Overview

Network Configuration Utility and Scripting

The HP Network Configuration Utility (NCU) enables configuration of network adapters and teams of

network adapters. The scripting feature of the utility provides the ability to perform adapter configuration

using a batch process.

This guide provides information about using the HP Network Adapter Scripting Utility to configure HP

adapters.

Scripting functionality

Scripting functionality provides the capability to configure a target system based on configuration

information saved from a source server. The target system is not required to be identical to the source

server. The configuration of the source server may not be duplicated in its entirety on the target system.

Both adapters and teams of adapters can be configured on the target system. When scripting is run, the

adapter properties specified in the data file from the source server are used to modify the configuration of

the adapters on the target system (see "Preliminary scripting information (on page 5)" for details about

running the scripting utility).

Scripting 5

Scripting

Preliminary scripting information

When using scripting to configure target systems, adapters are identified by their relative order in the

system. The relative order is determined by the following properties.

•Slot and port order for adapters in non-HP BladeSystem configurations

•Enclosure switch bay number and switch port order for adapters in HP BladeSystem configurations

Adapters embedded on the system board are assigned the lowest numbers, followed by adapters ordered

by their slot or switch bay number with the lowest slot or switch bay number first. Multiport adapters are

ordered by ascending port or switch port number within each slot.

Order of adapters on target systems

Adapters on the target system are configured to match the corresponding adapter number on the source

server.

•The first adapter on the target system is configured using data from the first adapter on the source

server.

•The second adapter on the target system is configured using data from the second adapter on the

source server, and so on.

•If the target system has more adapters than the source server, then the extra adapters retain their

current settings.

•If the target system has fewer adapters than the source server, data for additional adapters on the

source server is ignored.

Multifunction parameters on target systems

To transfer multifunction (TCP/IP Offload Engine and iSCSI) parameters the following conditions apply:

•The multifunction adapter must be located in the same relative position on the target server as on the

source server.

•If these multifunction parameters are assigned to an adapter that does not support iSCSI or TOE,

they are ignored.

•If an adapter supports multifunction parameters but the parameters are not assigned, the existing

settings are left unchanged.

•Some properties are not configurable if an adapter has FlexNIC enabled.

Multifunction adapter limitations

•For systems running Windows Server 2003 (SP1) or Windows Server 2003 x64 (SP1), you must

upgrade to Service Pack 2 or later.

Scripting 6

•TOE will not work with the following features enabled: Windows Firewall; Internet Protocol security

(IPsec); Internet Protocol Network Address Translation (IPNAT); third-party firewalls; and NDIS 5.1

intermediate drivers. Download article number KB912222

(http://support.microsoft.com/kb/912222/en-us) from the Microsoft website for more information.

•TOE and RSS are incompatible on NetXen adapters. If RSS is already enabled and then you enable

TOE, RSS is automatically disabled even though it may appear to be enabled. Likewise, if you

enable TOE after RSS, RSS becomes disabled.

•TOE is disabled system wide by default in the operating system. TOE must be enabled system-wide

for it to work on the adapter itself. To enable TOE in the Windows Server 2008 operating system,

execute the "netsh int tcp set global chimney=enabled" command.

•Some HP NC-Series NetXen adapters require a TOE license. See the NCDE Release Notes for

installation instructions and a list of adapters that require a TOE license.

•Some properties are not configurable if an adapter has FlexNIC enabled.

Teams on target systems

The target system is configured with the same number of teams that were present on the source server.

•Teams are created on the target system consisting of the same relative adapters that were teamed on

the source server. For example, if adapters 3 and 5 were teamed on the source server, then that

teaming information is saved in the data file, and adapters 3 and 5 are teamed on the target

system.

•In general, the adapters on the team on the target system do not have to be the same type of

adapters that were teamed on the source server. However, some adapters cannot be teamed and if

an attempt is made to form a team with invalid combinations of adapters an error occurs. For

example, teams with different speed capabilities cannot be teamed on a load balancing team.

•An error occurs in the configuration if the adapters forming the team on the source server are not

present on the target system. For example, if adapters 3 and 5 are teamed on the source server, but

the target system has only four adapters, an error is reported and the configuration is not applied.

•When teams are configured on the target system, the team properties are set to the values read from

the data file for the corresponding team on the source server. Properties not specified in the data file

(and properties specified with invalid data values) are configured using their default settings.

•If no teams are configured on the source server, no teaming information is written to the data file

and configuration of the target system consists only of configuring individual adapters.

Teaming limitations

•Only the following team types are supported on FlexNIC-enabled NC522m adapters.

oNetwork Fault Tolerance (NFT)

oNetwork Fault Tolerance with Preference Order (NFT-PO)

oTransmit Load Balancing with Fault Tolerance (TLB)

oTransmit Load Balancing with Fault Tolerance and Preference Order (TLB-PO)

•The NCU supports two or more FlexNIC-enabled adapters on the same port to be members of the

same team.

