–RSNXF–TE/958–000288–004

These Release Notes contain late-breaking and supplemental information for the

HP StorageWorks High Availability Fabric Manager (HA-Fabric Manager).

For the latest version of these Release Notes and other HA-Fabric Manager documentation,

access the HP storage website at:

http://www.hp.com/country/us/eng/prodserv/storage.html

2HA-Fabric Manager Release Notes

Hewlett-Packard Company makes no warranty of any kind with regard to this material, including, but not limited to,

the implied warranties of merchantability and fitness for a particular purpose. Hewlett-Packard shall not be liable for

errors contained herein or for incidental or consequential damages in connection with the furnishing, performance,

or use of this material.

This document contains proprietary information, which is protected by copyright. No part of this document may be

photocopied, reproduced, or translated into another language without the prior written consent of Hewlett-Packard.

The information contained in this document is subject to change without notice.

Microsoft®, Windows®, Windows XP®, and Windows 2000® are U.S. registered trademarks of Microsoft

Corporation.

UNIX® is a registered trademark of The Open Group.

Hewlett-Packard Company shall not be liable for technical or editorial errors or omissions contained herein. The

information is provided “as is” without warranty of any kind and is subject to change without notice. The warranties

for Hewlett-Packard Company products are set forth in the express limited warranty statements for such products.

Nothing herein should be construed as constituting an additional warranty.

Printed in the U.S.A.

HA-Fabric Manager Release Notes

Sixth Edition (June 2003)

Part Number: AV–RSNXF–TE/958–000288–004

About this Document

3HA-Fabric Manager Release Notes

About this Document

These Release Notes describe the contents of the HP StorageWorks high

availability fabric manager software kit, and any last-minute additions or notes on

the configuration or use of HAFM software.

Be sure to read these notes before installing the HAFM. This information is

periodically updated and available on the World Wide Web at:

http://www.hp.com/country/us/eng/prodserv/storage.html.

This section describes the content reflected in this document, including:

■Release Notes Information, page 4

■Intended Audience, page 5

■Other HAFM Documentation, page 5

■CD-ROM Directory Structure, page 5

■Software Version 07.01.00-09, page 6

■Important Information, page 7

■Known Issues, page 13

Release Notes Information

4HA-Fabric Manager Release Notes

Release Notes Information

These Release Notes cover the following major topics:

■Some IP Addresses must be Avoided, page 13

■Show Routes “Select a Source Node” Panel may be Blank, page 13

■Director and Edge Switch may be Displayed With WWN even if Display

Option “Product Name” is Selected, page 13

■“Port Properties” Option may be Unavailable in Node List View, page 14

■Port Diagnostics on All Ports is not Available When All Ports of an Edge

Switch are not Installed and Enabled, page 14

■Open Systems Management Server, page 14

■Multiple FC HBA Ports in Separate Zones, page 14

■CTP Controls Port Lights, page 15

■Support for Speed Auto-Negotiate, page 15

■Regressing to an Earlier HAFM Code, page 15

■Installing HAFM on an Existing HP EFCM or SDCM Server, page 15

■Replacing CD-ROM with ZIP Drive, page 16

■Losing LAN Connection to the HAFM Server Before Logging in to the

HAFM Application, page 16

■Effect of No LAN Connection to HAFM Server During Boot Up, page 16

Intended Audience

5HA-Fabric Manager Release Notes

Intended Audience

This document is intended for customers who purchased the HP StorageWorks

High Availability Fabric Manager.

Other HAFM Documentation

In addition to this guide, HP provides corresponding information:

■HP StorageWorks HAFM Server for Windows 2000 Installation Guide,

AA-RT4KC-TE

■HP StorageWorks HA-Fabric Manager User Guide, AA-RS2CC-TE

■HP StorageWorks Director and Edge Switch Glossary, AA-RU5JA-TE

CD-ROM Directory Structure

The HAFM software kit includes one CD. The HP StorageWorks HA-Fabric

Manager Documentation and Software CD, which contains the files necessary to

install the HAFM applications. The HP StorageWorks HA-Fabric Manager

Documentation and Software CD also contains the following items at the root

level directory:

■HAFM_ServerInstall.exe – (Install file for HAFM applications)

■version.txt – (contains the version number of the HAFM applications)

The hpClients directory is also at the root level. This directory contains the

remote client install files for the operating system platform noted by the name of

the directory in which it resides.

