Find the HP J4908A at our website: Click HERE

www.hp.com/go/hpprocurve

hp procurve switch

gl modules

installation guide

HP ProCurve Switch gl Modules

Installation Guide

L.P.The information contained herein is subject to change

without notice.

This document contains proprietary information, which is

protected by copyright. No part of this document may be

photocopied, reproduced, or translated into another

language without the prior written consent of Hewlett-

Packard.

Publication Number

5990-3090

November 2003

Edition 1

Applicable Products

HP ProCurve Switch 10/100-TX gl Module (J4862B)

HP ProCurve Switch 100/1000-T gl Module (J4863A)

HP ProCurve Switch Gigabit Transceivers gl Module

(J4864A)

HP ProCurve Switch 100-FX gl Module (J4892A)

HP ProCurve Switch mini-GBIC gl Module (J4893A)

HP ProCurve Gig-T/GBIC gl Module (J4908A)

Disclaimer

HEWLETT-PACKARD COMPANY MAKES NO WARRANTY

OF ANY KIND WITH REGARD TO THIS MATERIAL,

INCLUDING, BUT NOT LIMITED TO, THE IMPLIED

WARRANTIES OF MERCHANTABILITY AND FITNESS

FORA PARTICULAR PURPOSE. Hewlett-Packard shall not

be liable for errors contained herein or for incidental or

consequential damages in connection with the furnishing,

performance, or use of this material.

The only warrantiesfor HP products and services are set

forth in the express warranty statements accompanying

such products and services. Nothing herein should be

construed as constituting an additional warranty. HP shall

not be liable for technical or editorial errorsor omissions

contained herein.

Hewlett-Packard assumes no responsibility for the use or

reliability of its software on equipment that is not furnished

by Hewlett-Packard.

Warranty

See the Customer Support/Warranty booklet included with

the product.

A copy of the specific warranty terms applicable to your

Hewlett-Packard product and replacement parts can be

obtained from your HP salesand service office or

HP-authorized dealer.

Hewlett-Packard Company

8000 Foothills Boulevard, m/s 5552

Roseville, California 95747-5552

http://www.hp.com/go/hpprocurve

Contents

Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Installing the gl Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Installing the Module in an Unused Slot . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Installation Precautions: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Installation Procedures: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Installing or Removing the mini-GBICs . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Verifying the Moduleis Installed Correctly . . . . . . . . . . . . . . . . . . . . . . . 8

Connecting the Network Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Verifying the Network Connections Are Working . . . . . . . . . . . . . . . . 12

Customizing the Port Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Replacing orRemoving a Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Resetting the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Reasons for Resetting the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Methods ofResetting the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Switch and Module LED Error Indicators: . . . . . . . . . . . . . . . . . . . . . . . 17

Diagnostic Tips: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Customer Support Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Environmental . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Lasers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Twisted-Pair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Fiber-Optic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Twisted-Pair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Fiber-Optic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

iii

Mode Conditioning Patch Cord for Gigabit-LX . . . . . . . . . . . . . . . . . . . . . . 25

Installing the Patch Cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Recommended Patch Cords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

EMC Regulatory Statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

U.S.A. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Canada . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Australia/New Zealand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Japan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Korea . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Taiwan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

European Community Declaration of Conformity . . . . . . . . . . . . . . . . 28

Descriptions

HP ProCurve Switch gl Modules

For the HPProCurve Series 4100gl Switches

Descriptions. The HPProCurve Switch gl Modules are components that you

can add to an HP ProCurve gl switch to provide a variety of network connec-

tivity options. The following modules are available as of this printing:

Module Description

HP ProCurve Switch



















































  











 





24 twisted-pair ports with RJ-45

10/100-TX gl Module connectors for 10 Mbps or 100

(J4862B)* Mbpsoperation over 100-ohm

unshielded (UTP) or shielded (STP)

twisted-pair cable -- all ports have

the HP Auto-MDIX feature.

HP ProCurve Switch









 











6 twisted-pair ports with RJ-45

100/1000-T gl Module connectors for 1000 Mbps

(J4863A) (Gigabit) or 100 Mbps operation

over Category 5 orbetter 100-ohm

UTP or STP cable (category 5E

recommended for Gigabit) -- all

ports have the IEEE 802.3ab Auto

MDI/MDI-X feature.

HP ProCurve Switch

Gigabit Transceiver

gl Module (J4864A)



3 transceiver slots for installing

any of the supported HP ProCurve

Transceivers†.

†Supported HP ProCurve Transceivers (as of this printing):

• 100-FX Transceiver (J4853A) • 100/1000-T Transceiver (J4834A)

• Gigabit Stacking Transceiver (part of the HP ProCurve Switch

Gigabit Stacking Kit -- J4116A)

• Gigabit-SX Transceiver (J4131A or J4131B)

• Gigabit-LX Transceiver (J4132A)

HP ProCurve Switch

mini-GBIC gl Module

(J4893A)*

















 











6 mini-GBIC slots for installing any

of the supported HP ProCurve

mini-GBICs**.

