Honeywell HCM574L Manual de usuario
Document G-113078-001 – 02/07 – Rev 5
L-Series
B/W Camera
HCM574L HCM584LX
HCM384L HCM585LX
HCM404LX
HCM405LX
User Guide
EIA CCIR
Revisions
Issue Date Revisions
1.00 09/06 New document
1.01 09/06 Updated Mains 230V in Figure 2 and
Figure 7.
1.02 10/06 Changed 2nd ‘clockwise’ to
‘counterclockwise’ on page 8.
3 10/06 Updated Figure 1, Figure 4, and Figure 5
to show HCM model.
4 11/06 Updated Figure 1 for better quality.
5 02/07 Updated document part no.; added
warning to p. iii.
Rev 5 ii G-113078-001
02/07
Rev 5 iii G-113078-001
02/07
Warnings
Installation and servicing should be performed only by
qualified and experienced personnel to conform to all local
codes and to maintain your warranty.
WARNING! 12 VDC/24 VAC models require the use
of CSA Certified/UL Listed Class 2
power adapters to ensure compliance
with electrical safety standards.
Where the MAINS plug or an appliance coupler is used as
the disconnect device, the disconnect device shall remain
readily operable.
WEEE (Waste Electrical and Electronic Equipment).
Correct disposal of this product (applicable in the
European Union and other European countries with
separate collection systems). This product should be
disposed of, at the end of its useful life, as per applicable
local laws, regulations, and procedures.
Explanation of Graphical
Symbols
RISK OF ELECTRIC
SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE THE COVER.
NO USER-SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL
THIS SYMBOL INDICATES THAT
DANGEROUS VOLTAGE
CONSTITUTING A RISK OF
ELECTRIC SHOCK IS PRESENT
WITHIN THE UNIT.
THIS SYMBOL INDICATES THAT
IMPORTANT OPERATING AND
MAINTENANCE INSTRUCTIONS
ACCOMPANY THIS UNIT.
CAUTION
Rev 5 iv G-113078-001
02/07
FCC Compliance Statement
Information to the User: This equipment has been tested
and found to comply with the limits for a Class A digital
device. Pursuant to Part 15 of the FCC Rules, these limits
are designed to provide reasonable protection against
harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may
cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be
required to correct the interference at his own expense.
Caution Changes or modifications not expressly
approved by the party responsible for
compliance could void the user’s authority to
operate the equipment.
Manufacturer’s Declaration of
Conformance
The manufacturer declares that the equipment supplied
with this guide is compliant with the essential protection
requirements of the EMC directive 89/336/EEC and the Low
Voltage Directive LVD 73/23 EEC, conforming to the
requirements of standards EN 55013 for emissions.
Rev 5 G-113078-001
02/07
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . 2
Unpack Everything. . . . . . . . . . . . . . . . . . . . . . . . 2
Camera Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Camera Functions . . . . . . . . . . . . . . . . . . . . . . . . . 3
Setting Up Your Camera . . . . . . . . . . . . . . . . . . . . 4
Selecting the Lens . . . . . . . . . . . . . . . . . . . . . . 4
Fixed Lens . . . . . . . . . . . . . . . . . . . . . . . . . 4
Vari-focal Auto Iris Lens . . . . . . . . . . . . . . . 4
Direct Drive (DC) Lens . . . . . . . . . . . . . . . . 4
Video Drive (VSD) Lens . . . . . . . . . . . . . . . 5
Backlight Compensation (BLC). . . . . . . . . . . . 5
Automatic Gain Control (AGC) . . . . . . . . . . . . 5
Synchronization Selection (LL/INT) . . . . . . . . . 5
Line Lock Phase Adjustment Potentiometer . . 6
Lens Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Adjusting the Back Focus . . . . . . . . . . . . . . . . . . . 7
Completing the Installation . . . . . . . . . . . . . . . . . . . 9
Mounting the Camera . . . . . . . . . . . . . . . . . . . . . . 9
Connecting the Camera . . . . . . . . . . . . . . . . . . . 10
Warranty and Service . . . . . . . . . . . . . . . . . . . . . . 11
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Rev 5 1 G-113078-001
02/07
Introduction
The Honeywell L-Series monochrome cameras are ideally
suited for use in day-to-day surveillance applications. The
L-Series monochrome cameras are designed for
exceptional value and performance for everyday use. Their
off-the-shelf feature set is designed for high picture quality
in standard applications and they require little to no
adjustment after installation.
