HP Compaq 4000 Pro series Instrucciones de uso

HP Compaq 4000 Pro Small Form Factor Business PC

Rear I/O includes (4) USB 2.0 ports, serial port, PS/2 mouse and keyboard ports, RJ-45 network interface, VGA and DVI-D

video interfaces, and audio in/out jacks

Low profile expansion slots include (2) PCI slots, (1) PCI Express x1 slot, and (1) PCI Express x16 graphics slot

Front I/O includes (4) USB 2.0 ports, dedicated headphone output, and a microphone jack

HP Optical Mouse

HP Keyboard

3.5” external drive bay supporting a media card reader

5.25” external drive bay supporting an optical disk drive

3.5” internal drive bay supporting a hard disk drive

240W standard efficiency or 85% high efficiency Power Supply

HP Monitor (sold separately)

QuickSpecs

HP Compaq 4000 Pro Series

Overview

DA - 13860 North America — Version 14 — August 14, 2013

Page 1

At A Glance

Designed for long-term deployment within commercial and public sector organizations

BIOS developed and engineered by HP for better security, manageability and software image stability

Intel® B43 Express chipset featuring integrated GMA 4500 integrated graphics

Intel® 82567V Gigabit LAN Networking Controller

DDR3 Synchronous Dynamic Random Access Memory (SDRAM)

Integrated dual independent monitor support via a VGA and DVI-D video interface

Standard efficiency, high voltage protection or 85% high efficiency energy saving power supplies available (offering will vary by

geographic region)

ENERGY STAR qualified models available (dependent upon the desired configuration and geographic region)

Guaranteed lengthy purchase lifecycles and image stability

Created using industry leading Design for Environment standards

Tailored HP Factory Express deployment and lifecycle services available

(

http://h71028.www7.hp.com/enterprise/cache/97688-0-0-225-121.aspx

)

Protected by HP Services, including standard warranties up to 5-5-5 (terms and conditions vary by country; certain restrictions

and exclusions apply)

QuickSpecs

HP Compaq 4000 Pro Series

Overview

DA - 13860 North America — Version 14 — August 14, 2013

Page 2

Operating Systems

Preinstalled

Genuine Windows 7 Starter Edition (32-bit)

Genuine Windows 7 Home Basic Edition (32-bit)

Genuine Windows 7 Home Premium Edition (32-bit or 64-bit)

Genuine Windows 7 Professional Edition (32-bit or 64-bit)

Genuine Windows 7 Ultimate Edition (32-bit or 64-bit)

Red Flag Linux (available only in China)

FreeDOS

Supported

Genuine Windows XP Professional Edition

Genuine Windows Vista Business (32-bit)

Genuine Windows Vista Home Basic

Genuine Windows Vista Enterprise Edition

Genuine Windows 7 Enterprise Edition

FreeLnx

Certain Windows Vista product features require advanced or additional hardware. See

www.microsoft.com/windowsvista/getready/hardwarereqs.mspx

and

www.microsoft.com/windowsvista/getready/capable.mspx

for

details. Windows Vista Upgrade Advisor can help you determine which features of Windows Vista will run on your computer. To

download the tool, visit:

www.windowsvista.com/upgradeadvisor

System may require upgraded and/or separately purchased hardware and/or a DVD drive to install the Windows 7 software and take

full advantage of Windows 7 functionality. See

http://www.microsoft.com/windows/windows-7/

for details.

The following features are not supported on Linux certified systems:

HP 22-in-1 media card reader

HP 802.11b/g/n wireless NIC

HP Serial port adapter

HP Parallel port adapter

QuickSpecs

HP Compaq 4000 Pro Series

Standard Features and Configurable Components (availability may vary by country)

DA - 13860 North America — Version 14 — August 14, 2013

Page 3

Value Added Software

(included with select models; not included when configured with FreeDOS)

Computer Setup Utility

HP Connect Solutions

Norton Internet Security 2011*

Roxio Creator Business

HP Power Assistant

PC Network Clone

PDF Complete Corporate Edition

Corel WinDVD

Microsoft Office 2010 preloaded (purchase of a Product Key

required to activate a full Office 2010 suite)**

Mozilla Firefox for HP Virtual Solutions

HP Virtual Rooms

Huddle

* 60 day trial period for Norton Internet Security 2011 software. Internet access required to receive updates. First update included.

Subscription required for updates thereafter.

** Microsoft Office 2010 Preloaded includes reduced functionality versions of Word and Excel. Purchase of Product Key required to

activate full Office 2010 suite available at participating resellers/retailers and

http://www.office.com

HP Client Management Solutions

(available for free download from the Internet)

http://www.hp.com/go/easydeploy

)

HP Client Automation Starter*

HP SoftPaq Download Manager

HP Client Catalog for Microsoft SMS

HP Systems Software Manager

* Available from your HP Sales Representative or HP Channel Partner

Value Added Services and Features

HP Stable Platform Program

HP Product Change Notification Program

Factory Express Deployment and Lifecycle Services

Business-to-Business Portals

Service and Support

On-site warranty and service¹: This limited warranty and service offering delivers parts, labor and on-site repair for terms up to 5

years. Response time is next business day² and includes free telephone support³ 24 x 7. Some countries/regions do not offer one year

onsite and labor.

Terms and conditions may vary by country. Certain restrictions and exclusions apply.

On-site services may be provided pursuant to a service contract between HP and an authorized HP third party provider, and is not

available in certain countries. Global service response times are based on commercially reasonable best effort and may vary by

country.

Technical telephone support applies only to HP configured, HP and HP qualified third party hardware and software. Toll-free calling

and 24 x 7 support may not be available in some countries.

Chipset

Intel B43 Express with Intel GMA 4500 Graphics

QuickSpecs

HP Compaq 4000 Pro Series

Standard Features and Configurable Components (availability may vary by country)

DA - 13860 North America — Version 14 — August 14, 2013

Page 4

Processor

Intel Celeron Processors

Intel Celeron E3300 Processor

2.50 GHz, 1M L2 cache, 800 MHz FSB

Intel Celeron E3500 Processor

2.70 GHz, 1M L2 cache, 800 MHz FSB

Intel Pentium Processors:

Intel Pentium E5700 Processor

3.0 GHz, 2M L2 cache, 800 MHz FSB

Intel Pentium E5800 Processor

3.20 GHz, 2M L2 cache, 800 MHz FSB

Intel Pentium E6700 Processor

3.20 GHz, 2M L2 cache, 1066 MHz FSB

Intel Pentium E6800 Processor

3.33 GHz, 2M L2 cache, 1066 MHz FSB

Intel Core 2 Duo Processors

Intel Core 2 Duo E7500 Processor

2.93 GHz, 3M L2 cache, 1066 MHz FSB

Intel Core 2 Duo E7600 Processor

3.06 GHz, 3M L2 cache, 1066 MHz FSB

Intel Core 2 Duo E8400 Processor

3.0 GHz, 6M L2 cache, 1333 MHz FSB

Intel Core 2 Duo E8500 Processor

3.16 GHz, 6M L2 cache, 1333 MHz FSB

Intel Core 2 Duo E8600 Processor

3.33 GHz, 6M L2 cache, 1333 MHz FSB

Intel Core 2 Quad Processors

Intel Core 2 Quad Q8400 Processor

2.66 GHz, 4M L2 cache, 1333 MHz FSB

Intel Core 2 Quad Processors

Intel Core 2 Quad Q8400s Processor

2.66 GHz, 4M L2 cache, 1333 MHz FSB, 95W TDP

QuickSpecs

HP Compaq 4000 Pro Series

Standard Features and Configurable Components (availability may vary by country)

DA - 13860 North America — Version 14 — August 14, 2013

Page 5

DDR3 Synchronous DRAM NON-ECC System Memory

Memory upgrades are accomplished by adding single or multiple DIMMs of the same or varied sizes. This chart does not represent all

possible memory configurations. The HP Compaq 4000 Pro Series PC supports non-ECC DDR3 memory up to a maximum data rate of

1066 MHz.

CAUTION:

You must shut down the computer and disconnect the power cord before adding or removing memory modules. Regardless

of the power-on state, voltage is always supplied to the memory modules as long as the computer is plugged in to an active AC outlet.

Adding or removing memory modules while voltage is present may cause irreparable damage to the memory modules or system board.

Memory Configurations

Maximum Memory

Supports up to 8 GB of DDR3 SDRAM using DIMM modules. Slot 1 is black and must always be

populated. Not all memory configurations possible are represented below.

NOTE

For systems configured with more than 3 GB of memory and a 32-bit operating system, all memory

may not be available due to system resource requirements. Addressing memory above 4 GB requires a

64-bit operating system.

Total Memory

Slot

Channel A

Channel B

(black)

2 (white)

2 GB 2 GB

4 GB 2 GB 2 GB

8 GB 4 GB 4 GB

Data Storage Drives

Storage Drive Support

Media Card Reader

ODD

Hard Disk Drive

Quantity Supported

111

Position

123

QuickSpecs

HP Compaq 4000 Pro Series

Standard Features and Configurable Components (availability may vary by country)

DA - 13860 North America — Version 14 — August 14, 2013

Page 6

Hard Disk Drives

HP 250-GB Hard Disk Drive

7,200 rpm, NCQ, Smart IV

HP 500-GB Hard Disk Drive

7,200 rpm, NCQ, Smart IV

HP 750-GB Hard Disk Drive

7,200 rpm, NCQ, Smart IV

HP 1 TB Hard Disk Drive

7,200 rpm, NCQ, Smart IV

Solid State Drives

120-GB Solid State Drive

128-GB Solid State Drive

160-GB Solid State Drive

256-GB SED Solid State Drive

Optical Disc Drives

HP DVD-ROM Drive

HP SuperMulti DVD Writer Drive

1,2

HP Blu-ray Writer Drive

1,2

For playing DVDs, Corel WinDVD 8

For writing CDs and DVDs, Roxio Business Creator 10

Media Card Readers

HP Media Card Reader (22-in-1)

Security Solutions and Capabilities

Stringent Security (via BIOS) This setting is defaulted to disable, but when enabled, the PW jumper will not clear the BIOS pre-boot

authentication passwords.

SATA Port Disablement (via BIOS)

Drive Lock

Serial, Parallel, USB enable/disable (via BIOS)

Optional USB Port Disable at factory (user configurable via BIOS)

Removable Media Write/Boot Control

Power-On Password (via BIOS)

Setup Password (via BIOS)

HP Chassis Security Kit

Support for chassis padlocks and cable lock devices

HP Chassis Security Kit

HP Protect Tools

QuickSpecs

HP Compaq 4000 Pro Series

Standard Features and Configurable Components (availability may vary by country)

DA - 13860 North America — Version 14 — August 14, 2013

Page 7

HP Business PC Security Lock

Network Interface Connections

Intel® 82567V GbE Network Connection (integrated)

HP 802.11 b/g/n Wireless NIC (PCIe x1 card)

Video Graphics

Intel® Graphics Media Accelerator 4500 (integrated)

NVIDIA NVS 300 512MB graphics card

NVIDIA NVS 310 512MB graphics card

ATI Radeon HD 4550 512MB graphics card

AMD Radeon HD 6350 512MG graphics card

AMD Radeon HD 6450 512MB graphics card

Multi-Media

High Definition Audio with Realtek ALC261 codec (all ports are stereo)

Microphone/Headphone front ports (standard)

Line-out and Line-In rear Ports (standard)

Multi-streaming capable (standard)

Internal Speaker (standard)

HP Thin USB Powered Speakers (optional)

Note: The audio ports/jacks provided by all of our systems are 3.5mm in diameter. This would include both the front jacks and

rear jacks, for audio in/out, mic in and headphone out.

Input/Output Devices

HP PS/2 Standard Keyboard

HP USB Standard Keyboard

HP USB Smart Card (CCID) Keyboard

HP USB Mini Keyboard

HP USB and PS/2 Washable Keyboard

HP PS/2 Optical Mouse

HP USB Optical Mouse

HP USB Laser Mouse

HP USB and PS/2 Washable Mouse

Miscellaneous Devices and Configurations

QuickSpecs

HP Compaq 4000 Pro Series

Standard Features and Configurable Components (availability may vary by country)

DA - 13860 North America — Version 14 — August 14, 2013

Page 8

Serial Port Adapter (RS-232 compatible)

Parallel Port Adapter

PC Tower Stand

Non-Standard HDD Disk Partitioning (50%/50%)

QuickSpecs

HP Compaq 4000 Pro Series

Standard Features and Configurable Components (availability may vary by country)

