How to install snap ring

1Disassemble the derailleur

parts and dust seal from the

hub.

Put the sprocket on the hub.

3Hook the snap ring and take out it.

Work similarly at some notches to

remove the snap ring.

2Inset the tip of the remover

into the notch for engagement

of the sprocket and the hub.

3Screw the corn with the snap

ring into the hub axle until the

bottom face of the corn

reaches the hub.

Screw the cup over the corn

into the axle.

Turn clockwise the cup to

move the snap ring to the end.

Please go on even if the snap

ring falls into the gap between

the hub and the corn on the

way.

Installation is completed when the snap ring

fits to the correct groove.

Remove the tools from the axle. If it is hard

to remove the corn, use a pin spanner.

How to remove snap ring

Operation

23.09

C-85

SPROCKET SNAP

RING TOOL KIT

INSTRUCTION MANUAL

This is a tool kit for removing and installing

snap rings which are securing the sprocket

of bicycle rear wheel.

Identification of parts and contents

Cup Corn

SetterRemover

MADE IN JAPAN

C-85

23.09

4962772150856

Caution

Certainly do this work on the work

bench. Otherwise, the hub or the tool

could be damaged.

The snap ring could spring out

suddenly. Pay attention not to

be injured.

First, put a snap ring onto

the Corn. Do on the work

bench.

Push snap ring to the

bottom with the cup.
