XP 9000 Cache Partition User Guide

Abstract

This guide describes how to use the HP XP P9000 Cache Partition Software on HP XP P9000 disk arrays. The intended audience

is a storage administrator or authorized service provider with independent knowledge of HP XP P9000 disk arrays and HP XP

P9000 software.

HP Part Number: AV400-96477

Published: August 2012

Edition: Eighth

Confidential computer software. Valid license from HP required for possession, use or copying. Consistent with FAR 12.211 and 12.212, Commercial

Computer Software, Computer Software Documentation, and Technical Data for Commercial Items are licensed to the U.S. Government under

vendor's standard commercial license.

The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express

warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall

not be liable for technical or editorial errors or omissions contained herein.

This document is intended for system administrators and HP representatives who are involved in installing, configuring, and operating the P9500

storage system.

Readers of this document should meet the following requirements:

•Understand RAID storage systems and their basic functions.

•Be familiar with the HP XP P9000 Owner Guide.

•Be familiar with the Remote Web Console software.

Acknowledgements

Microsoft®, Windows®, Windows® XP, and Windows NT® are U.S. registered trademarks of Microsoft Corporation.

Export Requirements

You may not export or re-export this document or any copy or adaptation in violation of export laws or regulations.

Without limiting the foregoing, this document may not be exported, re-exported, transferred or downloaded to or within (or to a national resident

of) countries under U.S. economic embargo, including Cuba, Iran, North Korea, Sudan, and Syria. This list is subject to change.

This document may not be exported, re-exported, transferred, or downloaded to persons or entities listed on the U.S. Department of Commerce

Denied Persons List, Entity List of proliferation concern or on any U.S. Treasury Department Designated Nationals exclusion list, or to parties directly

or indirectly involved in the development or production of nuclear, chemical, biological weapons, or in missile technology programs as specified

in the U.S. Export Administration Regulations (15 CFR 744).

Revision History

DescriptionDateEdition

Applies to microcode version 70-01-01-00/00 or later.October 2010First

Applies to microcode version 70-01-24-00/00 or later.November 2010Second

Applies to microcode version 70-01-62-00/00 or later.January 2011Third

Applies to microcode version 70-02-01-00/00 or later.May 2011Fourth

Applies to microcode version 70-02-7x-00/00 or laterSeptember 2011Fifth

Applies to microcode version 70-03-00-00/00 or later.November 2011Sixth

Applies to microcode version 70-03-3x-00/00 or later.April 2012Seventh

Applies to microcode version 70-04-00-00/00 or later.August 2012Eighth

Contents

1 Creating virtual cache partitions...................................................................4

About virtual cache partitions.....................................................................................................4

Cache capacity for a CLPR........................................................................................................4

Cache partitioning rules and guidelines.......................................................................................7

Partitioning cache.....................................................................................................................9

Cache partition work flows....................................................................................................9

Creating a CLPR..................................................................................................................9

Migrating resources to and from a CLPR................................................................................10

Deleting a CLPR ................................................................................................................11

2 Troubleshooting........................................................................................12

Troubleshooting Cache Partition................................................................................................12

3 Support and other resources......................................................................13

Contacting HP........................................................................................................................13

Subscription service............................................................................................................13

Documentation feedback....................................................................................................13

Related information.................................................................................................................13

HP websites......................................................................................................................13

Conventions for storage capacity values....................................................................................14

Typographic conventions.........................................................................................................14

A Cache Partition GUI reference....................................................................16

Partition Definition tab (Storage System selected).........................................................................16

Partition Definition tab, Cache Logical Partition window (CLPR selected).........................................17

Partition Definition tab, Cache Logical Partition window (each CLPR information).............................17

Select CU dialog box..............................................................................................................19

Glossary....................................................................................................21

Index.........................................................................................................22

Contents 3

1 Creating virtual cache partitions

This topic provides detailed instructions for dividing storage system cache memory into virtual

cache logical partitions (CLPRs) using Cache Partition software.

About virtual cache partitions

If one storage system is shared with multiple hosts, one host reading or writing a large amount of

data can require enough of the storage system’s cache memory to affect other users. The Cache

Partition function allows improved I/O performance by dividing storage system cache memory

into multiple virtual cache memories (cache logical partitions or CLPRs).