DA - 13860 North America — Version 14 — August 14, 2013

Page 9

Communication Devices

Part Number

HP Wireless 802.11 b/g/n NIC (PCIe x1 card)

FH971AA

Broadcom NetXtreme GbE Ethernet Plus NIC (PCIe x1 card)

FS215AA

Graphics

Part Number

NVIDIA NVS 300 PCIe x1 512MB card

BV457AA

NVIDIA NVS 300 PCIe x16 512MB card

BV456AA

ATI Radeon HD 4550 (512MB DH) PCIe x16 Card

AT042AA

AMD Radeon HD 6350 512MG graphics card

QK638AA

AMD Radeon HD 6450 512MB graphics card

QM229AA

HP DMS59 DVI Dual-head Connector Cable

DL139A

HP DVI Cable Kit

DL198AT

Hard Disk Drives

Part Number

HP 250GB Hard Disk Drive

TBA

HP 500GB Hard Disk Drive

TBA

HP 750GB Hard Disk Drive

TBA

HP 1TB Hard Disk Drive

TBA

Solid State Drives

Part Number

HP 120GB Solid State Drive

TBA

HP 128GB Solid State Drive

TBA

HP 160GB Solid State Drive

QV064AA*

*Not available in

all regions.

QuickSpecs

HP Compaq 4000 Pro Series

After-Market Options (availability may vary by region)

DA - 13860 North America — Version 14 — August 14, 2013

Page 10

Otros manuales para Compaq 4000 Pro series

Tabla de contenidos

Otros manuales de De oficina de HP

HP Pavilion v300 - Desktop PC Instrucciones de instalación

HP Brio BAx Manual de usuario

HP Pavilion t500 - Desktop PC Manual de instrucciones

HP Xw4200 - Workstation - 1 GB RAM Manual de usuario

HP ProOne 440 G3 Instrucciones de instalación

HP EliteDesk 800 G3 Manual de usuario

HP Compaq Business Desktop dx2000 uT Series Instrucciones de montaje

HP ProDesk 400 G2 Small Form Factor Manual

HP A1210n - Pavilion - 512 MB RAM Manual de funcionamiento

HP Workstation x2000 Manual de usuario

HP A1210n - Pavilion - 512 MB RAM Manual de usuario

HP 260 G2 DM Instrucciones de montaje

HP Media Center m7100 - Desktop PC Instrucciones de instalación

HP Presario All-in-One CQ1-2100 Cómo utilizar

HP Xw4400 - Workstation - 2 GB RAM Instrucciones de montaje

HP Model 720 - Workstation Manual de usuario

HP Pavilion 900 CTO Manual de usuario

HP 512n - Pavilion - 128 MB RAM Manual de usuario

HP 100B - All-in-One PC Manual de usuario

HP ZHAN 99 Pro G1 Instrucciones de instalación

HP Compaq Business PC dc7600 Series Instrucciones de montaje

HP 300-1020 - TouchSmart - Desktop PC Manual de usuario

HP TouchSmart IQ504 Hoja de especificaciones

HP A320m - Pavilion - 256 MB RAM Manual de usuario

Manuales populares de De oficina de otras marcas

Asus

Asus E210 Series Manual de usuario

Dell

Dell Inspiron 600m Manual de usuario

Dell

Dell Inspiron 3662 Manual de usuario

TotalFlow

TotalFlow uFLO Manual de usuario

Logitech

Logitech MK320 Manual de usuario

Dell

Dell XPS 730 H2C Manual de usuario

Sony

Sony Vaio Series Manual de usuario

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Manual de usuario

Alto

Alto MD 250 Manual de usuario

Lenovo

Lenovo ThinkCentre Edge 72 Manual

Lenovo

Lenovo ThinkStation D20 Manual

Arbor Technology

Arbor Technology FPC-7800 Series Manual de usuario

Sony

Sony VAIO VGX-TP1 Series Manual de usuario

Asus

Asus Eee Box B204 Manual de usuario

Dell

Dell Optiplex 9010 All In One Manual de usuario

Everex

Everex eXplora Manual de usuario

Lenovo

Lenovo ThinkCentre M75e Manual de usuario

Dell

Dell Alienware Area-51 R4 Manual de usuario
