HP D3000 Manual de usuario

d3000

Digital Camera

Appareil photonumérique

Digitalkamera

macchina fotografica digitale

Cámara digital

Ψηφιακή Κάμερα

Câmera Digital

Quick Start Guide

Guide de démarrage rapide

Schnelleinstieg

Guida veloce

Guía rápida

Γρήγορος Οδηγός Εκκίνησης

Guia de Início Rápido

For the full version of the d3000 product user manual go to : www.hp.com/support

Per la versione completa del manuale d’uso del modello d3000 consultare il sito : www.hp.com/support

Pour obtenir une notice d'utlisation complete du d3000 allez sur le lien suivant : www.hp.com/support

Das vollständige Handbuch der d3000 Kameraist unter : www.hp.com/support zu finden

Para descargarse la versión completa del manual de instrucciones del modelo d3000,

puede acceder al siguiente enlace: www.hp.com/support

Για την πλήρη έκδοση του εγχειριδίου χρήσης του προϊόντος d3000 πηγαίνετε στο : www.hp.com/support

Para a versão completa do manual do usuário do produto d3000 ir para: www.hp.com/support

CONTENT

PORTUGUÊS

Ελληνικά

d3000 Quick Start Guide

ENGLISH

Camera Views

Front View Back View

1. Self-timer LED/

AF Assist Lamp

2. Microphones

3. Lens

4. LCD display

5. LED indicator

6. Video Record button

7. Playback button

8. OK button/4-way

navigation control

9. Function/Delete

button

10. Menu button

Top View

11. Flash enclosure

12. Zoom toggle

13. Shutter button

14. ON/OFF

(Power button)

15. Mode dial

Bottom View

16. Battery/Memory

card compartment

17. Tripod screw hole

Right View

18. Strap ring

Left View

19. Strap ring

20. Speaker

21. USB AV/Out

Step 1. Inserting the Battery

1. Unlock and open the battery/memory card compartment (feature no. 16 on page 2) on the bottom

of the camera as shown below. To unlock the door slide the release slider (step 1) towards the back

of the camera. At the same time slide the door (step 2) to the right.

2. Insert four AA batteries into the cavities with

the alternating battery orientation exactly as

shown in the figure to the right. Note:

inside each battery cavity there is a small

decal that depicts proper battery orientation.

3. Close the battery/memory card compartment

door and slide it back to its closed position.

The slider will click into its locked position.

Step 2. Inserting an SD/SDHC/SDXC Memory Card

1. Unlock and open the Battery/memory card

compartment at the bottom of the camera as

described in the previous section.

2. Insert an SD, SDHC, or SDXC card into the

memory card slot with the contact pins facing

the back side of the camera as shown.

3. Push the memory card into the memory slot

until it clicks into place.

4. Close and lock the Battery/memory card

compartment door as described in the

previous section.

NOTE: To remove the memory card: Gently push the card until it pops out. Pull the card out and lock the battery cover.

Step 3. Setting the Language, Date, and Time

1. Turn on the power by pressing Power button. (feature no. 14 on page 1)

2. Use 4-way navigation controller (feature no. 8 on page 1) to move and change the settings.

3. Press OK button to finish. (also feature no. 8 on page 1)

Step 4. Taking Pictures

1. Power on the camera by pressing the Power button.

2. Compose your image in the LCD display monitor.

3. Use the Zoom toggle (feature no. 12 on page 1) to

zoom in, or out, to frame your subject.

4. Press the Shutter button (feature no. 13 on page 1)

halfway down to start adjustment to the auto focus and

the exposure. Once the framing bracket turns green,

press the Shutter button down fully to take the Photo.

When using the flash strobe, note that the flash door does not pop-up automatically.

Please open the Flash manually. Lift using the tabs on the Flash cover. (feature no. 11

on page 1)

Step 5. Recording Video

1. Power on the Camera.

2. Press the Video Record button to start recording

(feature no. 6 on page 1). The green LED (feature no. 5 on

page 1) will blink as an indication that you are recording.

3. Use the Zoom toggle (feature no. 12 on page 1) to zoom in

and zoom out as desired.

4. To pause recording momentarily, press the located

on the top of the navigation controller (feature no. 8 on page

1).

5. To resume recording, press again.

6. To stop recording altogether, press the again.

Step 6. Viewing photos, videos and audio

clips

1. Press the Playback button on the camera. (feature

no. 7 on page 1)

2. The LCD screen displays an image. Press the left and right

quadrants of the navigation controller (feature no. 8 on page

1; the macro and flash symbols) to view the previous or next

image, or video.

3. Press the OK button (also feature no. 8 on page 1) to play a

video clip.

Step 7. Using the Setup Menu

1. Power on the Camera.

2. Press the Menu button (feature no. 10 on page 1)

to open the Record/Playback Menu.

3. Press the left and right quadrants of the navigation

controller (feature no. 8 on page 1; the macro and flash

symbols) to change the menu tab to Setup menu.

4. Press upper and lower quadrants of the navigation controller

to move up and down through the menu selections. Use

the right quadrant (flash symbol) to expand menus that

have sub features.

5. Press the OK button (also feature no. 8 on page 1) to save

and apply settings.

Guide de démarrage

FRANÇAIS

Vues de l’appareil photo

Vue de face Vue de dos

1. Diode du déclencheur

à retardement/

lumière de soutien AF

2. Microphone

3. Objectif

4. Écran LCD

5. Témoin diode

6. Bouton Vidéo

7. Bouton Lecture

8. Bouton OK/contrôle

de navigation à

quadruple

commande

9. Bouton

Fonction/Supprimer

10. Bouton Menu

Vue supérieure

11. Flash

12. Levier de zoom

13. Déclencheur

14. ON/OFF (Bouton

d’alimentation)

15. Molette de mode

Vue inférieure

16. Compartiment de la

batterie/carte

mémoire

17. Trou de vis du

trépied

Vue droite

18. Anneau de la

courroie

Vue gauche

19. Anneau de la

courroie

20. Haut-parleur

21. USB Sortie/AV

Étape 1. Insérer la batterie

1. Déverrouillez et ouvrez le compartiment de la batterie/carte mémoire dessous l’appareil photo.

2. Insérez la batterie dans le compartiment avec

la borne dirigée vers l’intérieur de l’appareil

photo.

3. Fermez et verrouillez le compartiment de la

batterie/carte mémoire.

Étape 2. Insérer une carte mémoire SD/SDHC/SDXC

1. Déverrouillez et ouvrez le compartiment de la

batterie/carte mémoire dessous l’appareil

photo.

2. Insérez la carte SD/SDHC/SDXC dans

l’emplacement de la carte mémoire avec la

partie métallique dirigée vers l’arrière de

l’appareil photo.

3. Poussez la carte SD/SDHC/SDXC dans

l’emplacement de la carte mémoire jusqu’à ce

qu’elle s’enclenche en place.

4. Fermez et verrouillez le compartiment de la

batterie/carte mémoire.

REMARQUE : Pour retirer la carte SD/SDHC/SDXC : Poussez doucement la carte jusqu’à ce qu’elle s’éjecte. Retirez la carte et verrouillez le

couvercle de la batterie.