■Unix – (directory containing the remote client install file for UNIX

platforms)

—aix – (directory containing the remote client install file for AIX)

hpClientInstall.bin—(the remote client install file for AIX)

—hpux – (directory containing the remote client install file for HPUX)

hpClientInstall.bin—(the remote client install file for HPUX)

—Linux – (directory containing the remote client install file for Linux)

hpClientInstall.bin—(the remote client install file for Linux)

Software Version 07.01.00-09

6HA-Fabric Manager Release Notes

—Solaris – (directory containing the remote client install file for Solaris)

hpClientInstall.bin—(the remote client install file for Solaris)

■Windows – (directory containing the remote client install file for Windows)

hpClientInstall.exe—(the remote client install file for Windows)

■Docs

— AA-RT4KC-TE – (HP StorageWorks HAFM Server for Windows 2000

Installation Guide)

— AA-RS2CC-TE – (HP StorageWorks HA-Fabric Manager User Guide)

— AA-RU5JA-TE – (HP StorageWorks Director and Edge Switch Glossary)

Software Version 07.01.00-09

HA-Fabric Manager 07.01.00-09 is the latest version of the HA-Fabric Manager

software (as of this date) and is contained on the HP StorageWorks HA-Fabric

Manager Documentation and Software CD (Part Number 516-000024-710). The

latest firmware is also available on the HP website at:

http://www.hp.com/country/us/eng/prodserv/storage.html.

After installing Version 07.01.00-09 on the HAFM server, all remote clients

running down-level versions of HAFM are required to re-install the client

application. When logging in to the HAFM server via the remote client, an error

message displays stating that the new version must be installed. Follow the

instructions to install the new version of the remote client.

Important Information

7HA-Fabric Manager Release Notes

Important Information

This section describes important information related to the Edge Switch 2/24,

Edge Switch 2/32, Director 2/64, and Director 2/140.

HAFM Server for Windows 2000 Setup Requirements

The HAFM Sever for Windows 2000® requires specific setup before installing

the HAFM software. These requirements include first restoring the notebook PC

to Windows 2000, because the notebook is delivered with Windows XP®

installed, which is not compatible with the HAFM software. Other setups include

installing the Windows Internet Information Server (IIS), and configuring the Web

Server and FTP Server. Refer to the HP StorageWorks HAFM Server for Windows

2000 Installation Guide for complete step-by-step instructions for setting up the

HAFM server for Windows 2000.

HAFM and Firmware Version Compatibility

Table 1 lists the minimum version of HAFM that can run with the various versions

of firmware for the directors and edge switches.

Table 1: HAFM and Firmware Compatibility

Firmware Version HAFM Version (Minimum)

01.01.02 04.00.01 (HP EFCM)

01.02.02-06 04.01.02-14 (SDCM)

01.03.00-35 04.02.00-40 (HP EFCM)

01.04.00-01 04.02.00-40 (SDCM)

02.00.00-33 06.00.00-45 (HP EFCM)

02.00.02-01 06.00.02-06

04.01.02-04 06.03.01-05

05.01.00-24 07.01.00-09

Important Information

8HA-Fabric Manager Release Notes

Upgrading to an Earlier Version of Firmware

Upgrading to firmware version 05.01.00-24 is nondisruptive to attached devices.

The edge switch or director is not required to be offline before performing an

upgrade operation. Limitations to upgrades are clearly identified if there are any

limitations to performing the operation.

Before upgrading firmware, it is highly recommended that you back up the edge

switch or director configuration in the event that a failure should occur. Refer to

the switch or director Product Manager user guide for more information.

Embedded Web Server (EWS) also provides an option to print or save product

configuration to a file. Refer to the HP StorageWorks Embedded Web Server User

Guide for more information.

Before upgrading the Director 2/64 or Director 2/140 to version 05.01.00-24,

execute a CTP switchover to assure that the backup CTP card is fully functional.

To execute a CTP switchover, perform the following steps:

1. From Product Manager Hardware view, verify that an amber LED indicator

does not display for either CTP card.

2. Right-click on a CTP card and choose Switchover from the menu.

Note: The switch or director will lose its Ethernet connection for a short period

during the switchover process.

3. Upgrade firmware to version 05.01.00-24.

All products must be running firmware version 04.00.00 or higher before

upgrading to version 05.01.00-24. If a switch or director is operating with a

firmware level below 04.00.00, you must upgrade to version 04.00.00 or higher

before installing version 05.01.00-24.

All products must be running version 02.00.00 or higher before upgrading to

version 04.01.02-04. Upgrading to version 04.01.02-04 from version 02.00.00 or

higher is nondisruptive to attached devices.

Firmware that predates the 01.03.00 or 01.04.00 firmware release must first be

upgraded to a 01.03.xx or 01.04.xx firmware version, and then upgraded to

version 02.00.00 or higher, before the upgrade to version 04.01.02-04 can be

completed.

Important Information

9HA-Fabric Manager Release Notes

Considerations for Downgrading the Version of Firmware

Directors and edge switches are not required to be offline before performing a

firmware downgrade operation. Limitations to downgrades are clearly identified if

there are any limitations to performing the operation.

