HIK VISION DS-2CC 2D9T Series Manual de usuario

HD 1080p Ultra Low-Light

PoC Camera

User Manual

UD02874B-A

User Manual

Thank you for purchasing our product. If there are any questions,

or requests, do not hesitate to contact the dealer.

This manual applies to HD 1080p Ultra Low-Light PoC Camera.

This manual may contain several technically incorrect places or

printing errors. The content is subject to change without notice,

and the updates will be added to the new version of this manual.

We will readily improve or update the products or procedures

described in the manual.

Regulatory Information

FCC Information

Please take attention that changes or modification not expressly

approved by the party responsible for compliance could void the

use’s authoity to opeate the euipet.

FCC compliance: This equipment has been tested and found to

comply with the limits for a Class A digital device, pursuant to

part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference when the

equipment is operated in a commercial environment. This

equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential

area is likely to cause harmful interference in which case the user

will be required to correct the interference at his own expense.

FCC Conditions

This device complies with part 15 of the FCC Rules. Operation is

subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including

interference that may cause undesired operation.

EU Conformity Statement

This product and - if applicable - the supplied

accessories too are marked with "CE" and comply

therefore with the applicable harmonized

European standards listed under EMC Directive

2014/30/EU, the RoHS Directive 2011/65/EU.

2012/19/EU (WEEE directive): Products marked

with this symbol cannot be disposed of as unsorted

municipal waste in the European Union. For proper

recycling, return this product to your local supplier

upon the purchase of equivalent new equipment,

or dispose of it at designated collection points. For more

information see: www.recyclethis.info.

2006/66/EC (battery directive): This product contains a battery

that cannot be disposed of as unsorted municipal

waste in the European Union. See the product

documentation for specific battery information.

The battery is marked with this symbol, which may

include lettering to indicate cadmium (Cd), lead

(Pb), or mercury (Hg). For proper recycling, return the battery to

your supplier or to a designated collection point. For more

information see: www.recyclethis.info.

Industry Canada ICES-003 Compliance

This device meets the CAN ICES-3 (A)/NMB-3(A) standards

requirements.

Safety Instruction

These instructions are intended to ensure that user can use the

product correctly to avoid danger or property loss.

The peautio easue is diided ito Waigs ad

Cautios

Warnings: Serious injury or death may occur if any of the

warnings are neglected.

Cautions: Injury or equipment damage may occur if any of the

cautions are neglected.

Warnings

In the use of the product, you must be in strict compliance

with the electrical safety regulations of the nation and region.

Refer to technical specifications for detailed information.

Input voltage should meet both the SELV (Safety Extra Low

Voltage) and the Limited Power Source with 24 V AC or 12 V DC

according to the IEC60950-1 standard. Refer to technical

specifications for detailed information.

Warnings Follow

these safeguards to

prevent serious injury

or death.

Cautions Follow these

precautions to prevent

potential injury or

material damage.

Do not connect several devices to one power adapter as

adapter overload may cause over-heating or a fire hazard.

Make sure that the plug is firmly connected to the power

socket.

When the product is mounted on wall or ceiling, the device

shall be firmly fixed.

If smoke, odor or noise rise from the device, turn off the power

at once and unplug the power cable, and then contact the

service center.

If the product does not work properly, contact your dealer or

the nearest service center. Never attempt to disassemble the

camera yourself. (We shall not assume any responsibility for

problems caused by unauthorized repair or maintenance.)

Cautions

Make sure the power supply voltage is correct before using the

camera.

Do not drop the camera or subject it to physical shock.

Do not touch senor modules with fingers. If cleaning is

necessary, use clean cloth with a bit of ethanol and wipe it

gently. If the camera will not be used for an extended period,

replace the lens cap to protect the sensor from dirt.

Do not aim the camera at the sun or extra bright places.

Blooming or smearing may occur otherwise (which is not a

malfunction), and affect the endurance of sensor at the same

time.

The sensor may be burned out by a laser beam, so when any

laser equipment is in using, make sure that the surface of

sensor will not be exposed to the laser beam.

Do not place the camera in extremely hot, cold, dusty or damp

locations, and do not expose it to high electromagnetic

radiation.

To avoid heat accumulation, good ventilation is required for

operating environment.

Keep the camera away from liquid while in use.

While in delivery, the camera shall be packed in its original

packing, or packing of the same texture.

Improper use or replacement of the battery may result in

hazard of explosion. Replace with the same or equivalent type

only. Dispose of used batteries according to the instructions

provided by the battery manufacturer.

1.1 Product Features..................................................................... 8

1.2 Overview of Type I Camera..................................................... 9

1.3 Overview of Type II Camera...................................................10

1.4 Overview of Type III Camera..................................................10

1.5 Overview of Type IV Camera..................................................11

1.6 Overview of Type V Camera...................................................11

2.1 Type I and Type II Camera Installation ...................................12

2.1.1 Ceiling Mounting ...........................................................12

2.1.2 Wall Mounting...............................................................15

2.1.3 In-Ceiling Mounting .......................................................17

2.1.4 In-Ceiling Mounting with Junction Box ..........................18

2.1.5 Mounting with Inclined Base of Type I Camera..............20

2.2 Type III and Type IV Camera Installation ................................21

2.2.1 Ceiling Mounting ...........................................................21

2.2.2 Mounting with Junction Box ..........................................24

2.3 Type V Camera Installation ....................................................26

2.3.1 Ceiling Mounting ...........................................................26

2.3.2 Ceiling Mounting with Junction Box...............................29

2.3.3 Wall Mounting...............................................................30

2.3.4 Mounting with Inclined Base .........................................32

3.1 VIDEO OUT ............................................................................36

3.2 LANGUAGE ............................................................................36

3.3 SET UP ...................................................................................36

3.3.1 SMART FOCUS ...............................................................36

3.3.2 SCENE ............................................................................37

3.3.3 LENS ..............................................................................37

3.3.4 EXPOSURE .....................................................................37

3.3.5 BACKLIGHT ....................................................................40

3.3.6 WHITE BALANCE ............................................................43

3.3.7 DAY & NIGHT .................................................................43

3.3.8 SPECIAL..........................................................................44

3.3.9 ADJUST ..........................................................................47

3.3.10 RESET.............................................................................48

3.3.11 EXIT ...............................................................................48

Introduction

1.1 Product Features

The camera is applicable for both indoor and outdoor conditions,

and the application scenarios include road, warehouse,

underground parking lot, bar, etc..

The main features are as follows:

High performance CMOS sensor

1080p resolution

Ultra low-light: 0.003 Lux@(F1.2, AGC ON), 0 Lux with IR

OSD menu, white balance, auto gain, backlight compensation,

electronic shutter, ect.

2D & 3D DNR

IR cut filter

Semi-auto focus

PoC

Remote parameters configuration and upgrade

External alarm in/out

Note:

Some mode(s) of type II camera is applicable for indoor only.

1.2 Overview of Type I Camera

Auxiliary Video

Output

Button

DIP Switch

Video Cable (CVBS)

Video Cable (TVI)

Power (24 V AC/12 V DC)

Alarm Cable

Bubble

Back Box

ALARM

IN G OUT G

Figure 1. 1 Overview of Type I Camera
