HIK VISION DS-2CD8153F-EWI Manual de usuario

NetworkCubeCamera

InstallationManual

V3.0.0



Thankyouforpurchasingourproduct.Ifthereareanyquestions,orrequests,please

donothesitatetocontactthedealer.

ThismanualappliestoDS‐2CD8153F‐E(W)(I)andDS‐2CD8133F‐E(W)(I)Network

Camera.

Thismanualmaycontainseveraltechnicalincorrectplacesorprintingerrors,andthe

contentissubjecttochangewithoutnotice.Theupdateswillbeaddedtothenew

versionofthismanual.Wewillreadilyimproveorupdatetheproductsorprocedures

describedinthemanual.

DISCLAIMERSTATEMENT

“UnderwritersLaboratoriesInc.(“UL”)hasnottestedtheperformanceorreliabilityof

thesecurityorsignalingaspectsofthisproduct.ULhasonlytestedforfire,shockor

casualtyhazardsasoutlinedinUL’sStandard(s)forSafety,UL60950‐1.UL

Certificationdoesnotcovertheperformanceorreliabilityofthesecurityorsignaling

aspectsofthisproduct.ULMAKESNOREPRESENTATIONS,WARRANTIESOR

CERTIFICATIONSWHATSOEVERREGARDINGTHEPERFORMANCEORRELIABILITYOF

ANYSECURITYORSIGNALINGRELATEDFUNCTIONSOFTHISPRODUCT.”

InstallationManualofNetworkCubeCamera

SafetyInstruction

Theseinstructionsareintendedtoensurethattheusercanusetheproductcorrectlytoavoid

dangerorpropertyloss.

Theprecautionmeasureisdividedinto‘Warnings’and‘Cautions’:

Warnings:Seriousinjuryordeathmaybecausedifanyofthesewarningsareneglected.

Cautions:Injuryorequipmentdamagemaybecausedifanyofthesecautionsareneglected.

 

WarningsFollowthesesafeguardsto

preventseriousinjuryordeath.

CautionsFollowtheseprecautionsto

preventpotentialinjuryormaterial

damage.

Warnings:

1. Intheuseoftheproduct,youmuststrictlycomplywiththeelectricalsafetyregulationsofthe

nationandregion.

2. SourcewithDC12VorAC24VaccordingtotheIEC60950‐1standard.Pleaserefertotechnical

specificationsformoredetails.

3. Donotconnectseveraldevicestoonepoweradapterasanadapteroverloadmaycause

over‐heatingandcanbeafirehazard.IfusethePOEasthepowersupply,pleasemakesurethat

thePOESwitchhavethesufficientpower.

4. Pleasemakesurethattheplugisfirmlyinsertedintothepowersocket.

5. Whentheproductisinstalledonawallorceiling,thedeviceshouldbefirmlyfixed.

6. Ifsmoke,odor,ornoiserisefromthedevice,turnoffthepoweratonceandunplugthepower

cable,thencontacttheservicecenter.

7. Iftheproductdoesnotworkproperly,pleasecontactyourdealerorthenearestservicecenter.

Neverattempttodisassemblethecamerayourself.(Weshallnotassumeanyresponsibilityfor

problemscausedbyunauthorizedrepairormaintenance.)

InstallationManualofNetworkCubeCamera

Notice:

1. Makesurethepowersupplyvoltageiscorrectbeforeusingthecamera.

2. Donotdropthecameraorsubjectittophysicalshock.

3. Donottouchsensormoduleswithfingers.Ifcleaningisnecessary,useacleanclothwithabit

ofethanolandwipeitgently.Ifthecamerawillnotbeusedforanextendedperiodoftime,put

onthelenscaptoprotectthesensorfromdirt.

4. Donotaimthecameraatthesunorextrabrightplaces.Abloomingorsmearmayoccur

otherwise(whichisnotamalfunctionhowever),andaffectingtheenduranceofsensoratthe

sametime.

5. Thesensormaybeburnedoutbyalaserbeam,sowhenanylaserequipmentisbeingused,

makesurethatthesurfaceofthesensorwillnotbeexposedtothelaserbeam.

6. Donotplacethecamerainextremelyhotorcoldtemperatures(theoperatingtemperature

shouldbebetween‐10°C~60°C,dustyordamplocations,anddonotexposeittohigh

electromagneticradiation.

7. Toavoidheataccumulation,goodventilationisrequiredforaproperoperatingenvironment.

8. Whileshipping,thecamerashouldbepackedinitsoriginalpacking,orpackingofthesame

texture.

9. Regularpartreplacement:afewparts(e.g.electrolyticcapacitor)oftheequipmentshouldbe

replacedregularlyaccordingtotheiraveragelifetime.Theaveragetimevariesbecauseof

differencesbetweenoperatingenvironmentandusagehistory,soregularcheckingis

recommendedforallusers.Pleasecontactwithyourdealerformoredetails.