Partitioning cache matches data to appropriate storage resources based on availability,

performance, capacity, and cost. It improves flexibility by allowing dynamic changes to cache

partitions while in use.

Partitioning cache dedicates cache resources for exclusive use by specific applications to maintain

priority and quality of service for business-critical applications. Storage administrators can secure

and/or restrict access to storage resources to ensure confidentiality for specific applications. By

dedicating resources to each partition as needed, a high quality of service can be maintained for

all users.

The following illustrates the use of cache memory within a corporation. In this example, cache

memory is partitioned into three segments of 40 GB, each of which is allocated to a branch office.

The host of branch A has a heavy I/O load. Because the cache memory is partitioned, that heavy

I/O load does not impact the cache memory for the other two branches.

Cache capacity for a CLPR

A CLPR is a pool of the cache and parity groups in the storage system. Partitioning cache into one

or more CLPRs allows storage administrators to dedicate individual CLPRs to a different host,

preventing I/O contention for cache memory.

Before you partition cache memory into CLPRs, calculate the cache capacity that will be needed

on your storage system. If necessary, install additional cache memory.

When you create a CLPR, the recommended cache capacity is determined by the conditions such

as: the number of mounted processor blades, RAID level, the number of drives that are installed

4 Creating virtual cache partitions

on the storage system, and whether Thin Provisioning, Smart Tiers, Cache Residency, Compatible

XRC, or External Storage is used or not (enabled or disabled).

Calculate the recommended cache capacity for a CLPR using the formula below:

Recommended cache capacity (GB) for a CLPR = (CLPR capacity (GB) – ceiling (Cache Residency

extents (MB)/ 2,048) × 2 GB)

(i) When Thin Provisioning, Smart Tiers, Cache Residency or Compatible XRC

is not used:

When you do not use any of Thin Provisioning, Smart Tiers, Cache Residency, or Compatible XRC

for a CLPR, see the table below for the recommended cache capacity.

Recommended cache capacity for a CLPRNumber of processor bladesTotal capacity of internal VOL* and

external VOL for a CLPR

7 GB or more2Less than 1,500 GB

15 GB or more4

22 GB or more6

30 GB or more8

8 GB or more21,500 GB or more

15 GB or more4

22 GB or more6

30 GB or more8

16 GB or more2 or 42,900 GB or more

22 GB or more6

30 GB or more8

22 GB or more2, 4 or 611,500 GB or more

30 GB or more8

24 GB or more2, 4 or 614,400 GB or more

30 GB or more8

30 GB or more2, 4, 6 or 8100,000 GB or more

32 GB or more128,000 GB or more

40 GB or more182,000 GB or more

48 GB or more218,000 GB or more

56 GB or more254,000 GB or more

64 GB or more290,000 GB or more

72 GB or more326,000 GB or more

* Calculate the internal volume capacity for a CLPR using the formula below.

Internal volume capacity = number of (3D+1P) parity groups x capacity of one HDD x 3 + number of (6D+2P) parity

groups x capacity of one HDD x 6 + number of (7D+1P) parity groups x capacity of one HDD x 7 + number of

(14D+2P) parity groups x capacity of one HDD x 14 + number of (2D+2D) parity groups x capacity of one HDD x 2

When you use an external volume or a virtual volume, you cannot use the above formula. If you

use an external volume, calculate the total capacity of parity groups that are associated with the

CLPR. If you use a virtual volume, calculate the total LDEV capacity of the virtual volume that is

Cache capacity for a CLPR 5

associated with the CLPR. To check the LDEV capacity of the virtual volume, see the LDEV dialog

box in the Basic Information Display dialog box of the Remote Web Console subwindow. For

further information about Remote Web Console subwindow, see the HP XP P9000 Remote Web

Console User Guide.

(ii) When Thin Provisioning or Smart Tiers is used:

When you use Thin Provisioning or Smart Tiers for a CLPR, see the table below for the recommended

cache capacity.

