HP Visualize c200 - Workstation Manual de usuario
For more details about the camera operation and troubleshooting, please read the User
Manual located on the CDROM disc included with your camera or visit
http://www.hp.com/support and download it for the camera support page.
1
English Français Español
Português BR
English English English English English English
Tour of Your HP Camera
Front View
12
3
4
Flash1.
Self-timer LED / AF Assist Lamp2.
Lens3.
Microphone4.
Back View
11
10
5
9
8
7
6
LCD Screen5.
Zoom Buttons6.
LED Indicator7.
Menu Button8.
Function / Delete Button9.
OK Button / 4-way Navigation Control10.
Playback Button11.
2
Top View
15 12 1413
Stabilizer Button12.
Speaker13.
Shutter Button14.
Power Button15.
Bottom View
1617
18
Tripod Screw Hole16.
Battery Compartment17.
SD Card Compartment18.
Left/Right View
19
20
USB Port19.
Strap Ring20.
3
English Français Español
Português BR
English English English English English English
1. Getting Started
Attach the Camera Strap
To reduce the risk of dropping the camera, it is strongly
recommended to attach and use the provided camera strap
.
Inserting the Batteries
Follow these instructions to insert the batteries into the battery compartment.
If the batteries are already installed, make sure to1.
power off the camera before removing and inserting
recharged or new batteries.
Open the battery compartment at the bottom of the2.
camera as illustrated.
4
Insert the batteries into the compartment with3.
correct orientation as illustrated.
Close and secure the battery compartment.4.
5
English Français Español
Português BR
English English English English English English
Inserting an SD/SDHC Memory Card
It is highly recommended that the camera storage is expanded by inserting a SD or SDHC
memory card. These memory cards are available at most consumer store and online
locations.
Make sure to power off the camera before proceeding.1.
Inserting the memory card while powered on may
damage the card and camera.
Open the memory card compartment at the bottom of the2.
camera.
Insert the SD/SDHC card into the memory card slot with3.
the metallic connectors facing the front side of the camera
as illustrated below.
Push the SD/SDHC card into the memory slot until it clicks into place. If the card does4.
not click into place, repeat the previous step to ensure proper orientation.
Close the memory card compartment.5.
The 720p video recording capability of this camera requires a class 6 (High Speed)
SD/SDHC memory card.
6
- To remove the SD/SDHC card
Make sure to power off the camera before proceeding.1.
Removing the memory card while powered on may
damage the card and camera.
Open the memory card compartment.2.
Gently push the card until it clicks and pushes our of3.
position.
Carefully pull out the card.4.
7
English Français Español
Português BR
English English English English English English
2. Initial Settings
When the camera is powered up for the first time, please set the display language and date
& time.
Setting the Language
Use the 4-way navigation control to move through the selections.1.
Highlight the desired language and press the2. OK button to select.
Setting the Date & Time
Use the 4-way navigation control to move through the selections and to change the1.
setting values.
Press2. OK button when finished. This will save your date and time settings.
If necessary, press3. Menu button to close the menu.
At this point, the camera settings are set to the default automatic mode and is ready to
take photos and videos.
8
Modes
This camera has a two mode selector switch. The different modes are:
Scene Mode
Set to Scene mode to capture images and record videos and audio clips.•
Scene mode can be further set to many options such as auto, video and scene selection.•
See “Selecting the Scene mode options” below.
Scene mode is selected by default when using the Power button to turn on the camera.
When you turn on your camera using the Power button, it will automatically set to scene
mode.
Playback Mode
Set your camera to Playback mode so you can view and edit captured images as well as•
playback videos and audio clips. You can also attach a voice memo to any image in this
mode.
- Switching between Scene Mode and Playback Mode
In Scene Mode, press the Play button to switch to Playback mode.
In Playback Mode, press the Play button to switch back to Shooting mode.