Figure 1 Camera Overview
Features
• 1/3” Monochrome CCD
• C/CS adjustable lens mount adapter
• Excellent signal-to-noise ratio of more than 50 dB
• Less than 0.1 lux low light sensitivity for excellent
performance in low light conditions
• Compatible with Video Iris (VSD) or Direct Drive (DC)
Auto Iris lens
• 12 VDC/24 VAC or 230 VAC operation (model
dependent)
Lens connector for
Auto Iris lens plug
Setscrew: loosen locking ring
with a Phillips screwdriver to
adjust mounting ring.
C/CS mount adapter:
C mount: turn
counterclockwise
CS mount: turn clockwise
Back focus adjustment ring
Rev 5 2 G-113078-001
02/07
Before You Begin
Unpack Everything
Check that the items received match those listed on the
order form and packing slip. The L-Series packing box
should include, in addition to this User Guide:
• One L-Series monochrome camera
• One Auto Iris lens plug
If any parts are missing or damaged, contact the dealer you
purchased the camera from or call Honeywell Customer
Service (see Contact Information on the back of this
manual).
Note You will also require a Phillips screwdriver to
complete the installation.
Please read this guide carefully
before you install the L-Series
monochrome camera.
Keep this guide for future reference.
Rev 5 3 G-113078-001
02/07
Camera Settings
Camera Functions
Figure 2 Camera Rear View
Legend
#Description
1DIP switches for mode settings (see Figure 3)
2Auto Iris Lens select switch, VSD for Video or DC for Direct
Drive
3Video output connector
4Power input connector (24 VAC: 3 terminals)—Low Voltage
model only
5Power LED indicator
6DC Iris level adjustment, for use with DC Iris lens
7V-Phase adjustment, for use with Line lock
8Mains 230V Line Voltage power connector
VSD
DC
VIDEO
IRIS
LEVEL
PWR
V- P H
AES
OFF
OFF
INT
AI
BLC
AGC
LL
VSD
DC
VIDEO
IRIS
LEVEL
PWR
V-PH
AES
OFF
OFF
INT
AI
BLC
AGC
LL
CLASS 2 ONLY
=ON
=OFF
LEGEND
2
3
4
765
Mains 230V—Line Voltage
(HCM585LX, HCM405LX)
Low Voltage
(HCM574L, HCM384L,
HCM584LX, HCM404LX)
Shaded box indicates default switch setting.
11
5376
8
Rev 5 4 G-113078-001
02/07
Setting Up Your Camera
Figure 3 shows the factory set DIP switch settings.
Automatic Gain Control (AGC) is set ON.
Figure 3 Factory Set DIP Switch Settings
Selecting the Lens
Fixed Lens
Set the AES/AI switch on the rear of the camera (see
Figure 3) to AES.
Vari-focal Auto Iris Lens
Vari-focal Auto Iris lenses (Direct Drive [DC] or Video Drive
[VSD]) are connected to the camera via a 4-pin square
socket located at the side of the camera. Set the AES/AI
DIP switch to AI.
To set a different exposure, see Backlight Compensation
(BLC) on page 5.
Direct Drive (DC) Lens
1. Set the VSD/DC switch on the rear of the camera to
DC. Set the AES/AI DIP switch to AI.
2. Slowly turn the IRIS LEVEL potentiometer until the
picture on the monitor is as clear as possible and is not
too bright.
VSD
DC
VIDEO
IRIS
LEVEL
PWR
V-PH
AES
OFF
OFF
INT
AI
BLC
AGC
LL
IRIS
LEVEL
CLASS 2 ONLY
AES
OFF
OFF
INT
AI
BLC
AGC
LL
VSD
DC
=ON
=OFF
LEGEND
Low Voltage version shown
Rev 5 5 G-113078-001
02/07
Video Drive (VSD) Lens
Set the VSD/DC switch on the rear of the camera (see
Figure 3) to VSD.
Backlight Compensation (BLC)
If there is excessive light (for example, a window exists in a
scene), the camera tries to compensate by reducing the
overall exposure, resulting in the areas surrounding the
window becoming too dark. Turn the BLC switch ON to
eliminate the silhouette effect.
Automatic Gain Control (AGC)
This feature can improve picture quality when the level of
scene illumination is low. When set to OFF, the maximum
gain is 11 dB. When set to ON, the maximum gain is 30 dB.
Synchronization Selection (LL/INT)
This switch selects the synchronization mode of the
camera. When the camera is connected to an AC supply,
the Line lock (LL) mode is used to lock the camera’s frame
rate to the frequency so that each camera in the system is
triggered at the same point on the supply’s AC cycle. The
default setting is LL.
WARNING! The LL/INT switch must be set to INT
when operating from 12 VDC.