Recommended cache capacity for a CLPRNumber of processor bladesTotal capacity of internal VOL* and

external VOL for a CLPR

12 GB or more2Less than 2,900 GB or more

22 GB or more4

22 GB or more6

42 GB or more8

16 GB or more22,900 GB or more

22 GB or more4

32 GB or more6

42 GB or more8

22 GB or more2 or 411,500 GB or more

32 GB or more6

42 GB or more8

24 GB or more2 or 414,400 GB or more

32 GB or more6

42 GB or more8

32 GB or more2, 4, or 6100,000 GB or more

42 GB or more8

32 GB or more2, 4, or 6128,000 GB or more

42 GB or more8

42 GB or more2, 4, 6, or 8182,000 GB or more

48 GB or more218,000 GB or more

56 GB or more254,000 GB or more

64 GB or more290,000 GB or more

72 GB or more326,000 GB or more

* Calculate the internal volume capacity for a CLPR using the formula below.

Internal volume capacity = number of (3D+1P) parity groups x capacity of one HDD x 3 + number of (6D+2P) parity

groups x capacity of one HDD x 6 + number of (7D+1P) parity groups x capacity of one HDD x 7 + number of

(14D+2P) parity groups x capacity of one HDD x 14 + number of (2D+2D) parity groups x capacity of one HDD x 2

(iii) When Cache Residency is used:

When you use the Priority mode by using Cache Residency for a CLPR, you may want to add

cache capacity depending on the number of areas in which the priority mode is set in addition to

the cache used for Cache Residency. For further information, see the Priority mode section of the

HP XP P9000 Performance for Open and Mainframe Systems User Guide.

6 Creating virtual cache partitions

(iv) When Compatible XRC is used:

When you use Compatible XRC for a CLPR, cache capacity for administrative information called

sidefile is needed. Therefore, you may want to add larger cache capacity than the recommended

cache capacity calculated from (i), (ii), or (iii) with sleep wait threshold in mind.

Calculate the recommended capacity using the formula below:

Recommended cache capacity = (Recommended cache capacity calculated from (i)-(iii)) × 100 /

(100 - (Sleep wait threshold))

(v) When only External Storage is used:

If the CLPR to be created meets the following conditions, the recommended cache memory capacity

in the table below can be applied.

•The CLPR uses only external volumes.

•The transfer speed is not emphasized.

•The cache mode of the mapped volume is Disable.

•The CLPR uses only volumes that are for Open systems.

Recommended cache capacity for a

CLPR

Number of processor

blades

Total capacity of external volume of CLPR in which

only Ext Stor is used

4 GB2 or 4Less than 128,000

8 GB6 or 8

8 GB2 or 4128,000 or more

16 GB6 or 8

When adding cache memory, use either the Standard Cache Access Model mode or the High

Performance Cache Access Model mode. If your storage system has any additional printed circuit

boards (PCBs), you must use the High Performance Cache Access Model mode. For more information

about adding cache memory, contact the HP Technical Support.

Cache partitioning rules and guidelines

Observe the following rules, restrictions, and guidelines when creating cache logical partitions:

For the priority mode cache requirements, see the HP XP P9000 Performance for Open and

Mainframe Systems User Guide.

You can operate Cache Partition from Remote Web Console or RAID Manager. To use RAID

Manager, see the HP XP P9000 RAID Manager User Guide.

Rules

•Cache Partition must be enabled on your system.

•CLPR0 is the default CLPR in a storage system. If you have not yet created any cache logical

partitions, all cache belongs to CLPR0.

•Usually, you can create a CLPR if the storage system has 4 GB cache. However, when creating

a CLPR while using Cache Residency, the remaining cache size, which is calculated by

subtracting Cache Residency size from the cache size of CLPR0, must be 8 GB or more.

•Adding or changing CLPR definitions or configurations may take hours to implement and

cannot be canceled or modified until all changes are complete. For assistance or for more

information, contact your HP account team.

Cache partitioning rules and guidelines 7

Restrictions

The following operations are not allowed when multiple CLPRs are involved:

•Creating LUSE volumes across multiple CLPRs. If you forcibly perform this operation and create

a LUSE across multiple CLPRs, the LUSE volumes cannot be used for Continuous Access

Synchronous or Continuous Access Synchronous Z pair volumes.

•Business Copy Quick Restore operations that affect multiple CLPRs.