** Supported HP ProCurve mini-GBICs (as of this printing):

• Gigabit-SX LC mini-GBIC (J4858A) • Gigabit-LX LC mini-GBIC (J4859A) • Gigabit-LH LC mini-GBIC (J4860A)

* These modules require switch software version G.05.02 or later to be installed in the switch.

Continued on the next page.

Features

Contact your HP-authorized networking products reseller or your HP repre-

sentative for information on availability of other modules, transceivers, and

mini-GBICs. You can also visit the HP networking products Web site at

http://www.hp.com/go/hpprocurve to get more information.

Features

Example: The HP ProCurve 24-Port 10/100-TX gl Module

HP ProCurve Switch

100-FX MTRJ

gl Module (J4892A)††

12 100-FX ports with MT-RJ

connectors for 100 Mbps

networking over multimode

fiber-optic cable.

HP ProCurve Gig-T/

mini-GBIC gl Module

(J4908A)** ++

20 ports of 10/100/1000Base-T with

2 ports of mini-GBIC gigabit

Ethernet.**.

** Supported HP ProCurve mini-GBICs (as of this printing):

• Gigabit-SX LC mini-GBIC (J4858A) • Gigabit-LX LC mini-GBIC (J4859A) • Gigabit-LH LC mini-GBIC (J4860A)

†† This module requires switch software version G.07.01 or later to be installed in the switch.

++ This module requires switch software version G.07.40 or later to be installed in the switch.

Module Description

         





 

 

  



























































  











 





retaining screw

network ports

Link and Mode LEDs

(one pair per port)



Features

The HP ProCurve Switch gl Modules have the following features:

■ auto-enabled ports—the ports are all configured to be ready for network

operation as soon as a viable network cable is connected.

■ auto-configuration—a default configuration is applied to the module

when the switch is powered on and the module passes self test; this default

configuration works well for most network installations.

■ LEDs that provide information on the link status, network activity,

connection bandwidth, and communication mode (half or full duplex).

■ “hot swap modules” operation—you can add a module or replace a

module without havingto shut down the switch (changing the module

type in a given slot does require a switch reset).

■ “hot swaptransceivers and mini-GBICs” operation—you can add, replace,

or change the type of any of the transceivers and mini-GBICs that you use

in the Gigabit Transceiver gl Module and mini-GBIC gl Module, without

having to first remove the module, and without having to shut down the

switch.

■ the ports on the 10/100-TX gl Modulehave the HP Auto-MDIX feature,

and the ports on the 100/1000-T gl Module have the IEEE 802.3ab Auto

MDI/MDI-X feature. These features operate the same way and allow you

to use either straight-through orcrossover twisted-pair cables for all the

twisted-pair network connections. Please see the note on “Automatic

Cable Sensing” on page 11.

■ standards adherence:

• the 10/100-TX gl Module is compatible with the IEEE 802.3

10Base-T and IEEE 802.3u 100Base-TX standards

• the 100/1000-T gl Module is compatible with the IEEE 802.3ab

1000Base-T and IEEE 802.3u 100Base-TX standards

• the ports on the transceivers that are installed in the Gigabit Trans-

ceiver gl Module are compatible with their appropriate standards. See

the Installation Guidethe comes with the transceivers.

• the ports on the Gigabit-SX and Gigabit-LX mini-GBICs that are

installed in the mini-GBIC gl Module are compatible with the IEEE

802.3z Gigabit-SX and Gigabit-LX standards respectively.

• the ports on the 100-FX MTRJ gl Module are compatible with the IEEE

802.3u 100-FX standard.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cambiar de HP

HP ProCurve 5372xl Manual de usuario

HP ProCurve 1600M Manual de usuario

HP ProCurve 4108gl Bundle Manual de usuario

HP StorageWorks 2/32 - SAN Switch Manual de usuario

HP 376227-B21 - ProLiant InfiniBand 4x Fabric Copper... Guía de referencia rápida

HP StorageWorks SN6000 Manual de usuario

HP 6125G Manual de instalación

HP Compaq Presario,Presario 1910 Instrucciones de uso

HP Q.11.XX Manual de usuario

HP 1920 Gigabit Ethernet Switch Series Manual de usuario

HP 10500 series Manual de usuario

HP GbE2c - Blc Layer 2/3 Fiber SFP Option Manual de usuario

HP A5500 SI Switch Series Manual de usuario

HP StorageWorks 2/16 - SAN Switch Manual de usuario

HP A7340A - Surestore FC 1Gb/2Gb Switch 16B Manual de usuario

HP ProCurve Switch 2650 Manual de usuario

HP ProCurv J8768A Manual

HP 1810 series Instrucciones de uso

HP 5920 Manual de instalación

HP JE069A Instrucciones de uso

HP aruba 9300-32D Series Manual de usuario

HP 5300 Manual de usuario

HP StorageWorks 9100 - Extreme Data Storage... Manual de usuario

HP 8/80 SAN series Manual de usuario

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario

HP invent ProCurve J4908A Manual de usuario

Manuales populares de Cambiar de otras marcas