Scripting 7

•Any changes to a teaming configuration that has an iSCSI-booted device present requires a system

reboot.

•In Transmit Load Balancing, Switch-assisted Load Balancing, and 802.3ad with Fault Tolerance

teams, the adapters must be capable of a common speed. If you try to add an adapter to one of

these existing team types and that adapter is not capable of a common speed with the other

adapters in the team then the team option is disabled.

•All server adapters in a team must be on the same broadcast domain.

•To ensure proper network functioning, be sure the protocol information for each teamed server

adapter is complete. Do not depend on a DHCP server to assign an IP Address as the results may be

undependable. Be sure that you have properly configured the protocols for the Virtual Miniport that

represents the team. To do this on Windows systems, go to Network Connections to select the Virtual

Miniport and then select File>Properties.

•If the properties of the server adapters are not supported by all team members, those properties may

be disabled for all the adapters in the team. The NCU displays a message listing the properties that

have been disabled.

TOE teaming limitations

The following are limitations for a TOE-enabled team:

•TOE and RSS teaming are not supported on Windows Server 2008 and Windows Server 2008 x64

in this release.

•For systems running Windows Server 2003 (SP1) or Windows Server 2003 x64 (SP1), you must

upgrade to Service Pack 2 or later.

•TOE teaming performance is reduced if a switch or network device is configured with the round

robin aggregation load balancing method. Configure the aggregation load balancing method on

the switch or network device to something else other than round robin and then re-start the team

(disable the team and enable the team for all VLANs).

•TOE will not work with the following features enabled: Windows Firewall; Internet Protocol security

(IPsec); Internet Protocol Network Address Translation (IPNAT); third-party firewalls; and NDIS 5.1

intermediate drivers. Download article number KB912222

(http://support.microsoft.com/kb/912222/en-us) from the Microsoft website for more information.

RSS teaming limitations

The following are limitations for a TOE-enabled team:

•TOE and RSS teaming are not supported on Windows Server 2008 and Windows Server 2008 x64

in this release.

•For systems running Windows Server 2003 (SP1) or Windows Server 2003 x64 (SP1), you must

upgrade to Service Pack 2 or later.

iSCSI teaming limitations

•The following team types are not supported for iSCSI-enabled adapters. Disable iSCSI on the

adapter or team before changing to any of the incompatible team types.

oAutomatic

o802.3ad Dynamic with Fault Tolerance

oSwitch-assisted Load Balancing with Fault Tolerance (SLB)

•HP NC-Series Intel adapters that have been iSCSI-booted do not support teaming.

Scripting 8

Script conversion

Scripts created with previous versions of the NCU are supported; however, HP recommends that you

recreate the script using the latest version of the NCU.

Scripting application (CQNICCMD)

CQNICCMD is a Windows utility that processes a network adapter configuration script file to duplicate

the adapter teaming configuration of a source ProLiant BL/ML/DL server on a target server.

This utility is supported on the following Windows operating systems:

•Windows Server 2008 SP2

•Windows Server 2008 R2

•Windows Server 2008

•Windows Server 2008 x64

•Windows Server 2003

•Windows Server 2003 x64

Run the utility from the command line in a Command Prompt window, from the Run option on the

Windows Start menu, or from a Windows command file. To execute the CQNICCMD utility from the

command line, the HP Network Configuration Utility (NCU) must be closed.

HP recommends that you use this application as part of the SmartStart Scripting Toolkit (SSST)

deployment. However, the application can be used outside of this environment. Follow these steps when

using the scripting application.

1. Configure adapter teaming on the source server.

2. Generate a script file on the source server by clicking Save in the HP NCU user interface or by

running CQNICCMD /S<filename> in the Command Line utility.

3. Modify the script file as necessary.

If you modify the script file, HP recommends that you run CQNICCMD/ P to check the syntax of the

modified file and check the log file for errors and warnings. The default location of the log file is

\cpqsystem\log\cpqteam.log on the system drive. The syntax of the /P option is cqniccmd

/p<filename>

4. Install the HP NCU on the target system.

5. Run the Command Line utility with the following syntax.

cqniccmd /c<filename>

6. Check the log file for errors and warnings. The default location of the log file is

\cpqsystem\log\cpqteam.log on the system drive.

For use of this utility with the SmartStart Scripting Toolkit (SSST), see the documentation included with

SSST, which can be downloaded from the HP website

(http://h18013.www1.hp.com/products/servers/management/toolkit/index.html).

Command line syntax

CQNICCMD [[F/] /C<filename>] [/D] [/L <filename>] [/P <filename>]

[/S<filename>] [/?]

Scripting 9

Only one of the following configuration options can be specified at a time:

The /L argument can be used with any of the configuration options. The /F argument can only be used

with the /C configuration option.

Command line arguments

Argument Description

/S This configuration option causes the source server configuration to be saved. The name of

the XML configuration data file must be specified and the path to the data file must exist.

This option is identical to saving the source server configuration by clicking Save in the

Network Teaming Configuration user interface.

