HIK VISION DS-2CD832F-E Series Manual de usuario

Hikvision Technical Manual

DS-2CD832F(-E) IP Camera

Technical Manual

Hikvision Technical Manual

Notices

The information in this documentation is subject to change without notice and does not represent any

commitment on behalf of HIKVISION. HIKVISION disclaims any liability whatsoever for incorrect data

that may appear in this documentation. The product(s) described in this documentation are furnished

subject to a license and may only be used in accordance with the terms and conditions of such license.

This documentation is issued in strict confidence and is to be used only for the purposes for

which it is supplied. It may not be reproduced in whole or in part, in any form, or by any means or

be used for any other purpose without prior written consent of HIKVISION and then only on the

condition that this notice is included in any such reproduction. No information as to the contents or

subject matter of this documentation, or any part thereof, or arising directly or indirectly therefrom,

shall be given orally or in writing or shall be communicated in any manner whatsoever to any third party

being an individual, firm, or company or any employee thereof without the prior written consent of

HIKVISION. Use of this product is subject to acceptance of the HIKVISION agreement required to use

this product. HIKVISION reserves the right to make changes to its products as circumstances may

warrant, without notice.

This documentation is provided “as-is,” without warranty of any kind.

Please send any comments regarding the documentation to:

[email protected]

Find out more about HIKVISION at www.hikvision.com

Hikvision Technical Manual

Contents

1. Key Features

2. Specifications

3. Dimension

Hikvision Technical Manual

1.Key Features

zLinux OS Embedded

zCS Mount Lens (Provide Optional Adapter for C Mount Lens)

zTI DaVinci Hardware Compression

zH.264 / MPEG-4 Video Compression

z1 Channel Audio Compression

zSupport 4CIF / DCIF / 2CIF / CIF / QCIF Real Time Compression

zSupport SD Card for Local Recording

zSupport Dual Stream Compression

zSupport Motion Detection, and Notification on PC Client

zSupport both Variable Bit Rate and Variable Frame Rate

zSupport TCP / IP, HTTP, DHCP, DNS, RTP / RTCP, PPPoE, etc.

zSupport IE for Network Preview

zSupport HIKVISION Watermark

zSupport PTZ Control

zSupport Sensor Alarm Input and Relay Output

zSupport Network Intercom Function

zCompatible with Current HIKVISION DVR/DVS SDK and Client Software

Hikvision Technical Manual

2.Specifications

Parameter

Model DS-2CD832F (-E) (-W)

Camera

Image Sensor 1/4 inch CMOS

Effective Pixels 640 (H) × 480 (V)

Lens Mount C / CS mount

Lens Option

Auto Iris Lens ---

Min. Illumination 0.4Lux @ F1.2

Day & Night Electronic

Compression Standard

Video Compression H.264 / MPEG-4

Video Output 32 K ~ 2M, adjustable (8Mbps maximum)

Audio Compression OggVorbis


Image Resolution 704 x 576, 640 x 480, 528 x 384, 704 x 288, 352 x 288, 176 x 144

Frame Rate 25fps (704 x 576), 30fps (704 x 480)

Functions

Motion Detect Support

Dual Stream Support

Heartbeat Support

SD Card Local Recording Support

Password Protect Support

Protocols TCP / IP, HTTP, DHCP, DNS, RTP / RTCP, PPPoE (FTP, SMTP, NTP, SNMP addible);

Interface

Audio Input 1 channel 3.5mm audio interface (2.0～2.4Vp-p, 1kΩ)

Audio Output 1 channel 3.5mm audio interface (Line level, 600Ω)

Communication 1 RJ45 10M / 100M self-adapted Ethernet port and, 1 RS-485 interface

Alarm Input 1 channel signal input ( 0～12VDC )

Alarm Output 1 channel signal relay output

Others

Working Temperature -10℃~ 60℃

Power Supply 12VDC, ±10%, (-E) series support PoE (Power over Ethernet)

Power Consumption 3W MAX

Dimensions (mm) 63 × 59 × 116

Weight 650g

Hikvision Technical Manual

3.Dimension