•Auto LUN manual migration operations that affect multiple CLPRs.

•A parity group containing LDEVs assigned to Cache Residency cache extents (cache areas)

cannot be migrated to another CLPR. See the HP XP P9000 Performance for Open and

Mainframe Systems User Guide for more information about cache extents.

•If you are using Continuous Access Journal, Continuous Access Journal data volumes and

journal volumes can belong to different CLPRs. All journal volumes in the same journal must

belong to the same CLPR. If not, an error occurs.

Guidelines

•Install any needed additional cache memory before partitioning cache. It will be difficult to

add additional cache memory after partitioning cache into CLPRs.

•If the cache capacity of defined CLPR is decreased by the Cache Residency cache area, cancel

Cache Residency bind mode setting, change the cache capacity of CLPR, and then set the

bind mode or priority mode again.

•Best practice is to create cache logical partitions either during the initial installation and setup

or during a maintenance window, because cache logical partition operations can significantly

degrade host performance. If you must perform such operations on a production machine,

use Performance Monitor to verify that the write pending rate, including spikes, is well below

30%.

The table below shows CLPR names set by default to associated CLPR numbers. Because CLPR

names are reserved, they cannot be set to alternative CLPR numbers. For example, "CLPR2" cannot

be set to the CLPR number 1.

CLPR nameCLPR numberCLPR nameCLPR number

CLPR1616CLPR00

CLPR1717CLPR11

CLPR1818CLPR22

CLPR1919CLPR33

CLPR2020CLPR44

CLPR2121CLPR55

CLPR2222CLPR66

CLPR2323CLPR77

CLPR2424CLPR88

CLPR2525CLPR99

CLPR2626CLPR1010

CLPR2727CLPR1111

CLPR2828CLPR1212

CLPR2929CLPR1313

8 Creating virtual cache partitions

CLPR nameCLPR numberCLPR nameCLPR number

CLPR3030CLPR1414

CLPR3131CLPR1515

Partitioning cache

Cache partition work flows

Creating a CLPR

1. Create a CLPR (see “Creating a CLPR” (page 9)).

2. Migrate resources to the new CLPR (see “Migrating resources to and from a CLPR” (page 10)).

Removing a CLPR

1. Migrate resources from the CLPR that is to be removed (see “Migrating resources to and from

a CLPR” (page 10)).

2. Delete the CLPR (see “Deleting a CLPR ” (page 11)).

Creating a CLPR

Before creating a CLPR, review “Cache partitioning rules and guidelines” (page 7).

1. Click Settings >Environmental Setting >Partition Definition on the menu bar of the Remote

Web Console main window.

2. Click to change the mode from View to Modify.

3. In Cache Partition, open the Partition Definition window, and select a CLPR in the Partition

Definition tree.

4. In the Cache Logical Partition window, right-click a CLPR from the Partition Definition tree and

select Create CLPR. This adds a cache logical partition to the Partition Definition tree. The

maximum number of CLPRs that can be manually created is 31 (not including CLPR0).

5. Select the newly created CLPR to open the Cache Logical Partition window.

Partitioning cache 9

6. In the Detail for CLPR in Storage System section, do the following:

•In CLPR Name field, type the name of the cache logical partition, in up to 16 alphanumeric

characters. However, it cannot be changed to the CLPR name that is reserved for the

storage system. See “Cache partitioning rules and guidelines” (page 7).

•In Cache Size, select the cache capacity. You may select from 4 to 508 GB, in 2 GB

increments. The default value is 4 GB. The size of the cache is allocated from CLPR 0,

but you must leave at least 8 GB remaining in CLPR 0.

•In Cache Residency Size, select the cache capacity. You may select from 4 to 508 GB,

in 2 GB increments. The default value is 4 GB. The size of the cache is allocated from

CLPR0, but you must leave at least 8 GB remaining in CLPR0.

•In Num of Cache Residency Areas, type the desired capacity for the Cache Residency

area. The range of values is 0 to 16384 and the default value is 0.

7. Click Apply. The progress bar appears. The change in cache capacity is reflected in this cache

logical partition and in the CLPR0.

8. To change the settings of an existing CLPR, repeat steps 5 through 7.

At this point, the CLPR has no parity groups. You can now migrate resources to the new CLPR (see

“Migrating resources to and from a CLPR” (page 10)).

