Honeywell HCC484TP Manual de usuario

Document 900.0512 – 07/06 – Rev 1.01

Color CCD Camera

HCC484TP HCC484TPX

User Guide

NTSC PAL

Italiano

Deutsch PortuguêsNederland English

Español Français

Revisions

Issue Date Revisions

1.00 07/06 New document

1.01 07/06 Corrected doc p/n to G112656-002.

Rev 1.01 ii 900.0512

07/06

Rev 1.01 iii 900.0512

07/06

Explanation of Graphical

Symbols

This symbol indicates the presence of

uninsulated “dangerous voltage” within

the product’s enclosure that may be of

sufficient magnitude to constitute a risk

of electric shock to persons.

This symbol indicates the presence of

important operating and maintenance

(servicing) instruction in the literature

accompanying the product.

CAUTION: TO REDUCE THE RISK OF

ELECTRIC SHOCK, DO NOT REMOVE THE

COVER (OR BACK). NO USER-SERVICEABLE

PARTS INSIDE. REFER SERVICING TO

QUALIFIED SERVICE PERSONNEL.

RISK OF ELECTRIC

SHOCK DO NOT OPEN

CAUTION

English

Rev 1.01 iv 900.0512

07/06

Warnings

Installation and servicing should be performed only by qualified and

experienced personnel.

For outdoor applications, use an appropriate protecting housing

conforming to IP65.

Safeguards

This camera is designed for use in general-purpose indoor CCTV

applications and no other purpose.

Only operate your camera between the temperature of -10°C to

+50°C (14°F to 122°F).

Do not operate your camera outside its specified power supply

range.

Camera must only be used in clean, dry, dust-free environments

unless housed in suitable protective housings to IP65 or better.

To prevent fire or shock hazard, do not

expose this camera to rain or moisture.

Rev 1.01 v 900.0512

07/06

FCC Compliance Statement

Information to the User: This equipment has been tested and

found to comply with the limits for a Class A digital device. Pursuant

to Part 15 of the FCC Rules, these limits are designed to provide

reasonable protection against harmful interference when the

equipment is operated in a commercial environment. This

equipment generates, uses, and can radiate radio frequency energy

and, if not installed and used in accordance with the instruction

manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause

harmful interference in which case the user will be required to

correct the interference at his own expense.

Caution Changes or modifications not expressly approved by

the party responsible for compliance could void the

user’s authority to operate the equipment.

Manufacturer’s Declaration of

Conformance

The manufacturer declares that the equipment supplied with this

guide is compliant with the essential protection requirements of the

EMC directive 89/336/EEC and the Low Voltage Directive LVD 73/23

EEC, conforming to the requirements of standards EN 55013 for

emissions.

English

Rev 1.01 vii 900.0512

07/06

English

Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Unpack Everything . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Lens Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Installing a C/CS Mount Lens . . . . . . . . . . . . . . . . . . . . .3

Installing an Auto Iris Lens . . . . . . . . . . . . . . . . . . . . . . . .3

Adjusting the Flange Back Focus . . . . . . . . . . . . . . . . . .5

Fixed Lens. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Zoom Lens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Mounting the Camera. . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Connecting the Camera . . . . . . . . . . . . . . . . . . . . . . . . . 6

Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Understanding the On-Screen Display . . . . . . . . . . . . . .8

On-Screen Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Saving your Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

OSD Menu Structure . . . . . . . . . . . . . . . . . . . . . . . . . .0

SETUP MENU Functions. . . . . . . . . . . . . . . . . . . . . 10

Adding a Camera Title Display . . . . . . . . . . . . . . . . .12

Setting the Camera Lighting Optimization . . . . . . . . . . .13

ELC / ALC Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

White Balance Control Setup . . . . . . . . . . . . . . . . . 15

Sync Control Setup . . . . . . . . . . . . . . . . . . . . . . . . . .6

Restore Factory Default Settings . . . . . . . . . . . . . . 16

Exit Setup Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Rev 1.01 1 900.0512

07/06

English

Introduction

The Honeywell HCC484TP is a low light CCD color camera with

digital slow shutter, UTP and RS485 remote control.

Figure 1 Camera Overview

Features

• 1/3” IT Super HAD CCD

• Outstanding BLC implementation with Honeywell’s BMB

(Black Mask BLC) function

• C/CS adjustable lens mount adapter

• Excellent signal-to-noise ratio of more than 50 dB

• High sensitivity: minimum illumination of 0.001 lux (F1.2, 30

IRE, DSS x 128)

• 2-way Auto Iris: Video Iris or Direct Drive (DC) Iris lens

•OSDcontrol

• External synchronization with line lock and auto detection

• RS485 remote control

Lens connector for

Auto Iris lens plug

Setscrew: loosen locking ring

with “L” type wrench to adjust

mounting ring.

C/CS mount adapter:

C mount: turn

counterclockwise

CS mount: turn clockwise

Rev 1.01 2 900.0512

07/06

Before You Begin

Unpack Everything

Check that the items received match those listed on the order form

and packing slip. The HCC484TP packing box should include, in

addition to this User Guide:

If any parts are missing or damaged, contact the dealer you

purchased the camera from or call Honeywell Customer Service

(see Contact Information on the back of this manual).

• One HCC484TP camera • One 4-pin connection cable

• One L-type wrench • One Auto Iris lens plug

Please read this guide carefully before

you install the HCC484TP camera.

Keep this guide for future reference.