InstallationManualofNetworkCubeCamera

TableofContents

Chapter 1 Introduction................................................................................................................................................. 1

1.1 Network camera Functions and Features....................................................................................................... 1

1.2 Applications................................................................................................................................................... 1

Chapter 2 Installation................................................................................................................................................... 2

2.1 Camera Description....................................................................................................................................... 2

2.1.1 Camera Physical Description.............................................................................................................. 2

2.1.3 Camera Connection ............................................................................................................................ 3

2.2 Hardware Installation..................................................................................................................................... 4

Appendix Product Specification.................................................................................................................................. 6

DS‐2CD8153F‐E(W)(I)........................................................................................................................................... 6

Specification................................................................................................................................................. 6

Dimensions .................................................................................................................................................. 7

DS‐2CD8133NF‐E(W)(I) ........................................................................................................................................ 8

Specification................................................................................................................................................. 8

Dimensions .................................................................................................................................................. 9

InstallationManualofNetworkCubeCamera

Chapter1Introduction

Networkcameraisakindofembeddeddigitalsurveillanceproductthatcombinesthefeatures

ofbothtraditionalanalogcameraandnetworkDVS(DigitalVideoServer).Duetotheembedded

LinuxoperationsystemandthelatestDavincihardwareplatformofTI,thesystemoperateswith

highschedulingefficiency.Furthermore,thefirmwareisburnedintheflash,whichmakesthe

productsmall,reliableandhighlystable.

1.1NetworkcameraFunctionsandFeatures

Functions:

NetworkFunction:SupporttheTCP/IPprotocolsandIEbrowsing.

HeartbeatFunction:Theservercanacquirerealtimeoperatingperformanceofthenetwork

camerathroughtheheartbeatfunction.

AlarmFunction:SupportsMotionDetection,Storageexception.

UserManagement:Supportmultilevelrightmanagement.Theadministratorcancreateupto

15separateuserswithdifferentrightlevels,whichhighlyimprovesthesystemsecurity.

CompressionFunctions:

Support1channelvideosignalandstandardH.264encodingcompression,whichsupportsboth

variablebitrateandvariableframerate;besides,youcanself‐defineboththevideoqualityand

itscompressedbitrate.

RemoteControl:

Theproductoffersa10M/100Mself‐adaptiveEthernetinterface.

SupportTCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP,PPPoE,SMTP,NTPprotocols.

Settheparameters,browserealtimevideosorcheckthecameraperformancebysoftwareor

IE,andstorethecompressedbitratethroughnetwork.

Supportremoteupgradesandmaintenance.

1.2Applications

Thiscameraisidealforremotecontrolnetworkapplications.E.g.:

1. Networksurveillanceforsupermarketsandfactories.

2. Remotesurveillanceforhomesandoffices.

3. Indoormonitoringscenes,suchashotel,corridor,stairway.

InstallationManualofNetworkCubeCamera

Chapter2Installation

NOTE:

1. Pleasecheckifalltheitemsonthepackagelisthavebeenincludedwithyourcamera.

2. Readthefollowingcontentscarefullybeforetheinstallation.

3. Makesurethatalltherelatedequipmentispower‐offduringtheinstallation.

4. Checkthepowersupplytopreventanydamagecausedbymismatchingproblems.

5. Iftheproductdoesnotoperateproperly,pleasecontactyourdealerorthenearestservice

center.Neverattempttodisassemblethecamerayourself.Usersareresponsibleforany

problemcausedbymodificationorrepairingwithoutauthorization.

2.1CameraDescription

2.1.1CameraPhysicalDescription

SerialNO.Description

1Microphonehole

2MicroSDcardsolt

3LINK:NetworkstatusLEDindicator.

Whenthenetworkisconnected,theLEDflickersingreen.

4PowerLEDindicator,whichturnsredwhenpowerisappliedtotheunit

5Lens

6ETHERNET:10M/100Mself‐adaptiveEthernetinterface

7RESET:Resetallparameterstofactorydefaultsettings

8Speakerhole

9Powersupply

InstallationManualofNetworkCubeCamera

10Bracketmountingholes,usedtofixthecameratothebracket

NOTE:

Whenthecameraispowerup,pressthe‘RESET’buttonforabout10seconds,thenallparameters,

includingusername,password,IPaddress,portnumber,etc.,willberesettothefactorydefault

settings.

2.1.3CameraConnection

Step1:

Connectoneendofthenetwork

cabletothecameraandtheother

endtoPC.

Step2:

Connectoneendofthepowercord

tothecameraandtheotherendto

powersokckettosupplypowerfor

thecamera.

Step3:

AccessthecameraoverIEorclient

softwaretoviewlivevideoimages.

InstallationManualofNetworkCubeCamera

2.2HardwareInstallation

Cubecameracanbefixedinbothwallandceiling,customerscanchoosediffierentwaystoinstall

thecameraaccordingtotheirspecificneeds.Thefollowingsectionintroducestheceilingmounting,

andthewallmountingfollowsthesameway:



Step1:Fixthecameramountingbrackettotheceiling.



Fig2.2.1Fixcameramountingbracket

NOTE:

Ifitiswall,youneedtofixtheexpandbolt(note:themountingholeoftheexpandboltshouldalign

withthebracket)beforefixingthebracketas①inFig2.2.1.Ifthewallsurfaceiswooden,thepart

of①inFig2.2.1canbeignoredandyoucanusetheself‐tappingscrewtodirectlyfixthebracket.

Pleasenotethatthewallonwhichthecameraisfixedshouldbeabletobearatleastthreetimes

theweightofthebracketandthecamera.



Step2:Screwthemountingholetothemountingbracket,andthenadjustthecameratothe

desiredmonitoringlocationandfinallytightentheknobonbrackettosecurethecameratothe

ceiling.

InstallationManualofNetworkCubeCamera



Fig2.2.2FixtheCamera



Step3:Viewingthevideoonthecomputer,ifthesceneisnotthatyouwanttomonitor,loosenthe

knobonthemountingbracketandadjustthecameralenstothedesiredmonitoringscene,and

finallytightentheknobonbracket.



Fig2.2.3Done