Migrating resources to and from a CLPR

After adding a CLPR, you must migrate resources (parity groups) from existing CLPRs to the new

CLPR. Before deleting a CLPR, you must first migrate resources from that CLPR to CLPRs that will

not be deleted.

When migrating resources to and from cache logical partitions:

•You can migrate resources only within the same CU.

•All interleaved parity groups must be in the same CLPR.

•LUSE volumes cannot be set across more than one CLPR.

•If a parity group contains one or more LDEVs that have defined Cache Residency extents, you

cannot migrate that parity group to another CLPR.

To migrate resources to and from a CLPR:

1. Click Settings >Environmental Setting >Partition Definition on the menu bar of the Remote

Web Console main window.

2. Click to change the mode from View to Modify.

3. Access the Logical Partition window, then select a CLPR from the Partition Definition tree.

4. In the Cache Logical Partition window, click Select CU to choose a CU.

5. Specify how you want to view information the CLPR resource list. In the Select CU dialog box,

choose one of the following:

•All CUs: Shows the information about all CUs on the CLPR resource list.

•Choose Specific CU, then specify the LDKC and the CU. This shows only CLPRs from the

selected CU.

•Unallocated: Shows information about only the CUs unallocated to CLPR on the CLPR

resource list.

10 Creating virtual cache partitions

Otros manuales para XP 9000

Tabla de contenidos

Otros manuales de Hardware de red de HP

HP StorageWorks HA-Fabric Manager Manual de usuario

HP JG602A Manual de usuario

HP FF 12910 Instrucciones de montaje

HP ProCurve Radio Port 210 Instrucciones de montaje

HP BladeSystem C-Class Interconnect Component Instrucciones de uso

HP X1600 - StorageWorks Network Storage System 5.4TB SAS Model NAS... Cómo utilizar

HP A3550A - High Availability Disk Arrays Model 20 Storage... Manual de usuario

HP X1600 - StorageWorks Network Storage System 5.4TB SAS Model NAS... Manual de usuario

HP AdvanceStack Hub-8U J2610B Manual de instalación y funcionamiento

HP Deskjet 870 Manual de usuario

HP HPE Synergy 12000 Frame Instrucciones de funcionamiento y seguridad

HP 12500 Series Manual de usuario

HP A3550A - High Availability Disk Arrays Model 20 Storage... Manual de usuario

HP MSR954 Series Instrucciones de montaje

HP StorageWorks 1/8 Tape Autoloader Manual de usuario

HP X1600 - StorageWorks Network Storage System 5.4TB SAS Model NAS... Cómo utilizar

HP 201723-B21 - HP StorageWorks Modular SAN Array 1000 Hard... Manual de usuario

HP StorageWorks T5521A Manual

HP E-MSM466-R Instrucciones de montaje

HP FF 12904E Instrucciones de instalación

HP Surestore Disk Array 12h - And FC60 Manual de usuario

HP StorageWorks AB466A Manual de usuario

HP 30020B Manual

HP MSA 2040 Manual de usuario

Manuales populares de Hardware de red de otras marcas

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Manual de usuario

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Manual de usuario

Yudor

Yudor YDS-16 Manual de usuario

D-Link

D-Link ShareCenter DNS-320L Manual de usuario

Samsung

Samsung ES1642dc Instrucciones de uso

Honeywell Home

Honeywell Home LTEM-PV Instrucciones de montaje

evertz

evertz 7700 Series Manual de usuario

D-Link

D-Link ShareCenter DNS-343 Manual de usuario

Asante

Asante AsanteBridge 1012 Manual de usuario

FireBrick

FireBrick FB2700 Manual de usuario

Audiovox Electronics

Audiovox Electronics ARWH2T Manual de usuario

ADC

ADC DSX-1 Manual

NetComm

NetComm NF2 Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 5620 Manual de usuario

Dell EMC

Dell EMC XC6420 Series Manual de usuario

Lanner

Lanner NCA-1020A Manual de usuario

Allied Telesis

Allied Telesis AT-TN121-A Manual de usuario

Arista

Arista CCA-ETM-Q12 Manual de usuario
