HIK VISION DS-2CC5102P Manual de usuario

Day Night Dome Camera·User Manual

Day Night Dome Camera

User Manual

UD.6L0201D0117A01

Day Night Dome Camera·User Manual

Thank you for purchasing our product. If there are any questions,

or requests, please do not hesitate to contact the dealer.

This manual applies to following cameras:

Models

DS-2CC5102P(N)

DS-2CC5112P(N)

DS-2CC5172P(N)

DS-2CC5182P(N)

DS-2CC5192P(N)

DS-2CC51A2P(N)

This manual may contain several technical incorrect places or

printing errors, and the content is subject to change without notice.

The updates will be added to the new version of this manual. We

will readily improve or update the products or procedures

described in the manual.

DISCLAIMER STATEMENT

“Underwriters Laboratories Inc. (“UL”) has not tested the

performance or reliability of the security or signaling aspects of

this product. UL has only tested for fire, shock or casualty hazards

as outlined in UL’s Standard(s) for Safety, UL60950-1. UL

Certification does not cover the performance or reliability of the

security or signaling aspects of this product. UL MAKES NO

REPRESENTATIONS, WARRANTIES OR CERTIFICATIONS

WHATSOEVER REGARDING THE PERFORMANCE OR RELIABILITY

OF ANY SECURITY OR SIGNALING RELATED FUNCTIONS OF THIS

PRODUCT.”

1000001021224

Day Night Dome Camera·User Manual

Regulatory Information

FCC Information

FCC compliance: This equipment has been tested and found to

comply with the limits for a digital device, pursuant to part 15 of

the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates,

uses, and can radiate radio frequency energy and, if not installed

and used in accordance with the instruction manual, may cause

harmful interference to radio communications. Operation of this

equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the

interference at his own expense.

FCC Conditions

This device complies with part 15 of the FCC Rules. Operation is

subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including

interference that may cause undesired operation

EU Conformity Statement

This product and - if applicable - the supplied

accessories too are marked with "CE" and comply

therefore with the applicable harmonized

European standards listed under the Low Voltage Directive

2006/95/EC, the EMC Directive 2004/108/EC.

Day Night Dome Camera·User Manual

2002/96/EC (WEEE directive): Products marked

with this symbol cannot be disposed of as unsorted

municipal waste in the European Union. For proper

recycling, return this product to your local supplier

upon the purchase of equivalent new equipment, or dispose of it at

designated collection points. For more information see:

www.recyclethis.info.

2006/66/EC (battery directive): This product

contains a battery that cannot be disposed of as

unsorted municipal waste in the European Union.

See the product documentation for specific battery

information. The battery is marked with this

symbol, which may include lettering to indicate cadmium (Cd),

lead (Pb), or mercury (Hg). For proper recycling, return the battery

to your supplier or to a designated collection point. For more

information see: www.recyclethis.info.

Day Night Dome Camera·User Manual

Safety Instruction

These instructions are intended to ensure that user can use the

product correctly to avoid danger or property loss.

The precaution measure is divided into “Warnings” and “Cautions”

Warnings: Serious injury or death may occur if any of the

warnings are neglected.

Cautions: Injury or equipment damage may occur if any of the

cautions are neglected.

Warnings

Please adopt the power adapter which can meet the safety

extra low voltage (SELV) request. And source with DC 12V or

AC 24V (depending on models) according to the IEC60950-1

and Limited Power Source standard.

If the product does not work properly, please contact your

dealer or the nearest service center. Never attempt to

disassemble the camera yourself. (We shall not assume any

Warnings Follow these

safeguards to prevent

serious injury or death.

Cautions Follow these

precautions to prevent

potential injury or material

damage.

Day Night Dome Camera·User Manual

responsibility for problems caused by unauthorized repair or

maintenance.)

To reduce the risk of fire or electrical shock, do not expose this

product to rain or moisture.

This installation should be made by a qualified service person

and should conform to all local codes.

Please install blackouts equipment into the power supply

circuit for convenient supply interruption.

Please make sure that the ceiling can support more than 50(N)

Newton gravities if the camera is fixed to the ceiling.

Cautions

Make sure the power supply voltage is correct before using the

camera.

Do not drop the camera or subject it to physical shock.

Do not touch sensor modules with fingers. If cleaning is

necessary, use a clean cloth with a bit of ethanol and wipe it

gently. If the camera will not be used for an extended period of

time, put on the lens cap to protect the sensor from dirt.

Do not aim the camera at the sun or extra bright places. A

blooming or smear may occur otherwise (which is not a

malfunction however), and affecting the endurance of sensor

at the same time.

Day Night Dome Camera·User Manual

The sensor may be burned out by a laser beam, so when any

laser equipment is being used, make sure that the surface of

the sensor will not be exposed to the laser beam.

Do not place the camera in extremely hot or cold temperatures

(the operating temperature should be between -10°C ~ 60°C ,

dusty or damp locations, and do not expose it to high

electromagnetic radiation.

To avoid heat accumulation, good ventilation is required for a

proper operating environment.

Do not let water and any liquid flow into the camera.

While shipping, the camera should be packed in its original

packing, or packing of the same texture.

Improper use or replacement of the battery may result in

hazard of explosion. Replace with the same or equivalent type

only. Dispose of used batteries according to the instructions

provided by the battery manufacturer.

Day Night Dome Camera·User Manual

Table of Contents

1 Introduction ........................................................................8

1.1 Features ..................................................................8

1.2 Overview .................................................................9

2 Installation........................................................................11

2.1 Ceiling Mounting .................................................... 11

2.2 Wiring .................................................................... 17

Appendix...............................................................................18

1 Glossary ................................................................... 18

2 Troubleshooting......................................................... 22

3 Technical Maintenance............................................... 25

Day Night Dome Camera·User Manual

1Introduction

1.1 Features

This camera adopts high performance sensor and advanced print

circuit board design techno logy. It possesses of high resolution,

low distortion, and low noise features, etc. It is extremely suitable

for surveillance system and image process system.

Supply high definition and clear image

Day Night Auto Switch

Low Illumination

Support auto white balance with high color rendition

Back Light Compensation

Support auto electronic shutter control to adapt to different

environments

Support auto gain control, adaptive brightness

High SNR ensures clear and pleased image

Advanced Engineering Design, High Reliability

Advanced 3-axis design allows this dome camera to be

adjusted horizontally and vertically to meet different mounting

requirements

Day Night Dome Camera·User Manual

1.2 Overview

The appearance of the cameras is as follows:

Figure 1-1 Overview

Table 1-1 Overview

Description

1 Black Liner

2 Lower Dome