Before downgrading firmware, it is highly recommended that you back up the

edge switch or director configuration in the event that a failure should occur. Refer

to the switch or director Product Manager user guide for more information.

Embedded Web Server (EWS) also provides an option to print or save product

configuration to a file. Refer to the HP StorageWorks Embedded Web Server User

Guide for more information.

Downgrading directly to a version prior to 04.00.00 from version 05.01.00-24 is

not allowed. To downgrade to a version before 04.00.00, you must first downgrade

to version 04.YY.ZZ.

Note: The Director 2/140 and Edge Switch 2/24 cannot be downgraded below

version 04.01.00.

Downgrading directly to a version prior to 02.00.00 from version 04.YY.ZZ is not

allowed. To downgrade to a version before 02.00.00, you must first downgrade to

version 02.YY.ZZ.

Firmware downgrades should not be performed using EWS and Microsoft®

Internet Explorer version 5.00.3315.1000x. If this operation is performed, the

download operation may not complete and may eventually time-out leaving the

switch with the previous version of firmware.

HAFM Upgrade Required for Firmware Version 05.01.00-24

If you are using the HAFM server to manage the Director 2/140, Director 2/64,

Edge Switch 2/32, Edge Switch 2/24, and/or Edge Switch 2/16, and they are

running firmware version 05.01.00-24, you need to upgrade HAFM to version

07.01.00-09 (minimum). For more information on upgrading software versions,

refer to the HP StorageWorks HA-Fabric Manager User Guide. The features of

this software version are detailed in the accompanying manuals listed in section

“Other HAFM Documentation”.

Important Information

10 HA-Fabric Manager Release Notes

Open Trunking Feature is Not Available in Current Release

The Open Trunking feature is not available in Firmware Version 05.01.00-24.

Open Trunking feature will be available in a future release.

Zoning is Disabled by Default

The default zone on the Edge Switch 2/24, Edge Switch 2/32, Director 2/64, and

Director 2/140 is disabled by default. Zoning must be configured in order for any

devices connected to the switches to communicate.

Hard Zoning

Hard Zoning is a security enhancement in firmware version 05.01.00-24 that

prevents ports from accessing devices outside their zones. Hard Zoning is enabled

by default when using firmware version 05.01.00-24 or greater and cannot be

disabled. All HP-approved host bus adapters (HBAs) limit access to devices

within their zones, so you will not see a change in fabric behavior unless you are

using nonstandard HBAs. Hard Zoning improves security against intruders that

load nonstandard HBA drivers.

Hard Zoning is compatible with legacy zone definitions, including World Wide

Name (WWN) and port zoning. You can use your existing zones and zone sets

without any changes. There are no changes to the zoning interfaces, so you do not

need to modify your zone management practice, documentation, or retrain Storage

Area Network (SAN) administrators.

Hard Zoning controls access at the ingress port. When a port attempts to send a

frame to a destination outside its zones, the frame is blocked. A Class 2 frame will

be fabric rejected, and a Class 3 frame will be dropped.

Zoning Change RSCN Control

Normally, when a zone set is activated, a fabric format domain Register State

Change Notification (RSCN) is sent to all devices in the fabric. With firmware

version 05.01.00-24. you can disable these RSCNs from being sent. This is done

using the Suppress RSCNs on zone set activations check box on the Configure

Switch Parameters dialog box.

Otros manuales para 316095-B21 - StorageWorks Edge Switch 2/24

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cambiar de HP

HP ProCurve 1600M Manual de usuario

HP 6125G Manual de usuario

HP 6125G Manual de instalación

HP ProCurve Switch xl Module Manual

HP ProCurve 1600M Manual de usuario

HP ProCurve 8212zl Series Manual de usuario

HP ProCurve 3500yl Series Manual del propietario

HP 316095-B21 - StorageWorks Edge Switch 2/24 Manual de instrucciones

HP A7533A - Brocade 4Gb SAN Switch Base Manual de servicio

HP A3724A - SureStore E Hub S10 Manual de usuario

HP 3600 v2 Series Manual de usuario

HP 6125XLG Manual de usuario

HP ProCurve 6120G/XG Manual de usuario

HP FlexFabric 12900E series Manual de instalación

HP ProCurve 2510 Manual de usuario

HP S7500E Manual de instrucciones

HP A7340A - Surestore FC 1Gb/2Gb Switch 16B Manual de usuario

HP ProCurve 2610-48 Manual de usuario

HP 316095-B21 - StorageWorks Edge Switch 2/24 Manual de instrucciones

HP FlexNetwork 5130 HI series Manual de instalación

HP 316095-B21 - StorageWorks Edge Switch 2/24 Guía de inicio rápido

HP P2361AA #ABA Manual de usuario

HP HPE 5140 Instrucciones de montaje

HP HP 2610 Series Manual de usuario

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario
