HP Model 748 - VME Workstation Manual de usuario

Installation Guide for Model A4350A

Mass Storage Module Upgrade Kit

THIS KIT IS TO BE INST

ALLED BY QUALIFIED

SER

VICE PERSONNEL ONL

Workstation

Systems Group

Order N0. A1658–90673

Edition E0895

Printed in U.S.A.

Introduction

These instructions document how to install the A4350A upgrade kit in the Model 748i/64 or 748i/100

Ruggedized W

orkstation (Kit A4309–70006) or TELEPACE (Kit A4350–70008).

Kit Contents

The tray in each kit come preassembled. The following are parts checklists for tray assemblies in Kit

numbers A4309–70006 for Model 748i/64 or 748i/100 and A4350–70008 for TELEPACE.

Kit A4309–70006 Kit A4350–70008

Tray Tray

SE Cable SE Cable

FW Cable 14 inch FW Cable 50 inch

Power Cable Power Cable

FW Bracket and screw FW Bracket and screw

Bracket Plug Bracket Plug

FW Tray Trim and screw FW Tray Trim and screw

Terminators (SE and FW) Terminators (SE and FW)

Installation Guide Installation Guide

Wrist Strap Wrist Strap

Bag Bag

Static Note Static Note

Tie wraps Tie wraps

Field Replaceable Units

The following are the spare part numbers for the tray assemblies

Description Part Number

Tray Assembly (Short Cable) A4309–60003

Tray Assembly (Long Cable) A4350–60007

Installation Procedures

Following are the procedures to install the HP A4350A Mass Storage Module upgrade in the Model

748i/64 or 748i/100 Ruggedized Workstation. or TELEPACE.

Prerequisites

The HP A4268A Fast Wide Differential SCSI Adapter must be installed on the Model 743 CPU board.

Refer to the Model A4268A Fast/Wide Differential SCSI Adapter Installation and Service Guide

(A4268–90600)

for installation instructions.

The Operating System must be HP–UX 9.05 or later.

Installation Procedures Overview

Installing the HP A4350A Mass Storage Module upgrade consists of the following procedures:

Prepare to install the mass storage module.

Power off the system.

Remove the existing mass storage module.

Install mass storage devices in the new mass storage module

Install the new mass storage module into the system, connect cables, and config-

ure system to include the FastWide SCSI devices.

Verify system operation.

Prepare to Install the Mass Storage Module Upgrade

Before upgrading the mass storage module, you should perform the following:

Unpack and verify kit contents. (See Kit Contents on previous page)

Observe Electrostatic Discharge (ESD) precautions.

Gather tools and accessories.

Observe Electr

ostatic Discharge Precautions

Electrostatic charges can damage the integrated circuits. To prevent such damage from occurring,

observe the following precautions when unpacking and installing the upgrade.

Stand on a static–free mat.

Wear a static strap to ensure that any accumulated electrostatic charge discharges

from your body to ground.

Connect all equipment together, including the static–free mat, static straps, and

all computer hardware.

Keep uninstalled printed circuit boards in their protective antistatic bags.

Handle printed circuit boards by their edges once you have removed them from

their protective antistatic bags.

Gather T

ools and Accessories

The tools required for the installation of the mass storage module upgrade kit are:

Flat–bladed screwdriver and Phillips Head screwdriver (not supplied with kit).

Grounding wrist strap supplied in the kit.

Anti–Static Bag supplied in the kit.

Mass Storage Module Configuration and Installation

The following provides the information for configuring and installing the new mass storage module.

Before configuring the new mass storage module, you need to know the type and location of the SCSI

devices that are going into the new module.

Mass Storage Module Configuration Guidelines

The following are guidelines on how to configure the mass storage module. The guidelines are divided

into two groups. The first group applies to all considerations of installing mass storage devices in the

mass storage module. If a CD–ROM drive is to be installed in the mass storage module, the second group

of guidelines also applies.

All Mass Storage Module Configurations

Ensure all the drives have their SCSI ID jumpers set prior to installation.

Attach the power and SCSI cable to the device before attaching the device to the

module.

A maximum of two fast wide devices and two single–ended devices can go into

the mass storage module

Mass Storage Module Configurations With CD–ROM Drive

Observe the guidelines stated above along with the following guidelines

A CD–ROM can only be put in the position diagonally opposite the F/W cable

entry into the mass storage module.

