Hikvision Technical Manual

DS-2CD712P(N) IP Camera

Technical Manual

Hikvision Technical Manual

Notices

The information in this documentation is subject to change without notice and does not represent any

commitment on behalf of HIKVISION. HIKVISION disclaims any liability whatsoever for incorrect data

that may appear in this documentation. The product(s) described in this documentation are furnished

subject to a license and may only be used in accordance with the terms and conditions of such license.

This documentation is issued in strict confidence and is to be used only for the purposes for

which it is supplied. It may not be reproduced in whole or in part, in any form, or by any means or

be used for any other purpose without prior written consent of HIKVISION and then only on the

condition that this notice is included in any such reproduction. No information as to the contents or

subject matter of this documentation, or any part thereof, or arising directly or indirectly therefrom,

shall be given orally or in writing or shall be communicated in any manner whatsoever to any third party

being an individual, firm, or company or any employee thereof without the prior written consent of

HIKVISION. Use of this product is subject to acceptance of the HIKVISION agreement required to use

this product. HIKVISION reserves the right to make changes to its products as circumstances may

warrant, without notice.

This documentation is provided “as-is,” without warranty of any kind.

Please send any comments regarding the documentation to:

[email protected]

Find out more about HIKVISION at www.hikvision.com

Hikvision Technical Manual

Contents

1. Key Features

2. Specifications

3. Dimension

Hikvision Technical Manual

1.Key Features

z±0.1° Preset Accuracy

z150°/s Pan Preset Speed and 60°/s Tilt Preset Speed

z0.7-80°/s Pan Manual Speed and 0.7-45°/s Tilt Manual Speed

zPark Action: Start to Call Preset / Patrol / Pattern / Auto Scan / Random Scan /

Frame Scan, after a Defined Time of Inactivity

zProgrammable Limit Stops for Auto / Random Scan / Frame Scan Modes

zAlarm I/O: 1 Channel Input and 1 Channel Relay output

zAlarm Actions: 200 Presets, 8 Patrols, 4 Patterns, Auto Scan, Alarm Output, SD

Memory Recording and Notification on PC Client

zEmbedded Linux OS

zTI DaVinci Hardware Compression

zH.264 video Compression

z1 Channel Audio Compression

zSupport 4CIF / DCIF / 2CIF / CIF / QCIF Real Time Compression

zSupport Dual Compression Stream

zSupport Motion Detection, and Notification on PC Client

zSupport both Variable Bit rate and Variable Frame Rate

zSupport TCP/IP, HTTP, DHCP, DNS, RTP/RTCP, PPPoE, etc.

zSupport IE for Network Preview

zSupport HIKVISION Watermark

zSupport Network Intercom Function

zCompatible with Current HIKVISION DVR/DVS SDK and Client Software

zBuilt-in Surge Protection

zWorking Temperature -10℃~50℃(Indoor)

Hikvision Technical Manual

2.Specifications

Parameter

Model DS-2CD712P (N) F-EPT

Camera

Image Sensor 1/3 inch SONY Super HAD CCD

Effective Pixels PAL: 752 (H) × 582 (V)

NTSC: 768 (H) × 494 (V)

Lens 3.5--9mm / F1.2 / Φ14 / Auto Iris

Signal System PAL / NTSC

Day & Night Electronic

Electronic Shutter 1/50s ~ 1/100,000s

Min. Illumination 0.1Lux @ F1.2

S/N Ratio More than 48dB

Video Output 480 TVL, 1Vp-p Composite Output (75Ω/ BNC)

BLC ON

Compression Standard

Video Compression H.264

Video Output 32 K ~ 2M, adjustable (8Mbps maximum)

Audio Compression OggVorbis


Image Resolution PAL: 704 × 576, 528 × 384, 704 × 288, 352 × 288, 176 × 144

NTSC: 704 × 480, 528 × 320, 704 × 240, 352 × 240, 176 × 120

Frame Rate 25fps (704 × 576)

Functions

Horizontal Range 0 ~ 360°endless

Vertical Range 0 ~ 90°

Horizontal Speed 0.7 ~ 80°/S

Vertical Speed 0.7 ~ 45°/S

RS-485 Protocols HIKVISION, Pelco-D, Pelco-P (addible), Self-adaptive

Pan Preset Speed 0 ~ 150°/S

Auto Mode Auto Scan, Frame Scan, Random Scan, 8 Patrol Scan, 4 Pattern Scan.

Number of Presets 200

Auto Flip Support

Menu Language Chinese, English

Mouse Control Support Mouse Drag while select HIKVISION protocol in Client Software

Dual Stream Support

SD card Local Recording Support

Hikvision Technical Manual

Heartbeat Support

Password Protect Support

Protocols TCP / IP, HTTP, DHCP, DNS, RTP / RTCP, PPPoE (FTP, SMTP, NTP, SNMP

addible).

Interface

Audio Input 1 channel (2.0 ~ 2.4Vp-p, 1kΩ)

Audio Output 1 channel (Line level, 600Ω)

Communication 1 RJ45 10M/100M self-adapted Ethernet port and, 1 RS-485 interface

Alarm Input 1 channel signal input

Alarm Output 1 channel signal relay output

Others

Working Temperature -10℃~ 50℃(Indoor)

Power Supply 12VDC, ±10%, (-E) series support PoE (Power over Ethernet)

Power Consumption 12W MAX

Dimensions (mm) φ145×132.8

Weight 2000g

Hikvision Technical Manual

3.Dimension
