HP StorageWorks D2D Backup System

release notes

Part number: EH880-90963

1st edition: February 2008

Description

This document outlines the functional changes and defect ﬁxesfortheHPStorageWorksD2DBackup

System introduced between ﬁrmware kn77 (001.395) and kn7B (001.559).

Update recommendation Recommended

Supersedes These release notes (part number EH880-90963) supersede those dated September 2007.

Product models

EH880A -- HP D2D110 Backup System

EH923A -- HP D2D110 Backup System with Data Protector Express SW Kit

EH884A -- HP D2D120 Backup System

EH924A -- HP D2D120 Backup System with Data Protector Express SW Kit

EH881A -- HP D2D110 Backup Sys/Ultr 448 Tape Drive

EH885A -- HP D2D120 Backup Sys/Ultr 920 Tape Drive

DW085A -- Ultrium 448 SAS Tape Drive for D2D110

EH847A -- Ultrium 920 SAS Tape Drive for D2D120

Operating systems

Cross operating system (BIOS, Firmware, Diagnostics, etc.)

Languages

Chinese (Simpliﬁed)

Chinese (Traditional)

English

French

German

Greek

Italian

Japanese

Korean

Polish

Portuguese

Russian

Spanish

Enhancements

•Increased maximum number of emulated target devices from four to six.

•Changed default emulation type for tape drive devices from Ultrium 2 to Ultrium 3.

•Added Ultrium 4 to tape attach support matrix.

•Included more error messages that generate email alerts.

HP StorageWorks D2D Backup System release notes 3

Fixes

•Firmware in attached tape drives can be updated.

Prerequisites

Requires Microsoft Internet Explorer 6.x or higher or Mozilla Firefox 1.5 or 2.x.

Installation instructions

NOTE:

During the update the HP D2D Backup System will reboot. After the update all conﬁguration settings

on the HP D2D Backup System will be retained.

1. Save the ﬁrmware image ﬁle on a server or PC that is connected to the same subnet as the HP

D2D Backup System.

2. From a Web Browser, launch the HP StorageWorks D2D Backup System Web Management Interface

by typing in the IP address of the HP D2D Backup System to be updated.

3. Ensure that there are no current or scheduled backup jobs that will occur during the ﬁrmware update

period, because the HP D2D Backup System will reboot during the update process.

4. Log in and navigate to the Firmware Page.

5. Select the Browse button in order to locate the ﬁrmware image on the host system.

6. Select Upload update the ﬁrmware.

NOTE:

Do NOT navigate away from the ﬁrmware page.

7. The LEDs on the HP D2D Backup System will ﬂash a ﬁrmware update pattern (alternate amber

and green).

8. After a few seconds the HP D2D Backup System will reboot, completion of the reboot is indicated by

all LEDs returning to current system status (generally all green).

9. Reconnect to the Web Management interface to observe that the upgrade has completed successfully.

10. Manually log back on to the HP D2D Backup System iSCSI targets via the iSCSI initiator from each

system. Use the HP D2D Backup System as a backup target. Alternatively, if targets have been made

persistent (restore automatically on reboot), simply reboot the host systems.

11 . To make use of new autoloader functionality any previously conﬁgured autoloaders should have

their emulation type changed to the new HP 1x8 G2 Autoloader emulation. To do this, use the

devices page from the web management interface.

Determining current version

From a Web Browser, launch the HP StorageWorks D2D Backup System Web Management Interface

by typing in the IP address of the HP D2D Backup System to be updated. Navigate to the Firmware

Pagewhich displays the current ﬁrmware version.

Effective date

February 11, 2008

4