If a fast wide hard disk is located behind the CD–ROM drive, it must be turned

90 degrees, with the cable connectors toward the center of the mass storage mod-

ule, to allow proper clearances.

A DDS Tape drive or Floppy drive can only be positioned next to the CD–ROM.

Mass Storage Device Configurations

The following shows the positions of single–ended and fast wide mass storage devices in the mass stor-

age module.

Depending on your system, the entry point of the FW SCSI cable is at the front or the rear of the mass

storage module. Figure 2 shows the entry of the FW SCSI cable at the rear of the mass storage module

(Model 748). Figure 3 shows the entry of the FW SCSI cable at the front of the mass storage module

(TELEPACE).

FW Cable

SE Cable

FW External Connector

SE External Connector

with

Terminator

with

Terminator

CD ROM

*SE Device

FW Drive

SE Hard Drive

FW Drive

*DDS

ape Drive or Floppy Disk Drive

The FW drive behind the

is turned 90

with the cable

connector

of the chassis

CD–ROM drive

turned toward the center

All devices are mounted in

the chassis as shown for the

Cable connector

SE Device or FW Drive

except for the FW drive

mounted behind the CD–ROM

drive.

Figure 1 Configurations for the Mass Storage Module in Model with Short Cable

FW Cable

SE Cable

FW External Connector

SE External Connector

The FW drive behind the

is turned 90

with the cable

connector

of the chassis

FW Drive

with Terminator

*DDS

ape Drive or Floppy Disk Drive

*SE Device

FW Drive

SE Hard Drive

CD ROM

CD–ROM drive

turned toward the center

Cable connector

All devices are mounted in

the chassis as shown for the

SE Device or FW Drive

except for the FW drive

mounted behind the CD–ROM

drive.

Figure 2 Configurations for the Mass Storage Module with Long Cable

   

Before performing this upgrade procedure, observe the following precautions:

1. Please refer to your system’s Owner’

s Guide

for the procedures to power off the system.

2. Unplug the system unit power cord and the power cords of any peripheral devices from the

power source

3. Unplug the system unit power cord from the power connector at the back of the power

supply.

WARNING: Failure to properly shut down and remove power from the system may create

a personal hazard, or may result in hardware damage or data corruption.

Remove the Existing Mass Storage Module

To remove the existing mass storage module follow these steps (See Figure 3):

CAUTION: Use care when handling the mass storage module. The mass storage

module can be heavy and awkwardly balanced.

1. Disconnect the SCSI interface cables connected to the mass storage module.

2. Unscrew both mass storage module handle screws until they pop out.

3. Pulling on the handles, slide the mass storage module out of the chassis.

4. Disconnect the DC power cables connected to the mass storage devices.

5. Disconnect the SCSI cables connected to the mass storage devices.

Mass Storage

Module Handle

Screws

SCSI Interface

Cable

Figure 3 Removing the Mass Storage Module

Installing Devices in the New Mass Storage Module

Follow these steps to install the mass storage devices in the new mass storage module. Figure 4 shows

the cabling scheme for the new mass storage module.

1. Remove the mass storage devices from the old mass storage module.

2. Install the mass storage devices into the new mass storage module. Refer to the Mass Storage

Module Configuration Guidelines for the configurations of mass storage devices allowed.

FW SCSI Cable

SE SCSI Cable

DC Power Cable

o External FW SCSI Devices

o External SE SCSI Devices

From FW SCSI Adapter

From SE SCSI Adapter

Figure 4 Mass Storage Module Cabling

CAUTION: The new mass storage module has a power cable, single–ended SCSI

cable and a fast wide SCSI cable. Be sure that the cables are secured to

their connectors on the drives and not pinched or pulled too tight before

installing the mass storage module back into the chassis.

3. Attach the mass storage devices to the appropriate slotted mounting holes in the new mass

storage module as shown in Figure 5.

Stand–offs

Mounting Screws

Slotted Mounting

Holes

Figure 5 Typical Mass Storage Device Attachment to the New Mass Storage Module

4. Secure loose cables with the tie–wraps provided to prevent damage to the cables while

sliding the tray in or out of the chassis.

5. Slide the new mass storage module into the chassis, secure the screws, and connect the SCSI

interface cables.

System

erification

Please

refer to your

Owners Guide

for information on running the appropriate diagnostics to verify

your

system’

s operation.