/D This configuration option causes all teams on the target server to be dissolved, all VLANs

to be removed, and 802.1p/q Packet Tagging to be disabled for all adapters that had

no VLANs. No additional arguments are required or allowed with this option.

/C This configuration option applies the configuration specified in the data file to the target

system. An existing XML configuration data file must be specified following the target

switch. A space following the switch is optional. Any teams that exist on the target server

will be dissolved before the configuration is applied, all VLANs will be removed, and

802.1p/q Packet Tagging will be disabled.

/P This option is identical to the /C option, except that the configuration options are not

applied to the target system. This is useful for syntax checking the XML data file.

/L This option can be used to change the name and location of the cpqteam.log default log

file that is created in \cpqsystem\log on the system drive. The supplied path must exist.

An invalid log file name will cause the configuration to terminate with no changes. HP

recommends this option only in batch files.

/F This option causes all errors, including those errors normally treated as non-fatal errors, to

be treated as fatal errors. This argument can be used only with the /C option.

/? This option displays usage information.

Command line examples

cqniccmd /Sc:\HP\teamcfg.xml

cqniccmd /S c:\HP\teamcfg.xml

cqniccmd /S"c:\HP\teamcfg.xml"

cqniccmd /D

cqniccmd /Cc:\HP\teamcfg.xml

cqniccmd /C c:\HP\teamcfg.xml

cqniccmd /C"c:\HP\teamcfg.xml"

cqniccmd /Pc:\HP\teamcfg.xml

cqniccmd /P c:\HP\teamcfg.xml

cqniccmd /P"c:\HP\teamcfg.xml"

Scripting 10

cqniccmd /Cc:\HP\teamcfg.xml /Lc:\HP\config.log

cqniccmd /C c:\HP\teamcfg.xml /L c:\HP\config.log

cqniccmd /C"c:\HP\teamcfg.xml" /L" c:\HP\config.log"

cqniccmd /F /C c:\HP\teamcfg.xml

Otros manuales para BladeSystem Dual NC370i - Multifunction Network...

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Software de HP

HP 2230s - Compaq Business Notebook Manual de instrucciones

HP T5145 - Thin Client - Tower Manual de usuario

HP HPE XP P9500 Manual de instrucciones

HP BL680c - ProLiant - G5 Manual de usuario

HP AK373A - StorageWorks All-in-One Storage System 1200r 5.4TB SAS Model NAS... Cómo utilizar

HP NonStop RDF J-series RVUs Manual de programación

HP Neoview SQL Manual de usuario

HP ProLiant BL280c G6 Manual de usuario

HP Xw25p - ProLiant - Blade Workstation Manual de usuario

HP T5720 - Compaq Thin Client Manual de instrucciones

HP Xw460c - ProLiant - Blade Workstation Manual de usuario

HP T1936AA - Digital Sending Software Instrucciones de instalación

HP 201723-B21 - HP StorageWorks Modular SAN Array 1000 Hard... Manual de instrucciones

HP BL680c - ProLiant - G5 Manual de referencia

HP Xw460c - ProLiant - Blade Workstation Manual de usuario

HP SysMan Manual de usuario

HP C7791C - DesignJet 130 Color Inkjet Printer Guía de configuración

HP VL400 - Vectra - 64 MB RAM Manual de servicio

HP Pavilion w1200 - Desktop PC Manual de usuario

HP FTAM/9000 Manual de usuario

HP 6200C Manual de usuario

HP DDL D40 Manual de usuario

HP NonStop SQL/MP Manual del propietario

HP 742n - Pavilion - 512 MB RAM Instrucciones de instalación y funcionamiento

Manuales populares de Software de otras marcas

COMPRO

COMPRO COMPROFM Manual de usuario

Muratec

Muratec OFFICEBRIDGE ONLINE Manual de usuario

Oracle

Oracle Contact Center Anywhere 8.1 Manual de usuario

Adobe

Adobe 65007312 - Photoshop Lightroom Manual

Avaya

Avaya NULL One-X for RIM Blackberry Manual de usuario

PS Audio

PS Audio PowerPlay Manual del propietario

Brady

Brady LOCKOUT PRO 3.0 Manual de servicio

Avaya

Avaya Interaction Center Manual de usuario

Texas Instruments

Texas Instruments TI-83 Plus Silver Edition Manual

Novell

Novell GROUPWISE 8 - INTERNET AGENT Manual de usuario

Oracle

Oracle Application 9i Manual de usuario

Acer

Acer RDM Manual de usuario

Canon

Canon Vixia HF21 Manual de usuario

Canon

Canon ZR950 Manual de usuario

Samsung

Samsung Auto Backup Manual de usuario

Polycom

Polycom Vortex EF2201 Instrucciones de instalación y funcionamiento

Brocade Communications Systems

Brocade Communications Systems Brocade 8/12c Manual de usuario

Novell

Novell SP2 - S Manual de instrucciones
