HIK VISION DS-2DE5225IW-AE(S6) Manual de usuario

DS-2DE5225IW-AE(S6)

2 MP 25× Network IR Speed Dome

Hikvision DS-2DE5225IW-AE(S6) 2 MP 25 × Network IR Speed

Dome adopts 1/2.8" progressive scan CMOS chip. With the

25 × optical zoom lens, the camera offers more details over

expansive areas.

This series of cameras can be widely used for wide ranges of

high-definition, such as rivers, roads, railways, airports,

squares, parks, scenic spots, and venues, etc.

1/2.8" Progressive Scan CMOS

High quality imaging with 2 MP resolution

Excellent low-light performance with

powered-by-DarkFighter technology

25× optical zoom and 16× digital zoom provide close up

views over expansive areas

WDR, HLC, BLC, 3D DNR, defog, EIS, regional exposure,

regional focus

Expansive night view with up to 150 m IR distance

24 VAC & PoE (802.3at)

Efficient H.265+/H.265 compression technology

DORI

The DORI (detect, observe, recognize, identify) distance gives the general idea of the camera ability to distinguish persons or

objects within its field of view.

It is calculated based on the camera sensor specification and the criteria given by EN 62676-4: 2015.

DORI

Detect

Observe

Recognize

Identify

Definition

25 px/m

63 px/m

125 px/m

250 px/m

Distance (Tele)

1600.0 m (5249.3 ft)

634.9 m (2083.1 ft)

320.0 m (1049.9 ft)

160.0 m (524.9 ft)

Specification

Camera Module

Image Sensor

1/2.8" Progressive Scan CMOS

Max. Resolution

1920 × 1080

Min. Illumination

Color: 0.005 Lux @ (F1.6, AGC ON); B/W: 0.001 Lux @ (F1.6, AGC ON), 0 Lux with IR

Shutter Speed

1 s to 1/30,000 s

Day & Night

IR cut filter

Zoom

25x optional, 16x digital

Slow Shutter

Yes

Lens

Focus

Auto, semi-auto, manual

Aperture

Max. F1.6

Zoom Speed

Approx. 3.6 s

Focal Length

4.8 mm to 120 mm

FOV

Horizontal field of view: 57.6°to 2.5°(wide-tele),

Vertical field of view: 34.4°to 1.4°(wide-tele),

Diagonal field of view: 64.5°to 2.9°(wide-tele)

Illuminator

Supplement Light Type

Supplement Light Range

IR Distance: up to 150 m

PTZ

Pan Speed

Pan speed: configurable from 0.1°to 120°/s; preset speed: 120°/s

Tilt Speed

Tilt speed: configurable from 0.1°to 80°/s, preset speed 80°/s

Proportional Zoom

Yes

Park Action

Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan,

panorama scan

Scheduled Task

Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan,

panorama scan, dome reboot, dome adjust, aux output

Movement Range (Pan)

360°

Movement Range (Tilt)

-15°to 90°(auto flip)

Presets

300

Patrol Scan

8 patrols, up to 32 presets for each patrol

Pattern Scan

4 pattern scans

Power-off Memory

Yes

3D Positioning

Yes

PTZ Status Display

Yes

Preset Freezing

Yes

Video

Video Compression

Main stream: H.265+/H.265/H.264+/H.264

Sub-stream: H.265/H.264/MJPEG

Third stream: H.265/H.264/MJPEG

Video Bit Rate

32 Kbps to 16 Mbps

H.264 Type

Baseline profile/Main profile/High profile

H.265 Type

Main profile

Scalable Video Coding (SVC)

H.264 and H.265 encoding

Region of Interest (ROI)

8 fixed regions for each stream

Main Stream

50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720)

60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720)

Sub-Stream

50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288)

60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)

Third Stream

50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)

60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)

Audio

Audio Compression

G.711/G.722.1/G.726/MP2L2/PCM

Audio Bit Rate

64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32-192 Kbps (MP2L2)/32 Kbps

(PCM)

Audio Sampling Rate

8 kHz/16 kHz/32 kHz/48 kHz

Environment Noise Filtering

Yes

Network

Protocols

IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP,

RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour, ISUP

Simultaneous Live View

Up to 20 channels

API

Open Network Video Interface (Version 18.12, Profile S, Profile G, Profile T), ISAPI, SDK,

ISUP

User/Host

Up to 32 users; 3 user levels: administrator, operator, and user

Security

Password protection, complicated password, HTTPS encryption, 802.1X authentication

(EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest

authentication for HTTP/HTTPS, control timeout settings, security audit log, TLS 1.2,

host authentication (MAC address)

Network Storage

NAS (NFS, SMB/CIFS), auto network replenishment (ANR)

Client

iVMS-4200, HikCentral Pro, Hik-Connect

Web Browser

IE 10-11, Chrome 57+, Firefox 52+, Safari 12+


Image Parameters Switch

Yes

Image Settings

Saturation, brightness, contrast, sharpness, gain, and white balance adjustable by

client software or web browser

Day/Night Switch

Day, Night, Auto, Schedule

Wide Dynamic Range (WDR)

120 dB

SNR

＞52 dB

Defog

Digital Defog

Image Stabilization

EIS

Image Enhancement

BLC, HLC, 3D DNR

Privacy Mask

24 programmable polygon privacy masks, mask color or mosaic configurable

Regional Focus

Yes

Regional Exposure

Yes

Interface

Ethernet Interface

1 RJ45 10M/100M self-adaptive Ethernet port

On-board Storage

Built-in memory card slot, support microSD/SDHC/SDXC card, up to 256 GB

Audio

1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%;

1 output (line out), line level, output impedance: 600 Ω

Alarm

2 inputs, 1 output

Reset

Yes

Event

Basic Event

Motion detection, video tampering alarm, exception, alarm input and output

Smart Event

Face detection, line crossing detection, intrusion detection, region entrance detection,

region exiting detection, unattended baggage detection, object removal detection,

audio exception detection

Alarm Linkage

Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm

output, trigger recording, and PTZ actions (such as preset, patrol scan, pattern scan)

General

Power

24 VDC, Max. 24 W (including max. 9 W for IR and max. 1.6 W for heater);

PoE (802.3at)

Material

Metal

Operating Condition

-30 °C to 65 °C (-22 °F to 149 °F). Humidity 90% or less (non-condensing)

Demist

Yes

Dimensions

Ø 210 mm × 344.7 mm (Ø 8.27" × 13.57")

Weight

Approx. 3.0 kg (6.61 lb.)

Approval

Protection

IP66 (IEC 60529-2013), TVS 6000V lightning protection, surge protection and voltage

transient protection

Available Model

DS-2DE5225IW-AE (S6)

Dimension

Accessory

Included

DS-1602ZJ

Optional

DS-1604ZJ-BOX-

POLE

DS-1660ZJ

DS-1663ZJ

DS-1604ZJ

DS-1661ZJ

DS-1673ZJ

DS-1604ZJ-corner

DS-1682ZJ

DS-1005KI

DS-1619ZJ

DS-1604ZJ-BOX-

CORNER

DS-1662ZJ

DS-1681ZJ

DS-1100KI

DS-1667ZJ

DS-1604ZJ-pole

DS-1604ZJ-box

*DS-1673ZJ should be used with DS-1661ZJ or DS-1602ZJ.
