HP NetRAID DIMM

Installation Guide for

HP NetServer LH 3000/3000r

a

n

d

LH

6000/6000

r

HP Part Number 5969-5909

Printed in November 1999

ii

Notice

The information contained in this document is subject to change without

notice.

Hewlett-Packard makes no warranty of any kind with regard

to this material, including, but not limited to, the implied

warranties of merchantability and fitness for a particular purpose.

Hewlett-Packard shall not be liable for errors contained herein or for

incidental or consequential damages in connection with the furnishing,

performance, or use of this material.

Hewlett-Packard assumes no responsibility for the use or reliability of its

software on equipment that is not furnished by Hewlett-Packard.

This document contains proprietary information that is protected by

copyright. All rights are reserved. No part of this document may be

photocopied, reproduced, or translated to another language without the

prior written consent of Hewlett-Packard Company.

Torx®is a registered trademark of Camcar Division of Textron, Inc.

3M®is a registered trademark of Minnesota Mining and Manufacturing

Company.

i960®is a registered trademark of Intel Corporation.

iii

Hewlett-Packard Company

Network Server Division

Technical Communications / MS 45SLE

10955 Tantau Avenue

Cupertino, CA 95014 USA

© Copyright 1999, Hewlett-Packard Company.

Audience Assumptions

The guide is for the person who installs, administers, and troubleshoots

LAN servers. Hewlett-Packard Company assumes you are qualified in

the servicing of computer equipment and trained in recognizing hazards

in products with hazardous energy levels.

v

Contents

Introduction......................................................................................... 1

Installing the HP NetRAID DIMM ........................................................ 3

Installation Overview......................................................................... 3

Tools You Need................................................................................ 4

Installation ........................................................................................ 5

A. Shutting Down and Disconnecting Power.................................. 5

B. Removing Cover 1 ................................................................... 5

C. Disconnecting the BBM ............................................................ 6

D. Replacing the DIMM................................................................. 8

E. Reconnecting the BBM........................................................... 12

F. Replacing Cover 1.................................................................. 12

G. Restarting the HP NetServer.................................................. 13

Warranty and Support....................................................................... 15

Hardware Accessories Limited Warranty......................................... 15

Hewlett-Packard Hardware Accessories...................................... 15

Third-Party Hardware Products................................................... 17

HP Repair and Telephone Support.................................................. 17

Regulatory Information..................................................................... 19

1

Introduction

This guide describes upgrading HP NetRAID memory in HP NetServer

LH 3000/3000r and LH 6000/6000r. HP NetRAID memory is required

for integrated HP NetRAID operation. For more information about

integrated HP NetRAID, refer to the Integrated HP NetRAID Controller

Configuration Guide.

Standard HP NetRAID memory resides in a 32-MB unbuffered SDRAM

DIMM on the I/O baseboard. It can be upgraded to 64 MB or 128 MB.

CAUTION To avoid damaging the DIMM with electrostatic

discharge, handle the DIMM in a static-free

environment only. Hold the module by its edges and

avoid touching its components. When you set down

a DIMM, always place it on its anti-static container.

In HP NetServer LH 3000/3000r and LH 6000/6000r, the HP NetRAID

memory can be backed up by an optional battery backup module (BBM).

CAUTION If a BBM is installed in the HP NetServer, shut the

NOS down properly and disconnect the BBM before

upgrading the HP NetRAID DIMM.

3

Installing the HP NetRAID DIMM

Installation Overview

This guide lists the tools and procedure for upgrading the HP NetRAID

DIMM in an HP NetServer LH 3000/3000r or LH 6000/6000r.

CAUTION The HP NetRAID DIMM is sensitive to static

electricity and can easily be damaged by improper

handling. Read the following information carefully

before you handle the accessory:

•Leave the DIMM in the anti-static bag until you

are ready to install it.

•Use an anti-static wrist strap and grounding mat.

•Before you touch the DIMM, touch a grounded,

unpainted metal surface on the system to

discharge static electricity.

4

The following procedures are required to install the DIMM:

A. Shutting Down and Disconnecting Power

B. Removing Cover 1

C. Disconnecting the BBM, if present

D. Replacing the DIMM

E. Reconnecting the BBM, if present

F. Replacing Cover 1

G. Restarting the HP NetServer

Tools You Need

The following materials are also required to install this upgrade:

•Anti-static Service Kit (3M®part number 8501/8502/8505 or

equivalent) containing a wrist strap, anti-static mat, and cable.

Use this kit to prevent damage to the system from static

electricity.

•T15 Torx®driver

•T25 Torx driver (required for systems mounted in HP racks)
